2BQYL-HSA-01Outdoor Wall Light

BONTECKPRECISIONCO.,LTD. S U - S H I N , C H A N G P I N G , D O N G G U A N C I T Y, G U A N G D O N G TEL :86.769.83818660 FAX :86.769.83819660 E-MAIL :lew@ bonteck.com SPECIFICATION PIR MOTION SENSOR with remote controller MD. ES-220PS-RM （ ON/OFF ） FEATURES ---Only sensor used Test Mode +Auto ModeManual Override Test mode function:During the day or night, when motionstops, the light will turn off in about 5 seconds. The test mode has a period of 2minutes, and then automatically enters Auto mode. Auto Mode Function:At dusk, The light will stay ON as long as the motion is detected. when people leaving, the light will turn on for 2 minutes, and then turn off automatically. Switch the power switch three times in 5 seconds to restore the factory settings . 8hrs Auto re-set Manual Override or re-set by flipping the switch within 2". ---Sensor and remote control be used together Test Mode + Auto Mode + DTD mode + ON/OFF mode can be set by remote controller Test mode function:During the day or night, whenmotionstops, the light will turn off in about 5 seconds. Auto Mode Function:At dusk, The light will be turned ON with high brightness as long as the motion is detected. when people leaving, the light will turn on forthe predetermined time you set (1 minute to 10 minutesadjustable), and then turn off automatically. DTD mode Function:Turn on the light withhigh-level brightnessat dusk and turn off at dawn automatically. ON/OFF mode ： Turn on the light withhigh-level brightnessor turn off it by remote controller. Delay time can be set from 1 minute to 10 minutes by remote-controller in Auto Mode. Sensitivity can be set at L(3 meters) or M(6 meters) or H(9 meters) by remote controller. High brightness can be adjusted from 100% to 20%Cyclic regulationby remote-controller in ， Test mode or Auto mode or DTD Mode or ON/OFF mode by “Dim+” and “Dim-” button on remote-controller. Activating light levelcan be adjusted from 15lux to 300luxCyclic regulation,by “lux+” and “lux-” button on remote-controller. Activating light level can be set as required by “Learn” button on remote-controller Detection range ： Min.9M×220°detection rangefor wall use. Switch the power switch three times in 5 seconds or press the "Reset" button on the remote control to restore the factory settings, and enter the Auto mode2minutes,Sensitivity H(9meters), Activating light level50lux. Meet FCC requirements when fullbright （ @ON mode high brightness 100% ） TECHNICAL DATA DESCRIPTIONSSPECIFICATIONS Input power 120 VAC±10 ﹪ , 60Hz Load Rating Max.100WattsIncandescent;orMax60WdimmableLED bulb/LEDdriver;orMax60WdimmableFluorescent Detection angle 220°(wallinstallation) Mounting height Max.2.2m(forwalluse) Detect Range,(tangential) Min.9m@25°Cambienttemperature Delay time 1min/2min/3min.../10min@Remotecontrol 2min@factorysetting Detection sensitivity 100%(H)/60%(M)/30%(L)@Remotecontrol 100%@factorysetting Daylight sensor activate threshold (OFF-ON) 15LUX/50lux/100lux/200lux/300lux/Define@Remote control 50lux@factorysetting Daylight sensor(ON-OFF) Max.500LUX high brightness dimming level 100%/90%/80%/70%/60%/50%/40%/30%/20% Power Consumption Max. 0.5 Watt when stand-by Working Temp - 30°C ~ 50°C IPrating Wet location(Assembled into lighting) WIRING DIAGRAM & SIZE DWG REMOTE CONTROL FUNCTION File/ ES-220PS-RM （ ON/OFF ） V1.1 2025/07/28 Remote control settingButton Functiondescription Press the "ON /OFF" button, the light goes to constant on mode, sensor is disabled . Press "ON /OFF" button again to quit from this modeand the sensor starts to work. With memory for ON/OFF setting after power off, on mode will keep after restart power supply Press "Reset" button to restore all parameters to factory settings. Factory setting function: Sensor operates in "Auto" mode, Delay time is 2 minutes,and Daylight sensor activates light level is 50LUX, Sensitivity H(9meters). Press the "TEST" button can enter the test mode anytime .In the mode, during the day or night, when motion stops, the light will turn off in about 5 seconds. Press the "Auto" button, and the sensor can detect motion to control the light to works at night. Press the "DTD" button can enter the DTD mode, control the light to turn on with high-level brightness at dusk and turn off at dawn automatically Press the "Time-" button to set the delay time of Auto mode. Delay time is reduced by one minute each time, and the adjustment range is 10Min to 1Min. Press the "Time+" button to set the delay time of Auto mode. Delay time is increased by one minute each time, and the adjustment range is 1Min to 10Min. Press the "100%→20%→50%→100%" button to set the single-level brightness of 100%→20%→50%→100%. In TEST mode, Auto mode, DTD mode and ON mode, press the "Dim-" button to dim the brightness level by 10% at a time, and the adjustment range is 100% ~ 20%. In TEST mode, Auto mode, DTD mode and ON mode, press the "Dim+" button to brighten the brightness level by 10% at a time, and the adjustment range is 20% ~ 100%. Press the" L "button to set 30% sensitivity, and the sensing distance is 3m±1.5m. Press the" M "button to set 60% sensitivity, and the sensing distance is 6m±2m. Press the" H "button to set 100% sensitivity, and the sensingdistance is Min.9m. Press the "Lux-" button to Set up daylight sensor activates threshold： 300LUX→200LUX→100LUX→50LUX→15LUX。 Press the "Lux+" button to Set up daylight sensor activates threshold： 15LUX→50LUX→100LUX→200LUX→300LUX。 Press the "Learn" button for 3 seconds to automatically learn the ambient light currently detected by the daylight sensor as the activate threshold. When the ambient light is lower than this threshold, the sensor will start working, and when it is higher than this threshold, the sensor will stop working. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including int…

