2BR3XIPC101-A02-A02Android All-in-one Panel PC

FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. user Instructions Industrial all-in-one Touch Pcs series Industrial all-in-one Touch PCs Overview Industrial all-in-one Touch PCs Maintenance Industrial all-in-one Touch PCs Common Troubleshooting Industria I a II-in-one Touch Pcs series cataIogue of industria I a II-in-one Touch Pcs 03 04 05 06 06 07 09 1 ! Important Notice 2 Transportation and After-sales Warranty 3 Industrial all-in-one Touch PCs Overview 4 Comprehensive Customized Service 5 Industrial all-in-one Touch PCs Maintenance and Repair 6 Industrial X86 all-in-one PC Common Troubleshooting 7 Industrial ARM all-in-one PC Common Troubleshooting 02 Thank you for purchasing the industrial all-in-one touch pc produced by our company! Please read the contents of the instruction carefully before using this product, it contains important information and precautions related to the use of industrial all-in-one touch pc . Our company is committed to continuous technological innovation and performance upgrading, the contents of the instruction and the specifications of this product are subject to change without further explanation . Thank you for your understanding! This product needs professional maintenance, please contact us in time if it is damaged! To ensure proper use of this product, please keep this instruction for reference. For users: 1 ! Important Note (1) Do not place the all-in-one pc in an unstable and easily falling place. (2) Avoid directly exposing the all-in-one pc to sunlight or other heat sources . (3) During thunderstorm weather (especially when there is lightning), please unplug the power supply and antenna . (4) Please do not step on the power cord and entangle it . ( 5 ) The working power of this machine is AC 100V-24 0V , please make sure the grounding wire is good when installing, and avoid connecting the same power plug with high-power electrical equipment. (6) Avoid overloading the external connection socket on the wall to avoid fire or electric shock . (7) Please wipe the all-in-one pc with a dry, soft cloth (free of volatile substances) . (8) Please avoid contact or exposure of the all-in-one pc to inappropriate temperature, solvent, acid , alkali, and humid environment . (9) Avoid products or components (such as housings, LED screens, interfaces, component circuits, etc.) from being broken, rusted, damaged, etc. caused by insect bites or foreign body intrusion . (10) Do not entrust an authorized institutions by none of our company to repair, add or disassemble this product . (11) Please install it under the guidance of professionals and a suitable location (12) If you don't use this product for a long time, please unplug it. (13) Do not use accessories that are not specially designed for this all- in -one pc. (1) Usage environment 2 Transportation and After-saIes warranty In order to ensure that you receive the goods in good condition, when receiving the goods, please open the box with the carrier face to face inspection, to confirm that the products are not transportation damage and missing before signing. If there is any transportation damage or loss, please do not sign for the goods and keep the goods, packaging materials and accessories intact and contact us immediately. If you have no objection to the product within the day of receipt, it will be regarded as acceptance, and our company will not bear the responsibility for the damage of the goods (unless otherwise agreed in the contract) . After opening the package, in addition to the industrial all-in-one touch pc, please make sure there are the following accessories in the box . Power adapter *1 Power connection cable *1 Installation Accessories *1 Product instruction *1 Warranty card *1 The warranty period of the product is calculated from the date of purchase, and the warranty period is three years. The first year's warranty is free of charge, and the following two years need to charge for repair. During the first year warranty period, if the product fails to work properly due t…

Text truncated - open the document above for the full version.

Page 1 of 16 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EF Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation For Shenzhen Touch Think Intelligence Co.,Ltd. Android All-in-one Panel PC Test Model: IPC101-A02-A02 Additional Model No.: Please Refer to Page 6 Prepared for : Shenzhen Touch Think Intelligence Co.,Ltd. Address : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : August 07, 2025 Number of tested samples : 2 Sample No. : C250801012-1, C250801012-2 Serial number : Prototype Date of Test : August 07, 2025 ~ September 03, 2025 Date of Report : September 04, 2025 Page 2 of 16 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EF Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation Report Reference No. ................. : LCSC08015015EF Date of Issue ................................... : September 04, 2025 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address ........................................... : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address ........................................... : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Test Specification Standard ......................................... : FCC KDB publication 447498 D01 General RF Exposure Guidance v06 FCC CFR 47 part1 1.1310 FCC CFR 47 part2 2.1091 Test Report Form No. ................... : TRF-4-E-214 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : Android All-in-one Panel PC Trade Mark ...................................... : Shenzhen Touch Think Intelligence Co.,Ltd. Test Model ...................................... : IPC101-A02-A02 Ratings ............................................ : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Supervised by: Approved by: Lifeng Le / File administrators Justin Zhu / Technique Director Gavin Liang/ Manager Page 3 of 16 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EF Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC08015015EF September 04, 2025 Date of issue EUT......................................... : Android All-in-one Panel PC Test Model............................... : IPC101-A02-A02 Applicant............................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address.................................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Shenzhen Touch Think Intelligence Co.,Ltd. Address................................... : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone............................... : / Fax.......................................... : / Factory................................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address................................... : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone............................... : / Fax.......................................... : / Page 4 of 16 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EF Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 September 04, 2025 Initial Issue -- Page 5 of 16 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EF Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng N…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID:2BR3XIPC101-A02-A02 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 Page 2 of 2 FCC ID:2BR3XIPC101-A02-A02 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3

