2BS79-K80dash camera

P S E RoHS Version 1.0

- 20 - 1.This dash cam records external footage of moving vehicles. It does not provide physical protection in accidents. We are not liable for traffic incidents, device failures, data loss, or operational consequences. 2.Product performance may vary due to differences in vehicle types, driving habits, environmental factors, and more. Conditions such as power loss, extreme temperatures or humidity, physical damage, and microSD card issues can interfere with normal recording. Not all recorded videos are guaranteed to be fully saved under all circumstances. Images captured by this device are solely for reference. 3.Ensure to properly install this device. Avoid blocking the driver's view or interfering with airbag deployment. Position the device at least 20cm from drivers and passengers. Improper installation could result in product failure or injury. 4.To avoid damage, keep the device clear of strong magnetic fields. 5.To maintain data integrity, refrain from inserting or removing the microSD card while the product is operating. 6.Over time, the microSD card might incur damage from continuous use. Timely replacement can prevent data loss. We are not liable for issues resulting from failed TF cards. 7.While the device can record and save footage of traffic accidents, not all accident footage is guaranteed to be captured and stored. Minor collisions may not be sensed and thus, may not be included in the event videos. 8.For optimal device performance, refrain from using it in extreme tempera-tures —above 60 or below -10. 9.Extensive periods of non-use can lead to battery discharge. If this happens, you may need to reset the device time upon restart. 10.Avoid unnecessary shaking or pressure to prevent damage to the product. 11.The use of chemical solvents or cleaners for this product is not recommended. 12.Please use this product within legal guidelines. 13.Avoid operating, installing, or adjusting the camera's settings while driving. Always pull off the road and perform these actions when it's safe to do so. 14.Please note that the device housing may become warm during operation. Notice - 21 - FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation Operations in the 5150-5250MHz band are restricted to indoor usage only. Any emission is maintained within the band of operation under all conditions of n ormal operation. The max. frequency stability is less than 20ppm. FCC Statement - 22 - Dear Valued Customer, Thank you for choosing ORSKEY — a trusted brand in smart electronic devices. We are committed to delivering high-quality, reliable products and exceptional customer support throughout your ownership experience. All ORSKEY devices undergo rigorous multi-stage quality inspections and comply with international safety and regulatory standards, including FCC, CE, UKCA, and RoHS. While no electronic product is entirely immune to rare functional issues, we stand behind every device with comprehensive technical assistance and warranty protection. ◆ Warranty Coverage Your ORSKEY dash cam comes with a Limited Warranty that covers defects in materials and workmanship under normal use: ● Standard Warranty Period: 12 months from the date of purchase ● Extended Warranty: Up to 18 months total — register your product within 14 days to receive an additional 6 months of coverage at no cost. What Is Covered: ● Manufacturing defects affecting device functionality ● Faulty components resulting in performance failure during the warranty period ● Free repair or replacement (with original or equivalent model) for covered issues What Is NOT Covered: ● Cosmetic wear, scratches, or normal aging of materials ● Damage caused by accidental drops, water exposure, fire, extreme temperatures, or other external factors ● Issues due to improper installation, misuse, neglect, or unauthorized repairs/ modifications ● Use of non-compatible or third-party accessories ● Data loss resulting from user error, formatting, or unforeseen circumstances ● Consumable parts or batteries subject to natural degradation Note: The warranty applies only to the original purchaser and is non- transferable. It does not cover shipping costs for returns unless a defect is confirmed. Incidental or consequential…

Text truncated - open the document above for the full version.

