2BS3U-PBDGW001Pebby AI toy

Hangzhou Pebby Intelligent Technology Co., Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 02, 2025
Application Purpose: Original Equipment
Equipment Note: Pebby AI toy
Frequency Range: 2402.00000000 - 2480.00000000
Company: Hangzhou Pebby Intelligent Technology Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

PBDGW系列-英文 Smart Al Plush Puppy User Manual Product Overview Smart Al Plush Puppy is an intelligent toy that integrates AI voice interaction with an electric plush doll, providing vivid and fun interactive experiences such as chatting companionship, playing nursery rhymes and stories, and answering general knowledge questions. App Installation "Smart Partner" is a mobile application designed specifically for smart devices. Please search for and download the "Smart Partner" App from the app store to easily manage your devices Device Reset and Pairing Enter Pairing Mode 1. Turn on the switch at the bottom of the device. 2. When you hear a looping prompt tone, it indicates that the device has successfully entered pairing mode. 3. If there is no prompt tone after powering on, long-press the device button for about 10 seconds until the prompt tone plays. The device will restore factory settings and re-enter pairing mode. Pair with the App Open the "Smart Partner" App, click the "+" icon in the upper right corner to enter the device pairing page. Note the following during pairing: 1. Ensure that your phone's Bluetooth and location services are enabled. 2. Use a 2.4GHz Wi-Fi network for pairing (5GHz Wi-Fi is not supported). 3. During pairing, keep your new device as close to the Wi-Fi router as possible to improve pairing accuracy. 4. Follow the in-App prompts to complete the device pairing process. Device Control Device Wake-up and Sleep • Wake-up: Click the device button. After hearing the prompt "I'm here!", the device enters smart conversation mode. • Sleep: It will automatically enter low-power mode after 3 minutes of inactivity and needs to be clicked again to wake up. Smart Conversation Control • During voice playback: Click the button to interrupt the current playback and enter the listening mode. • In listening mode : ￮ Automatically enters the reply state 2 seconds after the user stops speaking. ￮ Clicking during speaking can end voice input early. ￮ Clicking without voice input ends the current session. Play Instructions After the puppy is powered on, if the network connection is successful, it will automatically enter the online AI conversation mode. Voice Command Interaction • Simple commands : Directly say commands, e.g., "Puppy, do a street dance!" • Complex commands : Say multi-step commands, e.g., "Puppy, run a few steps forward, then lie down and act cute!" • Interrupt speech : Press the button to interrupt the current playback at any time. Voice Games and Learning • Idiom solitaire : Say "Let's play idiom solitaire!" to start the game. • General knowledge Q&A : Directly ask questions, e.g., "Where is the third highest mountain in the world?" • Role-playing : Say "Switch to Guard/Explorer" to change identities. • Story co-creation : Interact with the puppy in role-playing mode to create stories. Play Music and Stories • Play nursery rhymes : Say "Play 'Happy Birthday Song'." • Listen to stories : Say "Tell me a children's story." Other Functions • End the conversation : Say "Goodbye, Puppy!" to end the interaction. • Status settings : Say commands like "Adjust the volume to maximum." • Status query : Ask questions like "How much battery do you have left?" Offline Play Modes • Offline interaction mode : Touching the puppy's head triggers it to randomly perform different actions for interactive fun. • Repeat mode : The puppy will repeat the user's words in a fun voice. After the puppy finishes repeating, wait for the "ding" sound before speaking again. • Offline music mode : The puppy automatically plays built-in nursery rhymes in order; click the button to switch songs. Warning 1. Non-waterproof product. Forbid use in underwater or humid environments. 2. Avoid using or storing in high-temperature environments. 3. Do not obstruct the motor movement to prevent mechanical failure. Specifications Product name : Smart Al Plush Puppy (Schnauzer)Dimensions: 33x12x22 cm (13 x 4.7 x 8.6 in) Weigh t: 402 g (14.1 oz) Battery : 1000 mAh 3.7 V lithium battery Charging port : USB-C Wireless protocol : 2.4GHz Wi-Fi (5 GHz not supported) Package conten t: Plush puppy x 1, USB-C charging cable x 1 FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

