2BSCSEXPERTP34FSolid State Drive

TEAM GROUP Solid State Drive T-CREATE EXPERT P34F SSD User Manual 1. Insert this product into a USB 2.0 or USB 3.0 port on your computer. The system will automatically recognize the device. 2. A notification will appear on your computer system. 3. You will see an icon in "My Computer." Double-click it to access the device and transfer data and files. Bind Apple designated device smart positioning Detailed Specifications Product Name Solid State Drive Main Model EXPERT P34F SSD Series Models EXPERT P34F Find My; EXPERT P34F Find My 512GB; EXPERT P34F Find My 1TB; EXPERT P34F Find My 2TB; Interface Specification USB3.2 Gen2x1 Form Factor ORION_D52 REV 1.0 Product Dimensions (L x W x H) 81.3mm x 43.0mm x 16.5mm Mean Time Between Failures (MTBF) Over 3 million hours Product Life Monitoring Self-Monitoring, Analysis & Reporting Technology (S.M.A.R.T) Country of Manufacture Taiwan Manufacturer Information Applicant: Team Group Inc. Address: 3F., No. 166, Jian 1st Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Phone: +886-2-8226-5000 ext.418 Email: [email protected] FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. RF EXPOSURE WARNING This device contains transmitters and receivers which emit Radio Frequency (RF) energy. The device is designed to comply with the limits for exposure to RF energy set by the Federal Communications Commission (FCC) of the United States, Industry Canada (IC) of Canada, and the regulating entities of other countries. WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

Teamgroup Inc. Covered Equipment Certification Attestation Letter Date: Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2BSCSEXPERTP34F Teamgroup Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes certifying that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Teamgroup Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed Name: YU CHE CHENG Title: Product Specialist. Company Name: Teamgroup Inc. Date: 24/09/2025

Teamgroup Inc. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter August 15, 2025 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer Per section 2.911(d)(7) of the FCC rules, Teamgroup Inc. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: TEAM DATASOLUTION USA INC. Physical U.S. Company Address: 8 THE GREEN, STE A, DOVER, KENT, DE 19901, UNITED STATES OF AMERICA Agent name: Kevin.Chang Agent Email Address: [email protected] FRN: 0037296613 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: YU CHE CHENG Printed name: kevin.chang Title: Product Specialist. Title: Director. Company Name: Teamgroup Inc. Company Name: TEAM DATASOLUTION USA INC. FRN: 0037267341 FRN: 0037296613 Date: Click here to enter a date. Date: Click here to enter a date.

Teamgroup Inc. DATE : 2025/09/24 FCC ID: 2BSCSEXPERTP34F Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Company name: Global Certification Corp Address: No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221, Taiwan Name: Angel Huang For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America, Inc, still resides with us. Signature FCC grantee contact person information. Name/Title: YU CHE CHENG/ Product Specialist. Company Name: Teamgroup Inc. Address: 3F., No.166, Jian 1st Rd., Zhonghe Dist., New Taipei City 23511, Taiwan TEL: 02-8226-5000 FAX: 02-8226-5808 Email: [email protected]

Teamgroup Inc. September 24, 2025 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2BSCSEXPERTP34F Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of insert number of days (cannot exceed 180 days) days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒Permanent ☐Short Term External Photos ------------------ ☐Short Term Internal Photos ☐Permanent*☐Short Term Operation Description ☒Permanent ☐Short Term Parts List & Placement/BOM ☐Permanent☐Short Term Tune-Up Procedure ☐Permanent☐Short Term Schematic Diagrams ☒Permanent ☐Short Term Test Setup Photos ------------------ ☐Short Term User’s Manual ☐Permanent*☐Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: YU CHE CHENG Title: Product Specialist. Company Name: Teamgroup Inc.

