USER’S MANUAL Product Overview Antenna Power Switch/Volume Switch Indicator Light PTT Display Screen Function Key/ Menu Key UP Key Charging port Type-C Earphone Jack SIM Card Slot Back Key Microphone DOWEN Key Speaker Charging Instructions Functions Guide .The battery is not charged in the factory,please charge the battery under the environmental temperature - °C before using. .After purchasing or long-term storage(more than two months),charging the battery for the first time can not reach its saturation capacity,repeat charge/discharge for twice or three times to make battery capacity achieve the best state. .Before charging,please power off the transceiver,using the radio during charging may affect correct charging. .If the battery has been charged fully,please do not charge it again,otherwise the service life of the battery may be shorten or may be damaged. .If the service time is significantly reduced even after completely correct charging,the battery can not be used any more,please replace a new battery. Key Operations ●Group Selection Main Menu → Groups,select the groups with Up/Down keys,then press the Menu key to confirm. ●Single Call Selection Main Menu → Member List,use the Up/Down keys to select the target for the single call,press the Menu key to enter the single call interface,then press the PTT key to initiate communication. ●Group Talk After the transceiver is successfully logged in,press the PTT key to activate the group communication. ●Other Settings Press the Menu key to access the menu,in Settings,configure: keypad tone、screen brightness、screen timeout duration、call alert tone. Basic Operations Power Switch/Volume Adjustment Turn the power switch knob clockwise to turn on the transceiver,and adjust the volume by turning the volume switch;turn the power switch knob counterclockwise to turn it off. Navigate to Main Menu → About the device to view: device account、IMEI number、ICCID、device model、software version、key wake-up、 incoming call wake-up、voice prompts、power- saving mode、signal value、service information、call pop-up、software update、weather forecast (supported on select platforms)、location(supported on select platforms). Functions ●Single Call Steps:Go to the member list,select a member,then press the Menu key to enter the single call interface,both parties can press the PTT key to initiate a single call. ●Group Call After joining a group,press the PTT key,all members in the group can receive voice communication. Steps: Navigate to Main Menu→Groups→Select a Group,after the voice prompt confirms group entry,press the PTT key to speak from any interface,all members in the group can receive the message. ●Create Temporary Group Specify members to add to a temporary group (requires platform support). Steps: . Go to Main Menu→Create Temporary Group. . Select two or more members,then press the PTT key to create the temporary group. . Press the PTT key to initiate communication within the temporary group. . Members can exit the temporary group by pressing the Back key. .The creator can disband the temporary group by pressing the Back key,and all members exit automatically. Talk Rules When an active group call is initiated,other group members cannot receive any other incoming communications. Single Call:In the member list,select a member and press the confirm key to initiate a single call.During a single call,the two devices involved cannot be reached by any group call,cannot receive single calls from other members,and cannot form a temporary group. PTT Key Speak clearly into the microphone for best audio quality. Standby Indicator Green light blinks every s. Charging Status Red light during charging; Green light when fully charged. The complete machine part Technical Specifications: Network Product Size Operating Temperature Charging Temperature Mobile/Unicom/Telecom * * mm - °C- °C °C- °C We May Change The Specifications For Technical Improvement Without Prior Notice. Guarantee Model Number: Serial Number: Purchasing Date: Dealer: User’s Name: Country: Post Code: Remarks: .This guarantee card should be kept by the user,no replacement if lost. .The user can get warranty and after-sales service as below: ·Contact the seller where you buy. ·Products repaired by our local repair center .For warranty service,you will need to provide a receipt proof of purchase from the actual seller for verification Exclusions from Warranty Coverage: .To any product damaged by accident. .In the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs. .If the serial number has been altered,defaced,or removed. Telephone: Telephone: Address: Email: FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference including received interference that may cause undesired operation. The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. Replacement of any transmitter component (crystal, semiconductor, etc.) not authorized by the FCC equipment authorization for this radio could violate FCC rules. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can …
Text truncated - open the document above for the full version.
Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 43 of 47 Test_Graph_band5_846.5MHz_5M_QPSK_25RB#LOW_30M_1G_TX Test_Graph_band5_846.5MHz_5M_QPSK_25RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 44 of 47 Test_Graph_band5_829MHz_10M_QPSK_50RB#LOW_30M_1G_TX Test_Graph_band5_829MHz_10M_QPSK_50RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 45 of 47 Test_Graph_band5_836.5MHz_10M_QPSK_50RB#LOW_30M_1G_TX Test_Graph_band5_836.5MHz_10M_QPSK_50RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 46 of 47 Test_Graph_band5_844MHz_10M_QPSK_50RB#LOW_30M_1G_TX Test_Graph_band5_844MHz_10M_QPSK_50RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 47 of 47 Appendix E: Frequency stability Test Result Test Conditions (LTE Band 5(QPSK) /BW 10MHz) Frequency Range Frequency Error Verdict Temperature (°C) Voltage (Volt) >824 <849 Middle Channel Freq Reading @ Low End (MHz) Freq Reading @ High End (MHz) ≤2.5ppm 50 Normal Voltage 824.5939 848.4721 0.0065 PASS 40 Normal Voltage 824.5941 848.4721 0.0063 30 Normal Voltage 824.5941 848.4722 0.0070 20(Ref.) Normal Voltage 824.5940 848.4722 0.0070 10 Normal Voltage 824.5941 848.4722 0.0067 0 Normal Voltage 824.5940 848.4721 0.0067 -10 Normal Voltage 824.5940 848.4721 0.0068 -20 Normal Voltage 824.5940 848.4722 0.0066 -30 Normal Voltage 824.5940 848.4721 0.0060 20 +15% 824.5940 848.4721 0.0062 20 -15% 824.5941 848.4722 0.0061 20 Battery End Point 824.5940 848.4721 0.0061
Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 43 of 47 Test_Graph_band41_2506MHz_20M_QPSK_100RB#LOW_1G_10G_TX Test_Graph_band41_2506MHz_20M_QPSK_100RB#LOW_10G_26.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 44 of 47 Test_Graph_band41_2593MHz_20M_QPSK_100RB#LOW_30M_1G_TX Test_Graph_band41_2593MHz_20M_QPSK_100RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 45 of 47 Test_Graph_band41_2593MHz_20M_QPSK_100RB#LOW_10G_26.0G_TX Test_Graph_band41_2680MHz_20M_QPSK_100RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 46 of 47 Test_Graph_band41_2680MHz_20M_QPSK_100RB#LOW_1G_10G_TX Test_Graph_band41_2680MHz_20M_QPSK_100RB#LOW_10G_27.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 47 of 47 Appendix E: Frequency stability Test Result Test Conditions (LTE Band 41(QPSK) /BW 20MHz) Frequency Range Frequency Error Verdict Temperature (°C) Voltage (Volt) >2496 <2690 Middle Channel Freq Reading @ Low End (MHz) Freq Reading @ High End (MHz) ≤2.5ppm 50 Normal Voltage 2497.0094 2688.9801 0.0061 PASS 40 Normal Voltage 2497.0095 2688.9802 0.0066 30 Normal Voltage 2497.0096 2688.9803 0.0067 20(Ref.) Normal Voltage 2497.0095 2688.9801 0.0069 10 Normal Voltage 2497.0094 2688.9802 0.0068 0 Normal Voltage 2497.0094 2688.9802 0.0061 -10 Normal Voltage 2497.0095 2688.9802 0.0060 -20 Normal Voltage 2497.0095 2688.9802 0.0064 -30 Normal Voltage 2497.0095 2688.9803 0.0066 20 +15% 2497.0095 2688.9803 0.0068 20 -15% 2497.0094 2688.9803 0.0067 20 Battery End Point 2497.0094 2688.9802 0.0064
Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 1 of 73 Appendix Test Data for LTE band 66(Conducted Measurement) Product Name: 4G Poc Radio Trade Mark: N/A Test Model: N180 FCC ID: 2BQXTP360N Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: RF output power Test Result Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Average Power (dBm) Peak Power (dBm) PAR (dB) Limit (dB) AntGain (dBi) EIRP (dBm) Limit (dBm) Conclusion 66 1.4 1710.7 QPSK 6 LOW 22.41 27.81 5.40 13 0.66 23.07 33 Pass 66 1.4 1710.7 QPSK 3 LOW 23.32 28.26 4.94 13 0.66 23.98 33 Pass 66 1.4 1710.7 QPSK 3 MID 23.31 28.24 4.93 13 0.66 23.97 33 Pass 66 1.4 1710.7 QPSK 3 HIGH 23.42 28.4 4.98 13 0.66 24.08 33 Pass 66 1.4 1710.7 QPSK 1 LOW 23.32 28.13 4.81 13 0.66 23.98 33 Pass 66 1.4 1710.7 QPSK 1 MID 23.46 28.2 4.74 13 0.66 24.12 33 Pass 66 1.4 1710.7 QPSK 1 HIGH 23.52 28.32 4.80 13 0.66 24.18 33 Pass 66 1.4 1710.7 16QAM 6 LOW 21.56 28.15 6.59 13 0.66 22.22 33 Pass 66 1.4 1710.7 16QAM 3 LOW 22.4 28.26 5.86 13 0.66 23.06 33 Pass 66 1.4 1710.7 16QAM 3 MID 22.4 28.25 5.85 13 0.66 23.06 33 Pass 66 1.4 1710.7 16QAM 3 HIGH 22.51 28.29 5.78 13 0.66 23.17 33 Pass 66 1.4 1710.7 16QAM 1 LOW 22.62 27.85 5.23 13 0.66 23.28 33 Pass 66 1.4 1710.7 16QAM 1 MID 22.76 27.91 5.15 13 0.66 23.42 33 Pass 66 1.4 1710.7 16QAM 1 HIGH 22.7 27.99 5.29 13 0.66 23.36 33 Pass 66 1.4 1745 QPSK 6 LOW 22.39 28.05 5.66 13 0.66 23.05 33 Pass 66 1.4 1745 QPSK 3 LOW 23.31 27.67 4.36 13 0.66 23.97 33 Pass 66 1.4 1745 QPSK 3 MID 23.3 27.68 4.38 13 0.66 23.96 33 Pass 66 1.4 1745 QPSK 3 HIGH 23.37 27.8 4.43 13 0.66 24.03 33 Pass 66 1.4 1745 QPSK 1 LOW 23.31 27.34 4.03 13 0.66 23.97 33 Pass 66 1.4 1745 QPSK 1 MID 23.34 27.31 3.97 13 0.66 24 33 Pass 66 1.4 1745 QPSK 1 HIGH 23.32 27.34 4.02 13 0.66 23.98 33 Pass 66 1.4 1745 16QAM 6 LOW 21.51 27.49 5.98 13 0.66 22.17 33 Pass Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 2 of 73 Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Average Power (dBm) Peak Power (dBm) PAR (dB) Limit (dB) AntGain (dBi) EIRP (dBm) Limit (dBm) Conclusion 66 1.4 1745 16QAM 3 LOW 22.29 27.42 5.13 13 0.66 22.95 33 Pass 66 1.4 1745 16QAM 3 MID 22.28 27.42 5.14 13 0.66 22.94 33 Pass 66 1.4 1745 16QAM 3 HIGH 22.28 27.37 5.09 13 0.66 22.94 33 Pass 66 1.4 1745 16QAM 1 LOW 22.4 27.44 5.04 13 0.66 23.06 33 Pass 66 1.4 1745 16QAM 1 MID 22.47 27.39 4.92 13 0.66 23.13 33 Pass 66 1.4 1745 16QAM 1 HIGH 22.4 27.46 5.06 13 0.66 23.06 33 Pass 66 1.4 1779.3 QPSK 6 LOW 22.09 27.79 5.70 13 0.66 22.75 33 Pass 66 1.4 1779.3 QPSK 3 LOW 22.95 28.05 5.10 13 0.66 23.61 33 Pass 66 1.4 1779.3 QPSK 3 MID 22.94 28.03 5.09 13 0.66 23.6 33 Pass 66 1.4 1779.3 QPSK 3 HIGH 22.96 27.9 4.94 13 0.66 23.62 33 Pass 66 1.4 1779.3 QPSK 1 LOW 23.02 27.83 4.81 13 0.66 23.68 33 Pass 66 1.4 1779.3 QPSK 1 MID 22.94 27.72 4.78 13 0.66 23.6 33 Pass 66 1.4 1779.3 QPSK 1 HIGH 22.94 27.76 4.82 13 0.66 23.6 33 Pass 66 1.4 1779.3 16QAM 6 LOW 20.94 27.66 6.72 