AllGood IPG Pro Quick User Manual Safety instructions When using IPG, please read and abide by the following regulations:  Please make sure that your IPG uses suitable batteries.  When the IPG screen flickers, please replace with new batteries immediately to avoid affecting the construction.  If it is dropped, hit strongly, or touched with sharp or rough tools, the buttons, screen, or appearance may be damaged.  Never insert any metal objects into the gaps of the IPG. Doing so may cause equipment damage.  To avoid short circuits, never touch the internal parts. Onlyqualified technicians can open the shell.  When removing the IPG from the valve seat, use correct tools instead of rotating the body.  It is recommended to place the IPG in a dry place and do not let the IPG soakin water.  If your IPG fails to operate normally, especially when it makes any abnormal sounds or smells, please turn off the power immediately, remove the battery, and contact a qualified dealer or service center. IPG Pro Button introduction Power button Reset to zero and QR code display, please press button for 3 seconds. To switch the temperature unit, you must press the screen brightness and unit switch keys at the same time LCD brightness/Reset to Zero Unit switch/QR code Connection description 1. IPG and cell phone connection (by scanning devices) I. Please touch on the APP to enter the MAC selectionpage. II. Choose the MAC you want to add. III. After selecting "single gauge", then select "high pressure" or "low AllGood pressure" to complete the single meter setting. i. If you choose "dual gauge", you will select "high pressure" or"low pressure" for the first gauge. ii. Then return to the MAC selection page again, select the second gauge to complete the dual table setting。 2. IPG and cell phone connection (scan QR code) I. Please touch on the APP to enter the camera scan page. II. Please press the IPG button for 3 seconds and scan the QR code displayed on the IPG with your cell phone camera. III. After selecting "single gauge", then select "high pressure" or"low pressure" to complete the single gauge setting. IV. If you select "dual gauge", you will select "high pressure" or "low pressure" for the first gauge. V. Go back to the camera scan page and scan the QR code of the second gauge to complete the dual guage setting. 3. Device removes I. Please touch APP's to enter the remove device page. II. After selecting the device you want to remove, click "Remove Selected Device" icon. APP Page introduction APP Pages Page figure remark Home page The home page can display the connection status/pressure value of each meter, adding devices, removing devices, and calling devices. Pressure gauge display This page can dynamically display pressure value, unit switching, and refrigerant high/low pressure recommended AllGood Tool bar From left to right: go to homepage, wireless signal strength, record on/off, setting page, refrigerant model, record log. Product specification  Pressure range：-1~55bar  IP 65 waterproof and dustproof, suitable for industrial environment  3 data recording  Wireless communication within 10 meters, wireless broadcast distance up to 250 meters  Pressure Units Selection: PSI, MPa, KPa, Bar, Kg/cm2, CmHg  Display：White backlight display and easy-to-read, 5-digit, APP with analog gauge  Automatic ambient temperature display, APP recommends high- and low- pressure values of refrigerant  Power supply mode: 3 AAA dry batteries, power consumption more than 120 hours FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Regulatory AllGood FCC Warning Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

V01222025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Unite d S ta te s Da te : August 22, 2025 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID: 2BRLVAG-MCS-MS1 All Good Electronics CO.,LTD certifies that, as of the dates of this application, Americas Compliance Consulting LLC d b a iC e rtifi “ iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. All Good Electronics CO.,LTD accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: Name Americas Compliance consulting, LLC dba iCertifi FCC FRN 0033399411 Address 2445 NE Division Street, Suite 202 Bend, OR 97703 Unite d S ta te s Contact Person Paul Preston Telephone +1-866-885-4575 Email [email protected] S in c e re ly, All Good Electronics CO.,LTD Americas Compliance Consulting LLC dba iC e rtifi 0037376191 0033399411 CHUN HSIANG HU Paul Preston R&D Engineer P re s ide nt/CEO Signature Signature