Teamgroup Inc. Model Name Declaration Date: September 23, 2025 FCC ID: 2BSCSEXPERTP34F To whom it may concern We, Teamgroup Inc, declare that our product “Solid State Drive”, model: EXPERT P34F SSD ; EXPERT P34F Find My ; EXPERT P34F Find My 512GB; EXPERT P34F Find My 1TB; EXPERT P34F Find My 2TB are identical in HW design. The difference in model name is due to capacity. Authorized Signature on behalf of Teamgroup Inc Name: Position: Product Specialist

Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 External Photos Trade name：TEAMGROUP Model name：EXPERT P34F SSD 01. Front view of EUT 02. Rear view of EUT

Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 Label Trade name：TEAMGROUP Model name：EXPERT P34F SSD ID Label

Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 Internal Photos Trade name：TEAMGROUP Model name：EXPERT P34F SSD 01.Inside 02. Front view of PCB 1 Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 Internal Photos Trade name：TEAMGROUP Model name：EXPERT P34F SSD 03. Rear view of PCB 1 04. Front view of PCB 2 Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 Internal Photos Trade name：TEAMGROUP Model name：EXPERT P34F SSD 05. Rear view of PCB 2 06. Antenna 廠牌：Lenze Technology Co.,LTD 型號：PCB Antenna Global Certification Corp. Date of Issue: Jul.29.2025 Report No:FR2-571701 Internal Photos Trade name：TEAMGROUP Model name：EXPERT P34F SSD 07. View of RFIC 08. View of Battery

Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page1/7 RF EXPOSURE REPORT FOR Product Name: Solid State Drive Model : EXPERT P34F SSD Series: EXPERT P34F Find My, EXPERT P34F Find My 512GB, EXPERT P34F Find My 1TB, EXPERT P34F Find My 2TB Trade Name: TEAMGROUP Issued to Teamgroup Inc 3F., No.166, Jian 1st Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Issued by Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist.,New Taipei City 221, Taiwan (R.O.C.) Note: This test refers exclusively to the test presented test model and sample. This report shall not be reproduced except in full, without the written approval of Global Certification Corporation. This document may be altered or revised by Global Certification Corporation. Personnel only, and shall be noted in the revision section of the document.The decision rule is according to the standard test method and request, that measurement result doesn’t consider uncertainty. Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page2/7 Revision History Revision No. Report Number Issue Date Description Author/ Revised by 1. 571701 FR2-571701a Jul. 29, 2025 Original Report Judy Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page3/7 TABLE OF CONTENTS ------------------------------------------------------------------------------------------- 3 1. GENERAL INFORMATION ---------------------------------------------------------------------------------------------- 4 1.1 DESCRIPTION OF THE TESTED SAMPLES ------------------------------------------------------------------------------------- 5 2. GENERAL SAR TEST REDUCTION AND EXCLUSION GUIDANCE----------------------------------------- 6 3. MPE EVALUATION -------------------------------------------------------------------------------------------------------- 7 3.1 CACULATION METHOD --------------------------------------------------------------------------------------------------- 7 3.2. CALCULATED RESULT --------------------------------------------------------------------------------------------------- 7 Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page4/7 1. GENERAL INFORMATION Applicant : Teamgroup Inc Address : 3F., No.166, Jian 1st Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Manufacturer : DongGuan Kensway Photoelectric Technology co.，Ltd. Address : Room 418, Building 6, No. 36 Fuxing Road, Chang'an Town, Dongguan City, Guangdong Province, China EUT : Solid State Drive Model No. : EXPERT P34F SSD Series No. : EXPERT P34F Find My, EXPERT P34F Find My 512GB, EXPERT P34F Find My 1TB, EXPERT P34F Find My 2TB Trade Name : TEAMGROUP Model Differences : The major electrical and mechanical constructions of series models are identical to the basic model, except different capacity. The model, EXPERT P34F SSD is the testing sample, and the final test data are shown on this test report. Is here with confirmed to comply with the requirements set out in the FCC Rules and Regulations. The said equipment has been tested and found compliance with the requirement of the relative standards . Test Standard : FCC Title 47 Part 2.1091, KDB 447498 D01 V06 Tested By: Approved by: Jul. 29, 2025 Jul. 29, 2025 Date Emma Zhang, Engineer Date Adam Chou, Manager Designation Number: TW1640 Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page5/7 1.1 DESCRIPTION OF THE TESTED SAMPLES EUT Name : Solid State Drive Model : EXPERT P34F SSD FCC ID : 2BSCSEXPERTP34F Power From InsideOutside Support Unit PC Adaptor Battery Power Supply DC Power Source Power Rating(Battery) : 5 Vdc Power Rating(Adapter) 3 Vdc(Battery) Operate Frequency : Refer to the channel list as described below Basic Spec : Bluetooth Bluetooth LE 802.11b 802.11g 802.11n HT20/HT40 Operate Frequency : 2402 MHz ~ 2480 MHz Number of Channels : 40 Step of Channel : N/A  2 MHz Modulation Type : GFSK FHSS DSSS CCK OFDM Antenna Quantity : 1Tx/1Rx Antenna Type : PCB Antenna gain : -0.08 dBi EUT Received Date : Jul. 17, 2025 EUT Channel List : Channels Frequencies (MHz) Channels Frequencies (MHz) Channels Frequencie s (MHz) Channels Frequencie s (MHz) 0 2402 10 2422 20 2442 30 2462 1 2404 11 2424 21 2444 31 2464 2 2406 12 2426 22 2446 32 2466 3 2408 13 2428 23 2448 33 2468 4 2410 14 2430 24 2450 34 2470 5 2412 15 2432 25 2452 35 2472 6 2414 16 2434 26 2454 36 2474 7 2416 17 2436 27 2456 37 2476 8 2418 18 2438 28 2458 38 2478 9 2420 19 2440 29 2460 39 2480 Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page6/7 2. GENERAL SAR TEST REDUCTION AND EXCLUSION GUIDANCE 2.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR , where ● f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2.2 At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following ⚫ [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)] mW, at 100 MHz to 1500 MHz ⚫ [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 2.3 At frequencies below 100 MHz, the following may be considered for SAR test exclusion ⚫ The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separ…

