Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FRONT ACTIONHEAT PRO BT INSTRUCTION + FCC STATEMENT_insoles 7.15.26 BACK FCC ID: 2B0MK-AHINS-BT FCC ID: 2B0MK-AHREMOTE-BT ACTIONHEAT App Instructions SCAN QR CODE TO LEARN MORE ABOUT OUR TECHNOLOGY TO DOWNLOAD APP: “ACTIONHEAT” Connecting Your Devices 1.Connect the battery to your garment. 2.Open the app — the first-launch walkthrough handles Bluetooth permission and your preferences. 3.On Home, tap “+ Add a device”. 4.When your gear appears, tap “Connect”. 5.For pairs (Gloves, Footwear, Insoles): connect both pieces, once connected they will auto-link as a pair Controlling the Garment 1.Every connected garment shows as a card on the Home screen, Click the item you want to control. 2.Use the controls to: turn ON/OFF toggle through Low/Medium/High. 3.“All Gear” card adjusts every paired item simultaneously. Disconnecting the Garment Tap the “...” menu on a garment card → Disconnect. Troubleshooting Gear not appearing? • Tap “+ Add a device” again to re-scan. • Power-cycle the gear (o → wait 5 seconds→on). • Confirm Bluetooth is enabled in your phone settings. ACTIONHEAT App Instructions SCAN QR CODE TO LEARN MORE ABOUT OUR TECHNOLOGY TO DOWNLOAD APP: “ACTIONHEAT” Connecting Your Devices 1. Connect the battery to your garment. 2. Open the app — the first-launch walkthrough handles Bluetooth permission and your preferences. 3. On Home, tap “ + Add a device ”. 4. When your gear appears, tap “ Connect ”. 5. For pairs (Gloves, Footwear, Insoles): connect both piece, once connected they will auto-link as a pair Controlling the Garment 1. Every connected garment shows as a card on the Home screen, Click the item you want to control. 2. Use the controls to: turn ON/OFF toggle through Low/Medium/High. 3. “ All Gear ” card adjusts every paired item simultaneously. Disconnecting the Garment Tap the “...” menu on a garment card → Disconnect. Troubleshooting Gear not appearing? • Tap “ + Add a device ” again to re-scan. • Power-cycle the gear (o → wait 5 seconds → on). • Confirm Bluetooth is enabled in your phone settings.
Rev1/26/2023 JustBrandLimited FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2026-07-21 FCCID:2BOMK-AHINS-BT Ref.#1:AttestationStatementsPart2.911(d)(5)(i)Filing JustBrandLimitedcertifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCC rules. JustBrandLimitedcertifiesthattheequipmentforwhichauthorizationissoughtdoesnotinclude cybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofitssuccessors andassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsand assignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446D01Covered EquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Ref.#2:AttestationStatementsPart2.911(d)(5)(ii)Filing JustBrandLimitedcertifiesthat,asofthedateofthefilingoftheapplication,theapplicantisnot identifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesoraffiliates)asan entityproducing“covered”equipment. Applicant:JustBrandLimited Address:3791mainstPhiladelphia,PA19127,UnitedStates ContactPerson:BrandonSinger Tel.:2672376015 Email:[email protected] Sincerely, Signature:
Attestation Statements Date: 2026-07-21 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BOMK-AHINS-BT) JustBrand Limited, the undersigned, hereby authorize JustBrand Limited to act as our designated agent for service of process, JustBrand Limited accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. JustBrand Limited accepts the responsibility to act as designated agent for service of process. Applicant Information: Company name: JustBrand Limited Contact Name: Brandon Singer Address: 3791 main st Philadelphia, PA 19127, United States Telephone No: 2672376015 Email: [email protected] FRN: 0036878700 Signature: Brandon Singer Agent Information: Company Name: JustBrand Limited Address:3791 main st Philadelphia, PA 19127, United States FRN: 0036878700 Contact Name: Brandon Singer Telephone No: 2672376015 Email: [email protected] Signature: Brandon Singer
