Fompet User Manual 1. Introduction Thank you for purchasing Fompet, a pet bio-data measuring device developed by Pet Ground Co., Ltd. This product is designed to measure and monitor pets’ physiological data, such as body condition score and disease-related indicators, in an easy and convenient way. Fompet consists of: - A handheld measuring device - A mobile application - Wireless Bluetooth connectivity 2. Safety Information ⚠ General Warnings - Do not disassemble, repair, or modify the device on your own. - Keep the device away from water, high humidity, fire, or direct sunlight. - Do not press the sensor unit with excessive force. - Store the device out of reach of children. ⚠ Usage Precautions - Ensure your pet is calm and still during measurement. - Do not attempt measurement while your pet is moving. - Always place the device sensor flat against the pet’s skin or fur. - Use only the provided charging accessories. 3. Product Overview 3-1. Device Layout - Power Button (Upper Left): Turns the device ON/OFF. - Measurement Button (Lower Left): Starts measurement when pressed. - OLED Display: Shows device status, calibration, and results. - Sensor Area: The flat part that must be in contact with the pet’s body. Figure 1. Fompet device (Front view) Figure 2. Fompet device (Rear view showing sensor units) 3-2. Package Contents - Fompet device (1 unit) - USB charging cable (1 unit) - Quick Start Guide (1 copy) 4. Device Operation <Step 1: Power On> 1. Press the Power Button. 2. The Fompet logo will appear. 3. The display will show “Calibrating”. Place the device on a flat surface. 4. Once calibration is complete, the screen will display “Run the App”. <Step 2: Run the Application> 1. Install the Fompet APK on your smartphone. 2. Open the application and tap “Measure”. 3. Input the following data: - Category (Dog/Cat) - Breed - Age - Sex (Male/Female/FS/MC) - Petbody Condition Score (1–9) - Current treatment or managed disease (optional) - Additional notes (if necessary) 4. Tap “Measure” to proceed. Tip: If repeated measurements are required, you may use the option “Re-measure with previous data” to save time. <Step 3: Bluetooth Connection> 1. Tap “Bluetooth Scan” in the app. 2. Select the device labeled “Fompet”. 3. Once paired, the Bluetooth icon on the display will be activated. <Step 4: Power On Start Measurement> 1. The app will prompt: “Press the measurement button on the device.” 2. The device display will alternate between Step 1 and Step 2. 3. Place the sensor unit firmly against the measurement site on the pet’s body (recommended: abdomen). <Step 5: Measuring> 1. Press and hold the Measurement Button for 2–3 seconds, then release. 2. The device will show “In Progress”, and the app will display “Measuring...”. 3. Wait until measurement is complete (approx. 15 seconds). 4. When finished: - The app will display “Measurement Completed”. - The device will display results on the OLED screen. 5. Measurement data can be reviewed in the Admin page for detailed analysis. 5. Display Indicators - Calibrating: Device is preparing for measurement. - Run the App: Ready to connect with the mobile application. - Bluetooth Icon (Active): Device successfully connected. - In Progress: Measurement is running. - Results Displayed: Numerical or graphical output of bio-data. 6. Troubleshooting Problem Possible Cause Solution Device does not power on Battery discharged Recharge the device using USB cable Bluetooth cannot connect Device not paired Restart the device and retry scan App freezes or closes Software conflict Restart the app and relaunch Incorrect measurement values Pet moved during test Repeat measurement with pet still 7. Technical Specifications - Device Name: Fompet - Connectivity: Bluetooth 5.0 - Display: OLED - Power Supply: Rechargeable battery (via USB cable) - Measurement Duration: Approx. 15 seconds - Operating Temperature: 10°C – 40°C 8. Customer Support For technical assistance, contact: Pet Ground Co., Ltd. - Email: [email protected] - Address: 1815Ho, A-Dong, 136, LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea, 14118 FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada Statement This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interf…
Text truncated - open the document above for the full version.
Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 20, 2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID : 2BR6X-FPG-100 [Pet Ground Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is soughtis not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Pet Ground Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant toDA-24-886andKDB 986446 D01 Covered Equipment Guidancesection B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, CEO / Hong Sic An Pet Ground Co.,Ltd. Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 20, 2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID : 2BR6X-FPG-100 [Pet Ground Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, CEO / Hong Sic An Pet Ground Co.,Ltd.
Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: October 02, 2025 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID : 2BR6X-FPG-100 Applicant FRN : 0037496338 Pet Ground Co.,Ltd.certifies that, as of the date of the filing of the application,FCC US AGENT, LLC.is our designated U.S. agent for service of process for the above referenced FCC ID.Pet Ground Co.,Ltd.accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US AGENT, LLC.accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: FCC US AGENT, LLC. U.S. Agent FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Tel.: 708-571-3147 Email: [email protected] Sincerely, Pet Ground Co.,Ltd. FCC US AGENT, LLC. CEO / Hong Sic An Tim Payne [U.S. Agent signature] Rev 1/26/2023
Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 Date: October 02, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 Confidentiality Request regarding application for certification of FCC ID : 2BR6X-FPG-100 IC number : 34567-FPG100 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules and IC regulation, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit TypeFile Name Part ListPart List.pdf Schematics Diagram(s)Schematic.pdf Operation descriptionOperation description.pdf Block diagramBlock diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, CEO / Hong Sic An Pet Ground Co.,Ltd.
Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 Date: October 02, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 FCC ID : 2BR6X-FPG-100 IC number : 34567-FPG100 To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Pet Ground Co.,Ltd. A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Tel: +82- 10-7401-6701 e)upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, CEO / Hong Sic An Pet Ground Co.,Ltd. REMARK: 1.This authorization letter will be sent along with your application when filing with the Certification Division. 2.Please follow the format and type it on company letterhead and send original to us. 3.Authorized signature must be in agreement with grantee code contact in FCC database.
FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 1 of 2 External photos FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 2 of 2
FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 1 of 1 Label Location Label The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the User’s Manual.
FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 1 of 3 Internal photos FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 2 of 3 FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 3 of 3 Chip Antenna
FCC ID : 2BR6X-FPG-100Page 1 of 1 RF exposure FCC ID : 2BR6X-FPG-100 According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100㎒to 6㎓ at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(㎓)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, Where; f(㎓) is the RF channel transmit frequency in㎓ Power and distance are rounded to the nearest㎽andmmbefore calculation The result is rounded to one decimal place for comparison Results Mode Frequency (㎓) Distance (mm) Maxtune-up power (㏈m) Calculation value Exclusion Threshold (㏈m)(㎽) LE 1 Mbps 2.402 ~ 2.4805 4.02.5120.791≤3.0 LE 2 Mbps4.02.5120.791≤3.0
TEST REPORT Report No. : KES-RF250628 Page1/46 KES Co., Ltd. #3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si,Gyeonggi-do, 14057, Republic ofKorea Tel : +82-31-425-6200, Fax : +82-31-341-3838 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). FCC & IC TEST REPORT 1. Client ○ Name : Pet Ground Co.,Ltd. ○ Address : A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea 2. Sample Description ○ Product item : Fompet ○ Model name : FPG-100 ○ Manufacturer etc. : Pet Ground Co.,Ltd. 3. Date of test :2025.09.24 ~ 2025.09.26 4. Location of Test :Permanent Testing LabOn Site Testing ○ Adress : 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, Korea 5. Test method used :Part 15 Subpart C 15.247, RSS-247 (Issue 4), RSS-Gen (Issue 5) 6. Test result :PASS The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced and copied without permission without the written consent of KES Co., Ltd. This laboratory is not accredited for the test results marked *. This test report is not related to KOLAS accreditation. Affirmation Tested byTechnical Manager Name : Gu-Bong, Kang(Signature) Name :Yeong-Jun Cho(Signature) 2025. 11. 10. KES Co., Ltd. Report No. : KES-RF250628 Page2/46 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). REPORT REVISION HISTORY DateTest Report No.Revision History 2025.11.10KES-RF250628Initial This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. This document may be altered or revised by KES Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KES Co., Ltd. will constitute fraud and shall nullify the document. Report No. : KES-RF250628 Page3/46 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). TABLE OF CONTENTS 1.General information ................................................................................................................................... 