2BPIK-MT83254In-car wireless charging

In -car wireless charging – USER MANUAL Package Contents 1. Main Unit 2. Hook-Type Mount 3. Air Vent (Claw-Type) Mount 4. C-to -C Cable 5. Cable Organizer Clip (3P) Product Features - Supports Qi2-certified fast wireless charging with a maximum output of 15W. - Provides stable charging even on bumpy roads when used with the 10-point silicone surface. - Strong neodymium magnets securely hold the smartphone. - A high-quality silicone pad protects the device from scratches. Product Overview – Front View - Ambient Light Ring - Silicone Pad - Wireless Charging Area - Cable Connection Port Product Overview – Rear View - LED Button - Magnetic Ball Joint - Adjustable Mounting Hole Ambient Light Usage Instructions - Ten ambient colors are available to match your vehicle interior. - Press the LED button once to change the color. - Press the LED button twice continuously to adjust brightness (3 levels). - Long-press the LED button to turn the light ON/OFF. Air Vent Mount Usage Instructions 1. Insert the ball joint into the holder/head, then tighten the nut to secure it. 2. Attach the clip onto the air vent blade and rotate the knob to tighten. *Note: Excessive tightening may damage thin air vent blades depending on the vehicle.* Hook-Type Mount Usage Instructions - Cable Management Holder - Mount Locking Lever - Length Adjustment Dial - 360° Rotation Lock Pin - Lower Stabilizing Support Ultime (Claw-Type) Mount Usage Instructions - Locking Clip - Length Adjustment Dial - Lower Stabilizing Support Cable Connection Precautions - For fast charging, use a vehicle charger or power adapter capable of supplying at least 30W. Safety Precautions - This product operates only with smartphones that support wireless charging. - Connect the cable to the charger before use. - Use a vehicle charger or adapter capable of 30W or higher for fast charging. - Do not use non-Qi wireless charging pads. Use only Qi-certified equipment. - Avoid using in high-temperature environments or direct sunlight. - Do not place coins or metal objects on the charging surface. - Avoid exposure to moisture or liquids. - Do not charge in environments below −10°C or above 60°C. - Do not disassemble, repair, or modify the product. - Keep out of reach of children. - If charging performance decreases, replace the cable or charger. - Do not insert fingers into the vent or moving parts. - If the internal temperature exceeds 50°C, charging may slow down or stop automatically for safety. - If the device does not support wireless charging, purchase a MagSafe or magnetic- compatible case separately. Product Specifications Product Name: In-car wireless charging Model Number: MT83254 / MT83255/ MT83604 Input: 5V–2A, 9V–2A, 12V–1.5A Wireless Charging Output: 15W Max Dimensions: 70 × 70 × 40 mm Materials: ABS + PC + Silicone KC Certification: R-Rn-m31-MT83254 Manufacturer: (주)메이튼 Customer Support: 1544-7306 Address: 404, Annam-ro, Bupyeong-gu, Incheon, Republic of Korea Made in China FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radiofrequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The FCC certification of this device refers to RF exposure testing performed in typical operating conditions, where a person is no closer than 20 centimeters from the device surface at all times, except for non-repetitive patterns with transient time intervals in the order of a second. Only in the stated conditions, the device is shown to fully comply with the FCC RF Exposure requirements of KDB 447498.

AttestationStatements Date:2025-11-18 TO:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046,USA RE:AttestationStatementsPart2.911(d)(7)requestfor(FCCID:2BPIK-MT83254) MAYTONCO.,LTD.theundersigned,herebyauthorizeHOPEKCORPORATIONINCtoact asourdesignatedU.S.agentforserviceofprocess,MAYTONCO.,LTD.acceptsto maintainanagentfornolessthanoneyearafterthegranteehasterminatedall marketingandimportationortheconclusionofanyCommission-relatedproceeding involvingtheequipment. HOPEKCORPORATIONINCacceptstheresponsibilitytoactasdesignatedU.S.agentfor serviceofprocess. ApplicantInformation： Companyname:MAYTONCO.,LTD. ContactName:BINGQUANJIN Address:404,Annam-ro,Bupyeong-gu,Incheon,SouthKorea TelephoneNo:82-10-8826-6669 Email:[email protected] FRN:0037039294 Signature: BINGQUANJIN U.S.AgentInformation: CompanyName:HOPEKCORPORATIONINC Address:16755CoyoteBushDrUnit84,SanDiego,CA92127UnitedStates FRN:0034562900 ContactName:PeterDavis TelephoneNo:561-235-6113 Email:[email protected] Signature: PeterDavis

