GymAware RS Quick Start Guide 1. Introduction to the GymAware RS The GymAware RS is a gold-standard linear position transducer (LPT) used for velocity-based training (VBT). It attaches to your barbell (or weight belt) via a spring tether and measures the speed and load of each lift. GymAware RS tracks concentric/eccentric mean and peak velocity (m/s) and power (W or W/kg), along with other metrics like acceleration and distance. This real-time feedback helps coaches and athletes monitor 1RM progress, daily readiness, fatigue, and power output. Over 20 years, elite teams and world champions have relied on GymAware for precise performance data 2. Unboxing & What’s Included When you open the GymAware RS kit, you should find the following items : - GymAware RS unit: The main device with built-in tether and magnetic feet. - USB charging cable: A mini-USB cable for charging the device. - Service kit: Includes tools and spare parts for maintenance. - Quick start guide: This manual to help you get started. - Magnetic and Velcro straps: To attach the device to the barbell. - Velocity training bookmark: A visual aid for targets/zones. Be sure to keep the original packing and contents in case of future service needs. 3. Charging and Powering On Turn on the unit: Press the yellow ON/OFF button on the GymAware RS once. You should hear a single beep followed by a pause and then a slow beeping. The connection LED will pulse, indicating the unit is on and ready to connect. Sleep vs Shutdown: To sleep (brief off): Hold the ON/OFF button ~2 seconds, then release when you hear a slow double beep. Pulling the tether or tapping the button will wake it. To shut down (for long storage): Hold the button ~4 seconds total until the beeps stop. You must tap the button to turn it on again afterward. Always use the included charger. Using other chargers can damage the unit. Take care plugging in the USB cable so you don’t bend the port. 4. Installing and Mounting the Device - Floor placement (default): Place the GymAware RS on a flat, stable base (e.g. a weight plate) so its magnetic feet hold firmly to the floor. Position it directly under the barbell’s vertical path and keep it away from the lifter’s feet. The tether should hang vertically in line with the barbell’s intended lift direction. This alignment ensures accurate measurements. Using the straps: Attach the magnetic Velcro strap around the barbell collar, and pull the tether to clip the carabiner into the strap’s D-ring. Do not tighten the strap too much – it only needs to hold the device’s clip. Optional mounting: If you wish to attach GymAware RS to a rack or ceiling, use the optional mounting bracket. Secure the unit with screws when using the bracket. Always ensure the unit is firmly fixed to avoid drops. Magnetic feet: The RS unit has strong magnets on its base. You can place it against a metal surface for vertical or sideways mounting after powering it on. If you flip the unit (e.g. mounted to the rack), always wake it upright first (pull the tether or press ON) before use. This keeps the internal orientation sensor correct. Follow these guidelines to avoid interference or damage: never exceed the tether’s limit (about 1m) or let it snap back; always guide it back gently. 5. Connecting to the GymAware App (iOS only) Power on GymAware RS: Make sure the unit is on (see section 3). The RS will emit a slow beep and its LED will pulse when ready. Connect in the app: In the app’s main screen, tap the small Bluetooth/device icon in the bottom-left corner. A list of nearby devices will appear. Select and Zero: Find your GymAware RS by its serial number, then tap the green “Connect & 0” button next to it. This will pair the device to the app and automatically zero (calibrate) it. The unit will beep twice and flash its LED white when zeroing is complete. You need only connect/ zero once each time you power on the unit. Now the GymAware RS is paired. You should see its battery level and tether orientation icon on the Screen. 6. Setting Up an Account and Creating Profiles GymAware Cloud account: When you first open the app, you’ll be prompted to log in or create an account. All GymAware users need a free account to register hardware and sync data to the Cloud. Sign up with your email to access online features (e.g. data backup, team management). Adding athletes: In the app’s Setup screen, tap the “+” icon to create an athlete profile. Enter at least a first name (photo and additional details are optional), then tap Create. Repeat for each athlete. The list of athletes will sync between the iPad and your Cloud account. You can edit or delete profiles later if needed. Tip: Keep your athlete list short by focusing on those who will train with GymAware. You can also bulkmanage athletes on the GymAware Cloud website if you have many members. 7. Recording Workouts & Key Features Starting a session: In the app, select an athlete and choose the exercise (or create a custom exercise). Position the bar and GymAware as described above. When ready, press Record (or set the app to Auto Record mode) to begin. GymAware RS has no start/stop button on the device – it will automatically detect bar movement and record each rep for you. Performing lifts: Pull the tether taut and attach it to the barbell as explained. Execute your lift with proper form. The device’s green LED will flash rapidly during each set as it records data. After you finish, the set will auto-stop once the bar is at rest. You can then proceed to your next set or exercise. Live data on screen: During the lift, the app displays real-time metrics: velocity (concentric/ eccentric, mean & peak in m/s) and power (mean & peak in W or W/kg) for each rep. You’ll also see rep count, bar path, duration, and other values on-screen. After each set, you can review the data, save it, or move on. GymAware can also show leaderboards and target zones if you enable them, to gamify training. Key capabilities: GymAware RS’s auto st…

Text truncated - open the document above for the full version.

