2BRRK288Wireless Magnetic Trailer Light Kit

Operating Instructions T401 Please read all operating instructions before installing and operating the system. Keep the manual for future reference. Parameter Product Informa�on Pairing Installa�on WARNING LAMP SWITCH BUTTON SIGNAL LAMP SWITCH ON INDICATOR (WHITE) THREE LEVEL POWER INDICATOR (BLUE) TYPE-C SIGNAL LAMP SWITCH BUTTON TURN ON: Short press one time, warning lamp is on. TURN OFF: Long press three seconds warning lamp off. MODE SWITCHING: After turning on the device, each short press to the next flashing mode. TURN ON: Short press one time; switch on indicator is on, means it’s working now, meanwhile power indicator will be light up, then off after 40 seconds.lamp is on. TURN OFF: Short press again. The switch on indicator turn off, means stop working, meanwhile power indicator will be light up, then off after 40 seconds. 10 Text Tail Lamp Direction Indicator Lamp Stop/Brake Reflector Reversing Lamp Warning Lamp Charging Ba�ery Life 1.5 hours All Lamp On2200mAh 2200mAh 2200mAh 2200mAh Tail Lamp On Warning Lamp On Tail Lamp+Stop/Brake On 1 hour 30 minutes ModelBa�ery CapacityWorking Hours 12 hours 12 hours 3 hours Contents Mount MAGNETIC MOUNT Packing box x 1 Left lamp x 1 Right lamp x 1 USB adaptor x 1 Charging cord x 1 Transmitters x1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance of 20cm from your body.

Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Sep. 8, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BRRK288 Agrieyes (Guangzhou) Technology CO.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: ryan liu Title: Assistant Address: 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Tel.: 8618814377649 Email: [email protected]

Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Sep. 8, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2BRRK288 Product Name: Wireless Magnetic Trailer Light Kit This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: ryan liu Title: Assistant Address: 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Tel.: 8618814377649 Email: [email protected] Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Date: 2025/9/1 Dear Sir/Madam, We, Agrieyes (Guangzhou) Technology CO.,Ltd., Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Wireless Magnetic Trailer Light Kit Model no.: AG-T325, AG-T326, AG-T327, AG-T328, AG-T329, AG-T330, AG-T331, AG-T332, AG- T333, AG-T334, AG-T335, AG-T336, AG-T337, AG-T338, AG-T339, AG-T340, AG-T341, AG-T342, AG-T343, AG-T344, AG-T345 Sincerely, Name/Title： ryan liu / Assistant Company: Agrieyes (Guangzhou) Technology CO.,Ltd. Address: 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Phone: 8618814377649 Fax: N/A E-Mail: [email protected]

Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China September 8, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BRRK288 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of 0 days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOM in the event information regarding the product or the product is made available to the public before the requested period has expired. Sincerely, Title: Assistant Address: 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Tel.: 8618814377649 Email: [email protected]

Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China September 8, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BRRK288 I, the undersigned, hereby authorize Shenzhen Tongzhou Testing Co.,Ltd. to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by Shenzhen Tongzhou Testing Co.,Ltd. shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with Agrieyes (Guangzhou) Technology CO.,Ltd.. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, ryan liu Assistant Tel: 8618814377649 Fax: N/A Email: [email protected]

Report No.: TZ0120250701PH02 Page 1 of 4 Exterior Photographs of EUT Fig.1 Fig.2 Report No.: TZ0120250701PH02 Page 2 of 4 Fig.3 Fig.4 Report No.: TZ0120250701PH02 Page 3 of 4 Fig.5 Fig.6 Report No.: TZ0120250701PH02 Page 4 of 4 Fig.7

Label Location FCC ID: 2BRRK288

Report No.: TZ0120250701PH03 Page 1 of 4 Interior Photographs of EUT Fig.1 Fig.2 Antenna Report No.: TZ0120250701PH03 Page 2 of 4 Fig.3 Fig.4 Report No.: TZ0120250701PH03 Page 3 of 4 Fig.5 Fig.6 Report No.: TZ0120250701PH03 Page 4 of 4 Fig.7

Shenzhen Tongzhou Testing Co., Ltd FCC ID: 2BRRK288 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 1 RADIO FREQUENCY EXPOSURE Limit According to section B.2 of 447498 D04 Interim General RF Exposure Guidance v01: The 1 mW Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1 mW, regardless of separation distance. The 1 mW blanket exemption applies at separation distances less than 0.5 cm, including where there is no separation. This exemption shall not be used in conjunction with other exemption criteria other than those for multiple RF sources in paragraph § 1.1307(b)(3)(ii)(A). The 1 mW exemption is independent of service type and covers the full range of 100 kHz to 100 GHz, but it shall not be used in conjunction with other exemption criteria or in devices with higher-power transmitters operating in the same time-averaging period. Exposure from such higher-power transmitters would invalidate the underlying assumption that exposure from the lower-power transmitter is the only contributor to SAR in the relevant volume of tissue. Results Test Mode Max Field strength at 3m distance (dBμV/m) Max of ERP (dBm) Max of ERP (mW) Exemption Limit(mW) Transmitting 92.91 -4.44 0.36 1 When necessary, Field strength measurements shall be converted to ERP or EIRP for comparison to the applicable regulatory limits. EIRP (dBm) = E (dBuV/m) + 20log(D) - 104.8, where D is the measurement distance ERP = EIRP - 2.15 dB Conclusion Meet the requirements of RF exposure.