JustBrandLimited OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:July24,2026 Subject;RequestforConfidentiality FCCID: 2BOMK-AHINS-BT ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SOFTWARESECURITYREQUIREMENTSFORU-NIIDEVICES Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:BrandonSinger Title:CEO
EffectiveDate:April2,2020QSF7.6.4-8–AgentAuthorizationLetterTemplatePage1of1 RevisionDate:Revision:0 JustBrandLimited Date:2026-07-21 ProductModelNumber:AHI308-BT,AHI308,AHINS-BT FCCID:2BOMK-AHINS-BT Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C.CanadaV5J5K5to actonourbehalfonallmattersconcerningtheabovenamedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformationrelatedtothe approvalprojecttotheappliedcertificationbodyandtothenotificationentitiesandtodiscuss anyissuesconcerningtheapprovalapplication.AnyandallactscarriedoutbyQAI LaboratoriesLtd.onourbehalfshallhavethesameeffectasactsofourown. Signature: By: BrandonSinger ContactListedonFCCWesbite Title:CEO Email:[email protected] Onbehalfof:JustBrandLimited
JustBrandLimited DeclarationLetterofModelDifference Date:2026-07-21 FCCID:2BOMK-AHINS-BT TestedModelNumber:AHI308-BT AddingModelNumber(s):AHI308,AHINS-BT AllAddingModelNumber(s)is/aresameelectricallyidenticalasTestedModelNumber.Only differentismodelname. YoursSincerely, Applicant:JustBrandLimited Address:3791mainstPhiladelphia,PA19127,UnitedStates ContactPerson:BrandonSinger Tel.:2672376015 Email:[email protected] Sincerely, Signature:
Page 1 of 4 Report No.: LGT26G015 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26G015 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26G015 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 4 Report No.: LGT26G015 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8
FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT FCC ID:2BOMK-AHINS-BT FCC ID:2BOMK-AHREMOTE-BT
Page 1 of 4 Report No.: LGT26G015 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26G015 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26G015 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 433M RX ANT BT ANT Page 4 of 4 Report No.: LGT26G015 Appendix - Internal Photographs of EUT Constructional Details Photo 7
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Rechargeable Heated Insoles Model Number: AHI308-BT, AHI308, AHINS-BT FCC ID: 2BOMK-AHINS-BT Issued For : JustBrand Limited 3791 main st Philadelphia, PA 19127, United States Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G015HA01 Sample Received Date: Jul. 03, 2026 Date of Test: Jul. 03, 2026 ~ Jul. 14, 2026 Date of Issue: Jul. 14, 2026 Report No.: LGT26G015HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: JustBrand Limited Address: 3791 main st Philadelphia, PA 19127, United States Manufacturer: NINGBO GRAND INTERNATIONAL TRADING CO., LTD Address: Room 901, Guangbo Panorama Building, No.252 Tianda Alley, South Business District, Yinzhou, 315194, Ningbo, China Product Name: Rechargeable Heated Insoles Trademark: N/A Model Number: AHI308-BT, AHI308, AHINS-BT Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26G015HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT26G015HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jul. 14, 2026 Initial Issue Report No.: LGT26G015HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Rechargeable Heated Insoles Test Model Number: AHI308-BT Series Number: AHI308, AHINS-BT Model Difference: Only different is model name. Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 5V 1.0A Battery: Capacity: 1800mAh Rated Voltage: 3.7V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26G015HA01 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT26G015HA01 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT26G015HA01 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power BLE 1M-GFSK 1.5±1.5dBm BLE 2M-GFSK 1.5±1.5dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BLE 2440 3.00 2.00 0.623 3 0.208 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※