RF Exposure Info

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : CTA25092202403 2BS3U-PBDGW001 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 26, 2025 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Hangzhou Pebby Intelligent Technology Co., Ltd Address............................................ : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Pebby AI toy Trade Mark ........................................ Pebby Manufacturer .................................... : Hangzhou Pebby Intelligent Technology Co., Ltd Model/Type reference ...................... : PBDGW001 Listed Models ................................... : PBDGW002, PBDGW003, PBDGW004, PBDGW005, PBDGW006, PBDGW007, PBDGW008, PBDGW009, PBDGW010 Rating ............................................... : Input: 5V 1A Battery: 3.7V 1000mAh 3.7Wh Result ............................................... : PASS Report No.: CTA25092202403 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Pebby AI toy Model /Type : PBDGW001 Listed Models : PBDGW002, PBDGW003, PBDGW004, PBDGW005, PBDGW006, PBDGW007, PBDGW008, PBDGW009, PBDGW010 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number, the design of the exterior fabric, and the colors are different for these model. Applicant : Hangzhou Pebby Intelligent Technology Co., Ltd Address : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Manufacturer : Hangzhou Pebby Intelligent Technology Co., Ltd Address : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25092202403 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 Conducted Power Results ....................................................................................... 7 4.3 Manufacturing tolerance .......................................................................................... 8 4.4 Evaluation Result ..................................................................................................... 8 4.5 Simultaneous Transmission for SAR Exclusion ...................................................... 8 5 C…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: 2BS3U-PBDGW001 Test Setup Photos of the EUT FCC ID: 2BS3U-PBDGW001

Test Report

1 FCC Appendix RF Test Data for BLE Company: : Hangzhou Pebby Intelligent Technology Co., Ltd EUT : Pebby AI toy Model Number : PBDGW001 FCC ID : 2BS3U-PBDGW001 Report No. : CTA25092202401 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.648 2401.688 2402.336 0.5 PASS 2440 0.632 2439.704 2440.336 0.5 PASS 2480 0.652 2479.688 2480.340 0.5 PASS 3 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 4 5 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0051 2401.5157 2402.5208 --- --- 2440 1.0024 2439.5186 2440.5210 --- --- 2480 1.0074 2479.5160 2480.5234 --- --- 6 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 7 8 Appendix C: Maximum conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 -0.03 ≤30 PASS 2440 -0.40 ≤30 PASS 2480 -0.41 ≤30 PASS 9 Appendix D: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -15.71 ≤8.00 PASS 2440 -15.86 ≤8.00 PASS 2480 -15.92 ≤8.00 PASS 10 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 11 12 Appendix E: Band edge measurements Test Result TestMod e Antenn a ChNam e Freq(MHz ) RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t BLE_1M Ant1 Low 2402 0.06 -52.12 ≤-19.94 PASS High 2480 -0.44 -51.37 ≤-20.44 PASS 13 Test Graphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 14 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference -1.47 -1.47 --- PASS 30~1000 -1.47 -67.57 ≤-21.47 PASS 1000~26500 -1.47 -41.29 ≤-21.47 PASS 2440 Reference -1.13 -1.13 --- PASS 30~1000 -1.13 -67.93 ≤-21.13 PASS 1000~26500 -1.13 -42.68 ≤-21.13 PASS 2480 Reference -2.39 -2.39 --- PASS 30~1000 -2.39 -67.37 ≤-22.39 PASS 1000~26500 -2.39 -44.05 ≤-22.39 PASS 15 Test Graphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 16 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 17 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 18 BLE_1M_Ant1_2480_1000~26500 19 Appendix G: Duty Cycle Test Result TestMode Antenna Freq(MHz) ON Time [ms] Period [ms] X DC [%] xFactor Limit Verdict BLE_1M Ant1 2402 0.41 0.62 0.6613 66.13 1.80 --- --- 2440 0.41 0.62 0.6613 66.13 1.80 --- --- 2480 0.41 0.62 0.6613 66.13 1.80 --- --- 20 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 21