Page 1 of 35 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Shenzhen Touch Think Intelligence Co.,Ltd. Android All-in-one Panel PC Test Model: IPC101-A02-A02 Additional Model No.: Please Refer to Page 6 Prepared for : Shenzhen Touch Think Intelligence Co.,Ltd. Address : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : August 07, 2025 Number of tested samples : 2 Sample No. : C250801012-1, C250801012-2 Serial number : Prototype Date of Test : August 07, 2025 ~ September 03, 2025 Date of Report : September 04, 2025 Page 2 of 35 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSC08015015EB Date of Issue .................................. : September 04, 2025 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address .......................................... : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address .......................................... : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No.................... : TRF-4-E-145 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Android All-in-one Panel PC Trade Mark ..................................... : Shenzhen Touch Think Intelligence Co.,Ltd. Test Model ...................................... : IPC101-A02-A02 Ratings ........................................... : Please Refer to Page 6 Result ............................................ : PASS Compiled by: Supervised by: Approved by: Lifeng Le / File administrators Justin Zhu / Technique Director Gavin Liang/ Manager Page 3 of 35 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Model.......................... : IPC101-A02-A02 EUT.................................... : Android All-in-one Panel PC Applicant........................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Manufacturer..................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Factory.............................. : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC08015015EB September 04, 2025 Date of issue Page 4 of 35 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 September 04, 2025 Initial Issue --- Page 5 of 35 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.co…

Text truncated - open the document above for the full version.

Page 1 of 40 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Shenzhen Touch Think Intelligence Co.,Ltd. Android All-in-one Panel PC Test Model: IPC101-A02-A02 Additional Model No.: Please Refer to Page 6 Prepared for : Shenzhen Touch Think Intelligence Co.,Ltd. Address : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : August 07, 2025 Number of tested samples : 2 Sample number : C250801012-1, C250801012-2 Serial number : Prototype Date of Test : August 07, 2025 ~ September 03, 2025 Date of Report : September 04, 2025 Page 2 of 40 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSC08015015EC Date of Issue .................................. : September 04, 2025 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address .......................................... : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address .......................................... : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No. .................. : TRF-4-E-147 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Android All-in-one Panel PC Trade Mark ..................................... : Shenzhen Touch Think Intelligence Co.,Ltd. Test Model ...................................... : IPC101-A02-A02 Ratings ........................................... : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Supervised by: Approved by: Lifeng Le / File administrators Justin Zhu / Technique Director Gavin Liang/ Manager Page 3 of 40 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Model.......................... : IPC101-A02-A02 EUT.................................... : Android All-in-one Panel PC Applicant........................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Manufacturer..................... : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Factory.............................. : Shenzhen Touch Think Intelligence Co.,Ltd. Address.............................. : Building 4, XinJianXing Industrial Park, Yangguang second road, Xili Subdistrict, Nanshan District, Shenzhen City, Guangdong Province, China Telephone.......................... : / Fax..................................... : / Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC08015015EC September 04, 2025 Date of issue Page 4 of 40 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 September 04, 2025 Initial Issue --- Page 5 of 40 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.c…

Text truncated - open the document above for the full version.