Text truncated - open the document above for the full version.

Zhongshan Hansson Lighting Technology Co.,Ltd. Covered Equipment Certification Attestation Letter 5/22/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BQYL-HSA-01 Zhongshan Hansson Lighting Technology Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Zhongshan Hansson Lighting Technology Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Zhongshan Hansson Lighting Technology Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Patrick Huang Title: Manager Company Name: Zhongshan Hansson Lighting Technology Co.,Ltd. Date: 5/22/2026

Zhongshan Hansson Lighting Technology Co.,Ltd. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: May 22, 2026 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BQYL-HSA-01 Zhongshan Hansson Lighting Technology Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Company Name: Zhongshan Hansson Lighting Technology Co.,Ltd. FRN: 0037301389 Address: No.2,Fuqing 3rd Road,Yongxing Industrial Zone, Henglan Town, Zhongshan,Guangdong, China Signature: Contact Person: Patrick Huang Tel: 13927773871 Email: [email protected]

DATE: May 22, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen CCUT Quality Technology Co., Ltd. (1F, Building 35, Changxing Technology Indstrl Park Changzhen Community, Yutang Street, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Zhongshan Hansson Lighting Technology Co.,Ltd. (No.2,Fuqing 3rd Road,Yongxing Industrial Zone, Henglan Town, Zhongshan,Guangdong, China). <Signature> Name: Patrick Huang Title: Manager Company: Zhongshan Hansson Lighting Technology Co.,Ltd.

Date: May 22, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Patrick Huang Title: Manager Company: Zhongshan Hansson Lighting Technology Co.,Ltd.

DATE: May 22, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BQYL-HSA-01 Product Name: Outdoor Wall Light Product Model: HSA-01, yx-101-B-B1, yx-101-RC-B1, yx-101-RC-B2, FD-HWD-01, FD-HWD-02, yx-101-B-B2, FD-HWD-B01, FD-HWD-B02 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Patrick Huang Title: Manager Company: Zhongshan Hansson Lighting Technology Co.,Ltd.