Rev 1/26/2023 MAYTON CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2025-11-18 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BPIK-MT83254 MAYTON CO., LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. MAYTON CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (BINGQUAN JIN) Rev 1/26/2023 MAYTON CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2025-11-18 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BPIK-MT83254 MAYTON CO., LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (BINGQUAN JIN)

Page1of 5 东莞市德弗力五金电子材料有限公司 产品规格书 PRODUCT SPECIFICATION 客 户： CUSTOMER:____________________________________________________________________ 客户料号： CUST P/N:____________________________________________________________________ 德弗力料号： K C P/N:____________________________________________________________________ 产品型号： 20.5*39.5*15*0.08mm*80P*11TS D E S E : 日 期：2025.05.14 D A T E :____________________________________________________________________ 版 本： A.0 VERSION :____________________________________________________________________ （客户承认受领印）ACCEPTANCE STAMP 拟制跟单员 PREPARED BY 曾小仙 Address:东莞市石碣镇新风西路107号Tel：86-076986016320 Http://www.hartai.com Fax：86-076986372427 MERCHANDISER 工程审核 ENGINEER CHECKED BY 批准 APPROVED BY 邱志辉 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD Y-Y20.5*39.5-15-FR B.10.021060069-00 No. 107, Xinfeng West Road, Shijie Town, Dongguan City 版本 Rev. A.0 变更前 Before Change -- 变更后内容 DESCRIPTION(Content Or Reason ForChanged) 新发行（Initial Release） 日期 Date 修订者 Revisor 2025/05/14 曾小仙 拟制工程审核 PREPARED BY 曾小仙 ENGINEER CHECKED BY 邱志辉 版 本 变 更 履 历 Version Change History 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD Address:东莞市石碣镇新风西路107号Tel：86-076986016320 Http://www.hartai.com Fax：86-076986372427 客户料号： CUST P/N 德弗力料号： DFL P/N Page2of 5 Y-Y20.5*39.5-15-FR B.10.021060069-00 No. 107, Xinfeng West Road, Shijie Town, Dongguan City H G D C A B 42.5±0.5 39.5±1.0 20.5±0.5 20±0.515±2.0 3±2 0.8±0.2 1±0.2 1.产品外形尺寸（OVERALL DIMENSIONS OF PRODUCTS): 2.单位(Unit):毫米(mm) A J B K C D LM E N1/N2 F O G P H I1/I2 拟制工程审核 PREPARED BY 曾小仙 ENGINEER CHECKED BY 邱志辉 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD Address:东莞市石碣镇新风西路107号Tel：86-076986016320 Http://www.hartai.com Fax：86-076986372427 客户料号： CUST P/N 德弗力料号： DFL P/N 规 格 内 容 Specification Page3of 5 E F 20*0.8MM Y-Y20.5*39.5-15-FR B.10.021060069-00 J 2.2±0.4 double faced adhesive tape Center sticker small round hard magnetic No. 107, Xinfeng West Road, Shijie Town, Dongguan City 圈数 Turns 11TS 线径 Wire Dia. 0.08MM*80P热风线 （Silk-Covered Wire） 所有材料要求合格 ROHS 标准 绕线方式 疏/密 Wdg. Type Spred/Close 密绕（Close） 绕线方向 Wdg.Direction （Anticlockwise） 相交 是/否 Intersect Yes/Not 相交（Yes） 线圈 正/反贴 Coil Positive/Anti Paste （Anti/-Paste） 2.电气特性（ELECTRICAL CHARACTERISTICS): 温度 TEMPERATURE:25±10°C,湿度 RELATIVE HUMIDITY:65±10% 序号 NO. 1 2 3 项目 ITEM IND DCR 端子 TERMINAL S-F S-F Q 值 S-F 标准 SPECIFICATION 电感：7.9uH±0.3 阻值： Q 值：85 测试条件 TEST FREQUENCY 100kHz/V 100kHz/V 100kHz/V 测试仪器 TEST EQUIPMENTS 拟制工程审核 PREPARED BY 曾小仙 ENGINEER CHECKED BY 邱志辉 规 格 内 容 Specification 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD Address:东莞市石碣镇新风西路107号Tel：86-076986016320 Http://www.hartai.com Fax：86-076986372427 客户料号： CUST P/N 德弗力料号： DFL P/N SHDA 1062 SHDA 1062 SHDA 1062 Page4of 5 逆时针 反贴 Y-Y20.5*39.5-15-FR B.10.021060069-00 No. 107, Xinfeng West Road, Shijie Town, Dongguan City

Differences Description We MAYTON CO., LTD. state: Product： In-car wireless charging Model(s) Name： MT83254, MT83255 Brand Name： MAYTON FCC ID： 2BPIK-MT83254 All models have the same circuit schematic, construction, PCB Layout and critical components. All designs are the same, only the color difference in appearance. Sincerely, Name: BINGQUAN JIN Tel.: 82-10-8826-6669 Email: [email protected]

MAYTON CO., LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 18, 2025 Subject; Request for Confidentiality FCC ID: 2BPIK-MT83254 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: BINGQUAN JIN Title: PM

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 MAYTON CO., LTD. Date：11/18/2025 Product Model Number: MT83254, MT83255 FCC ID：2BPIK-MT83254 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: BINGQUAN JIN Contact Listed on FCC Wesbite Title: PM Email: [email protected] On behalf of: MAYTON CO., LTD.

Page 1 of 4 Report No.: FCS202504151 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MT83254 Photo 1 Photo 2 Page 2 of 4 Report No.: FCS202504151 Photo 3 Photo 4 Page 3 of 4 Report No.: FCS202504151 Photo 5 Photo 6 Page 4 of 4 Report No.: FCS202504151 Photo 7

Label Size: R30mm 1. The label is silk-screen on the sample In-car wireless charging Model Name: MT83254 FCC ID: 2BPIK-MT83254

Page 1 of 3 Report No.: FCS202504151 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MT83254 Photo 1 Photo 2 Page 2 of 3 Report No.: FCS202504151 Photo 3 Photo 4 Loop Antenna Page 3 of 3 Report No.: FCS202504151 Photo 5

FCC Test Report Report No: FCS202504151W02 Issued for Applicant: MAYTON CO., LTD. Address: 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Product Name: In-car wireless charging Brand Name: MAYTON Model Name: MT83254 Series Model: MT83255 FCC ID: 2BPIK-MT83254 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Te c h Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : MAYTON CO., LTD. Address .................................. : 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Manufacture's Name .............. : MAYTON CO., LTD. Address .................................. : 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Product Description Product Name ........................ : In-car wireless charging Brand Name ......................... : MAYTON Model Name ........................... : MT83254 Series Model .......................... : MT83255 Test Standards ....................... : FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ................................ : Date (s) of performance of tests . : Mar. 28, 2025 ~ Apr. 10, 2025 Date of Issue .............................. : Apr. 10, 2025 Test Result .................................. : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Jack Wang) Page 3 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. TEST FACTORY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 3 TEST METHODOLOGY 7 3.1 MEASURING STANDARD 7 3.2 REQUIREMENTS 7 3.1 LIMITS 7 3.2 TEST SETUP 8 3.3 TEST PROCEDURE 8 4 EQUIPMENT APPROVAL CONSIDERATIONS 9 4.1 DESCRIPTION OF THE TEST MODE 10 4.2 PERIPHERAL LIST 10 4.3 TEST INSTRUMENTS LIST 10 4.4 DUTY CYCLE 11 4.5 TEST RESULT 12 4.6 TEST SETUP PHOTO 13 Page 4 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 Apr. 10, 2025 ALL Initial Issue Page 5 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 CNAS: L15566 Page 6 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name In-car wireless charging Trade Name MAYTON Model Name MT83254 Series Model MT83255 Model Difference All designs are the same, only the color difference in appearance Operation frequency 113kHz-205kHz Modulation Technology ASK Antenna Type Loop coil antenna Antenna gain 0dBi Power Supply Input: DC9V-2A Output(Phone): 15W/10W/7.5W/5W Hardware version number V1.0 Software version number V1.0 Connecting I/O Port(s) Please refer to the User's Manual Page 7 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 3 TEST METHODOLOGY 3.1 Measuring Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: KDB 680106 D01 Wireless Power Transfer v04. 3.2 Requirements According to the item 3 of KDB 680106 D01v04: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Mobile Device and Portable Device Configurations (2) Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz (3) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the top surface. 3.1 Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Page 8 of 15 Report No.: FCS202504151W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Indus…