Troubleshooting - 18 - Why does the dash cam display "Card Error," "Card Full," or "Please Format Memory Card"? 1.Format the memory card to resolve potential data errors or fragmentation issues. 2. Go to "System Settings" > "Format Reminder" and check if the memory card format prompt feature is enabled. 3.If the issue persists, restore the dash cam to factory settings and restart it. 4.If the issue persists, the memory card may be incompatible, counterfeit, or damaged. We recommend testing with a high-quality, compatible memory card. Why does the device keep restarting or fail to start? 1.Use the charger/cable provided with the device to avoid issues caused by incompatible power adapters. 2. Remove the memory card and press the power button once to check if the device starts normally. If the device experiences lag, delays, or fails to record videos, this could indicate poor performance or damage to the memory card. 3.Disconnect the camera cable and car charger, then reconnect them and check if the issue is resolved. 4.Connect the device to a smartphone USB charger using a different USB cable and plug it into a home wall outlet for a power test. If the device starts normally in this case, the issue may be with the car charger; if it still fails to power on, there may be a hardware fault with the dash cam itself. 5.While keeping the device plugged in, gently press the reset hole on the bottom with a pen tip or paperclip to reset the dash cam. 6.If the issue remains unresolved, please contact our customer service team for further support. Why does the screen show "Mass Storage"? When using a USB cable with data transfer capabilities, the device enters file transfer mode, displaying "Mass Storage" on the screen. In this mode, the device only supports data transfer, and other functions will be paused. For optimal performance, use the original car charger or a USB cable without data transfer capabilities for power supply. Troubleshooting Why can't I connect to Wi-Fi? 1.Ensure the operating distance is within 2 meters to maintain a stable Wi-Fi signal connection. 2.Verify that the entered Wi-Fi SSID and password are correct and confirm that the network is not being used by other devices. If you forget the password, it can be reset by restoring factory settings. 3. Turn off mobile data and VPN services on your phone to rule out interference. 4.If the issue persists, please contact our customer service team for further support. Why is the device's time displayed incorrectly? 1.Check if the "GPS Auto Time Sync" feature is enabled. 2.Go to "System Settings" > "Time Zone" and confirm that the current time zone matches your actual location. 3.Verify whether the daylight saving time function is correctly turned on or off based on your needs to ensure accurate time display. - 19 -

1.After activation, the screen displays the parking monitoring icon, then turns off, and the indicator light turns red. 2.Parking Mode Function Settings Recommendations To optimize performance and protect your car's battery, set the continuous monitoring duration based on battery age: ●New batteries (within 1 year): Maximum 48 hours. ●Batteries aged 1–2 years: Maximum 24 hours. ●Batteries older than 2 years: Maximum 12 hours. 3. Avoid Wiring Errors: Two wiring errors can disrupt the parking mode: ● Connecting yellow and red wires to ACC power disables parking monitoring. ●Connecting both wires to Battery power keeps the dash cam active, draining the battery. Important: Incorrect wiring may cause battery drain, short circuit, or permanent vehicle damage. Verify parking mode functionality by waiting 15 minutes after engine shutdown, as some vehicles have a delayed power-off feature. S5 Hardwire Kit Installation Tips - 17 -

Step 2: Wi-Fi Activation: Press and hold the ▼ (down key) until the Wi-Fi icon appears on the screen. Ensure your phone remains within 2 meters (6.5 feet) of the device during this process. Step 3: Connect via the AMGEKE App Open the AMGEKE app and tap "+ Connect Device" on the home screen. Network Pairing ● For Android:The app automatically detects nearby networks. Select ORSKEY_XX X_XXXXXX and enter password 12345678. ● For iOS: Tap "Search on WLAN page", go to Settings > Wi-Fi, Select ORSKEY _XXX_XXXXXX, and enter password 12345678. Safety & Usage Tips ● Perform all steps only when the vehicle is parked. ● Set password protection for the dash cam's Wi-Fi to control device access. ● If you forget the Wi-Fi password, access the device's Settings menu and use the 'Default Settings' function to restore the default password. Connect & Control via App The ORSKEY dash cam features a built-in Wi-Fi module for direct smartphone pairing. Use the AMGEKE app to view live footage, playback recordings, and download content without mobile data usage. Connection Steps: Step 1: Download the "AMGEKE" App: Scan the QR code on the packaging or search "AMGEKE" in the Apple App Store or Google Play Store - 15 - - 16 - S5 Hardwire Kit Installation The S5 Dash Cam Hardwire Kit (USB Type-C connector) is designed exclusively for ORSKEY dash cams to enable advanced parking mode. Note: This accessory is sold separately and not included in the standard package . Step 1: Fuse Identification Locate your vehicle’s fuse box (typically in the glove compartment, trunk, or engine bay). Common fuse types: ATC, ATS, MICRO2, MINI (MINI is most common). Remove the panel cover to access the fuses. Refer to your vehicle’s manual for details . Step 2: Locating ACC & Battery Fuses Use a multimeter or circuit tester to find: ●ACC Fuse (Yellow): A slot active only when the ignition is turned on (e.g., audio system, power outlet). ●Battery Fuse (Red): A slot with constant power (even when ignition is off; e.g., hazard lights) Step 3: Removing Fuses With the ignition key removed, carefully remove the identified ACC and Battery fuses. Place them into the add-a-fuse connector in the kit. Step 4: Crimping Connectors Insert the bullet connectors into the color-coded adapters. Secure the joints with wire crimps or pliers, ensuring insulation covers all connections. Step 5: Installing Fuse Tap & Ground Wire Insert the fuse tap cable, attach the black Ground connector to a ground screw or bolt, then connect the hardwire kit to the dash cam. Step 6: Final Check Start the vehicle to verify power supply.The kit supports continuous parking mode and automatically cuts power when voltage drops to prevent battery drain. If needed, consult a professional installer.

- 14 - System Settings 1. The S5 hardwiring kit is required to enable Advanced Parking Mode recording and is sold separately. 2.1fps represents one image captured per second. All parking surveillance videos are saved in Parking folders.The front camera's parking recording files are named as Year_Date_Time_******A, and Year_Date_Time_******B for the rear camera. Note Volume: Allow you to select the volume that suits you best. Options: OFF / Low / Middle / High Boot-up Sound: Enable or disable the start-up tone. Options: ON / OFF Beep Sound: Enable or disable all system alert tones. Options: ON / OFF LED Status Indicator: Control the device's LED Status Indicator light on/off. Options: ON / OFF Fatigue Driving Reminder: When enabled, it will issue a prompt within the set time to remind you to take a timely break and ensure your safety. ● Options: OFF / 1 Hour / 2 Hours / 3 Hours / 4 Hours Format Reminder: The device periodically reminds you to format the storage card, reducing risk of data corruption from prolonged use. •Options: OFF / 15 Days / 30 Days / 60 Days / 90 Days Storage Space: Check the memory card's capacity usage. License Plate: Optionally input your vehicle's license plate number to overlay it on recorded videos. Format: Formatting the Micro SD card will permanently erase all data stored on it. Before proceeding, ensure you have backed up any important files, as the operation cannot be undone. Default Setting: Reset all configurations to the original factory state. APP: Download the app by scanning the QR code. Card Speed Test: Checks the memory card's quality to determine if it meets the device's usage standards. Version: Check the installed firmware version for updates.