13 0.66 21.6 33 Pass 66 1.4 1779.3 16QAM 3 LOW 22 27.61 5.61 13 0.66 22.66 33 Pass 66 1.4 1779.3 16QAM 3 MID 22 27.62 5.62 13 0.66 22.66 33 Pass 66 1.4 1779.3 16QAM 3 HIGH 21.98 27.43 5.45 13 0.66 22.64 33 Pass 66 1.4 1779.3 16QAM 1 LOW 22.18 27.46 5.28 13 0.66 22.84 33 Pass 66 1.4 1779.3 16QAM 1 MID 22.26 27.35 5.09 13 0.66 22.92 33 Pass 66 1.4 1779.3 16QAM 1 HIGH 22.18 27.42 5.24 13 0.66 22.84 33 Pass 66 3 1711.5 QPSK 15 LOW 22.76 28.02 5.26 13 0.66 23.42 33 Pass 66 3 1711.5 QPSK 8 LOW 22.68 28.14 5.46 13 0.66 23.34 33 Pass 66 3 1711.5 QPSK 8 MID 22.67 28.07 5.40 13 0.66 23.33 33 Pass 66 3 1711.5 QPSK 8 HIGH 22.77 28.18 5.41 13 0.66 23.43 33 Pass 66 3 1711.5 QPSK 1 LOW 23.54 27.92 4.38 13 0.66 24.2 33 Pass 66 3 1711.5 QPSK 1 MID 23.76 28.2 4.44 13 0.66 24.42 33 Pass 66 3 1711.5 QPSK 1 HIGH 23.62 28.23 4.61 13 0.66 24.28 33 Pass 66 3 1711.5 16QAM 15 LOW 21.79 27.97 6.18 13 0.66 22.45 33 Pass 66 3 1711.5 16QAM 8 LOW 21.76 28.27 6.51 13 0.66 22.42 33 Pass 66 3 1711.5 16QAM 8 MID 21.76 28.26 6.5 13 0.66 22.42 33 Pass 66 3 1711.5 16QAM 8 HIGH 21.83 28.52 6.69 13 0.66 22.49 33 Pass 66 3 1711.5 16QAM 1 LOW 22.82 27.65 4.83 13 0.66 23.48 33 Pass 66 3 1711.5 16QAM 1 MID 23 27.84 4.84 13 0.66 23.66 33 Pass 66 3 1711.5 16QAM 1 HIGH 22.87 27.92 5.05 13 0.66 23.53 33 Pass 66 3 1745 QPSK 15 LOW 22.55 27.76 5.21 13 0.66 23.21 33 Pass 66 3 1745 QPSK 8 LOW 22.65 27.53 4.88 13 0.66 23.31 33 Pass 66 3 1745 QPSK 8 MID 22.65 27.45 4.80 13 0.66 23.31 33 Pass 66 3 1745 QPSK 8 HIGH 22.6 27.45 4.85 13 0.66 23.26 33 Pass 66 3 1745 QPSK 1 LOW 23.43 27.32 3.89 13 0.66 24.09 33 Pass 66 3 1745 QPSK 1 MID 23.42 27.27 3.85 13 0.66 24.08 33 Pass 66 3 1745 QPSK 1 HIGH 23.33 27.26 3.93 13 0.66 23.99 33 Pass Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 3 of 73 Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Average Power (dBm) Peak Power (dBm) PAR (dB) Limit (dB) AntGain (dBi) EIRP (dBm) Limit (dBm) Conclusion 66 3 1745 16QAM 15 LOW 21.46 28.39 6.93 13 0.66 22.12 33 Pass 66 3 1745 16QAM 8 LOW 21.55 27.37 5.82 13 0.66 22.21 33 Pass 66 3 1745 16QAM 8 MID 21.55 27.36 5.81 13 0.66 22.21 33 Pass 66 3 1745 16QAM 8 HIGH 21.61 27.19 5.58 13 0.66 22.27 33 Pass 66 3 1745 16QAM 1 LOW 22.46 27.42 4.96 13 0.66 23.12 33 Pass 66 3 1745 16QAM 1 MID 22.53 27.39 4.86 13 0.66 23.19 33 Pass 66 3 1745 16QAM 1 HIGH 22.4 27.36 4.96 13 0.66 23.06 33 Pass 66 3 1778.5 QPSK 15 LOW 22.15 27.9 5.75 13 0.66 22.81 33 Pass 66 3 1778.5 QPSK 8 LOW 22.15 27.56 5.41 13 0.66 22.81 33 Pass 66 3 1778.5 QPSK 8 MID 22.15 27.62 5.47 13 0.66 22.81 33 Pass 66 3 1778.5 QPSK 8 HIGH 22.1 27.5 5.40 13 0.66 22.76 33 Pass 66 3 1778.5 QPSK 1 LOW 23.06 27.91 4.85 13 0.66 23.72 33 Pass 66 3 1778.5 QPSK 1 MID 23.05 27.79 4.74 13 0.66 23.71 33 Pass 66 3 1778.5 QPSK 1 HIGH 22.89 27.65 4.76 13 0.66 23.55 33 Pass 66 3 1778.5 16QAM 15 LOW 20.96 27.42 6.46 13 0.66 21.62 33 Pass 66 3 1778.5 16QAM 8 LO…
Text truncated - open the document above for the full version.
Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 42 of 73 Test_Graph_band66_1720MHz_20M_16QAM_1RB#LOW_Band edge Test_Graph_band66_1720MHz_20M_QPSK_100RB#LOW_Band edge Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 43 of 73 Test_Graph_band66_1720MHz_20M_QPSK_1RB#LOW_Band edge Test_Graph_band66_1770MHz_20M_16QAM_1RB#HIGH_Band edge Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 44 of 73 Test_Graph_band66_1770MHz_20M_QPSK_100RB#LOW_Band edge Test_Graph_band66_1770MHz_20M_QPSK_1RB#HIGH_Band edge Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 45 of 73 Appendix D: Unwanted spurious emissions at antenna terminals Test Result Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Conclusion 66 1.4 1710.7 QPSK 6 LOW Pass 66 1.4 1745 QPSK 6 LOW Pass 66 1.4 1779.3 QPSK 6 LOW Pass 66 3 1711.5 QPSK 15 LOW Pass 66 3 1745 QPSK 15 LOW Pass 66 3 1778.5 QPSK 15 LOW Pass 66 5 1712.5 QPSK 25 LOW Pass 66 5 1745 QPSK 25 LOW Pass 66 5 1777.5 QPSK 25 LOW Pass 66 10 1715 QPSK 50 LOW Pass 66 10 1745 QPSK 50 LOW Pass 66 10 1775 QPSK 50 LOW Pass 66 15 1717.5 QPSK 75 LOW Pass 66 15 1745 QPSK 75 LOW Pass 66 15 1772.5 QPSK 75 LOW Pass 66 20 1720 QPSK 100 LOW Pass 66 20 1745 QPSK 100 LOW Pass 66 20 1770 QPSK 100 LOW Pass Note: Both QPSK and 16QAM modulation modes were tested. Since the QPSK mode produced the worst-case results, only the corresponding QPSK test results are included in this report. Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 46 of 73 Test Graphs Test_Graph_band66_1710.7MHz_1.4M_QPSK_6RB#LOW_30M_1G_TX Test_Graph_band66_1710.7MHz_1.4M_QPSK_6RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 47 of 73 Test_Graph_band66_1710.7MHz_1.4M_QPSK_6RB#LOW_10G_20.0G_TX Test_Graph_band66_1745MHz_1.4M_QPSK_6RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 48 of 73 Test_Graph_band66_1745MHz_1.4M_QPSK_6RB#LOW_1G_10G_TX Test_Graph_band66_1745MHz_1.4M_QPSK_6RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 49 of 73 Test_Graph_band66_1779.3MHz_1.4M_QPSK_6RB#LOW_30M_1G_TX Test_Graph_band66_1779.3MHz_1.4M_QPSK_6RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 50 of 73 Test_Graph_band66_1779.3MHz_1.4M_QPSK_6RB#LOW_10G_20.0G_TX Test_Graph_band66_1711.5MHz_3M_QPSK_15RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 51 of 73 Test_Graph_band66_1711.5MHz_3M_QPSK_15RB#LOW_1G_10G_TX Test_Graph_band66_1711.5MHz_3M_QPSK_15RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 52 of 73 Test_Graph_band66_1745MHz_3M_QPSK_15RB#LOW_30M_1G_TX Test_Graph_band66_1745MHz_3M_QPSK_15RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 53 of 73 Test_Graph_band66_1745MHz_3M_QPSK_15RB#LOW_10G_20.0G_TX Test_Graph_band66_1778.5MHz_3M_QPSK_15RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 54 of 73 Test_Graph_band66_1778.5MHz_3M_QPSK_15RB#LOW_1G_10G_TX Test_Graph_band66_1778.5MHz_3M_QPSK_15RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 55 of 73 Test_Graph_band66_1712.5MHz_5M_QPSK_25RB#LOW_30M_1G_TX Test_Graph_band66_1712.5MHz_5M_QPSK_25RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 56 of 73 Test_Graph_band66_1712.5MHz_5M_QPSK_25RB#LOW_10G_20.0G_TX Test_Graph_band66_1745MHz_5M_QPSK_25RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 57 of 73 Test_Graph_band66_1745MHz_5M_QPSK_25RB#LOW_1G_10G_TX Test_Graph_band66_1745MHz_5M_QPSK_25RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 58 of 73 Test_Graph_band66_1777.5MHz_5M_QPSK_25RB#LOW_30M_1G_TX Test_Graph_band66_1777.5MHz_5M_QPSK_25RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 59 of 73 Test_Graph_band66_1777.5MHz_5M_QPSK_25RB#LOW_10G_20.0G_TX