www.softwincn.com 使用说明书 GPD WIN 5 GPD微信公众号 GPD微博公众号 十字方向键.2 D-Pad.2 十字ボタン.2 Menu键.8 Menu Button.8 Menu ボタン.8 挂绳孔.7 Lanyard Hole.7 ストラップホール.7 左电容摇杆.1 1.Left Capacitive Joystick.1 1.左キャパシティブジョイスティック.1 “当前窗口/桌面”切换键.4 "Current Window/Desktop" Toggle Button.4 「現在のウィンドウ/デスクトップ」切り替えキー.4 电源键/指纹解锁.5 Power Button / Fingerprint Unlock.5 電源ボタン / 指紋認証.5 6.扬声器 6.Speaker 6.スピーカー Back键.3 Back Button.3 Backボタン.3 17.“手柄/鼠标”切换键 17.Controller/Mouse Toggle Switch 17.コントローラー/マウス切り替えボタン 22.光学手指鼠标 22.Optical Finger Mouse 22.光学式指紋マウス 20.右电容摇杆 20.Right Analog Stick (Capacitive) 20.右アナログスティック(キャパシティブ式) 21.Start 键 21.Start Button 21.スタートボタン 25.“屏幕键盘”显示/隐藏键 25."Screen Keyboard" Show/Hide Button 25.「スクリーンキーボード」 の表示/非表示ボタン 18.ABXY 键 18.ABXY Button 18.ABXY ボタン 23.音量键 23.Volume Buttons 23.音量ボタン 12.“霍尔/微动”扳机切换键 12.Hall Effect/Microswitch Trigger Mode Toggle 12.ホールトリガー/スイッチトリガー切り替えキー 11.自定义背键 L4 / R4 11.Customizable Back Button L4 / R4 11.カスタム背面ボタン L4 / R4 28.电池固定卡槽 28.Battery Retention Slot 28.電池固定用スロット 27.进风口 27.Air Inlet 27.きょうせつよう きゅうきこう 26.电池插槽 26.Battery Slot 26.バッテリースロット 19.microSD 读卡器 19.microSD Card Reader 19.microSDカードリーダー 13.出风口 13.Exhaust Vent 13.排気口 15.耳机/麦克风二合一端口 15.Headset/Microphone Combo Port 15.ヘッドセット/マイク兼用ポート 14.霍尔扳机键 14.Hall-effect Trigger 14.ホールトリガーボタン 16.USB 3.2 Gen2 Type A30.USB4 31.DC 电源端口 (5525) 31.DC Power Port (5.5×2.5mm) 31.DC電源ポート (5.5×2.5mm) 29.BIOS复位孔 29.BIOS Reset Hole 29.BIOSリセットホール 9.麦克风口 9.Mic Port 9.マイク 10.USB 3.2 Gen2 Type C24.Mini SSD 卡槽 (1517) 24.Mini SSD Slot (1517) 24.ミニSSDスロット (1517) 端口及功能键说明 2 左电容摇杆1 可在手柄和鼠标两种状态之间切换。 当切换手柄模式时，左摇杆被激活。当切换到鼠标模式 时，手柄功能失效，此时，左摇杆模拟器键盘的 W、A、 S、D 键。 十字方向键 连体式方向键。 当切换为鼠标模式时，方向键的左、右键为键盘的 Home 和 End 键。 3 Back 键 手柄的 Back（Select）键。 当切换到鼠标模式下，Back 键是 Esc 键。 4 “当前窗口/桌面” 切换键 仅限于在当前窗口和桌面之间切换。 在 Windows 系统下，它是 “Win+D” 的组合键，手柄和鼠 标模式下均有效。在开机时，它可用于“一键还原”系统。 5 电源键/指纹解锁 红灯 / 绿灯 / 白灯三种显示状态，且支持 Windows Hello 指 纹身份验证。 插上电源适配器亮红灯（在没有电池和关机状态），充满 亮绿灯，拆掉电池亮白灯；断开电源适配器，开机亮白灯 睡眠状态白色呼吸灯效果，关机灯灭。若中途断开电源适 配器，则切换回无适配器状态。关于电源指示灯状态请参 考后面的《电源指示灯状态对应表》。 端口及功能键说明 扬声器6 内置的超线性扬声器，用于声音输出。 双扬声器，环绕立体声，支持 DTS: X Ultra 全景音效。 7 挂绳孔 可搭配胸牌挂绳、手机挂绳，方便随身携带防丢失，在发生 意外状况时防止跌落。 8 Menu 键 360 手柄的 Xbox 键。 在串流 Xbox 游戏时，Xbox 键除作为手柄开关，还起到 “回到主页”、“长按关机”、“截屏录像”、“贴靠切换”等功能。 在 SteamOS 系统（如：Bazzite）的手柄模式下， “Menu+A” 组合键可以呼出电源控制面板。 9 麦克风口独立的麦克风口。 10 USB 3.2 Gen2 Type C 10Gbps 速率。 非全功能端口，带有 DisplayPort 2.1，仅支持影音和数据 传输，不支持充电。 11自定义背键 L4 / R4 可映射、可编程按键 通过系统内整合的 “WinControls” 工具，将键盘任意按键 或组合键映射到 L4 / R4。 端口及功能键说明 “霍尔/微动”扳机 切换键 12 在霍尔扳机与微动扳机之间切换。 LT、RT 带有 “长 / 短行程” 双模式切换开关，长行程支持 256 阶（0 ~ 255），短行程支持 2 阶（0 或 255），更适 合动作 / 格斗游戏。 热风排出。 LT、RT 采用霍尔扳机键，0.1mm 级精度，丝滑无磨损，电 磁感应零延迟，千万次寿命。 适合赛车、模拟、射击等场景，如是动作和格斗游戏， 建议切换到微动扳机状态。 13出风口 3.5mm 耳机麦克风二合一端口，兼容苹果耳机（美规），支 持 DTS: X Ultra 全景音效。 10Gbps速率。 耳机/麦克风二合 一端口 14 霍尔扳机键 15 16 USB 3.2 Gen2 Type A 在手柄与鼠标之间物理切换。 当切换到鼠标模式，右摇杆模拟鼠标，右摇杆 +RT 键组 合，可实现鼠标加速。 17“手柄/鼠标”切换键 ABXY（硅胶按键）、△○×□双字符丝印。 当切换到鼠标模式， XYBA 为键盘的 键。 18ABXY 键 端口及功能键说明 microSD 读卡器19 兼容 microSDHD、microSDXC 闪存卡。 总线端口：UHS-I，视频速度等级：V30，I/O 性能：A2， 理论速度：读 160MB/s，写 120MB/s。 可在手柄和鼠标两种状态之间切换。 当切换手柄模式时，右摇杆被激活。当切换到鼠标模式时 手柄功能失效，此时，右摇杆可模拟鼠标。RT+右摇杆实 现鼠标加速。右摇杆下压对应键盘的 “Enter” 键。 Start 键 20 右电容摇杆 21 控制扬声器的音量大小。23 音量键 手柄的 Start 键。 当切换到鼠标模式时，Start 键可模拟键盘的 “Delete” 键。 这通常用于开机时进入 BIOS。 光学手指鼠标22 是一种红外鼠标。 作为鼠标功能，支持手指滑动将鼠标移至目标位置，也支 持下压确认。 一种全新的闪存卡连接端口。 Mini SSD 卡由佰维科技研发，但并未上市，主因是在 WIN 5之前，并没有第三方设备整合这种卡槽。WIN 5 是 全球首整合了 Mini SSD 卡槽的产品。Mini SSD 卡也会在 WIN 5 正式上市后由 GPD 官方店铺销售。 24 Mini SSD 卡槽 （1517） 端口及功能键说明 “屏幕键盘”显示/ 隐藏键 25 用于显示或隐藏屏幕键盘。 相当于组合键 “Ctrl + Win + O”，方便通过屏幕输入。它 同时也可作为开机进入 BIOS 的按键，而无需开机切换鼠 标模式再通过按 Start 键进入。 电池插槽26用于连接背挂电池或电池延长线。 进风口27冷风进入。 电池固定卡槽28用于电池卡扣部位卡住机身两侧。 端口及功能键说明 DC 电源端口 （5525） 31 用于连接 180w DC 电源。 180w DC 电源能满足给主板供电的同时给背挂或延长线 连接的电池充电，移除电池对设备的开机、关机、待机、 满载状态没有任何影响，满载状态 CPU 封装功耗在 70W 左右，GPD 推荐用此方式给设备供电。 BIOS 复位孔29 支持 RTC、CPU、EC 全部复位。 当死机等异常状态后，按复位按键，保证机器断电关机， 再按开机按键可以正常开机。BIOS 复位后，再次开机会 加电自检并黑屏一段时间，请保持电池电量充足或充电 状态。 USB430 40Gbps 速率。 带有 PD 快充协议 & DisplayPort 2.1，最高支持 100w （20V==5A）PD协议快充。但其输出功率不足以保证在 设备缺少背挂电池时能够开机，必须安装背挂电池才能开 机。当进入系统后，100w PD 协议快充或同等规格移动电 源可以满足给主板供电的同时给电池充电，满载状态 CPU 封装功耗在 45W 左右，同时也能保证开机状态下更换第 二块电池。 