2BQIA-VERDANDIKinera Imperial Verdandi Wireless

Dongguan Yutai Electronics Co., Ltd.
Kinera Imperial Verdandi Wireless - FCC ID 2BQIA-VERDANDI - Dongguan Yutai Electronics Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 02, 2025
Application Purpose
Original Equipment
Equipment Note
Kinera Imperial Verdandi Wireless
Frequency Range
2402.00000000 - 2480.00000000
Company
Dongguan Yutai Electronics Co., Ltd.
Country
China

Documents & Files

Select a file to view

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Dongguan Yutai Electronics Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Dongguan Yutai Electronics Co., Ltd. Address: Room 1802, Building N6, Tianan Cyber City, Fenggang Town, Dongguan City, Guangdong Province, China Product Name: Kinera Imperial Verdandi Wireless FCC ID: 2BQIA-VERDANDI Model(s): Verdandi Wireless 2.911(d)(5)(i) Equipment Type We, [Dongguan Yutai Electronics Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Chris Yao Date: 2025.11.25 Title and Company name: manager / Dongguan Yutai Electronics Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Dongguan Yutai Electronics Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Dongguan Yutai Electronics Co., Ltd. Address: Room 1802, Building N6, Tianan Cyber City, Fenggang Town, Dongguan City, Guangdong Province, China Product Name: Kinera Imperial Verdandi Wireless FCC ID: 2BQIA-VERDANDI Model(s): Verdandi Wireless 2.911(d)(5)(ii) Applicant filing We, [Dongguan Yutai Electronics Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Chris Yao Date: 2025.11.25 Title and Company name: manager / Dongguan Yutai Electronics Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Dongguan Yutai Electronics Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 [November 26, 2025] U.S. Agent Designation [Dongguan Yutai Electronics Co., Ltd.] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought FCC ID: 2BQIA-VERDANDI Name and company of U.S. agent: [GLOCERTS TECHNOLOGY INC] Physical U.S. address of agent: [19784 SUNKISSED RIDGE DR, RIVERSIDE, CA 92507] FRN of U.S. agent: [0036339737] Email address of U.S. agent: [[email protected]] Telephone of U.S.agent: (626) 588-8039 [GLOCERTS TECHNOLOGY INC] acknowledges their obligation to accept service of process on behalf of [Dongguan Yutai Electronics Co., Ltd.]. [Dongguan Yutai Electronics Co., Ltd.] with the FRN [0037196466] accepts its obligation to maintain an agent for service of process in the United States for no less than 1 year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Signature [Chris Yao] [Huiying Fan] [manager] [Director] [Dongguan Yutai Electronics Co., Ltd.] [GLOCERTS TECHNOLOGY INC]

Cover Letter(s)

Dongguan Yutai Electronics Co., Ltd. Agent Authorization Company: Dongguan Yutai Electronics Co., Ltd. Address: Room 1802, Building N6, Tianan Cyber City, Fenggang Town, Dongguan City, Guangdong Province, China Product Name: Kinera Imperial Verdandi Wireless Model Number(s): Verdandi Wireless Product Description: Kinera Imperial Verdandi Wireless We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: November 25, 2025 Name: Chris Yao Title: manager Company: Dongguan Yutai Electronics Co., Ltd.

Cover Letter(s)

Dongguan Yutai Electronics Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 25, 2025 Subject; Request for Confidentiality FCC ID: 2BQIA-VERDANDI To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chris Yao Title: manager

External Photos

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 8 Model: Verdandi Wireless External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 8 L Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 8 R Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 6 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 7 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 8 of 8

ID Label/Location Info

FCC ID LABEL: Label Location: FCC ID: 2BQIA-VERDANDI

Internal Photos

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 8 Model: Verdandi Wireless Internal Photos L Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 8 R ANT Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 6 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 7 of 8 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 8 of 8 ANT

RF Exposure Info

Shenzhen CTB Testing Co., Ltd. FCC ID:2BQIA-VERDANDI Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Left ear: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.793 1.20 0±1 1.00 1.26 <5 0.39023 3.00 YES 2.441 1.359 1.37 1±1 2.00 1.58 <5 0.49524 3.00 YES 2.480 0.354 1.08 0±1 1.00 1.26 <5 0.39651 3.00 YES 2.402 1.62 1.45 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 2.173 1.65 2±1 3.00 2.00 <5 0.62347 3.00 YES 2.480 1.181 1.31 1±1 2.00 1.58 <5 0.49918 3.00 YES 2.402 1.98 1.58 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 2.444 1.76 2±1 3.00 2.00 <5 0.62347 3.00 YES 2.480 1.56 1.43 1±1 2.00 1.58 <5 0.49918 3.00 YES GFSK π /4DQPSK 8DQPSK EDR: Right ear: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.81 1.21 0±1 1.00 1.26 <5 0.39023 3.00 YES 2.441 2.285 1.69 2±1 3.00 2.00 <5 0.62347 3.00 YES 2.480 1.734 1.49 1±1 2.00 1.58 <5 0.49918 3.00 YES 2.402 1.534 1.42 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 3.041 2.01 3±1 4.00 2.51 <5 0.78490 3.00 YES 2.480 2.314 1.70 2±1 3.00 2.00 <5 0.62843 3.00 YES 2.402 1.751 1.50 1±1 2.00 1.58 <5 0.49127 3.00 YES 2.441 3.256 2.12 3±1 4.00 2.51 <5 0.78490 3.00 YES 2.480 2.467 1.76 2±1 3.00 2.00 <5 0.62843 3.00 YES GFSK π /4DQPSK 8DQPSK Shenzhen CTB Testing Co., Ltd. BLE: Left ear:1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.711 1.180±11.001.26<50.390233.00YES 2.44 1.228 1.331±12.001.58<50.495143.00YES 2.480 0.254 1.060±11.001.26<50.396513.00YES GFSK BLE: Left ear:2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.796 1.200±11.001.26<50.390233.00YES 2.44 1.353 1.371±12.001.58<50.495143.00YES 2.480 0.411 1.100±11.001.26<50.396513.00YES GFSK BLE: Right ear:1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.433 1.10 0±1 1.00 1.26 <5 0.39023 3.00 YES 2.44 1.968 1.57 1±1 2.00 1.58 <5 0.49514 3.00 YES 2.480 1.453 1.40 1±1 2.00 1.58 <5 0.49918 3.00 YES GFSK BLE: Right ear:2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.513 1.130±11.001.26<50.390233.00YES 2.44 2.147 1.642±13.002.00<50.623343.00YES 2.480 0.326 1.080±11.001.26<50.396513.00YES GFSK Conclusion: For the max result : 0.78490≤ FCC Limit 3.0 for 1g SAR.

