2BOZY-R102Base Station

R102 Base Station User Manual R102 Base Station User Manual 1 I. Product Introduction Base Station×1 Antenna×2 Adapter×1 Screw×2Manual×1 II. Specifications Model R102 Function Ethernet/BT to 2.4G Power Consumption 330mA@DC-5V/60mA@POE-48V Size 140mm*79mm*27mm Weight 135g Power POE (802.3af supported) or DC5.9V adapter Interface Type RJ45, DC-IN LED Indicator RGB indication for Ethernet and 2.4G and BT status Ethernet Speed 10Mbps RF standard ISM 2.4GHz and BLE Antenna External high gain antenna ×2 and PCB antenna x1 IP Level IP55 Working Temperature -20 ~ 70°C Working Humidity ≤80%, non-condensing R102 Base Station User Manual 2 III. Installation 1. Connect via Ethernet: Take the Base station parts out of the box. Connect the router through the network cable, and select the network of the same router to connect the tablet or mobile phone (as the picture below). It is recommended to place the receiver at a high place close to the indicator light without shelter 2. Connect via Bluetooth: Install Pick Tag Demo APP in the Android smart phone/tablet. Open the APP, click ‘BLUETOOTH STATION’ and search R102 base station at to match and connect via Bluetooth. After the connection completed, select and click the light tag such as ‘L102’ and find scanning button ‘[-]’ at the homepage, and scan the S/N barcode or QR code on the indicator to bind, and then start light control. *Download the Demo APP at https://www.hycoiot.com/download/app-release.apk R102 Base Station User Manual 3 R102 Base Station User Manual 4 3. The three-color light of the receiver will be on after network cable connection finished. When the light keeps green, it means that the receiver is built and can be used normally. Colour Meaning Red flash Network cable not connected Green stay The base station obtained the IP address successfully Blue stay The base station connected BT master successfully IV. Repairing 1. 1 year warranty for the main base station and 6 months warranty for the adapter and other parts. (Free repair within 1 year, except for human causes) 2. Service email contact: [email protected] FCC ： ■ This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ■ Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ■This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. ■This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with a minimum distance of 20cm between the radiator and your body. IC （ISED）: ■ This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil nedoit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Cet équipement respecte les limites d’exposition aux rayonnements ionisants fixées pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre corps. Cet émetteur ne doit pas être localisé ou fonctionner en conjonction avec une autre antenne ou un autre émetteur. Company Name: Lotwork Inc. Address FCC: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada IC: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada Caution

Company: Lotwork Inc. Add: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada Tel: +1(519)7215803 Fax: N/A Email: [email protected] Date: 2025-11-17 Attestation Letter FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: The chip WL2400 installed in our product Base Station (model name: R102. FCC ID: 2BOZY-R102), only activate 2.4G SRD: 2405-2480 MHz, There are two WL2400 chips in total, One only supports receiving and the other only supports transmitting(U3:For transmit function; U11: For receive function). Whether it is used for TX or RX is achieved through software configuration, the other frequency is disabled by using the software and the end users cannot activate it. The chip TLSR8253F512ET32 installed in our product Base Station (model name: R102. FCC ID: 2BOZY-R102), only activate BLE(1 Mbps & 2 Mbps): 2402-2480 MHz, the other frequency is disabled by using the software and the end users cannot activate it. Please contact me if there is need for any additional clarification or information. Sincerely, Signature: Printed Name: Rulin Xu Title: CEO

Company name: Lotwork Inc. Address: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada Tel: +1(519)7215803 Fax: N/A Email: [email protected] Attestation Letter Date: 2025-05-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911 (d) (5) (i) (ii) Filing FCC ID: 2BOZY-R102 Lotwork Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Lotwork Inc. (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Lotwork Inc. (“the applicant”) certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature: Contact Person: Rulin Xu Title: CEO

CFR 47 §2.911(d)(7) U.S Agent U.S. AGENT LETTER OF ATTESTATION Date: 2025-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2BOZY-R102 Lotwork Inc. (“the Applicant”) certifies that, as of the date of the filing of the application, LW SOLUTIONS INC (U.S. agent). is our designated U.S. agent for servi ce of process for the above referenced FCC ID. Lotwork Inc. (“the Applicant”) accepts to maintain an agent for no less than one year after the gr antee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. LW SOLUTIONS INC (U.S. agent) accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: LW SOLUTIONS INC Address: 4641 Spencer Dr Plano, TEXAS 75024, United States FRN: 0037395712 Tel.: +1(519)7215803 Email: [email protected] Signed by (printed name): Rulin Xu Signature: Applicant: Lotwork Inc. Add: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada FRN: 0036788925 Tel: +1(519)7215803 Email: [email protected] Signed by (printed name): Rulin Xu Signature:

QA-FR-170-B Company: Lotwork Inc. Add: 200 9 Oxbow Ave. Ottawa ON K1H 5P1 Canada Tel: +1(519)72 15803 Fax: N/A E-mail: [email protected] FCC Authorization Date: 2025-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Lotwork Inc., hereby authorizes Bay Area Compliance Laboratories Corp. (Kunshan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Kunshan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely, Signature: Prin t Name : Rulin Xu Title: CEO

QA-FR-171-A Company name: Lotwork Inc. Address: 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada Tel: +1(519)7215803 Fax: N/A Email: [email protected] FCC Confidential Authorization Date: 2025-05-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Sub ject: Confidentiality Request regarding application for certification of FCC ID: 2BOZY-R102 In accordance with Sectio ns 0.4 57 and 0.459 of the Commission’s Rules, Lotwork Inc. hereby requests long-term confidential treatment of i nformation accompanying this application as outlined below: Block Diagram Schematics Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Rulin Xu Title: CEO

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 1 / 5 EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS SRD ANT 1（TX） SRD ANT port 2 (RX) SRD ANT port 1（TX） SRD ANT 2 (RX) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 2 / 5 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 3 / 5 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 4 / 5 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 5 / 5

• 7

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 1 / 2 EXHIBIT B - EUT INTERNAL PHOTOGRAPHS BLE Antenna Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 2 / 2

Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RSHA250529007-00B Page 14 of 74 FCC §1.1310 & §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart §2.1091 and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f²) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); For simultaneously transmit system, the calculated power density should comply with: Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RSHA250529007-00B Page 15 of 74 Calculated Data: Mode Frequency Range (MHz) Antenna Gain ★Tune-up Output Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm) (mW) BLE 2402-2480 -2.15 0.61 -11.0 0.08 20 0.00001 1.0 SRD 2405-2480 4.1 2.57 4.0 2.51 20 0.0013 1.0 BLE and SRD can Simultaneous Transmit For simultaneously transmit, the worst condition is below: =0.00001/1.0+0.0013/1.0=0.00131< 1.0 Result: The device meets MPE at distance 20cm.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S.Government. FCC PART 15.247 TEST REPORT For Lotwork Inc. 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada FCC ID: 2BOZY-R102 R e p o r t T y p e : O r i g i n a l R e p o r t P r o d u c t N a m e: B a s e S t a t i o n Report Number: RSHA250529007-00B Report Date: 2025-12-13 Reviewed By: Bard Liu Approved By: Kyle Xu Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RSHA250529007-00B Page 2 of 74 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 SPECIAL ACCESSORIES ................................................................................................................................................. 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 9 EXTERNAL I/O CABLE .................................................................................................................................................. 9 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 TEST EQUIPMENT LIST ......................................................................................................................................... 12 SUMMARY OF TEST RESULTS ............................................................................................................................. 13 FCC §1.1310 & §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ....................................................... 14 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 16 APPLICABLE STANDARD ............................................................................................................................................ 16 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 16 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 17 APPLICABLE STANDARD ............................................................................................................................................ 17 TEST SYSTEM SETUP .................................................................................................................................................. 17 EMI TEST RECEIVER SETUP ....................................................................................................................................... 17 TEST PROCEDURE ...................................................................................................................................................... 18 TEST RESULTS SUMMARY .......................................................................................................................................... 18 TEST DATA: SEE APPENDIX ....................................................................................................................................... 18 FCC §15.209, §15.205 & §15.247(d) - SPURIOUS EMISSIONS ............................................................................. 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST SYSTEM SETUP .................................................................................................................................................. 19 EMI TEST RECEIVER SETUP .......................................................................................................................…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S. Government. FCC PART 15.247 TEST REPORT For Lotwork Inc. 2009 Oxbow Ave. Ottawa ON K1H 5P1 Canada FCC ID: 2BOZY-R102 R e p o r t T y p e : O r i g i n a l R e p o r t P r o d u c t N a m e: B a s e S t a t i o n Report Number: RSHA250529007-00C Report Date: 2025-12-13 Reviewed By: Bard Liu Approved By: Kyle Xu Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RSHA250529007-00C Page 2 of 50 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 SPECIAL ACCESSORIES ................................................................................................................................................. 9 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 9 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 9 EXTERNAL I/O CABLE .................................................................................................................................................. 9 BLOCK DIAGRAM OF TEST SETUP .............................................................................................................................. 10 SUMMARY OF TEST RESULTS ............................................................................................................................. 13 TEST EQUIPMENT LIST ......................................................................................................................................... 14 FCC §1.1310 & §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ....................................................... 15 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 17 APPLICABLE STANDARD ............................................................................................................................................ 17 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 17 FCC §15.207 (a) - AC LINE CONDUCTED EMISSIONS ...................................................................................... 18 APPLICABLE STANDARD ............................................................................................................................................ 18 TEST SYSTEM SETUP .................................................................................................................................................. 18 EMI TEST RECEIVER SETUP ....................................................................................................................................... 18 TEST PROCEDURE ...................................................................................................................................................... 19 TEST RESULTS SUMMARY .......................................................................................................................................... 19 TEST DATA: SEE APPENDIX ....................................................................................................................................... 19 FCC §15.205, §15.209 & §15.247(d) – RADIATED EMISSIONS ........................................................................... 20 APPLICABLE STANDARD ............................................................................................................................................ 20 TEST SYSTEM SETUP .................................................................................................................................................. 20 EMI TEST RECEIVER SETUP ........................................................................................................................…

Text truncated - open the document above for the full version.