Test_Graph_band66_1715MHz_10M_QPSK_50RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 60 of 73 Test_Graph_band66_1715MHz_10M_QPSK_50RB#LOW_1G_10G_TX Test_Graph_band66_1715MHz_10M_QPSK_50RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 61 of 73 Test_Graph_band66_1745MHz_10M_QPSK_50RB#LOW_30M_1G_TX Test_Graph_band66_1745MHz_10M_QPSK_50RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 62 of 73 Test_Graph_band66_1745MHz_10M_QPSK_50RB#LOW_10G_20.0G_TX Test_Graph_band66_1775MHz_10M_QPSK_50RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 63 of 73 Test_Graph_band66_1775MHz_10M_QPSK_50RB#LOW_1G_10G_TX Test_Graph_band66_1775MHz_10M_QPSK_50RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 64 of 73 Test_Graph_band66_1717.5MHz_15M_QPSK_75RB#LOW_30M_1G_TX Test_Graph_band66_1717.5MHz_15M_QPSK_75RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 65 of 73 Test_Graph_band66_1717.5MHz_15M_QPSK_75RB#LOW_10G_20.0G_TX Test_Graph_band66_1745MHz_15M_QPSK_75RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 66 of 73 Test_Graph_band66_1745MHz_15M_QPSK_75RB#LOW_1G_10G_TX Test_Graph_band66_1745MHz_15M_QPSK_75RB#LOW_10G_20.0G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 67 of 73 Test_Graph_band66_1772.5MHz_15M_QPSK_75RB#LOW_30M_1G_TX Test_Graph_band66_1772.5MHz_15M_QPSK_75RB#LOW_1G_10G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 68 of 73 Test_Graph_band66_1772.5MHz_15M_QPSK_75RB#LOW_10G_20.0G_TX Test_Graph_band66_1720MHz_20M_QPSK_100RB#LOW_30M_1G_TX Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 69 of 73 Test_Graph_band66_1720MHz_20M_QPSK_100RB#…
Text truncated - open the document above for the full version.
Report No.: TZ0414260401FRF10 Page 1 of 36 This publication may be reproduced, in whole or in part, for non-commercial purposes provided that Shenzhen Tongzhou Testing Co., Ltd. is acknowledged as the copyright holder and source. The laboratory assumes no liability for any consequences arising from the reader’s interpretation of reproduced material. This report is valid only for the specific sample(s) tested under the stated conditions. No part of the test results may be extracted or reproduced without written authorization from the laboratory. The test methods used in this report fully complied with the applicable standards without any deviation. TEST REPORT Report Number : TZ0414260401FRF10 Product Name : 4G Poc Radio Model/Type reference : N180, N188, N166, PN100, PN110, PN120, P10, P11, P12, FP200, FP210, FP220, MP218, MP228, MP238, DP160, DP168, DP166, SK250, SK240, SK230, RC200, RC208, RC218, C18, C19, C17, HK200, HK266, HK288 FCC ID : 2BQXTP360N Prepared for : Quanzhou UNIKOO Electronic Technology Co., Ltd. B1604,Building2, Xiamei Jiayuan Xiamei Town, Nan'an City Quanzhou, Fujian CHINA Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 22, FCC CFR Title 47 Part 24, FCC CFR Title 47 Part 27, ANSI C63.26:2015 Date of Test : 2026-04-24 ~ 2026-05-28 Date of Issue : 2026-05-29 Prepared by : Lena Wen Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0414260401FRF10 Page 2 of 36 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-05-29 Valid Initial release Report No.: TZ0414260401FRF10 Page 3 of 36 TABLE OF CONTENTS 1. S U M MARY ............................................................................ 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 5 1.4. Normal Accessory setting ...................................................................................................... 7 1.5. Related Submittal(s) / Grant (s) ............................................................................................. 