Page 90 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs Restrict Band NVNT b 2412MHz Ant1 Peak Restrict Band NVNT b 2412MHz Ant1 Average Page 91 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT b 2462MHz Ant1 Peak Restrict Band NVNT b 2462MHz Ant1 Average Page 92 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT g 2412MHz Ant1 Peak Restrict Band NVNT g 2412MHz Ant1 Average Page 93 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT g 2462MHz Ant1 Peak Restrict Band NVNT g 2462MHz Ant1 Average Page 94 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT n20 2412MHz Ant1 Peak Restrict Band NVNT n20 2412MHz Ant1 Average Page 95 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT n20 2462MHz Ant1 Peak Restrict Band NVNT n20 2462MHz Ant1 Average Page 96 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT n40 2422MHz Ant1 Peak Restrict Band NVNT n40 2422MHz Ant1 Average Page 97 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Restrict Band NVNT n40 2452MHz Ant1 Peak Restrict Band NVNT n40 2452MHz Ant1 Average Page 98 of 108 FCC ID:2BR3XIPC101-A02-A02 Report No.: LCSC08015015EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Condition Mode Frequency (MHz) Antenna Spur Freq (MHz) Power (dBm) Gain (dBi) Duty Factor (dB) E (dBuV/m) Detector Limit (dBuV/m) Verdict NVNT b 2412 Ant2 2310 -50.32 2.95 - 47.89 Peak 74 Pass NVNT b 2412 Ant2 2310 -58.59 2.95 0 39.62 Average 54 Pass NVNT b 2412 Ant2 2327.55 -46.94 2.95 - 51.27 Peak 74 Pass NVNT b 2412 Ant2 2388.741 -55.25 2.95 0 42.96 Average 54 Pass NVNT b 2412 Ant2 2390 -47.38 2.95 - 50.83 Peak 74 Pass NVNT b 2412 Ant2 2390 -55.72 2.95 0 42.49 Average 54 Pass NVNT b 2462 Ant2 2483.5 -47.4 2.95 - 50.81 Peak 74 Pass NVNT b 2462 Ant2 2483.5 -54.82 2.95 0 43.39 Average 54 Pass NVNT b 2462 Ant2 2486.697 -39.87 2.95 - 58.34 Peak 74 Pass NVNT b 2462 Ant2 2485.213 -54.02 2.95 0 44.19 Average 54 Pass NVNT b 2462 Ant2 2500 -47.99 2.95 - 50.22 Peak 74 Pass NVNT b 2462 Ant2 2500 -57.98 2.95 0 40.23 Average 54 Pass NVNT g 2412 Ant2 2310 -51.05 2.95 - 47.16 Peak 74 Pass NVNT g 2412 Ant2 2310 -58.74 2.95 0.1 39.57 Average 54 Pass NVNT g 2412 Ant2 2389.794 -37.63 2.95 - 60.58 Peak 74 Pass NVNT g 2412 Ant2 2389.677 -52.89 2.95 0.1 45.42 Average 54 Pass NVNT g 2412 Ant2 2390 -38.52 2.95 - 59.69 Peak 74 Pass NVNT g 2412 Ant2 2390 -54.33 2.95 0.1 43.98 Average 54 Pass NVNT g 2462 Ant2 2483.5 -39.42 2.95 - 58.79 Peak 74 Pass NVNT g 2462 Ant2 2483.5 -54.69 2.95 0.1 43.62 Average 54 Pass NVNT g 2462 Ant2 2483.835 -36.71 2.95 - 61.50 Peak 74 Pass NVNT g 2462 Ant2 2483.729 -52.74 2.95 0.1 45.57 Average 54 Pass NVNT g 2462 Ant2 2500 -49.36 2.95 - 48.85 Peak 74 Pass NVNT g 2462 Ant2 2500 -57.52 2.95 0.1 40.79 Average 54 Pass NVNT n20 2412 Ant2 2310 -49 2.95 - 49.21 Peak 74 Pass NVNT n20 2412 Ant2 2310 -58.51 2.95 0.12 39.82 Average 54 Pass NVNT n20 2412 Ant2 2389.443 -37.22 2.95 - 60.99 Peak 74 Pass NVNT n20 2412 Ant2 2389.794 -52.58 2.95 0.12 45.75 Average 54 Pass NVNT n20 2412 Ant2 2390 -37.13 2.95 - 61.08 Peak 74 Pass NVNT n20 2412 Ant2 2390 -53.38 2.95 0.12 44.95 Average 54 Pass NVNT n20 2462 Ant2 2483.5 -41.95 2.95 - 56.26 Peak 74 Pass NVNT n20 2462 Ant2 2483.5 -53.02 2.95 0.12 45.31 Average 54 Pass NVNT n20 2462 …

Text truncated - open the document above for the full version.