- 09 - Adjust collision detection sensitivity via the G-sensor menu in device settings. Protected files save to the ORSDC/Event folder . Note Operation Guidance Power On / OFF Recording Mode Insert a compatible microSD card to enable automatic loop recording when power is detected. Configure video durations to 1/2/3/5-minute intervals. When storage is full, the system overwrites the oldest files sequentially. All recordings save to the ORSDC/Video directory . Emergency Recording If the G-sensor detects a collision or significant impact, the system automatically creates a protected video clip and locks it to prevent overwriting . To preserve evidence: 1) Connect to the device via the AMGEKE app immediately after an incident to download the locked clip. 2) For extended footage, manually lock and download additional recordings through the app . ● Automatic: The dash cam powers on and starts recording when the vehicle’s engine is started. It stops recording and powers off when the engine is turned off or the charging cable is disconnected. ● Manual: Press and hold the Power Button to turn the device on or off . Note: Some vehicles supply continuous power to 12V accessory sockets even when locked. This may disrupt automatic power on/off. Prolonged recording while the vehicle is stationary can drain the battery (risk of insufficient charge for engine start). To mitigate this: ● Install the ORSKEY S5 Hardwire Kit (direct fuse box integration), or ● Reconfigure your fuse box to activate the 12V outlet only when the ignition is in ACC or ON position . - 10 - 1. Front and rear camera recordings save as separate files. 2. Front files are named Year_Date_Time_A, rear files Year_Date_Time_B. Note ModeDescription Dual View(Rear Overlay) Dual View(Front Overlay) Front Only Rear Only Shows feeds from both cameras, rear preview on upper left. Shows both feeds, front preview on upper left. Shows front camera preview exclusively. Shows rear camera preview exclusively. Operation Guidance Playback Videos In standby or recording mode, press and hold the Menu Button to open the video playlist. Use the Up/Down Buttons to select a video, then press the Power Button to start playback. Press and hold the Menu Button again to exit playback . Connection to Computer For optimal playback, transfer files to your computer and use VLC Media Player for decoding . Front and Rear Camera Display Options(For K80 Model） When the rear camera is connected via the dedicated AV input, the LCD supports four live preview modes: 1.Connect the camera to your computer using the included USB Type-C Data Cable (0.8m / 2.6ft). 2.Select “Mass Storage” on the camera when prompted. Your computer will detect a “Removable Disk” drive. 3.Videos are stored in the ORSDC folder with four subfolders: ○ Loop: Unlocked files for loop recording (manually lock via device playback or app). ○ Emergency: Protected clips triggered by collisions (G-sensor). ○ Photos: Unlocked still images captured from video streams. ○ Time-lapse: Unlocked time-lapse and parking monitoring footage. System Settings Resolution: Select your preferred video resolution for recordings. ※ Single-channel recording: ● 4K 30fps ● 2K 60fps ● 2K 30fps ● 1080p 60fps ● 1080p 30fps ※ Dual-channel recording: ●4K + 1080p 30fps ●2K + 1080p 30fps ●1080p + 1080p 60/30fps ●1080p + 1080p 30fps Loop Recording: Ensures continuous recording without any interruptions. When the storage is full, it automatically overwrites the earliest footage with new recordings. Customize the video retention period to your preference. ● Options: OFF / 1 Minute / 2 Minutes / 3 Minutes / 5 Minutes WDR: WDR(Wide Dynamic Range) enhances video exposure by dynamically adjusting brightness levels across varying lighting conditions, ensuring clear visibility in challenging environments. ● Options: ON / OFF Exposure: Adjust the Exposure Value from -2.0 to +2.0 to optimize image brightness in various lighting conditions. ● Options: +2,+1.7,+1.3,+1.0,+0.7,+0.3,+0.0,-0.3,-0.7,-1.0,-1.3,-1.7,-2 G- Sensor: Detects sudden impacts or collisions through adjustable sensitivity levels, triggering automatic protection of related video files to prevent overwriting. Ensures critical footage is preserved for incident review. ● Options: OFF, Low, 2, Middle, 4, High Video Coding: Advanced Video Coding with H.265 delivers superior compression efficiency compared to H.264. ● Options: H.265 / H.264 Record Audio: Enable or disable the microphone. Adjust this setting with the UP button when not recording. ● Options: ON / OFF - 11 - System Settings - 12 - Speed Unit: Choose your preferred speed unit: Kilometers per Hour (KM/H) or Miles per Hour (MPH). Options: KM/H / MPH Frequency: Set the video recording frequency to 50Hz or 60Hz to match your region's power grid standards. ● Options: 50 Hz / 60 Hz Daylight Saving Time: Activate this feature to automatically adjust the time during daylight saving periods. Ensure compliance with local regulations for correct synchronization. ● Options: ON / OFF Date Stamp: Add date and time to videos. ● Options: ON / OFF GPS Coordinates Stamp: Embed GPS information into videos. ● Options: ON / OFF LOGO Stamp: Add the camera model to videos. ● Options: ON / OFF Speed Stamp: Display speed on videos. ● Options: ON / OFF License Plate Stamp: Overlay license plate information on videos. ● Options: ON / OFF Wi-Fi: Long-press the Down button to quickly enable Wi-Fi. ※ Limited Time: Wi-Fi turns off automatically after a set period. Ideal for most users. ※ Always: Wi-Fi stays on continuously once the device is powered on. ● Options: OFF / 2.4GHz(Limited Time) / 2.4GHz(Always) / 5GHz(Limited Time) / 5GHz(Always). WiFi Password: Set password protection for the dash cam's Wi-Fi to control device access. ● Options: ON / OFF GPS: When enabled, the GPS module embeds location data into videos. If disabled, the camera will not track speed, location, or synchronize time and date (requires a GPS signal). Use the app for video playb…

Text truncated - open the document above for the full version.