深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 1 SPECIFICATIONFORAPPROVAL CUSTOMERNAME:GuangzhouWeilun PRODUCTNAME:2.4Grubberrodantenna,SMAcurvedmalehead innerhole,totallength50mm CUSTOMERP/N:10000027 MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY:YanPeihao APPROVEDBY:FengJuan DATE:2025.08.20 Address:401-406,BuildingA,JinfulaiBuilding,DabaoRoad,Bao'anDistrict28,Shenzhen telephone:0755-27728733 fax:0755-27805416 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 2 Contents ItemDescription 1.Testinginstrumentsandenvironment................................................3 2.matchingcircuit.................................................................................3 3.Antennasample.................................................................................4 4.Passivetestdata.....................................................................................5 5.AntennaPattern...............................................................................6 6.Antennastructuredimensiondiagram....................................................6 7.ExperimentalTestReport...................................................................7 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 3 1.Testingequipmentandenvironment:CTIA743darkroom,8960/5515C,withthephone placedfacingawayfromthestandardspeakerantennaatadistanceof4metersfromthe turntable 2、matchingcircuit Matchingcircuitremainsunchanged 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO ., Ltd 创建日期 2025-8-2015:51:46 4 3.Antennasamples Workindicatorsworkingparameters modelTCWZJB2400-2500 SpecificationsSMAcurvedmale head innerhole, total length50mm operatingfrequency2400-2500MHZ standing-waveratio<2.0 ReturnLoss<-10 gain3dBi OperatingTemperature-60+80degrees OperatingHumidity<90% sizeL=50 MM weight3.8 g packagingPE bags and cardboardboxes 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 5 4.Passivetestdata 5.AntennaPattern： 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 6 6.Antennastructuredimensiondiagram： 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 创建日期 2025-8-2015:51:46 7 7.ExperimentalTestReport：

This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TZ0120250701FRF20 Page 1 of 29 TEST REPORT Report Number : TZ0120250701FRF20 Product Name : Wireless Magnetic Trailer Light Kit Model/Type reference : AG-T325, AG-T326, AG-T327, AG-T328, AG-T329, AG-T330, AG-T331, AG-T332, AG-T333, AG-T334, AG-T335, AG-T336, AG-T337, AG-T338, AG-T339, AG-T340, AG-T341, AG-T342, AG-T343, AG-T344, AG-T345 FCC ID : 2BRRK288 Prepared for : Agrieyes (Guangzhou) Technology CO.,Ltd. 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15 Subpart C, ANSI C63.10: 2013 Date of Test : 2025-08-01~ 2025-08-14 Date of Issue : 2025-08-15 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0120250701FRF20 Page 2 of 29 Page 2 of 29 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2025-08-15 Valid Initial release Report No.: TZ0120250701FRF20 Page 3 of 29 Page 3 of 29 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ........................................................ 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 6 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 2. T E S T M E T H O D O L O G Y ............................................................ 7 2.1. EUT Configuration .................................................................................................................. 7 2.2. EUT Exercise ........................................................................................................................... 7 2.3. Test Sample ............................................................................................................................. 7 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 8 3.1. Justification ............................................................................................................................. 8 3.2. Special Accessories ............................................................................................................... 8 3.3. Block Diagram/Schematics .................................................................................................... 8 3.4. Equipment Modifications ....................................................................................................... 8 3.5. Configuration of Tested System ............................................................................................ 8 4. S U M M A R Y O F T E S T R E S U L T S ................................................. 9 5. T E S T R E S U L T ..................................................................... 10 5.1. Bandwidth Measurement ..................................................................................................... 10 5.2. Radiated Emissions Measurement ...................................................................................... 16 5.3. AC Power line conducted emissions .................................................................................. 26 5.4. Antenna Requirements ......................................................................................................... 27 6. L I S T O F M E A S U R I N G E Q U I P M E N T S ......................................... 28 7. T E S T S E T U P P H O T O G R A P H S O F E U T ...................................... 29 8. E X T E R I O R P H O T O G R A P H S O F E U T ......................................... 29 9. I N T E R I O R P H O T O G R A P H S O F E U T .......................................... 29 Report No.: TZ0120250701FRF20 Page 4 of 29 Page 4 of 29 1. G E N E R A L I N F O R M A T I O N 1.1. Client Information Applicant : Agrieyes (Guangzhou) Technology CO.,Ltd. Address : 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China Manufacturer : Agrieyes (Guangzhou) Technology CO.,Ltd. Address : 2F No.191 Tai Cheng West Road, Renhe Town, Baiyun, Guangzhou, China 1.2. Description of Device (EUT) Product Name : Wireless Magnetic Trailer Light Kit Trade Mark : (AgriEyes) Model Number : AG-T325, AG-T326, AG-T327, AG-T328, AG-T329, AG-T330, AG-T331, AG-T332, AG-T333, AG-T334, AG-T335, AG-T336, AG-T337, AG-T338, AG-T339, AG-T340, AG-T341, AG-T342, AG-T343, AG-T344, AG-T345…

Text truncated - open the document above for the full version.

Report No.: TZ0120250701PH01 Page 1 of 1 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz
