电池管理系统 BatteryManagementSystem 电池保护板APP使用说明书 UserManualforBatteryProtectionBoardAPP 版本号（Version）V2.1.15+ 撰写者（DocumentWriter）高康 发布时间（WriterTime）2025-3-25 一、软件概述SoftwareOverview 电池保护板APP软件，简称：ZXH-BMS；它是一款专门为管理和 维护电池状态而设计的移动应用程序。它与电池保护板硬件协同工 作，通过蓝牙、Wi-Fi或其它通信方式连接，为用户提供对电池各项 参数的实时监测、控制以及保护功能，旨在确保电池安全、稳定、高 效地运行，延长电池使用寿命，广泛应用于各类使用可充电电池的设 备，如电动车、储能设备、便携式电子产品等。 TheBatteryProtectionBoardAPPsoftware,abbreviatedasZXH-BMS,isa mobileapplicationspecificallydesignedformanagingandmaintainingthe batterystatus.Itworksinconcertwiththebatteryprotectionboardhardware andconnectsthroughBluetooth,Wi-Fi,orothercommunicationmethods.It providesuserswithreal-timemonitoring,control,andprotectionfunctions forvariousbatteryparameters,aimingtoensurethesafe,stable,andefficient operationofthebattery,extendthebatteryservicelife,andiswidelyapplied tovariousdevicesusingrechargeablebatteries,suchaselectricvehicles, energystoragedevices,andportableelectronicproducts. 二、功能介绍FunctionIntroduction 实时参数监测：能够实时获取并展示电池的关键参数。例如它可 实时显示电池的电压，让用户了解电池当前的剩余电量状态，判断是 否需要充电；显示电流，帮助用户知晓电池充放电时的电流大小，评 估电池工作负载情况；还能监测电池温度，因为过高或过低的温度都 可能影响电池性能与寿命，及时掌握温度信息可避免电池在不良环境 下工作。这些实时参数通常以数字、图表等直观形式呈现在手机APP 界面，方便用户一目了然地获取电池状态。 Real-timeParameterMonitoring TheAPPcanobtainanddisplaythekeyparametersofthebattery inreal-time.Forexample,itcanshowthebatteryvoltage inreal-time,allowinguserstounderstandthecurrent remainingpowerstatusofthebatteryandjudgewhetheritneeds tobecharged.Itcanalsodisplaythecurrent,helpingusers knowthemagnitudeofthecurrentduringbatterychargingand discharging,andevaluatethebattery'sworkingload. Additionally,itcanmonitorthebatterytemperature.Since bothtoohighandtoolowtemperaturescanaffectthebattery performanceandlifespan,timelyaccesstotemperature informationcanpreventthebatteryfromoperatinginadverse environments.Thesereal-timeparametersareusually presentedinanintuitivewaysuchasnumbersandchartsonthe mobileAPPinterface,allowinguserstoclearlyobtainthe batterystatusataglance. 充放电管理：在充电方面，APP可设置充电截止电压、电流限制 等参数。 Charge-DischargeManagement Intermsofcharging,theAPPcansetparameterssuchasthe chargingcut-offvoltageandcurrentlimit. 故障诊断与报警：APP具备强大的故障诊断功能，持续监测电池 保护板及电池的运行状况。一旦检测到异常，如电池过压、欠压、过 流、短路或电池保护板硬件故障等情况，APP还会详细显示故障类型 及可能的原因，例如显示“电压检测线开路、高温保护、限流充电、 短路保护”，帮助用户快速定位并解决问题，保障电池系统安全运行。 FaultDiagnosisandAlarm TheAPPhasapowerfulfaultdiagnosisfunctionand continuouslymonitorstheoperatingstatusofthebattery protectionboardandthebattery.Onceabnormalitiesare detected,suchasbatteryover-voltage,under-voltage,over -current,short-circuit,orhardwarefailuresofthebattery protectionboard,etc.,theAPPwillalsodisplayindetailthe typeoffaultandpossiblecauses.Forexample,itwillshow "opencircuitofvoltagedetectionline,high-temperature protection,current-limitedcharging,short-circuit protection",helpingusersquicklylocateandsolveproblems toensurethesafeoperationofthebatterysystem. 电池健康评估：通过对电池充放电数据，APP显示电池健康状态， 用户根据电池当前健康状态进行评估，预测电池剩余使用寿命，让用 户提前做好电池更换等相关准备。 BatteryHealthAssessment Throughtheanalysisofbatterycharge-dischargedata,the APPdisplaysthebatteryhealthstatus.Userscanevaluatethe batterybasedonitscurrenthealthconditionandpredictthe remainingservicelifeofthebattery,enablinguserstomake preparationsinadvanceforbatteryreplacementandother relatedmatters. 保护板固件升级：随着技术的不断进步与优化，电池保护板的固 件也需要适时更新。APP为用户提供便捷的保护板固件升级功能。当 有新的固件版本可用时，用户可以选择下载进入升级。 ProtectionBoardFirmwareUpgrade Withthecontinuousprogressandoptimizationoftechnology, thefirmwareofthebatteryprotectionboardalsoneedstobe updatedinatimelymanner.TheAPPprovidesuserswitha convenientprotectionboardfirmwareupgradefunction.Whena newfirmwareversionisavailable,userscanchoosetodownload andproceedwiththeupgrade. 保护板电流校准：在电池保护板长期使用过程中，由于电子元件 老化、环境因素影响等，可能导致电流监测出现偏差。准确的电流监 测对于电池的充放电管理和安全保护至关重要，因此APP提供了保 护板电流校准功能。 ProtectionBoardCurrentCalibration Duringthelong-termuseofthebatteryprotectionboard,due tofactorssuchastheagingofelectroniccomponentsandthe influenceoftheenvironment,deviationsmayoccurincurrent monitoring.Accuratecurrentmonitoringiscrucialforthe charge-dischargemanagementandsafetyprotectionofthe battery.Therefore,theAPPprovidesaprotectionboardcurrent calibrationfunction. 保护板参数配置：合理的保护板参数配置对于电池的高效运行和 长久使用起着关键作用。APP允许用户根据电池的实际情况和使用需 求对保护板的多项参数进行灵活配置。 ProtectionBoardParameterConfiguration Reasonableparameterconfigurationoftheprotectionboard playsacrucialroleintheefficientoperationandlong-term useofthebattery.TheAPPallowsuserstoflexiblyconfigure multipleparametersoftheprotectionboardaccordingtothe actualsituationandusagerequirementsofthebattery. 三、下载与安装Downloadandinstallation 3.1客户端二维码 Client-sideQRcode 3.1.1ZXH-BMSAndroid客户端Client 方式一：根据上方提供的二维码进行扫码，选择安装合适版本。 Method1:ScantheQRcodeprovidedaboveandthenchooseto install. 方式二：在浏览器输入网址，选择安装合适版本。 https://mestts.zhixinhang.com/pages/app/zxhbms Method2:EnterthewebsiteURLinthebrowser,thenselectand installtheappropriateversion. 方式三：（国外）通过GooglePlay搜索“ZXH-BMS”,搜索成功之 后，选择安装。【对不起，此下载渠道暂未开通】 Method3(Foroverseasusers):Searchfor"ZXH-BMS"onGoogle Play.Afterasuccessfulsearch,selecttheoptiontoinstall. [Sorry,thisdownloadchannelisnotyetavailable. 3.1.2ZXH-BMSiOS客户端 Client 方式一：根据上方提供的二维码进行扫码，选择安装。 Method1:ScantheQRcodeprovidedaboveandthenchooseto install. 方式二：通过AppStore搜索“ZXH-BMS”,搜索成功之后，选择安装。 Method2:Searchfor"ZXH-BMS"intheAppStore.Aftera successfulsearch,select"Install". 四、操作教程OperationTutorial 功能一：打开手机蓝牙功能 打开手机“设置”，找到“蓝牙”，点击开启。 Function1:TurnontheBluetoothFunctionoftheMobilePhone Openthe"Settings"onthemobilephone,find"Bluetooth",and clicktoturniton. 安卓Android苹果Apple/iPad 功能二：启动 APP 上图所示：APP图标 （1）在手机屏幕上，找到ZXH-BMS（上图所示），点击启动。 （2）ZXH-BMS首次运行时，弹出提示权限授权窗口。 （3）请您选择允许，否则可能无法搜索到蓝牙。 如果因拒绝权限授权，造成设备列表无法自动发现蓝牙信息，则 需要卸载APP，然后重新安装APP。 重新安装完成后，第一次启动APP时，系统弹出授权提示窗口， 请选择“允许”。 Function2:LaunchtheAPP Asshowninthepictureabove:APPIcon (1)Onthemobilephonescreen,findZXH-BMS(asshowninthe pictureabove)andclicktolaunchit. (2)WhenZXH-BMSrunsforthefirsttime,apermission authorizationpromptwindowwillpopup. (3)Pleaseselect"Allow",otherwiseyoumaynotbeableto searchforBluetoothdevices. Ifyourefusethepermissionauthorizationandasaresult,the dev…
