2BQ4O-B1ULTRAsmart watch

smart watch B1 Ultra User Manual 1.Please read the instruction manual below before use, in order to install the SIM card properly and use the product easily. 2.The product pictures displayed in the manual are for illustration only, please refer to the actual product. 1) SIM card installation method: 1.Prepare a Nano SIM card. 2.With the watch turned off, take out the card tray with a tool. Insert the SIM card in the direction of the card tray, and finally push the card tray into the card slot together with the card. 3.Caller display function and data flow must be opened (Data flow is not less than 50M per month). Note: It is strictly forbidden to poke the microphone hole next to the SIM card tray with a needle. 2) How to Use the watch: 1.Power on: hold the power button for 3 seconds to start the watch. 2.How to power off: (Option 1) Press and hold the power button to pop up a new page, click the ‘Shutdown’ icon (Option 2) by APP: ‘Function’ / ‘Remote Power Off’ 3. Battery Charge: Fully charge the battery before first use. Use the magnetic charging lead to attach to the back of the device (it will only connect one way), the other end is connected to a usb charger, which supports output DC 5V~1A.Please do not use a charger with an output voltage exceeding 5V, it will damage the device. 4. Switch and clean up background apps: Press and hold the power button to pop up a new page, click the menu icon to switch or clean up background apps. 5. Volume adjustment: Press and hold the power button to pop up a new page, Click the speaker icon to adjust the volume. Note: (1) About one minute to read the SIM card information after power on, the signal is normal, automatic timing. (2) If the watch cannot be turned on normally, please check whether the watch has electricity, if there is no electricity, please charge it in time and turn it on again. (3) If the card is not inserted or the card cannot be read after power on, you can re-insert the card or replace the SIM card, and then restart to confirm the card reading. (4)Make sure you're using the magnetic charging cable that came with your watch. Using other charging cables may damage your watch. 3) Download and install the App: (Option1) - Scan the following QR code, download and install the App (Option 2) - Scan code to download in the GPS watch in ‘QR Code’ (Option 3）-Search “MiWiTracker” in App Store - Apple or Google Play Note: During installation, the phone prompts whether to trust the APP or whether to allow prompt access to phone location, etc. Please select trusted and allowed all the time. 4) Registering the watch and log in: Open the App, new users will need to register a new account by clicking on the bottom left “Register” button, complete the registration steps. 5) Connecting the watch to your APP account: After successful registration, login to the account, select ‘+’  Add watch, scan the QR code on the watch. Note: During the process, the phone prompts whether to trust the APP or whether to allow prompt access to phone location, etc. Please select trusted and allowed all the time. 6) Product Features: 1.Real-time GPS, WIFI & CELL location 2.Historical track, Geofence 3.Calling (Contacts, SOS, two-way communication) 4.Voice Chat message 5.Camera function[*Optional, only for devices with a camera] 6.Health pedometer 7.Location Update Modes 8.Clock 9.Heart Rate[*Optional, only for devices with heart rate] 10.Do Not Disturb 11.Other settings and functions 7) Function Description: 1. Location Update Schedule Modes: There are two location update modes. User can combine the two modes to better experience location services. (1).Manual positing: Click ’Refresh’ in the real-time location map interface of APP or click ’Function’’Real-time Position’ to update current location information,and the watch will report the up-to-date position as soon as possible. (2).Real-time positing: Updates location data to APP according to the set interval when there is continuous movement. Note: ①User can click’Function’’Upload Interval’ to set the device upload interval in minutes.The value should be an integer between 1 and 86400 ②The default interval of real-time positioning mode is 10 minutes ③ In the real-time positioning, the watch will regularly update the location on the APP Map page and History 2. Historical Location Playback: In the real-time location map interface of APP, click the ‘History’ button on the right, you can check the location history playback. 3. Geo-fence (safe area): This feature defines a Geo-fence (safe area) perimeter and sends the user a push notification if the tracker has left or entered the safe area. Click ‘GeoFence’  Click the "+" icon in the upper right corner  Click and drag the map to set the centre point  Drag to set the coordinates coordinate area range  Click ‘√’ at the top right Enter fence name  Click confirm to save . Note: (1)App will show enter or leave geofence alarm information (Click ‘Mine’ ‘message’). (2) After the watch uploads the location, the APP can judge whether to enter or exit the geofence. 4. Calling: (1)Phone Book: ①Add a contact: Click APP ‘Function’Set phone book Click the ‘+’ icon  Insert name, number , and finally click ‘SAVE’ to save. ②Edit Contact:Click APP ‘Function’Set phone book  drag to select the number you want to edit  Save after editing ③Delete Contact: Click APP ‘Function’Set phone book  drag the number you want to delete  Click ‘Delete’ (delete information will be synchronized in both of watches and app). (2)Call: ①Use phonebook to call: Click ‘Contact’ icon in the watch to view the contact list, slide up and down to select a contact to Call. ②One Button SOS:In case of emergency, press and hold the power button to pop up a new page, click the ‘SOS’ icon. At this time, the watch will call the 3 preset emergency numbers circularly. ③Call dialing: Click the ‘Phone’ icon in the watch, enter phone numbers manually, the telephone dial-out. 5. Chat features: (1) Voice message: ①…