Text truncated - open the document above for the full version.

Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China GENERAL INFORMATION 1.1 Test Environment Condition Ambient Temperature 19 to 25 °C Ambient Relative 45 to 55 % Humidity Ambient Pressure N/A (Not applicable) 1.2 Announce (1) The test report is invalid if not marked with the signatures of the persons responsible for preparing and approving the test report. (2) The test report is invalid if there is any evidence and/or falsification. (3) The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. (4) This document may not be altered or revised in any way unless done so and all revisions are duly noted in the revisions section. (5) Content of the test report, in part or in full, cannot be used for publicity and/or promotional purposes without prior written approval from the laboratory. Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China PRODUCT INFORMATION 2.1 Applicant Applicant Lenze Technology Co.,LTD Address d.c., 26c newspaper west tower, 6008 shennan Avenue, Futian District , Contact Person Tony Telephone Number +86 0755-82031775;25332530 Fax Number +86 0755-82713604 E-mail Address [email protected] 2.2 Manufacturer Manufacturer Lenze Technology Co.,LTD Address d.c., 26c newspaper west tower, 6008 shennan Avenue, Futian District , Shenzhen City, Guangdong Province, China Contact Person N/A Telephone Number N/A Fax Number N/A E-mail Address N/A 2.3 General Description for Equipment under Test (EUT) EUT Type Bluetooth Antenna Model Name PCB Antenna Antenna Type PCB Antenna Hardware Version N/A Serial Number N/A Dimensions N/A 2.4 Technical Information Frequency Range 2400MHz~ 2500MHz Test Frequencies 2402MHz, 2441MHz, 2480MHz Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China SUMMARY OF TEST RESULTS 3.1 Test Standards No. Identity Document Title 1 IEEE149-1979 IEEE Standard Test Procedures for Antennas 3.2 Test Verdict Report Section Description Remark ANNEX A.1 Gain And Efficiency -- ANNEX B Radiation Pattern -- 3.3 Test Uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. Item Uncertainty VSWR(S11) 0.4 Gain -0.08dBi Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China GENERAL TEST CONFIGURATIONS 4.1 Test Condition Environment Parameter Selected Values During Tests Temperature Voltage Relative Humidity Normal Temperature, Normal Voltage 25°C N/A 51% (NTNV) 4.2 Test Equipment List Description Manufacturer Model Serial No. Cal. Date Cal. Due Vector Network Agilent E5071C MY46103472 2014.09.07 2015.09.06 Analyzer 5*5*5 Full Anechoic SATIMO 5*5*5 N/A 2014.09.05 2015.09.04 Chamber SG24 Multi-probe Antenna Measurement SATIMO SG24-L 1101855-0001 2014.10.25 2015.10.24 System 4.3 Test Setup Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China ANNEX A TEST RESULTS A.1 Gain and Efficiency Frequency Gain (dBi) Efficiency (%) 2402MHz -0.08 0.99 2441MHz -0.21 1.06 2480MHz -0.18 1.12 ANNEX B RADIATION PATTERN 3DPattern 2402MHZ 0 -1 -3 -6 -15 -30 Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China 2402MHZ 1D Radiation Pattern PHI =0 Phi=0 freq=2402MHz 0 -1 -3 -6 -15 -30 Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China PHI =90 THETA = 90 Phi=90 freq=2402MHz Theta=90 freq=2402MHz Lenze Technology Co.,LTD Tel:+86 0755-82031775;25332530 Fax:+86 0755-82713604 26c newspaper west tower, 6008 shennan Avenue,Futian District, Shenzhen City, GuangdongProvince,China ANNEX C TEST SETUP PHOTO ANNEX D EUT PHOTO Antenna shape

Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page1/58 FCC Part 15 Subpart C TEST REPORT FOR Product Name: Solid State Drive Model : EXPERT P34F SSD Series: EXPERT P34F Find My, EXPERT P34F Find My 512GB, EXPERT P34F Find My 1TB, EXPERT P34F Find My 2TB Trade Name: TEAMGROUP Issued to Teamgroup Inc 3F., No.166, Jian 1st Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Issued by Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist.,New Taipei City 221, Taiwan (R.O.C.) Note: This test refers exclusively to the test presented test model and sample. This report shall not be reproduced except in full, without the written approval of Global Certification Corporation. This document may be altered or revised by Global Certification Corporation. Personnel only, and shall be noted in the revision section of the document. The decision rule is according to the standard test method and request, that measurement result doesn’t consider uncertainty. Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page2/58 Revision History Revision No. Report Number Issue Date Description Author/ Revised by 1. 571701 FR2-571701 Jul. 29, 2025 Original Report Judy Global Certification Corp. Date of Issue: Jul. 29, 2025 Report No:FR2-571701 Page3/58 TABLE OF CONTENTS ----------------------------------------------------------------------------------------------------- 3 1. GENERAL INFORMATION -------------------------------------------------------------------------------------------------------- 5 1.1 DESCRIPTION OF THE TESTED SAMPLES ------------------------------------------------------------------------------------- 6 2. TEST METHODOLOGY ------------------------------------------------------------------------------------------------------------- 8 2.1 GENERAL TEST PROCEDURES --------------------------------------------------------------------------------------------------- 8 2.2 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ----------------------------------------------------------------- 9 2.3 DESCRIPTION OF TEST MODES ------------------------------------------------------------------------------------------------- 10 2.4 DESCRIPTION OF THE SUPPORT EQUIPMENTS ----------------------------------------------------------------------------- 10 3. TEST AND MEASUREMENT EQUIPMENT ---------------------------------------------------------------------------------- 12 3.1 CALIBRATION ------------------------------------------------------------------------------------------------------------------ 12 3.2 EQUIPMENT --------------------------------------------------------------------------------------------------------------------- 12 4. ANTENNA REQUIREMENTS ----------------------------------------------------------------------------------------------------- 14 4.1 STANDARD APPLICABLE---------------------------------------------------------------------------------------------------- 14 4.2 ANTENNA CONSTRUCTION AND DIRECTIONAL GAIN ------------------------------------------------------------- 14 5. CONDUCTED EMISSIONS -------------------------------------------------------------------------------------------------------- 15 5.1 TEST SETUP---------------------------------------------------------------------------------------------------------------------- 15 5.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------ 15 5.3 TEST PROCEDURE ------------------------------------------------------------------------------------------------------------- 15 5.4 TEST RESULT ------------------------------------------------------------------------------------------------------------------- 16 5.5 TEST DATA ---------------------------------------------------------------------------------------------------------------------- 16 6. PEAK OUTPUT POWER ----------------------------------------------------------------------------------------------------------- 18 6.1 TEST SETUP---------------------------------------------------------------------------------------------------------------------- 18 6.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------ 18 6.3 TEST PROCEDURE ------------------------------------------------------------------------------------------------------------- 18 6.4 TEST RESULT ------------------------------------------------------------------------------------------------------------------- 18 6.5 TEST DATA ---------------------------------------------------------------------------------------------------------------------- 19 7. RADIATED BAND EDGE ----------------------------------------------------------------------------------------------------------- 23 7.1 TEST SETUP---------------------------------------------------------------------------------------------------------------------- 23 7.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------ 24 7.3 TEST RESULT ------------------------------------------------------------------------------------------------------------------- 24 7.4 TEST DATA ---------------------------------------------------------------------------------------------------------------------- 25 8. 6DB BANDWIDTH ------------------------------------------------------------------------------------------------------------------- 26 8.1 TEST SETUP---------------------------------------------------------------------------------------------------------------------- 26 8.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------ 26 8.3 TEST PROCEDURE ------------------------------------------------------------------------------------------------------------- 26 8.4 TEST RESULT ----------------------------------------------------------…

Text truncated - open the document above for the full version.

Global Certification Corp. APPENDIX 3 TEST DATA Report No: FR2-571701 Global Certification Corp. 7.4 RADIATED BAND EDGE TEST DATA Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221,Taiwan (R.O.C.) Date:2025-7-18 Site : GCC_RE_01 RBW : 1000 KHz VBW : 3000 KHz SWT:Auto Polarity : HORIZONTAL EUT : Refer page1 of the report Model : Refer page1 of the report Mode : TX BLE 1M Low CH Temp/Humidity : 25°C / 63% Voltage : From NB Memo : 571701,Power Set:3F Freq Meter Level System Factor Cable Loss Antenna Factor Preamp Gain Real Level Limit Line Margin Remark MHz dBuV dB/m dB dB/m dB dBuV/m dBuV/m dB 1 2390.000 11.58 37.08 4.81 32.27 0.00 48.66 54.00 -5.34 Average 2 2390.000 23.70 37.08 4.81 32.27 0.00 60.78 74.00 -13.22 Peak 3 2402.300 61.04 37.13 4.83 32.30 0.00 98.17 Peak System Factor = Cable Loss + Antenna Factor - Preamp Gain Real Level = Meter Level + System Factor Margin = Real Level - Limit Line Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221,Taiwan (R.O.C.) Date:2025-7-18 Site : GCC_RE_01 RBW : 1000 KHz VBW : 3000 KHz SWT:Auto Polarity : VERTICAL EUT : Refer page1 of the report Model : Refer page1 of the report Mode : TX BLE 1M Low CH Temp/Humidity : 25°C / 63% Voltage : From NB Memo : 571701,Power Set:3F Freq Meter Level System Factor Cable Loss Antenna Factor Preamp Gain Real Level Limit Line Margin Remark MHz dBuV dB/m dB dB/m dB dBuV/m dBuV/m dB 1 2390.000 11.55 37.08 4.81 32.27 0.00 48.63 54.00 -5.37 Average 2 2390.000 23.70 37.08 4.81 32.27 0.00 60.78 74.00 -13.22 Peak 3 2401.800 55.20 37.13 4.83 32.30 0.00 92.33 Peak System Factor = Cable Loss + Antenna Factor - Preamp Gain Real Level = Meter Level + System Factor Margin = Real Level - Limit Line Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221,Taiwan (R.O.C.) Date:2025-7-18 Site : GCC_RE_01 RBW : 1000 KHz VBW : 3000 KHz SWT:Auto Polarity : HORIZONTAL EUT : Refer page1 of the report Model : Refer page1 of the report Mode : TX BLE 1M High CH Temp/Humidity : 25°C / 63% Voltage : From NB Memo : 571701,Power Set:3F Freq Meter Level System Factor Cable Loss Antenna Factor Preamp Gain Real Level Limit Line Margin Remark MHz dBuV dB/m dB dB/m dB dBuV/m dBuV/m dB 1 2480.275 62.62 37.20 4.90 32.30 0.00 99.82 Peak 2 2483.500 12.12 37.20 4.90 32.30 0.00 49.32 54.00 -4.68 Average 3 2483.500 24.30 37.20 4.90 32.30 0.00 61.50 74.00 -12.50 Peak System Factor = Cable Loss + Antenna Factor - Preamp Gain Real Level = Meter Level + System Factor Margin = Real Level - Limit Line Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221,Taiwan (R.O.C.) Date:2025-7-18 Site : GCC_RE_01 R…

Text truncated - open the document above for the full version.
