2BSCE-WPC01Magnetic Wireless Charger

Safety Manual Use Handle this wireless charger with care; it contains sensitive electronics and strong magnets. Do not expose it to direct sunlight or high humidity. The charger is not waterproof. If it becomes wet, disconnect it and allow it to dry completely before use. Do not disassemble, modify, or attempt to repair the charger yourself; doing so voids the warranty and may compromise safety. Protect the charger from physical impact or deformation. Keep it away from children; small components may present a choking hazard. The charger contains magnets and emits electromagnetic fields when charging. Keep it at a safe distance from credit cards, magnetic storage media and implanted medical devices; if you have a pacemaker or similar implant, consult your physician before use. Specifications Input: 5 V⎓3 A, 9 V⎓3A via USB-C Output: Up to 15 W Operating frequency:111-205KHz,360 kHz Operating temperature range: 0 °C to 45 °C. Safety The charger includes built-in protection against over-voltage, over-tem perature, short circuits and foreign object detection. Do not use the charger in extremely hot, humid, or corrosive environments. Keep the USB-C port dry. Persons with implanted medical devices should maintain a safe distance from the charger’s magnets and consult a physician before using the char ger. Magnets may interfere with credit cards or magnetic storage devices; keep them separate from the charging area. Maintenance Disconnect the charger from power before cleaning. Use a soft, slightly damp cloth to wipe the surface; do not use solvents or abrasive cleaners. Store the charger in a cool, dry place. Avoid dropping, crushing or exposing it to excessive force. Disposal Do not dispose of this product with household waste. Follow local regula tions for recycling electronic devices. The crossed-out wheelie bin symbol indicates that the product must be disposed of separately according to the European Waste Electrical and Electronic Equipment (WEEE) directive. Support & Warranty For assistance, visit trezor.io/support FCCWARNIN For warranty, see trezor.io/terms-of-use Manufacturer Trezor Company s.r.o., Kundratka 2359/17a, 180 00 Prague 8, Czech Republic. Made in China. Compliance EU Declaration of Conformity This device conforms to the Radio Equipment Directive (2014/53/EU), EMC Directive (2014/30/EU) and RoHS Directive (2011/65/EU, as amended). Frequency band: inductive power transfer at ~360 kHz. Maximum transmit ted power: 30 dBμA/m @ 10 m. Full declaration available at www.trezor.io/legal. UKCA Compliance The device complies with the UK Radio Equipment Regulations 2017. Frequency band: inductive power transfer at approximately 360 kHz. See www.trezor.io/legal for the UK declaration of conformity. United States (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Canada (ISED) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-ex empt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. The regulatory information for this product can be found at trezor.io/legal. Australia / New Zealand (RCM) This product bears the RCM to indicate conformance with relevant Austra lian and New Zealand regulations. Include the local supplier’s registration number where required. G Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust ICCaution accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation configurations of the transmitter and its antenna(s). : RSS-GenIssue5"&"RSS-Gennuméro5 -English: Thisdevicecontainslicence-exempttransmitter(s)/receiver(s)thatcomplywithInnovation, ScienceandEconomicDevelopmentCanada’slicence-exemptRSS(s).Operationissubject to thefollowingtwoconditions: (1)Thisdevicemaynotcauseinterference.(2)Thisdevicemustacceptanyinterference, includinginterferencethatmaycauseundesired operationofthedevice.Anychangesormodificationsnotexpresslyapprovedbytheparty responsib…

Text truncated - open the document above for the full version.