SPECIFICATION FOR APPROVAL CUSTOMER : CUSTOMER’S P/N : PART NUMBER : WAN3216F245H08 DESCRIPTION : Chip Antenna 3216 L Ant 2.45G Type H08 VERSION : V1.3 ISSUE DATE : 2020/05/20 CUSTOMER APPROVED R&D CENTER APPROVAL CHECKED DRAWN Ray Tennyson Snow OneWave Electronic Co., Ltd. 1F, No. 151, Li Gong Street, Beitou District, Taipei City 11261, Taiwan TEL:+886 2 2898-2220 FAX:+886 2 2898-5055 2/11 ONEWAVE TECHNOLOGY CO., LTD. 3216 Chip antenna For Bluetooth / WLAN Applications Dimension (mm) L 3.23 ± 0.20 W 1.66 ± 0.20 T 0.45 ± 0.20 P/N: WAN3216F245H08 3/11 ONEWAVE TECHNOLOGY CO., LTD. Part Number Information WAN 3216 F 245 H 08 A B C D E F A Product Series Antenna B Dimension L x W 3.2 x 1.6mm (±0.2mm) C Material High K material D Working Frequency 2.4 ~ 2.5GHz E Feeding mode PIFA & Single Feeding F Antenna type Type = 08 1. Electrical Specification Remark : Bandwidth & Peak Gain was measured under evaluation board of next page Specification Part Number WAN3216F245H08 Central Frequency 2450 MHz Bandwidth 120 (Min.) MHz Return Loss -6.5 (Max) dB Peak Gain 1.75 dBi Impedance 50 Ohm Operating Temperature -40~+110 °C Maximum Power 4 W Resistance to Soldering Heats 10 ( @ 260°C) sec. Polarization Linear Azimuth Beamwidth Omni-directional Termination Ni / Au (Leadless) 4/11 ONEWAVE TECHNOLOGY CO., LTD. 2. Recommended PCB Pattern Evaluation Board Dimension 2 nd Evaluation Board Dimension Suggested Matching Circuit Important information: It is recommended to use high precision inductors ±0.1~0.3nH and capacitance ±0.1pF for matching components. 5/11 ONEWAVE TECHNOLOGY CO., LTD. Layout Dimensions in Clearance area( Size=5.9*5.0mm) FootPrint (Unit : mm) ◆ 2 nd Layout Dimensions in Clearance area( Size=8.0*3.0mm) Matching Circuit 50 ohm transmission Line 6/11 ONEWAVE TECHNOLOGY CO., LTD. 3. Measurement Results Return Loss 7/11 ONEWAVE TECHNOLOGY CO., LTD. Radiation Pattern Efficiency Peak Gain Directivity 2400MHz 81.46% 1.67 dBi 2.56 dBi 2450MHz 84.75% 1.75 dBi 2.46 dBi 2500MHz 82.68% 1.70 dBi 2.52 dBi Chamber Coordinate System Z Y X 8/11 ONEWAVE TECHNOLOGY CO., LTD. 4.Reliability and Test Condictions ITEM REQUIREMENTS TEST CONDITION Solderability 1. Wetting shall exceed 90% coverage 2. No visible mechanical damage Pre-heating temperature:150°C/60sec. Solder temperature:230±5°C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Solder heat Resistance 1. No visible mechanical damage 2. Central Freq. change :within ± 6% 10 ± 0.5 sec. 60 sec . . T E M P ( °C ) 150 °C 2 6 0 °C Pre-heating temperature:150°C/60sec. Solder temperature:260±5°C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Component Adhesion (Push test) 1. No visible mechanical damage The device should be reflow soldered(230±5°C for 10sec.) to a tinned copper substrate A dynometer force gauge should be applied the side of the component. The device must with-ST-F 0.5 Kg without failure of the termination attached to component. Component Adhesion (Pull test) 1. No visible mechanical damage Insert 10cm wire into the remaining open eye bend ,the ends of even wire lengths upward and wind together. Terminal shall not be remarkably damaged. Thermal shock 1. No visible mechanical damage 2. Central Freq. change :within ±6% Phase Temperature(°C) Time(min) 1 +110±5°C 30±3 2 Room Temperature Within 3sec 3 -40±2°C 30±3 4 Room Temperature Within 3sec +110°C=>30±3min -40°C=>30±3min Test cycle:10 cycles The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to High Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: +110±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to Low Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature:-40±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Humidity 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: 40±2°C Humidity: 90% to 95% RH Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. 