Test Report

33 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 34 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 35 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 36 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 37 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 38 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 39 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 40 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 41 11N40SISO_Ant1_2452_1000~26500 42 Appendix G: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11G Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11N20SISO Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11N40SISO Ant1 2422 20.00 20.00 100.00 2437 20.00 20.00 100.00 2452 20.00 20.00 100.00 43 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 44 11G_Ant1_2412 11G_Ant1_2437 45 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 46 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 47 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452

Test Report

1 FCC Appendix RF Test Data for 2.4GWIFI Company: : Hangzhou Pebby Intelligent Technology Co., Ltd EUT : Pebby AI toy Model Number : PBDGW001 FCC ID : 2BS3U-PBDGW001 Report No. : CTA25092202402 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.280 2408.040 2416.320 0.5 PASS 2437 9.040 2432.520 2441.560 0.5 PASS 2462 8.760 2457.560 2466.320 0.5 PASS 11G Ant1 2412 16.320 2403.880 2420.200 0.5 PASS 2437 16.360 2428.880 2445.240 0.5 PASS 2462 16.320 2453.920 2470.240 0.5 PASS 11N20SISO Ant1 2412 17.280 2403.400 2420.680 0.5 PASS 2437 17.360 2428.360 2445.720 0.5 PASS 2462 17.200 2453.400 2470.600 0.5 PASS 11N40SISO Ant1 2422 33.920 2405.360 2439.280 0.5 PASS 2437 33.840 2420.280 2454.120 0.5 PASS 2452 34.000 2435.200 2469.200 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 7 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 8 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.941 2405.5947 2418.5357 --- --- 2437 12.994 2430.5225 2443.5165 --- --- 2462 13.019 2455.5152 2468.5342 --- --- 11G Ant1 2412 16.583 2403.7480 2420.3310 --- --- 2437 16.576 2428.7498 2445.3258 --- --- 2462 16.559 2453.7596 2470.3186 --- --- 11N20SISO Ant1 2412 17.462 2403.3173 2420.7793 --- --- 2437 17.464 2428.3147 2445.7787 --- --- 2462 17.441 2453.3108 2470.7518 --- --- 11N40SISO Ant1 2422 34.836 2404.7041 2439.5401 --- --- 2437 34.807 2419.7494 2454.5564 --- --- 2452 34.797 2434.7055 2469.5025 --- --- 9 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 10 11G_Ant1_2412 11G_Ant1_2437 11 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 12 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 13 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 14 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Maximum Peak conducted output power [dBm] Limit [dBm] Verdict 11B Ant1 2412 6.93 ≤30.00 PASS 2437 6.82 ≤30.00 PASS 2462 7.24 ≤30.00 PASS 11G Ant1 2412 4.75 ≤30.00 PASS 2437 5.63 ≤30.00 PASS 2462 5.93 ≤30.00 PASS 11N20SISO Ant1 2412 5.23 ≤30.00 PASS 2437 6.02 ≤30.00 PASS 2462 6.22 ≤30.00 PASS 11N40SISO Ant1 2422 4.57 ≤30.00 PASS 2437 4.95 ≤30.00 PASS 2452 5.13 ≤30.00 PASS 15 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -21.84 ≤8.00 PASS 2437 -22.60 ≤8.00 PASS 2462 -21.53 ≤8.00 PASS 11G Ant1 2412 -29.62 ≤8.00 PASS 2437 -28.71 ≤8.00 PASS 2462 -28.49 ≤8.00 PASS 11N20SISO Ant1 2412 -29.37 ≤8.00 PASS 2437 -28.50 ≤8.00 PASS 2462 -28.37 ≤8.00 PASS 11N40SISO Ant1 2422 -30.73 ≤8.00 PASS 2437 -30.17 ≤8.00 PASS 2452 -29.82 ≤8.00 PASS 16 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 17 11G_Ant1_2412 11G_Ant1_2437 18 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 19 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 20 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 21 Appendix E: Band edge measurements Test Result TestMode Antenn a ChNam e Frequency[MH z] RefLevel[dB m] Result[dB m] Limit[dBm ] Verdic t 11B Ant1 Low 2412 -6.71 -56.67 ≤-26.71 PASS High 2462 -6.75 -57.54 ≤-26.75 PASS 11G Ant1 Low 2412 -15.36 -55.96 ≤-35.36 PASS High 2462 -14.83 -57.91 ≤-34.83 PASS 11N20SIS O Ant1 Low 2412 -15.65 -56.39 ≤-35.65 PASS High 2462 -15.18 -58.18 ≤-35.18 PASS 11N40SIS O Ant1 Low 2422 -18.89 -57.17 ≤-38.89 PASS High 2452 -18.23 -57.72 ≤-38.23 PASS 22 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 23 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 24 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 25 26 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference -6.91 -6.91 --- PASS 30~1000 -6.91 -61.17 ≤-26.91 PASS 1000~26500 -6.91 -44.12 ≤-26.91 PASS 2437 Reference -7.24 -7.24 --- PASS 30~1000 -7.24 -60.49 ≤-27.24 PASS 1000~26500 -7.24 -44.89 ≤-27.24 PASS 2462 Reference -6.62 -6.62 --- PASS 30~1000 -6.62 -61.37 ≤-26.62 PASS 1000~26500 -6.62 -45.37 ≤-26.62 PASS 11G Ant1 2412 Reference -16.06 -16.06 --- PASS 30~1000 -16.06 -64.31 ≤-36.06 PASS 1000~26500 -16.06 -44.13 ≤-36.06 PASS 2437 Reference -15.44 -15.44 --- PASS 30~1000 -15.44 -64 ≤-35.44 PASS 1000~26500 -15.44 -44.71 ≤-35.44 PASS 2462 Reference -15.02 -15.02 --- PASS 30~1000 -15.02 -63.91 ≤-35.02 PASS 1000~26500 -15.02 -45.38 ≤-35.02 PASS 11N20SISO Ant1 2412 Reference -15.93 -15.93 --- PASS 30~1000 -15.93 -64.51 ≤-35.93 PASS 1000~26500 -15.93 -44.22 ≤-35.93 PASS 2437 Reference -15.65 -15.65 --- PASS 30~1000 -15.65 -64.38 ≤-35.65 PASS 1000~26500 -15.65 -44.5 ≤-35.65 PASS 2462 Reference -15.09 -15.09 --- PASS 30~1000 -15.09 -64.19 ≤-35.09 PASS 1000~26500 -15.09 -45.32 ≤-35.09 PASS 11N40SISO Ant1 2422 Reference -19.06 -19.06 --- PASS 30~1000 -19.06 -65.83 ≤-39.06 PASS 1000~26500 -19.06 -44.43 ≤-39.06 PASS 2437 Reference -18.62 -18.62 --- PASS 30~1000 -18.62 -65.93 ≤-38.62 PASS 1000~26500 -18.62 -44.77 ≤-38.62 PASS 2452 Reference -18.64 -18.64 --- PASS 30~1000 -18.64 -65.96 ≤-38.64 PASS 1000~26500 -18.64 -45.17 ≤-38.64 PASS 27 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 28 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 29 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 30 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 31 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 32 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500