深圳市深广电子有限公司 ShenzhenShenguangElectronicTechnologyCo.,LTD 承認書 客戶： CUSTOMER: 客戶料號： CUSTP/N: 名称： NAMAP/N: 産品型號： DESC: 日期： DATE: 版本： Version: 深圳市乐充科技有限公司 ShenzhenLechongTechnologyCo.,Ltd V3C 无线充发射线圈/Wirelesschargingtransmittingcoil G41.5x0.8magneticsheet,20x0.8circular piece,singleholedoublegrooveadhesive linelength6MM,0.08x80Px11TS8.0UH 2025-9-10 A.0 擬制 PREPAREDBY 審核 CHECKEDBY 批准 APPROVEDBY 客戶承認 CUSTOMERAPPROVE 谢燕琪 YanqiXie 段家旺 JiawangDuan 谢小仔 XiaozaiXie 深圳市深广电子有限公司 ShenzhenShenguangElectronicTechnologyCo.,LTD 版本變更履歷 VersionChangeHistory 版本 Rev. 變更前 BeforeChang 變更後 AfterChange 更改日期 ChangeDate 批准 ApprovedBy A.0 新发行/Newrelease ---- 20250910XiaozaiXie 谢小仔 深圳市深广电子有限公司 ShenzhenShenguangElectronicTechnologyCo.,LTD SPECIFICATION 産品型號： DESC G41.5x0.8磁片20x0.8圆片,单孔双 槽背胶线长6MM,0.08x80Px11TS 8.0UH, G41.5x0.8MagneticSheet20x0.8RoundPi ece,SingleHoleDoubleSlotBackAdhesive WireLength6MM,0.08x80Px11TS8.0UH 版本 Rev：A.0 客戶CUST: 客户料号CUSTP/N: V3C 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATICDIAGRAM: 三、绕线参数WindingSpecification: A41.5±0.5 B 39±1 C20±0.5 D 20.5±0.5 H 6±2 E 3±1 I 0.8±0.1 T 2.3Max 注： 1.交叉出线; 2.磁片尺寸41.5±0.5mm,厚度为0.8±0. 1mm。 3、折线位置贴6mm(Ref)高温胶纸 4.中间贴20*0.8厚小磁片 Notes: 1.Crossedwireexit; 2.Magneticsheetsize41.5±0.5mm,thickness0. 8±0.1mm. 3.Apply6mm(Ref)high- temperaturetapeatthefoldinglineposition 4.Attach20*0.8thicksmallmagneticsheetinthe middle 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection 1SF 漆包线0.08*80P 11TsCCW 四、电气特性ELECTRICALCHARACTERISTICS: 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1 IND.S-F 3.8uH±10%单独线圈 100KHz/1.0V CH1063 2 IND. S-F 8.0uH±10%加磁片 100KHz/1.0VCH1063 3DCRS-F 70mΩMAX 100KHz/1.0V 502BC 4 Q S-F30MIN100KHz/1.0V502BC 擬制/日期PREPAREDBY/DATE審核/日期CHECKEDBY/DATE 2025-9-102025-9-10 深圳市深广电子有限公司 ShenzhenShenguangElectronicTechnologyCo.,LTD 五、包装/PACKAGE 360 1080 5.3包装以现有包装盘为参照标准，以实际出货包装为准，如有特需要求可以定制。 Thepackagingshalbebasedontheexustingpackingplateandtheactualdeliverypackageshal prevail.Ifthereisanyrequirement,wecancustomizeit. 六、贮存和使用条件StorageandUsecondition 6.1贮存条件Storagecondition 6.1.1建议贮存条件：温度-25°C~85°C,湿度70%(Max.) Recommendedkeepingconditions:-25°C~85°C,70%RH(Max.) 6.1.2贮存期限：自生产之日起六个月内 Storagelife:Withinthelimitsofsixmonthsfrombeingproduced. 6.2使用条件Usecondition 使用条件限制：温度=-25°C~85°C,湿度≤90% Useconditionlimit:T=-25°C~85°C,RH≤90%.

TrezorCompanys.r.o OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:December5,2025 Subject;RequestforConfidentiality FCCID:2BSCE-WPC01 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:AdamBudinsky Title:ProductManager