Rev 1/26/2023 KINETIC PERFORMANCE TECHNOLOGY PTY LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/11/2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BP9V-VD KINETIC PERFORMANCE TECHNOLOGY PTY LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. KINETIC PERFORMANCE TECHNOLOGY PTY LTD (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) Kane Rowe Rev 1/26/2023 KINETIC PERFORMANCE TECHNOLOGY PTY LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/11/2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID:2BP9V-VD KINETIC PERFORMANCE TECHNOLOGY PTY LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) Kane Rowe

Rev 1/26/2023 KINETIC PERFORMANCE TECHNOLOGY PTY LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/11/2025 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: 2BP9V-VD Applicant FRN: 0037154580 KINETIC PERFORMANCE TECHNOLOGY PTY LTD(“the applicant”) certifies that, as of the date of the filing of the application, FCC US Agent, LLC is our designated U.S. agent for service of process for the above referenced FCC ID. KINETIC PERFORMANCE TECHNOLOGY PTY LTD accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent, LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: FCC US Agent, LLC U.S. Agent FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Tel.: 708-571-3148 Email: [email protected] Sincerely, KINETIC PERFORMANCE TECHNOLOGY PTY LTDFCC US Agent, LLC Kane RoweTim Payne [Insert Applicant signature][U.S. Agent signature]

KINETIC PERFORMANCE TECHNOLOGY PTY LTD Date:7/11/2025 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:2BP9V-VD Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit TypeFile Name Schematics Block Diagram Operational Description Schematic.pdf Block Diagram.pdf Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, KINETIC PERFORMANCE TECHNOLOGY PTY LTD Signature Kane Rowe/Manager Typed name and Title

KINETIC PERFORMANCE TECHNOLOGY PTY LTD FCC ID: 2BP9V-VD POWER OF ATTORNEY Date: June 21, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Foshan) Co., Ltd. (Dara Zhou) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Foshan) Co., Ltd. (Dara Zhou) on our behalf shall have the same effect as acts of our own. This authorization expires on June 21, 2026 . This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, KINETIC PERFORMANCE TECHNOLOGY PTY LTD are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti- Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, KINETIC PERFORMANCE TECHNOLOGY PTY LTD Signature Kane Rowe/Manager Typed name and Title

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 1 of 4 Picture 1 Picture 2 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 2 of 4 Picture 3 Picture 4 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 3 of 4 Picture 5 Picture 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 4 of 4 Picture 7

FCC ID: 2BP9V-VD This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 1 of 3 Picture 1 Picture 2 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 2 of 3 Picture 3 Picture 4 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Reference No.: WTF24F09213699W Page 3 of 3 Picture 5 Picture 6

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn RF Exposure Requirements 1 General Information Client Information Applicant ....................................... : Kinetic Performance Technology Pty Ltd Address of applicant ................... : Unit 3/24 Girrahween St, Braddon ACT 2612, Australia Manufacturer ................................. : The same as above Address of manufacturer ............. : The same as above General Description of E.U.T FCC ID ............................................ : 2BP9V-VD Product Name ............................... : GymAware RS Model No. ...................................... : VD Model Description ........................ : --- Rating ............................................. : Type-C USB Port Input: DC 5V Battery: 3.6V, 3350mAh (18650) Technical Characteristics of EUT Bluetooth Version ......................... : Bluetooth LE Frequency Range ......................... : 2402-2480MHz RF Output Power .......................... : -0.119 dBm (Conducted ) Modulation..................................... : GFSK Data Rate ....................................... : 1Mbps Quantity of Channels ................... : 40 Channel Separation ...................... : 2MHz Type of Antenna ........................... : Chip antenna Antenna Gain ................................ : 3.8dBi Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 2 Applicable Standard According to §1.1307(b)(1) and KDB 447498 D01 General RF Exposure Guidance v06, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. (a) Limits for Occupational / Controlled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 / / F/300 6 1500-100000 / / 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-100000 / / 1 30 Note: f = frequency in MHz: * = Plane-wave equivalents power density 3 Calculation Method S = (30*P*G) / (377*R 2 ) S = power density (in appropriate units, e.g., mw/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mw) G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor is normally numeric gain. R = distance to the center of radiation of the antenna (in appropriate units, e.g., cm), R=20cm. 4 MPE Calculation Result Frequency (MHz) Antenna Gain (dBi) Numeric gain Conducted Power (dBm) Maximum Tune-up output power PD (mW/cm2) Limit (mW/cm2) (dBm) (mW) 2402 3.8 2.40 -0.119 0.00 1.00 0.00048 1.0 Result: Pass ======End of Report======