7 1.6. Modifications ........................................................................................................................... 7 2. TE S T E N V I R O N M E N T ............................................................ 8 2.1. Test Facility ............................................................................................................................. 8 2.2. Measurement uncertainty ...................................................................................................... 8 3. S U M M A R Y O F T E S T R E S U L T S ................................................. 9 3.1. Environmental conditions .................................................................................................... 11 4. E Q U I P M E N T S U S E D D U R I N G T H E T E S T .................................... 12 5. T E S T CON D IT I ONS AND RESULTS .......................................... 13 5.1. Conducted Output Power / E.I.R.P / E.R.P / Peak-to-Average Ratio (PAR) ..................... 13 5.2. Occupied Bandwidth and Emission Bandwidth ................................................................ 15 5.3. Band Edge compliance ........................................................................................................ 16 5.4. Spurious Emission on Antenna Port .................................................................................. 19 5.5. Radiated Spurious Emssion ................................................................................................ 20 5.6. Frequency Stability under Temperature & Voltage Variations ......................................... 34 6. T E S T S E T U P P H O T O S O F T H E E U T ......................................... 36 7. E X T E R N A L P H O T O S O F T H E E U T ............................................ 36 8. INTERNAL P H O T O S OF T H E EUT .............................................. 36 Report No.: TZ0414260401FRF10 Page 4 of 36 1. S U M MARY 1.1. Client Information Applicant : Quanzhou UNIKOO Electronic Technology Co., Ltd. Address : B1604,Building2, Xiamei Jiayuan Xiamei Town, Nan'an City Quanzhou, Fujian CHINA Manufacturer : Quanzhou UNIKOO Electronic Technology Co., Ltd. Address : B1604,Building2, Xiamei Jiayuan Xiamei Town, Nan'an City Quanzhou, Fujian CHINA 1.2. Description of Device (EUT) Product Name : 4G Poc Radio Trade Mark : N/A Model Number : N180, N188, N166, PN100, PN110, PN120, P10, P11, P12, FP200, FP210, FP220, MP218, MP228, MP238, DP160, DP168, DP166, SK250, SK240, SK230, RC200, RC208, RC218, C18, C19, C17, HK200, HK266, HK288 Model Declaration : Identical electrical specifications and PCB boards, differing only in model name, and outer plastic shell. Test Model : N180 Power Supply : Input: DC 3.7V by battery or DC 5V by adapter Hardware version : V1.0 Software version : V1.0 Report No.: TZ0414260401FRF10 Page 5 of 36 1.3. Wireless Function Tested in this Report E-UTRA E-UTRA Operation Frequency : FDD Band 2 (UL: 1850 – 1910 MHz/DL: 1930 – 1990 MHz) FDD Band 4 (UL: 1710 – 1755 MHz/DL: 2110 – 2155 MHz) FDD Band 5 (UL: 824 – 849 MHz/DL: 869 – 894 MHz) FDD Band 7(UL: 2500 – 2570 MHz/DL:2620 – 2690 MHz) FDD Band 12 (UL: 699 – 716MHz/DL:729 – 746 MHz) FDD Band 13 (UL: 777 – 787 MHz/DL:746 – 756 MHz) FDD Band 17 (UL: 704 – 716 MHz/DL:734 – 746 MHz) TDD Band 38 (UL/DL: 2570 – 2620 MHz) TDD Band 40 (UL/DL pair1: 2305 – 2315 MHz; UL/DL pair2:2350 – 2360 MHz) TDD Band 41 (UL/DL: 2496 – 2690 MHz) FDD Band…
Text truncated - open the document above for the full version.
Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 1 of 73 Appendix Test Data for LTE band 2(Conducted Measurement) Product Name: 4G Poc Radio Trade Mark: N/A Test Model: N180 FCC ID: 2BQXTP360N Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: RF output power Test Result Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Average Power (dBm) Peak Power (dBm) PAR (dB) Limit (dB) AntGain (dBi) EIRP (dBm) Limit (dBm) Conclusion 2 1.4 1850.7 QPSK 6 LOW 22.05 27.99 5.94 13 0.56 22.61 33 Pass 2 1.4 1850.7 QPSK 3 LOW 22.87 28.5 5.63 13 0.56 23.43 33 Pass 2 1.4 1850.7 QPSK 3 MID 22.86 28.47 5.61 13 0.56 23.42 33 Pass 2 1.4 1850.7 QPSK 3 HIGH 23.03 28.58 5.55 13 0.56 23.59 33 Pass 2 1.4 1850.7 QPSK 1 LOW 22.87 27.7 4.83 13 0.56 23.43 33 Pass 2 1.4 1850.7 QPSK 1 MID 22.97 27.65 4.68 13 0.56 23.53 33 Pass 2 1.4 1850.7 QPSK 1 HIGH 22.91 27.72 4.81 13 0.56 23.47 33 Pass 2 1.4 1850.7 16QAM 6 LOW 21.02 27.73 6.71 13 0.56 21.58 33 Pass 2 1.4 1850.7 16QAM 3 LOW 22.07 28 5.93 13 0.56 22.63 33 Pass 2 1.4 1850.7 16QAM 3 MID 22.06 27.99 5.93 13 0.56 22.62 33 Pass 2 1.4 1850.7 16QAM 3 HIGH 22.3 28.21 5.91 13 0.56 22.86 33 Pass 2 1.4 1850.7 16QAM 1 LOW 22 27.73 5.73 13 0.56 22.56 33 Pass 2 1.4 1850.7 16QAM 1 MID 22.09 27.77 5.68 13 0.56 22.65 33 Pass 2 1.4 1850.7 16QAM 1 HIGH 22.12 27.86 5.74 13 0.56 22.68 33 Pass 2 1.4 1880 QPSK 6 LOW 21.8 27.75 5.95 13 0.56 22.36 33 Pass 2 1.4 1880 QPSK 3 LOW 22.72 28.08 5.36 13 0.56 23.28 33 Pass 2 1.4 1880 QPSK 3 MID 22.71 28.08 5.37 13 0.56 23.27 33 Pass 2 1.4 1880 QPSK 3 HIGH 22.74 28.26 5.52 13 0.56 23.30 33 Pass 2 1.4 1880 QPSK 1 LOW 22.71 27.99 5.28 13 0.56 23.27 33 Pass 2 1.4 1880 QPSK 1 MID 22.75 27.9 5.15 13 0.56 23.31 33 Pass 2 1.4 1880 QPSK 1 HIGH 22.79 28.01 5.22 13 0.56 23.35 33 Pass 2 1.4 1880 16QAM 6 LOW 20.9 27.54 6.64 13 0.56 21.46 33 Pass Shenzhen Tongzhou Testing Co., Ltd Report No.: TZ0414260401FRF10 Page 2 of 73 Band Bandwidth (MHz) UL Frequency (MHz) Modulation RB Size RB Offset Average Power (dBm) Peak Power (dBm) PAR (dB) Limit (dB) AntGain (dBi) EIRP (dBm) Limit (dBm) Conclusion 2 1.4 1880 16QAM 3 LOW 21.79 28.16 6.37 13 0.56 22.35 33 Pass 2 1.4 1880 16QAM 3 MID 21.79 28.17 6.38 13 0.56 22.35 33 Pass 2 1.4 1880 16QAM 3 HIGH 21.85 28.19 6.34 13 0.56 22.41 33 Pass 2 1.4 1880 16QAM 1 LOW 21.92 27.08 5.16 13 0.56 22.48 33 Pass 2 1.4 1880 16QAM 1 MID 21.99 27.06 5.07 13 0.56 22.55 33 Pass 2 1.4 1880 16QAM 1 HIGH 22.03 27.16 5.13 13 0.56 22.59 33 Pass 2 1.4 1909.3 QPSK 6 LOW 22.18 27.79 5.61 13 0.56 22.74 33 Pass 2 1.4 1909.3 QPSK 3 LOW 23.09 28.14 5.05 13 0.56 23.65 33 Pass 2 1.4 1909.3 QPSK 3 MID 23.08 28.15 5.07 13 0.56 23.64 33 Pass 2 1.4 1909.3 QPSK …