Covered list attestation FCC application letter Kiwa Page 1 of 2 RF_755_03 06-06-2024 All Good Electronics CO.,LTD 4F., No. 369, Fuxing N. Rd., Songshan Dist., Taipei City 105, Taiwan Certification Application Attestation Statements All Good Electronics CO.,LTD <FRN: 0037376191> 4F., No. 369, Fuxing N. Rd., Songshan Dist., 105 Taipei City, Taiwan Subject: FCC ID: 2BRLVAG-MCS-MS1 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [All Good Electronics CO.,LTD] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [All Good Electronics CO.,LTD] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: August 22, 2025 City: Taipei City Name (2) : CHUN HSIANG HU Function: R&D Engineer Telephone number: +886-929961202 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

RF_160_05 Declaration of Authorisation Date of issue 02-01-2023 Declaration of Authorization We Name: All Good Electronics CO.,LTD Address: 4F., No. 369, Fuxing N. Rd., Songshan Dist., City: Taipei City 105 Country: Taiwan Declare that: Name Representative of agent: Nina Hsu (1) Agent Company name: Cerpass Technology Corporation Address: No.10, Lane 2, Lianfu Street, Luzhu District City: Taoyuan City Country Taiwan R.O.C. is authorized to apply for Certification of the following product(s): Product description: Mira capture Type designation: MS1 Trademark: All -Good Validity/ expiry date N/A on our behalf. Date: August 22, 2025 City: Taipei City Name: CHUN HSIANG HU (2) Function: R&D Engineer Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 02-01-2022 RF_501, Issue 10 Company Name: All Good Electronics CO.,LTD Address : 4F., No. 369, Fuxing N. Rd., Songshan Dist., City: Taipei City 105 Country: Taiwan To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: 2BRLVAG-MCS-MS1 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Date: 2025/8/22 Name and signature of applicant: CHUN HSIANG HU Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 1 of 12 Photographs of EUT All-Good / Mira capture / MS1 Red CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 2 of 12 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 3 of 12 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 4 of 12 All-Good / Mira capture / MS1 Black CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 5 of 12 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 6 of 12 All-Good / Mira capture / MS1

Label & location Rear side Label drawing: All Good Mira capture Model: MS1 FCC ID: 2BRLVAG-MCS-MS1 This device complies with Part15 of the FCC Rules. Operafion is subject to the following two condifions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operafion. 4cm 2cm

CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 4 of 9 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 5 of 9 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 6 of 9 All-Good / Mira capture / MS1 RF Chip CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 7 of 9 All-Good / Mira capture / MS1 Antenna CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 8 of 9 All-Good / Mira capture / MS1 CERPASS TECHNOLOGY CORP. Report No.: 25070193 Cerpass Technology Corp. Issued Date : Sep. 12, 2025 Page No. : 9 of 9 All-Good / Mira capture / MS1

CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 1 of 9 FCC ID : 2BRLVAG-MCS-MS1 Radio Frequency Exposure Applicant : All Good Electronics CO.,LTD Address : 4F, No. 369, Fuxing N. Rd., Songshan Dist., Taipei City 105 Equipment : Mira capture Model No. : MS1 Trade Name : All-Good FCC ID : 2BRLVAG-MCS-MS1 I HEREBY CERTIFY THAT : The sample was received on Jul. 31, 2025 and the testing was completed on Aug. 07, 2025 at Cerpass Technology Corp. The test result refers exclusively to the test presented test model / sample. Without written approval of Cerpass Technology Corp., the test report shall not be reproduced except in full. Approved by: Mark Liao / Supervisor Laboratory Accreditation: Cerpass Technology Corporation Test Laboratory CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 2 of 9 FCC ID : 2BRLVAG-MCS-MS1 CONTENTS 1. Summary of Test Procedure and Test Results ...................................................................................... 4 1.1. Applicable Standards ................................................................................................................. 4 2. Test Configuration of Equipment under Test ......................................................................................... 5 2.1. Feature of Equipment under Test ............................................................................................... 5 2.2. General Information of Test ........................................................................................................ 6 2.3. Measurement Uncertainty .......................................................................................................... 6 3. Test Equipment and Ancillaries Used for Tests ..................................................................................... 7 4. Radio Frequency Exposure .................................................................................................................. 8 4.1. Applicable Standards ................................................................................................................. 8 4.2. EUT Specification ....................................................................................................................... 9 4.3. Result ......................................................................................................................................... 9 CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 3 of 9 FCC ID : 2BRLVAG-MCS-MS1 History of this test report Report No. Issued Date Description 25070193-TRFCC0 Aug. 22, 2025 Original CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 4 of 9 FCC ID : 2BRLVAG-MCS-MS1 1. Summary of Test Procedure and Test Results 1.1. Applicable Standards FCC Rules and Regulations Part 2.1091 FCC Rule . Description of Test Result 2.1091 . Radio Frequency Exposure PASS *The lab has reduced the uncertainty risk factor from test equipment, environment and staff technicians which according to the standard on contract. Therefore, the test result will only be determined by standard requirement, measurement uncertainty evaluation is not considered. CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 5 of 9 FCC ID : 2BRLVAG-MCS-MS1 2. Test Configuration of Equipment under Test 2.1. Feature of Equipment under Test Operation Frequency Range 2400MHz~2483.5MHz Center Frequency Range 2402MHz~2480MHz Modulation Type GFSK Modulation Technology DTS Data Rate 1Mbps Antenna Type Ceramic Chip Antenna Antenna Gain 1.50 dBi Note: For more details, please refer to the User’s manual of the EUT. Difference description: There are two colors: Black, Red. Only different colors, other model, circuits, layout, product specifications are all the same. Red was the worst case, so it was used for the test result. CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 6 of 9 FCC ID : 2BRLVAG-MCS-MS1 2.2. General Information of Test Organization Cerpass Technology Corp. Test Site Cerpass Technology Corporation Test Laboratory Address: No.10, Ln. 2, Lianfu St., Luzhu Dist., Taoyuan City 33848, Taiwan (R.O.C.) Tel: +886-3-3226-888 Fax: +886-3-3226-881 FCC TW1439, TW1079 IC 4934E-1, 4934E-2 Frequency Range Investigated Conducted: from 150kHz to 30 MHz Radiation: from 30 MHz to 40,000MHz Test Distance The test distance of radiated emission from antenna to EUT is 3 M. Test Item Test Site Test period Environmental Conditions Tested By RF Conducted RFCON01-NK 2025/08/07 26.3°C / 47% Leon Huang 2.3. Measurement Uncertainty ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Measurement Item Uncertainty AC Power Line Conduction(150K~30MHz) ±3.2dB Radiated Spurious Emission(9KHz~30MHz) ±3.5dB Radiated Spurious Emission(30MHz~1GHz) ±5.1dB Radiated Spurious Emission(1GHz~40GHz) ±5.2dB Conducted Spurious Emission ±2.1dB 6dB Bandwidth ±5.4% 20dB Bandwidth ±4.4% Occupied Bandwidth ±4.5% Peak Output Power(Conducted Power Meter) ±1.1dB Dwell Time / Deactivation Time ±7.6% Power Spectral Density ±2.0dB Duty Cycle ±3.5% CERPASS TECHNOLOGY CORP. Report No.: 25070193-TRFCC03 CERPASS TECHNOLOGY CORP. Issued date : Aug. 22, 2025 T-FD-523-0 V1.1 Page No. : 7 of 9 FCC ID : 2BRLVAG-MCS-MS1 3. Test Equipment and Ancillaries Used for Tests Test Item RF Conducted Test Site RFCON01-NK Instrument Manufacturer Model No Serial No Calibration Date Vali…