- 04 - Product Overview Integrated Memory Card Instructions Card Installation: 1. Power off the dash cam before inserting the microSD card. 2. Align the card with its label facing upward (contacts toward the base of the slot) and insert it firmly until it clicks into place . Card Removal: Ensure the dash cam is powered off and not recording. To eject, briefly press the exposed edge of the microSD card until it springs out slightly, then carefully remove it. Formatting Procedure For initial setup and monthly maintenance: ●Access Menu > Settings > Format ●Confirm action when prompted (Warning: This permanently erases all data) ●Always back up critical files before formatting LED Indicators ● Use only authentic UHS Speed Class 3 (U3) microSD cards (8GB-512GB). ● Cards ≥ 64GB require FAT32 formatting (available via your computer or the dash cam’s built-in formatting tool). ● Device malfunctions (e.g., freezing, recording interruptions) usually indicate microSD card compatibility issues . Technical Requirements LED Status Steady Green Blinking Green Steady Red Blinking Red Mode Normal Recording Emergency Event Saved Parking Surveillance System Alert Additional Information Loop recording active Triggers by G-sensor/collision Requires hardwired power connection Check storage or firmware version - 05 - Product Overview Buttons Description Mode Short Press Toggle microphone on/off — Power off the device Activate/deactivate Wi-Fi Standby Mode (Not Recording) Open system settings Start continuous recording Up Down Menu Power Long Press (2+ seconds) Access playback mode — Mode Short Press Lock emergency clip Capture video snapshot Power off the device Activate/deactivate Wi-Fi Recording Mode Open system settings Stop recording Up Down Menu Power Long Press ((2+ seconds) Access playback mode Switch view modes Mode Short Press Scroll upward Scroll downward Power off the device — System Menu Navigation Select/Confirm Back/Exit Up Down Menu Power Long Press (2+ seconds) — — Mode Short Press Slow down playback Speed up playback Power off the device Unlock protected files Playback Interface Open clip options Pause/Resume playback Up Down Menu Power Long Press (2+ seconds) Switch view modes Lock file from deletion - 06 - Installation Front Camera Installation 1) Mount Preparation: Insert the mounting clips into the camera bracket, then slide the assembly horizontally into the top slot of the bracket until it clicks . 1)Location Selection: Choose a central position on the rear windshield, avoiding defrosting grid lines and ensuring full rear coverage. 2)Surface Preparation: Clean the installation area with a dry cloth, following the same protocol as the front camera. 3)Secure Mounting: Remove the protective film from the adhesive pad and lens. Press the rear camera firmly onto the prepared surface. 4)System Integration: Power off the front camera (main unit). Connect the rear camera cable to the main unit, route the cables along the vehicle’s interior using the provided Trim Removal Tool, and avoid sharp edges or moving parts. 1 2 Front Camera Rear Camera 2)Optimal placement: Install behind the rearview mirror with a clear forward view, avoiding wiper blade coverage zones. 3)Surface Treatment: Clean the installation area thoroughly with a dry cloth, ensuring no oil or grease remains on the windshield surface. 4)Device Activation: Remove the protective film from the adhesive pad and camera lens. Use the LCD screen’s live view to align the camera angle, then press firmly to secure it . 5)Power Connection: Connect the USB power adapter to your vehicle's 12V/24V DC outlet. Insert the USB connector (3.5-meter cable) into the camera mount. Rear Camera Installation(For K80 Model） - 07 - Installation Tips 1.Ensure the camera is positioned in a way that does not obstruct the driver's view or compromise safety. 2. Place the camera near the rearview mirror to ensure balanced coverage of both sides within its field of view (FOV). 3. Position the lens within the area covered by windshield wiper sweeps for clear visibility in rain . 4.Avoid mounting near sun control film (window tint) or other electronic devices to optimize performance . 5. Do not place the camera or cables near airbag panels or within their deployment range. The manufacturer accepts no liability for injuries from airbag interference. Exercise extreme caution if your vehicle has side curtain airbags . 6.Use only the included ORSKEY USB Car Charger to avoid issues like frequent reboots or LCD flickering (insufficient power). At home, use a standard iPhone/Android USB charger. Do not use chargers exceeding 3 amps (risk of device damage) . - 08 - Display Overview IconName Recording Mode Loop Recording Emergency Lock GPS Microphone Wi-Fi Video Resolution Recording Status Recording Time NO SD Card 00:00:00 4K+1080P Advanced Parking Mode G-Sensor Fatigue Driving Reminder