Test Report

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA25092202402 2BS3U-PBDGW001 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 26, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : Hangzhou Pebby Intelligent Technology Co., Ltd Address ............................................ : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Pebby AI toy Trade Mark ....................................... : Pebby Manufacturer .................................... : Hangzhou Pebby Intelligent Technology Co., Ltd Model/Type reference ...................... : PBDGW001 Listed Models ................................... : PBDGW002, PBDGW003, PBDGW004, PBDGW005, PBDGW006, PBDGW007, PBDGW008, PBDGW009, PBDGW010 Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : Input: 5V 1A Battery: 3.7V 1000mAh 3.7Wh Result ............................................... : PASS Report No.: CTA25092202402 Page 2 of 27 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Pebby AI toy Model /Type : PBDGW001 Listed Models : PBDGW002, PBDGW003, PBDGW004, PBDGW005, PBDGW006, PBDGW007, PBDGW008, PBDGW009, PBDGW010 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number, the design of the exterior fabric, and the colors are different for these model. Applicant : Hangzhou Pebby Intelligent Technology Co., Ltd Address : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Manufacturer : Hangzhou Pebby Intelligent Technology Co., Ltd Address : 518-11, Building 1, 237 Sansheng Street, Qiaosi Street, Linping District, Hangzhou City, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25092202402 Page 3 of 27 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 6 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT .......................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.