外置聚合物锂电池需要首先背挂在设备上。使用随机附带的 DC 电源适配器和 充电线缆连接到电源插座，机身的电源键指示灯亮红灯表示电池正在充电，充 满灯变绿色。设备关机或处于睡眠状态时，电池充电速度更快。 使用电源适配器为设备充电 电源指示灯状态对应表 给设备充电充电注意事项 请使用设备随附的电源适配器和线缆充电。 使用第三方配件可能导致设备性能下降，且有可能存在安全隐患。 请在适宜的温度范围内和通风良好的阴凉区域为设备充电。 在高温环境下充电可能会损坏设备。 设备充电时间会随温度条件和电池使用状况而变化。 设备长时间工作和充电时，可能会表面发热，这属于正常现象。感觉发 烫时，请关闭部分功能并停止充电。 了解电池状态 您可以通过屏幕上的电量图标判断当前的电池状态。 当设备接入电源时， 电池图标会显示已连接状态。 当设备使用时，移动光标至 电池图标上，可查看电池的剩余电量和剩 余使用时间。 电池属于易损耗品，如发现待机时间大幅度减少，请勿自行拆换，请联 系购买店铺客服购买原装电池。 设备状态电源适配器电池电量（=100%）电池电量（＜100%）红灯 绿灯 白灯 熄灭 呼吸灯效果 关机 关机 关机 关机 开机 开机 开机 开机 睡眠 睡眠 睡眠 “一键还原” 是将系统还原到设备的出厂状态，它并非 Windows 提供的重置功能。 Windows 重置时间漫长，几乎解决不了什么问题，还会将整合的第三方驱动全部 移除，重置后仍然要安装官方提供的驱动包。 “一键还原” 的系统镜像保存在 SSD 的隐藏分区，非人为操作通常不会破坏隐藏分 区的镜像。但如用户安装原版镜像、或通过第三方 WINPE 工具写入镜像，可能会 破坏 EFI 分区的引导数据或移除隐藏分区，导致无法还原。 “一键还原” 方式有两种： 机身按键方式：开机后长按 “当前窗口/桌面” 切换键，进入 “系统还原” 窗口，根 据提示操作，可将系统还原到出厂状态。 外接键盘方式：开机后按 Tab 键，进入 “系统还原” 窗口，根据提示操作，可将系 统还原到出厂状态。 如果系统还原镜像被破坏，可登录 GPD 官网： 中文官网：softwincn.com 英文官网：gpd.hk 点击官网顶部的 “固件” 或 “Download” 页面，找到产品对应的固件下载页面，下 载官方提供的系统镜像，并根据操作说明安装即可，官方提供的系统镜像在恢复 系统后，同样会将镜像写入隐藏分区，以供之后“一键还原”，因此无需用户每次 都下载镜像安装。 如何“一键还原”系统？ 首次开机时，请先连接电源适配器和充电线缆为设备充电。 设设备关机或睡眠时，短按电源键至屏幕亮起，即可开启或唤醒设备。 设备正常使用时，点击 > < 使设备进入睡眠、关机或重启的状态。 长按电源键7~8秒，可强制关闭设备。强制关机时，未保存的数据可能 会丢失。 开启和关闭设备 “手柄/鼠标”模式，各功能键对应表 手柄模式鼠标模式 右摇杆鼠标 右摇杆+RT 键鼠标加速 右摇杆下压Enter 键 左摇杆键盘的 W、A、S、D 键 左摇杆下压键盘的 Spacebar 键 单击 LB 键鼠标左键单击 双击 LB 键鼠标左键双击 单击 RB 键鼠标右键单击 十字方向键左、右方向是键盘的 Home 和 End 键 Back（Select）键键盘的 Esc 键 Start 键键盘的 Delete 键 X, Y, B, A键盘的 键 1.没有键盘的情况下，保证在“鼠标模式”下开机，同时按住“屏幕键盘”显示/隐藏键。 2.连接键盘的情况下，开机按住 Delete 键，可进入 BIOS。 如何进入 BIOS？ “鼠标模式” 下，开机进入 BIOS，在 Main 页面，选择 Battery Full Charge Settings， 右摇杆下压展开列表项，这里提供了 “60~100” 五个选项，选择哪一个，就代表充 电到设置的阈值即停止给电池充电。用 Back 键可取消选择并退出下拉列表。 如何调整电池充电阈值？ 在 “鼠标模式” 下，操作步骤如下： 1.开机进入 BIOS，使用 X/B 键切换至 Advanced 签页。 2.通过 Y/A 键 选择，右摇杆下压进入下一层目录。 3.依次导航至：AMD CBS → SUM Comon Option → System Configuration TDP设置选项� 默认模式： System Configuration 提供预设 TDP 范围（45W~120W），默认值为 Auto。 超低 TDP 手动配置： 1.将 PPT Control 设为 Manual。 2.调整以下两项参数（需外接键盘直接输入数值）： � Slow PPT Limit：长期稳定功耗（如10W，输…