4±1 sec. 60sec TEMP (°C) 150°C 230°C 9/11 ONEWAVE TECHNOLOGY CO., LTD. 5.Soldering and Mounting Mildly activated rosin fluxes are preferred. The minimum amount of solder can lead to damage from the stresses caused by the difference in coefficients of expansion between solder, chip and substrate. The terminations are suitable for all wave and re-flow soldering systems. If hand soldering cannot be avoided, the preferred technique is the utilization of hot air soldering tools. Recommended temperature profiles for re-flow soldering in Figure 1. Products attachment with a soldering iron is discouraged due to the inherent process control limitations. In the event that a soldering iron must be employed the following precautions are recommended. ‧Preheat circuit and products to 150°C ‧Never contact the ceramic with the iron tip ‧Use a 20 watt soldering iron with tip diameter of 1.0mm ‧280°C tip temperature (max) ‧1.0mm tip diameter (max) ‧Limit soldering time to 3 sec. SOLDERING COOLING NATURAL PRE-HEATING TEMPERATURE(°C) 60~120 s 10s max. 30~60s 250~260 230 180 150 TIME(sec.) Reflow Soldering SOLDERING COOLING NATURAL PRE-HEATING TEMPERATURE(°C) within 3s Gradual cooling 150 TIME(sec.) Iron Soldering Over 60s 350 300 10/11 ONEWAVE TECHNOLOGY CO., LTD. 6.Packaging Information Tape Specification: Reel Specification: (7’’, Φ180 mm) Tape Width(mm) A(mm) B(mm) C(mm) D(mm) Chip/Reel(pcs) 8 9.0±0.5 60±2 13.5±0.5 178±2 3000 11/11 ONEWAVE TECHNOLOGY CO., LTD. 7.Storage and Transportation Information Storage Conditions To maintain the solderability of terminal electrodes: 1. Temperature and humidity conditions: -10~ 40°C and 30~70% RH. 2. Recommended products should be used within 6 months from the t…
Text truncated - open the document above for the full version.
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 56 RF TEST REPORT Product Name: Rechargeable Heated Insoles Model Number: AHI308-BT, AHI308, AHINS-BT FCC ID: 2BOMK-AHINS-BT Issued For : JustBrand Limited 3791 main st Philadelphia, PA 19127, United States Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G015RF01 Sample Received Date: Jul. 03, 2026 Date of Test: Jul. 03, 2026 ~ Jul. 14, 2026 Date of Issue: Jul. 14, 2026 Report No.: LGT26G015RF01 Page 2 of 56 TEST REPORT CERTIFICATION Applicant: JustBrand Limited Address: 3791 main st Philadelphia, PA 19127, United States Manufacturer: NINGBO GRAND INTERNATIONAL TRADING CO., LTD Address: Room 901, Guangbo Panorama Building, No.252 Tianda Alley, South Business District, Yinzhou, 315194, Ningbo, China Product Name: Rechargeable Heated Insoles Trademark: N/A Model Number: AHI308-BT, AHI308, AHINS-BT Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26G015RF01 Page 3 of 56 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 Report No.: LGT26G015RF01 Page 4 of 56 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX I - TEST RESULTS 32 DUTY CYCLE 32 MAXIMUM PEAK CONDUCTED OUTPUT POWER 35 -6DB BANDWIDTH 38 OCCUPIED CHANNEL BANDWIDTH 41 MAXIMUM POWER SPECTRAL DENSITY LEVEL 44 BAND EDGE 47 CONDUCTED RF SPURIOUS EMISSION 51 APPENDIX II - MEASUREMENT PHOTOS 56 Report No.: LGT26G015RF01 Page 5 of 56 Revision History Rev. Issue Date Revisions 00 Jul. 14, 2026 Initial Issue Report No.: LGT26G015RF01 Page 6 of 56 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024. Report No.: LGT26G015RF01 Page 7 of 56 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26G015RF01 Page 8 of 56 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Rechargeable Heated Insoles Test Model Number: AHI308-BT Series Number: AHI308, AHINS-BT Model Difference: Only different is model name. Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY, 2M PHY) Number Of Channel: 40 Antenna Designation: Chip Antenna Antenna Gain (dBi) 1.75 Channel List: Please refer to the Note 3. Rating: Input: DC 5V 1.0A Battery: Capacity: 1800mAh Rated Voltage: 3.7V Hardware Version: N/A Software Vers…
Text truncated - open the document above for the full version.
Page 1 of 2 Report No.: LGT26G015 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26G015 Set-up for Conducted Emission
3791 main st Philadelphia, PA 19127, United States · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.80 mW |

Rechargeable Heated Insoles
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