4 1.1.EUT description .......................................................................................................................... 4 1.2.Test configuration........................................................................................................................ 5 1.3.Information about derivative model ............................................................................................ 5 1.4.Accessory information ................................................................................................................ 5 1.5.Device modifications................................................................................................................... 5 1.6.Sample calculation ..................................................................................................................... 5 1.7.Worst case data rate................................................................................................................... 5 1.8.Measurement Uncertainty .......................................................................................................... 5 1.9.Frequency/channel operations ................................................................................................... 6 2.Summary of tests ....................................................................................................................................... 7 3.Test results ................................................................................................................................................. 8 3.1.99% Occupied Bandwidth .......................................................................................................... 8 3.2.6㏈bandwidth .........................................................................................................................11 3.3.Output power ............................................................................................................................ 14 3.4.Power spectral density ............................................................................................................. 16 3.5.Radiated restricted band and emissions .................................................................................. 19 3.6.Conducted spurious emissions & band edge ........................................................................... 38 3.7.AC conducted emissions .......................................................................................................... 43 3.8.Antenna Requirement............................................................................................................... 45 Appendix A. Measurement equipment.......................................................................................................... 46 Report No. : KES-RF250628 Page4/46 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). 1.General information Applicant:Pet Ground Co.,Ltd. Applicant address:A-1815, 136 LS-ro, Dongan-gu, Anyang-si, Gyeonggi-do, South Korea Test site:KES Co., Ltd. Test site address:#3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Republic of Korea 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, Korea Test FacilityFCC Accreditation Designation No.: KR0100, Registration No.: 444148 ISED Registration No.: 23298 FCC rule part(s):15.247 FCC ID:2BR6X-FPG-100 IC rule part(s):RSS-247 (Issue 4), RSS-Gen (Issue 5) IC Number:34567-FPG100 Test device serial No.:ProductionPre-productionEngineering 1.1.EUT description Equipment under testFompet Frequency range & Number of channels 2 402㎒~ 2 480㎒(LE 1 Mbps / 2 Mbps) : 40 ch ModelFPG-100 Modulation techniqueGF…
Text truncated - open the document above for the full version.
< FomPet Antenna Specification > Photo & dimesion Table of Contents 1 Description 1 Features 2 Applications 2 Ordering Information 2 (OHFWULFDO6SHFLĬFDWLRQV 3 Footprints 3 3LQ&RQĬJXUDWLRQ 4 Theory of Operation 4 Layout Considerations 5 Microstrip Details 6 Assembly Considerations 8 Test Boards 9 VSWR Graphs 10 Tape Dimensions 12 Reel Dimensions 13 Mismatch Conversion Table – – 1 Description The exciting ANT-***-CHP family is among the world’s smallest high-performance chip antennas. They are ideal for embedding in wireless products including Bluetooth, 802.11, Home RF, ZigBee and other popular standards. These tiny antennas use advanced Low Temperature Co-fired Ceramic (LTCC) technology and proprietary elements to achieve superior size and performance characteristics. The entire family is com- patible with hand and reflow-assembly. Excellent electrical specifications, stability, and outstanding cost-effectiveness make CHP Series antennas the logical choice for a wide variety of applications. Features s Incredibly compact SMD package s Superior LTCC technology s 50: characteristic impedance s Low loss s Wide bandwidth s Favorable linear polarization s > Unity gain s No external matching required s Highly stable over