2BOYX-18KEYLong Remote Control

Remote Control Instruction Manual Product Name: Long Remote Control I. Product Application Scope This product is applicable to integrated smart toilets and smart toilet seats. II. Product Operating Conditions 1. Operating Environment: This product is required to be used in an environment free of dust and corrosive air. 2. Operating Temperature Range: Ambient temperature 0°C~40°C 3. Operating Humidity Range: Ambient humidity ≤ 95%RH (no condensation) 4. Storage Temperature Range: -10°C~50°C III. Product Characteristics 1. Operating Voltage: 3.0V (DC) 1. Stop button Press and hold to stop function Long press to enter standby / power on 2. Buttocks wash button Press the buttocks to clean them 3. Female wash button Press the female wash button 4. Water pressure +/- button Press +/- to adjust water pressure for cleaning 5. Position Button Tap to adjust the cleaning position 6. Press the bubble button to start foaming. 7. Press the energy-saving button to switch on/off energy-saving mode. 8. Drying button Press to activate warm air drying 9. Night light button for pressing switch on/off the night light 10. Flip cover button Press to open/close the seat cover open/close button 11. Flip ring button Press to open/close the seat ring 12. Press the "Dai Chong" button Press and hold to start the flushing and fully discharge the water volume 13. Press the "Big Flush" button Press and hold to start the flushing with half the water volume 14. Water temperature button Press and hold to start adjusting water temperature 15. Wind temperature button Press again to start adjusting the wind temperature 16. Seat temperature button Press again to start adjusting the water temperature Seat F C C I D : 2 B O Y X - 1 8 K E Y M o d e l : 1 8- K E Y This device complies with part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Declaration Letter Related FCC ID: 2BOYX-18KEY Justification statement stating that all measurements for Long Remote Control were performed radiated and therefore additional antenna gain documentation is not required for Long Remote Control part. See internal photo for details of the antenna for Long Remote Control. By: David Chen (Signature) (Print name) Title: Senior Project Engineer Company: Shenzhen UnionTrust Quality and Technology Co., Ltd.

Page 1 of 3 Model No.: 18-KEY Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 3 Model No.: 18-KEY Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 3 Model No.: 18-KEY Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

HARBOURWAVE PTE. LTD. Label and label location

Page 1 of 2 Model No.: 18-KEY Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT INTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 2 Model No.: 18-KEY Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Antenna

RF Exposure Requirements Product Description: Long Remote Control Model No.: 18-KEY FCC ID: 2BOYX-18KEY Tx frequency: 433.92 MHz Type of Modulat ion: OOK Antenna Type: PCB Antenna Nominal rated field strength: 75.87 dBμV/m at 3 meter Based on the Maximum allowed field strength was 75.87 dBμV/m at 3m in frequency 433.92 MHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 0.0116 mW According to the FCC Part 1.1307(b)(3)(i)(A) and KDB 447498 D04v01, a single RF source is exempt RF device if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing.