Text truncated - open the document above for the full version.

FCC Test Report Report No: FCS202504151W01 Issued for Applicant: MAYTON CO., LTD. Address: 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Product Name: In-car wireless charging Brand Name: MAYTON Model Name: MT83254 Series Model: MT83255 FCC ID: 2BPIK-MT83254 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Te c h Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com EST RESULT CERTIFICATION Applicant’s Name ................... : MAYTON CO., LTD. Address .................................. : 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Manufacture's Name .............. : MAYTON CO., LTD. Address .................................. : 404, Annam-ro, Bupyeong-gu, Incheon, South Korea Product Description Product Name ........................ : In-car wireless charging Brand Name ......................... : MAYTON Model Name ........................... : MT83254 Series Model .......................... : MT83255 Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ................................ : Date (s) of performance of tests . : Mar. 28, 2025 ~ Apr. 10, 2025 Date of Issue .............................. : Apr. 10, 2025 Test Result .................................. : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Jack Wang) Page 3 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.4 EQUIPMENTS LIST 10 3. CONDUCTED EMISSION MEASUREMENT 11 3.1 LIMIT 11 3.2 TEST PROCEDURE 11 3.3 TEST SETUP 12 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 15 4.1 LIMIT 15 4.2 TEST SETUP 16 4.4 TEST RESULTS 17 5. 20 DB BANDWIDTH TEST 21 5.1 TEST PROCEDURE 21 5.2 TEST SETUP 21 5.4 TEST RESULTS 22 6. ANTENNA REQUIREMENT 23 6.1 STANDARD REQUIREMENT 23 6.2 EUT ANTENNA 23 Page 4 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 Apr. 10, 2025 ALL Initial Issue Page 5 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. SUMMARY OF TEST RESULTS Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Spurious Emission 15.209(a)(f) Pass 20dB Bandwidth 15.215 Pass NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2020 Page 6 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 CNAS: L15566 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±4.13 dB 2 Conducted Emission (150KHz-30MHz) ±4.74 dB 3 All emissions, radiated 9kHz-30MHz ±3. 10 dB 4 All emissions, radiated 30MHz-1000MHz ±3.20 dB 5 Occupied Channel Bandwidth ±3.5% Page 7 of 23 Report No.: FCS202504151W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name In-car wireless charging Trade Name MAYTON Model Name MT83254 Series Model MT83255 Model Difference All designs are the same, only the color difference in appearance Operation frequency 113kHz-205kHz Modulation Technology ASK Antenna Type Loop coil antenna Antenna gain 0dBi Power Supply Input: DC9V-2A Output (Phone): 15W/10W/7.5W/5W Hardware version number V1.0 Software version number V1.0 Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) …

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: 2BPIK-MT83254 DCD Setup photo Model name: MT83254 DCD radiation 9k-30M DCD radiation 30M-1G