temperature & time s Hand and reflow-assembly compatible s RoHS compliant s Cost-effective Ultra Compact Chip Antenna Data Guide Figure 1: 2.4GHz Dimensions Revised 8/8/12 2.4 xxx Figure 2: 868MHz and 916MHz Dimensions 2.4 xxx 2.45GHz 868MHz916MHz Figure 3: Actual Sizes – –– – 23 Ordering Information Figure 4: Ordering Information Applications s Bluetooth s 802.11 s ZigBee s Wireless PCMCIA cards s Telemetry s Data collection s Industrial process monitoring s Compact wireless products s External antenna elimination Ordering Information Part NumberDescription ANT-868-CHP-x868Mhz Chip Antenna ANT-916-CHP-x916MHz Chip Antenna ANT-2.45-CHP-x2.45GHz Chip Antenna x = "T" for tape/reel, "B" for bulk All parts are RoHS compliant. Standard reel is 3,000pcs. (868/916MHz), 1,500pcs. (2.45GHz) Quantities less than reel size are supplied in bulk. Footprints 0.100" 0.040" 0.260" 0.130" 0.040" 0.630" Figure 6: 2.4GHz Footprint Figure 7: 868MHz and 916MHz Footprint Specifications Parameter2.45GHz868MHz916MHz Physical Dimensions (mm) 6.5(L) x 2.2(W) x 1.0(H) 16.0(L) x 3.0(W) x 1.7(H) 16.0(L) x 3.0(W) x 1.7(H) Operating/Storage Temp–40 to +85°C–40 to +85°C–40 to +85°C ConstructionLTCCLTCCLTCC Electrical Center Frequency2.45GHz868MHz916MHz Bandwidth180MHz10MHz10MHz Wavelength¼-wave¼-wave¼-wave PatternOmni-directionalOmni-directionOmni-directional PolarizationLinearLinearLinear VSWR2.0 (Max.)2.0 (Max.)2.0 (Max.) Maximum Gain+0.5dBi+0.5dBi+0.5dBi Impedance50:50:50: Power Handling3W (Max.)3W (Max.)3W (Max.) (OHFWULFDO6SHFLĬFDWLRQV Figure 5: Ordering Information 3LQ&RQĬJXUDWLRQ 2.4 12 Figure 8: Pin Configuration Pin Descriptions Pin NumberDescription 1 Feed Termination This pin connects to the transmitter or receiver. 2 Solder Termination This pin is soldered down for physical support only. There is no electrical connection. Figure 9: Pin Configurations – –– – 45 Theory of Operation The CHP Series antennas utilize Low Temperature Cofired Ceramic (LTCC) technology to embed the antenna element into a ceramic substrate. Advances in this technology have resulted in materials that are extremely stable over time and temperature, producing an antenna that is highly reliable across a wide range of applications. The high-frequency charac- teristics of this technology enable exceptional performance in a very small package. The construction techniques for LTCC devices lends itself well to favorable pricing in high volume. Layout Considerations Proper layout is vital to ensure correct operation and optimum perfor- mance. Improper placement of planes, traces, or system components will result in nulls or complete de-tuning. Ideally, the antenna will be mounted on the board in such a way as to allow an unobstructed field of view. The area underneath the antenna must be free of components, traces, and planes. Components may be placed to the rear of the antenna in the ground plane counterpoise area. The feed trace from the RF stage to the antenna must be a microstrip trace or coax transmission line and should be kept as short as practical. The layout of our reference jigs is illustrated on the following pages. While they demonstrate various aspects of a layout, it is not necessary to replicate them exactly. While your board size and layout may differ, it is important to recognize that the counterpoise plays an important role in resonance and stability since it acts, in essence, as part of the antenna. After your own layout is complete, the performance of the antenna in your specific product should be carefully checked using tools like a network analyzer. In some cases, the size of the product’s PCB, proximity of the case, or other factors may make a custom version of the antenna necessary. Contact Linx for more information. 2.4 No ground plane or traces under the antenna Ground plane on bottom layer for counterpoise 50-ohm microstrip line No electrical connection. For physical support only PCB pads for the CHP Figure 10: Layout Microstrip Details A transmission line is a medium whereby RF energy is transferred from one place to another with minimal loss. This is a critical factor, especially in high-frequency products like Linx RF modules, because the trace lead- ing to the module’s antenna can effectively contribute to the length of the antenna, changing its resonant bandwidth. In order to minimize loss and detuning, some form of transmission line between the antenna and the module should be used unless the antenna can be placed very close (<1/8in.) to the module. One common form of transmission line is a coax cable and another is the microstrip. This term refers to a PCB trace run- ning over a ground plane that is designed to serve as a transmission line between the module and the antenna. The width is base…
Text truncated - open the document above for the full version.
FCC ID : 2BR6X-FPG-100 IC Number : 34567-FPG100 Page 1 of 1 Test setup photos Radiated testAC Conducted test Blank
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.17 mW |