Zhongshan Hansson Lighting Technology Co.,Ltd. Model Difference Statement FCC ID: 2BQYL-HSA-01 DATE: May 22, 2026 Dear Sir/Madam, Added models yx-101-B-B1, yx-101-RC-B1, yx-101-RC-B2, FD-HWD-01, FD-HWD-02, yx-101-B-B2, FD-HWD-B01, FD-HWD-B02 basis of the original product HSA-01. The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, Name: Patrick Huang Company name: Zhongshan Hansson Lighting Technology Co.,Ltd. Address: No.2, Fuqing 3rd Road, Yongxing Industrial Zone, Henglan Town, Zhongshan, Guangdong, China

Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report Annex A. EUT External Photos Model: HSA-01 EUT View 1 EUT View 2 Just the infrared function Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT View 3 EUT View 4 Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT View 5 EUT View 6 Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT View 7

Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report Annex D. Label and Information FCC Label Sample FCC Labe Size: 14cm* 7cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report Annex B. EUT Internal Photos Model: HSA-01 EUT Internal View 1 EUT Internal View 2 Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT Internal View 3 EUT Internal View 4 Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT Internal View 5 EUT Internal View 6 Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report EUT Internal View 7 EUT Internal View 8

Report No: SSP26050330-1E EMC Test Report Page 1 of 14 EMC TEST REPORT FCC ID: 2BQYL-HSA-01 Report No. : SSP26050330-1E Applicant : Zhongshan Hansson Lighting Technology Co.,Ltd. Product Name : Outdoor Wall Light Model Name : HSA-01 Test Standard : FCC Part 15 Subpart B Date of Issue : 2026-05-22 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP26050330-1E EMC Test Report Page 2 of 14 Test Report Basic Information Applicant..................................: Zhongshan Hansson Lighting Technology Co.,Ltd. Address of Applicant...............: No.2, Fuqing 3rd Road, Yongxing Industrial Zone, Henglan Town, Zhongshan, Guangdong, China Manufacturer..........................: Zhongshan Hansson Lighting Technology Co.,Ltd. Address of Manufacturer........: No.2, Fuqing 3rd Road, Yongxing Industrial Zone, Henglan Town, Zhongshan, Guangdong, China Product Name.........................: Outdoor Wall Light Brand Name.............................: - Main Model..............................: HSA-01 Series Models..........................: yx-101-B-B1, yx-101-RC-B1, yx-101-RC-B2, FD-HWD-01, FD-HWD-02, yx-101-B-B2, FD-HWD-B01, FD-HWD-B02 Test Standard..........................: FCC Part 15 Subpart B ANSI C63.4-2014 Date of Test .............................: 2026-05-19 to 2026-05-21 Test Result...............................: PASS Tested By ................................: (Walker Wu) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP26050330-1E EMC Test Report Page 3 of 14 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................5 1.3 Compliance Standards ...........................................................................................................................................6 1.4 Test Facilities ........................................................................................................................................................6 1.5 Measurement Uncertainty .....................................................................................................................................6 1.6 List of Test and Measurement Instruments ............................................................................................................7 2. Summary of Test Results .............................................................................................................................................8 3. Conducted Emissions ..................................................................................................................................................9 3.1 Standard and Limit................................................................................................................................................9 3.2 Test Procedure......................................................................................................................................................9 3.3 Test Data and Results ............................................................................................................................................9 4. Radiated Disturbance ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 12 Report No: SSP26050330-1E EMC Test Report Page 4 of 14 Revision History Revision Issue Date Description Revised By V1.0 2026-05-22 Initial Release Lahm Peng Report No: SSP26050330-1E EMC Test Report Page 5 of 14 1. General Inf ormation 1.1 Product Information Product Name: Outdoor Wall Light Trade Name: - Main Model: HSA-01 Series Models: yx-101-B-B1, yx-101-RC-B1, yx-101-RC-B2, FD-HWD-01, FD-HWD-02, yx-101-B-B2, FD-HWD-B01, FD-HWD-B02 Test Sample No: SSP26050330-1 Class of Equipment: Class A Class B Highest Internal Frequency: <108MHz Rated Voltage: Input: AC 120V/60Hz Note 1: The test data is gathered from a production sample, provided by the manufacturer. Note 2: The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. 1.2 Test Setup Information List of Test Modes Test Mode Description Remark TM1 Operating AC 120V/60Hz - - - List and Details of Auxiliary Cable Description Length (cm) Shielded/Unshielded With/Without Ferrite - - - - - - - - - - - - List and Details of Auxili…

Text truncated - open the document above for the full version.

Report No: SSP26050330-1E FCC ID: 2BQYL-HSA-01 Annex of Test Report Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View 1