Test Report

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 63 TEST REPORT Compiled by: Reviewed by: Approved by: Zhou Kui Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Kinera Imperial Verdandi Wireless FCC ID: 2BQIA-VERDANDI Trademark: Model Number: Verdandi Wireless Prepared For: Dongguan Yutai Electronics Co., Ltd. Address: Room 1802, Building N6, Tianan Cyber City, Fenggang Town, Dongguan City, Guangdong Province, China Manufacturer: Dongguan Yutai Electronics Co., Ltd. Address: Room 1802, Building N6, Tianan Cyber City, Fenggang Town, Dongguan City, Guangdong Province, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Oct. 24, 2025 Sample tested Date: Oct. 24, 2025 to Nov. 29, 2025 Issue Date: Nov. 29, 2025 Report No.: CTB25102411802RF01 Test Standards FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2020 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25102411802RF01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 63 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 3 2. TEST SUMMARY ........................................................................................................................... 4 3. MEASUREMENT UNCERTAINTY ................................................................................................. 5 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 6 4.1 Product Information .......................................................................................................................... 6 4.2 Test Setup Configuration .................................................................................................................. 6 4.3 Support Equipment........................................................................................................................... 6 4.4 Channel List ..................................................................................................................................... 7 4.5 Test Mode ........................................................................................................................................ 7 4.6 Test Environment ............................................................................................................................. 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 8 5.1 Test Facility ...................................................................................................................................... 8 5.2 Test Instrument Used ....................................................................................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 11 6.1 Block Diagram Of Test Setup ......................................................................................................... 11 6.2 Limit ................................................................................................................................................ 11 6.3 Test procedure ............................................................................................................................... 11 6.4 Test Result ..................................................................................................................................... 13 7. RADIATED SPURIOUS EMISSION ............................................................................................. 15 7.1 Block Diagram Of Test Setup ......................................................................................................... 15 7.2 Limit ................................................................................................................................................ 15 7.3 Test procedure ............................................................................................................................... 16 7.4 Test Result ..................................................................................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 31 8.1 Block Diagram Of Test Setup ......................................................................................................... 31 8.2 Limit ................................................................................................................................................ 31 8.3 Test procedure ............................................................................................................................... 31 8.4 Test Result ..................................................................................................................................... 32 9. COUDUCTED OUTPUT POWER .........................................................................................…

Text truncated - open the document above for the full version.

Test Report

page 1 of 3 Antenna Specifications 1. General Description This document provides the antenna specifications on electric, mechanic and reliability. The testing conditions and related pictures are also included. 1.1 Print Acceptance Samples and Antenna Specifications are to be sent to customer. When they are approved, the approval form should be completed, signed, and sent back to HX before further mass production batches can be delivered. 1.2 Coordinate System The coordinate system for the phone is defined as follows:  Origin in center of gravity.  Positive X axis is perpendicular to, and directed from, front plane.  Positive Y axis is perpendicular to, and directed from, right side plane (as seen from front).  Positive Z axis is perpendicular to, and directed from, top plane. a) E0-plane b) E90-plane c) Az-plane Figure 1-1 The coordinate system for the phone 2. Specifications This report mainly provides the testing conditions of various electric and structural performance parameters for cell phone antenna ----B6*8-1 Figure 2-1 shows the antenna designed by HX & The fixturing of B6*8-1 y x  y z x x y z z page 2 of 3 Figure 2-1 The antenna designed by HX & The fixturing of B6*8-1 2.1 Antenna frequency band and switching logic 2.2 Impedance 2.2.1 Nominal Nominal Impedance(including matching circuit) : 50 ohms 2.2.2 Matching Circuit Main antenna 2.2.3 Passive efficiency of antenna Main antenna BT 网络模式 频段 BT 2.4G page 3 of 3 3. Environmental Characteristic Test Item Test description 1. Low Temperature Temp.: -20 °C Time: 24 hours 2. High Temperature Temp.: 80°C Time: 24 hours 3. Salt Fog 5±0.1% Nad salt fog PH Value: 6.5-7.2 Temp: 35±1°C Time:24 hours

Test Setup Photos

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: Verdandi Wireless Radiated Emission Below 1G Above 1G Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Conducted emissions RF Conducted

Contact Information

Applicant

Chris Yao
[email protected]Fax: 17802009164

Test Firm

Shenzhen CTB Testing Technology Co., Ltd.Rita Xiao
[email protected]

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz1.64 mW
Confidentiality
Long Term
Grant Notes
Power listed is the maximum conducted output power.