ORSKEY K Series User Manual Copyright ORSKEY Ltd. All rights reserved. Contents Quick Start Guide...........................................................01 Product Overview...........................................................02 Standard Items......................................................... ...02 Product Diagram..........................................................03 Integrated Memory Card Instructions..........................04 LED Indicators..............................................................04 Buttons Description................................................. .....05 Installation................................................. .......................06 Display Overview................................... ...........................08 Operation Guidance................................... .....................09 System Settings.................................... ...........................11 Connect & Control via App............................................15 S5 Hardwire Kit Installation...........................................16 Notice..............................................................................20 FCC Statement...............................................................21 Warranty & Support Guide............................................22 Customer Service............................................................24 Troubleshooting.............................................................18 About US........................................................................24 Step 1- Memory Card Installation Before using the dash cam, insert a compatible microSD card (Class 10, UHS Speed Class 3 [U3] or higher, max. 512GB). Step 2- Power Connection Connect the dash cam to a power source using the included USB Type-C cable—it will power on automatically . ● Important: This dash cam uses a supercapacitor rather than a battery. It must remain plugged in at all times to operate. ● For temporary use, connect to a standard 5V USB wall charger (e.g., smartphone charger). Step 3- AMGEKE App Setup Download the App by scanning the QR code or searching “AMGEKE” on the Apple App Store (iOS) or Google Play Store (Android). Pair the App with the dash cam for remote access (see details on p.15). Step 4- Initial Configuration ●Set your time zone via Time Zone function using your local UTC offset (see details on p.13). ●Format the memory card via Format function (required for first-time use). Step 5- Ready to Use The dash cam operates on optimized default settings. Customize settings further via the AMGEKE App or manual controls . Quick Start Guide - 01 - Product Overview Standard Items 1.This User Manual applies to Model K80 (4K + 1080P) and Model K70 (4K). Accessories listed are for reference only and may vary by product configuration or region. For exact details about your purchase, refer to the retailer’s product page. Review the warranty policy in this manual to understand coverage terms . 2.The included USB Type-C Data Cable is for video file transfer to computers only—it does not support charging . Notes ORSKEY Front Camera Rear Camera (6m/20ft cable) 12V Car Charger Adapter USB Type-C Car Charger Cable (3.5m / 11.5 ft) USB Type-C Data Cable (0.8m / 2.6 ft) Spare 3M Adhesive Sticker (2×Front + 2×Rear) Electrostatic Films Trim Removal Tool User Manual -- 02 - - 03 - Product Overview Product Diagram Camera Lens Mounting Bracket Power Switch Reset Button microSD Card Slot Menu / Playback / Confirm Up Button / Emergency Recording Down Button / Wi-Fi Toggle AV Output Port USB Type-C Power Input Status LED Display ❼ ❽ ❾ ❿ ⓫ ⓬ ❶ ❷ ❸ ❹ ❺ ❻ ❶ ❷ ❺ ❸ ❹ ❿ ❾ ⓫ ⓬ ❻ ❼ ❽

Reference No.: WTH25D08232085W003 Page 78 of 123 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 802.11n(HT40) U-NII-3 Low channel 802.11n(HT40) U-NII-3 High channel Reference No.: WTH25D08232085W003 Page 79 of 123 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 13 Conducted Output Power Test Requirement: FCC 47CFR Part 15 Section 15.407(a) Test Method: KDB662911 D01 Multiple Transmitter Output v02r01 KDB789033 D02 General U-NII Test Procedures New Rules v02r01 Section E Test Limit: For the band 5.15-5.25 GHz For an outdoor access point operating in the band 5.15-5.25 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W provided the maximum antenna gain does not exceed 6 dBi. For an indoor access point operating in the band 5.15-5.25 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W provided the maximum antenna gain does not exceed 6 dBi. For fixed point-to-point access points operating in the band 5.15-5.25 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W. For client devices in the 5.15-5.25 GHz band, the maximum conducted…