FCCID:2BSCE-WPC01 EUTPHOTO(ExternalPhotos) FCCID:2BSCE-WPC01 FCCID:2BSCE-WPC01 FCCID:2BSCE-WPC01 ※※※※※ENDOFREPORT※※※※※

TOPBOTTOM 2BSCE-WPC01 XXXXX-YYYYY

FCCID:2BSCE-WPC01 EUTPHOTOS(InternalPhotos) FCCID:2BSCE-WPC01 FCCID:2BSCE-WPC01 FCCID:2BSCE-WPC01 ※※※※※ENDOFREPORT※※※※※

ProjectNo.:ZHT-250910106W03-2 Page 1 of 10 RFExposureEvaluation FCCID:2BSCE-WPC01 ReportNo........................:ZHT-250910106W03-2 Product............................:MagneticWirelessCharger Trademark.......................:Trezor Model(s)...........................:WPC01 ModelDifference..............:/ Applicant..........................:TrezorCompanys.r.o Address............................:Kundratka2359/17a,Prague,CZECHIA,CZECHREPUBLIC Manufacturer....................:ShenzhenLechongTechnologyCo.,Ltd Address............................:Room802,8thFloor,BuildingA,ZhaoyeTechnologyPark,No.280,Dabutou Road,SongxuanCommunity,GuanhuStreet,LonghuaDistrict,Shenzhen Preparedby......................:GuangdongZhonghanTestingTechnologyCo.,Ltd. Address............................:Room104/201,Building1,YibaolaiIndustrialPark,Qiaotou,Fuhai Subdistrict,Bao'anDistrict,Shenzhen,Guangdong,China DateofReceipt................:Sept.10,2025 DateofTest(s)..................:Sept.10,2025toOct.31,2025 DateofIssue....................:Oct.31,2025 TestStandard(s)..............: KDB680106D01WirelessPowerTransferv04 Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. PreparedbyReviewedby:Approvedby: LeonLi/EngineerBaretWu/DirectorLeviLee/Manager Note:ThisdevicedescribedabovehasbeentestedbyZHT,andthetestresultsshowthattheequipment undertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport.Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZHT, thisdocumentmaybealteredorrevisedbyZHT,personalonly,andshallbenotedintherevisionofthe document. ProjectNo.:ZHT-250910106W03-2 Page 2 of 10 TableofContentsPage 1.GENERALINFORMATION................................................................................................................................3 1.1.GENERALDESCRIPTIONOFEUT.......................................................................................................3 1.2.TestModes.............................................................................................................................................4 1.3.Auxiliaryequipment................................................................................................................................4 2.RFEXPOSURETEST........................................................................................................................................5 2.1.MeasuringStandard...............................................................................................................................5 2.2.Requirements..........................................................................................................................................5 2.3.Limits.......................................................................................................................................................5 2.4.TestSetup...............................................................................................................................................6 2.5.TestProcedure.......................................................................................................................................6 2.6.MEASUREMENTUNCERTAINTY.........................................................................................................6 2.7.TestInstrumentslist................................................................................................................................7 2.8.TestResult..............................................................................................................................................7 2.9.TestPhotos.............................................................................................................................................8 ProjectNo.:ZHT-250910106W03-2 Page 3 of 10 1.GENERALINFORMATION 1.1.GENERALDESCRIPTIONOFEUT ProductName:MagneticWirelessCharger TestModelNo.: WPC01 Hardwareversion:V1.0 Softwareversion:V1.0 OperationFrequency: 111-205KHz,360KHz Modulationtype:ASK AntennaType:CoilAntenna Antennagain:0dBi RatingsInput:5V3A,9V3A Output:5W/7.5W/10W/15W SampleNumber:250910106YP001 Remark:Theantennagainisprovidedbythecustomer,ifthedataprovidedbythecustomerisnotaccurate, GuangdongZhonghanTestingTechnologyCo.,Ltd.doesnotassumeanyresponsibility. ProjectNo.:ZHT-250910106W03-2 Page 4 of 10 1.2.TESTMODES TestModes: Mode1ACAdapter+Phonecharging(EPPProtocol:BatteryStatus:≤1%) Mode2ACAdapter+Phonecharging(EPPProtocol:BatteryStatus:50%) Mode3ACAdapter+Phonecharging(EPPProtocol:BatteryStatus:≥98%) Mode4 ACAdapter+Phonecharging(MPPProtocol:BatteryStatus:≤1%) Mode5 ACAdapter+Phonecharging(MPPProtocol:BatteryStatus:50%) Mode6 ACAdapter+Phonecharging(MPPProtocol:BatteryStatus:≥98%) Mode7Standby Note:Allmodesweretested,onlytheworst-casewasrecordedinthereport.Mode1istheworstmode. 1.3.AUXILIARYEQUIPMENT ItemEquipmentMfr/BrandModel/TypeNo.SeriesNo.Note E-1ACAdapter HuizhouJinhuIndustrial DevelopmentCo.,Ltd. VCBAJACH/AE E-2MobilephoneXiaomiXiaomi12SPro/AE E-3MobilephoneAppleInc.iPhone15Pro/AE ProjectNo.:ZHT-250910106W03-2 Page 5 of 10 1.RFEXPOSURETEST 2.1.MEASURINGSTANDARD KDB680106D01WirelessPowerTransferv04 2.2.REQUIREMENTS Accordingtotheitem5ofKDB680106D01v04: Inductivewirelesspowertransferapplicationsthatmeetallofthefollowingrequirementsareexcludedfrom submittinganRFexposureevaluation. Requirementsofsection3ofKDB680106D01Yes/NoDescription MobileDeviceandPortableDeviceConfigurationsYesMobileDevice EquipmentAuthorizationProceduresforDevicesOperatingat FrequenciesBelow4MHz Yes Thedeviceoperateinthe frequencyrange:111-205KHz, 360KHz RFExposurecompliancemaybeensuredonlyforaminimum conditionsatsmallerdistancescanstillbeconsidered unlikely.separationdistancethatisgreaterthan20cm,whileuse Yes TheEUTH-fieldandE-field strengthsat20cmsurrounding thedevice. 2.3.LIMITS Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspeci…