东莞市一佳电子通讯科技有限公司 Dongguan YiJia Electronics Communication Technology Co.,Ltd. 规格承认书 SPECIFICATION FOR APPROVAL 客户 日期2021/07/08 Date 编号21070801 File No 版本1.0 Revision SPECIFICATION FOR APPROVAL 客户 Shanghai Hyco Genyong Technology Co., Ltd. CUSTOMER: 客户料号 R101 CUSTOMER NO: 品名 2 4GHz Antenna 品名 2. 4GHz Antenna PART NAME: 供方料号 YJ128W.100001.W02 SUPPLIER NO: 送样日期Date: 送样数量Q“TY:送样日期送样数量Q 客户确认CUSTOMER APPROVED BY APPROVALCHIEFSUPERVISOR 供方确认SUPPLIER SIGNATURE APPROVALCHECKDESIGN add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 APPROVALCHECKDESIGN ChenGuoqiangWenXueChenXingyi YJ-RD-F04-A 承认书项目表 Recognition letter project list NO . 内容 （Contents） 页数 （Number of Page） 页码 （Page Code） 1 承认书封面 （Spec Cover） 11 2 承认书项目表（Spec Item ） 12 3 工程成品图 （Drawing） 13 4 天线规格（Antenna Specification） 14 5 S参数测试 （S Parameter ） 15 6 无源测试（Passive Test） 26~76 无源测试（Passive Te s t ） 26 7 7 方向图（ Radiation Pattern ） 68 ~ 13 8 天线装配图（Antenna Profile） 214~ 15 材质 明 9 材质证明（Material Certificate ） 916 ~ 18 10 RoHS报告（RoHS Test Report ） **** 11N/AN/AN/A a dd:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 12--- 13--- 天线规格 Antenna Specification Electrical Properties Frequency 2.4-2.5GHz Impedance50 Ohm Nominal VS WR20MaxV.S.W.R2.0 Max Gain 4.1dBi RadiationOmni-directional PolarizationLinea r Physical Properties ConnectorSMA Male Reverse Cable TypeNone Cable LengthNone Cable ColorNone add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity 25±5 ̊C / <70% AntennaPerformance Test Agilent Antenna Performance Te s t Agilent E5071B SS Parameter Test // BT Antenna add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 AntennaPassive TestAntenna Passive Te s t ZZ Y XX X Z Y X add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Passive Test For BT Antenna FreqEffiEffiGain (MHz)(%)(dB)(dBi) 2400 60.9-2.22.3 2410 63.4-2.03.3 2420 66.2-1.83.8 2430 67.4-1.74.1 2440 64.4-1.93.6 2450 60.9-2.22.3 2460 57.7-2.43.0 2470 58.5-2.33.3 2480 59.8-2.23.4 add:Y uanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 2490 61.6-2.13.6 2500 60.7-2.22.6 Radiation Pattern For BT Antenna(2400MHz) add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For BT Antenna(2450MHz) add:Y uanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For BT Antenna(2500MHz) add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For BT Antenna(Phi 0 2D) add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For BT Antenna(Phi 90 2D) add:Y uanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For BT Antenna(Theta 90 2D) add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 BT Antenna add:Y uanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086 add:Yuanfu Industrial Park, No. 59 Muyu Road, Shatou, Chang'an, Dongguan, Guangdong, China Tel:0769-82586086 Fax:0769-82586086

公司名称 Company name 上海浩创亘永科技有限公司 Shanghai Hyco Genyong Technology Co.,Ltd 地址 Address 3A19 Building B, 999 Huaxu Rd., Qingpu Dist., Shanghai, China 型号 Model ANT_2D4G_3PIN 场形图 Radiation Pattern 增益值 Gain 天线照片 Antenna photo

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 1 / 7 EXHIBIT C - TEST SETUP PHOTOGRAPHS By adapter Conducted Emissions (Front View) Conducted Emissions (Left View) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 2 / 7 Radiated Emissions-Ground-parallel View (Below 30 MHz) Radiated Emissions-Perpendicular View (Below 30 MHz) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RSHA250529007 3 / 7 Radiated Emissions-Parallel View (Below 30 MHz) Radiated Emissions (30MHz-1GHz) Bay Area Compliance Laboratories Cor…

Text truncated - open the document above for the full version.
