Manual Selction Default FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

FCC ID:2BSIZ-MANTA5SE External Photos of the EUT FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location FCC ID : 2BSIZ-MANTA5SE

FCC ID:2BSIZ-MANTA5SE Internal Photos of the EUT FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE 5.8G Antenna FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE 2.4GRX Antenna FCC ID:2BSIZ-MANTA5SE 2.4GWIFI Antenna FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE FCC ID:2BSIZ-MANTA5SE

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID............................................. : CTA25091001103 2BSIZ-MANTA5SE Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 30, 2025 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Jiangxi Kufei Intelligent Technology Co., Ltd. Address............................................ : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Drone Trade Mark ........................................ Axisflying Manufacturer .................................... : Jiangxi Kufei Intelligent Technology Co., Ltd. Model/Type reference ...................... : Manta5SE Listed Models ................................... : Manta5 SE DC, Manta36, Manta5, Manta5 PRO, Kolas7, Manta30, Manta7, Manta10, Bando 5, Pocky20, Pocky25, C20, C25, C20PRO, C25PRO, C30, C35, C35V3, C35V2 Rating ............................................... : Battery: 22.2V, 1300mAh, 28.86Wh Result ............................................... : PASS Report No.: CTA25091001103 Page 2 of 9 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Drone Model /Type : Manta5SE Listed Models : Manta5 SE DC, Manta36, Manta5, Manta5 PRO, Kolas7, Manta30, Manta7, Manta10, Bando 5, Pocky20, Pocky25, C20, C25, C20PRO, C25PRO, C30, C35, C35V3, C35V2 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Jiangxi Kufei Intelligent Technology Co., Ltd. Address : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Manufacturer : Jiangxi Kufei Intelligent Technology Co., Ltd. Address : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25091001103 Page 3 of 9 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks .................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................ 5 2.4 Modifications ........................................................................................................... 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory ................................................................................. 6 3.2 Test Facility ............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................ 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ........................................................................................................... 7 4.2 MPE Calculation Method ........................................................................................ 7 4.3 Conducted Power Results ...................................................................................... 8 4.4 Manufacturing tolerance ......................................................................................... 8 4.5 Standalone MPE Result ..............................................................................…

Text truncated - open the document above for the full version.

1. Antenna Description: Antenna type PCB antenna Model Manta5SE-2.4G WIFI Frequency range 2400-2500MHz Manufacturer Jiangxi Kufei Intelligent Technology Co., Ltd. Address Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China ANT Peak Gain 0.88 dBi 2. Antenna Photo: Length :4.66mm Width:1.59mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA25091001102 2BSIZ-MANTA5SE Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Sep. 30, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : Jiangxi Kufei Intelligent Technology Co., Ltd. Address ............................................ : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Drone Trade Mark ....................................... : Axisflying Manufacturer .................................... : Jiangxi Kufei Intelligent Technology Co., Ltd. Model/Type reference ...................... : Manta5SE Listed Models ................................... : Manta5 SE DC, Manta36, Manta5, Manta5 PRO, Kolas7, Manta30, Manta7, Manta10, Bando 5, Pocky20, Pocky25, C20, C25, C20PRO, C25PRO, C30, C35, C35V3, C35V2 Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : Battery: 22.2V, 1300mAh, 28.86Wh Result ............................................... : PASS Report No.: CTA25091001102 Page 2 of 25 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Drone Model /Type : Manta5SE Listed Models : Manta5 SE DC, Manta36, Manta5, Manta5 PRO, Kolas7, Manta30, Manta7, Manta10, Bando 5, Pocky20, Pocky25, C20, C25, C20PRO, C25PRO, C30, C35, C35V3, C35V2 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Jiangxi Kufei Intelligent Technology Co., Ltd. Address : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Manufacturer : Jiangxi Kufei Intelligent Technology Co., Ltd. Address : Room 1902, No. 2222, Jiefang East Road, Qingshanhu District, Nanchang City, Jiangxi Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25091001102 Page 3 of 25 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 6 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ...........................................................................…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for 2.4GWIFI Company: : Jiangxi Kufei Intelligent Technology Co., Ltd. EUT : Drone Model Number : Manta5SE FCC ID : 2BSIZ-MANTA5SE Report No. : CTA25091001102 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.320 2408.040 2416.360 0.5 PASS 2437 9.080 2432.440 2441.520 0.5 PASS 2462 8.800 2457.600 2466.400 0.5 PASS 11G Ant1 2412 16.240 2403.920 2420.160 0.5 PASS 2437 16.320 2428.880 2445.200 0.5 PASS 2462 16.320 2453.920 2470.240 0.5 PASS 11N20SISO Ant1 2412 17.360 2403.360 2420.720 0.5 PASS 2437 17.240 2428.400 2445.640 0.5 PASS 2462 17.360 2453.360 2470.720 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 7 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.964 2405.5661 2418.5301 --- --- 2437 12.975 2430.5542 2443.5292 --- --- 2462 13.009 2455.5077 2468.5167 --- --- 11G Ant1 2412 16.558 2403.7787 2420.3367 --- --- 2437 16.563 2428.7437 2445.3067 --- --- 2462 16.593 2453.7351 2470.3281 --- --- 11N20SISO Ant1 2412 17.459 2403.3283 2420.7873 --- --- 2437 17.441 2428.3197 2445.7607 --- --- 2462 17.444 2453.3173 2470.7613 --- --- 8 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 9 11G_Ant1_2412 11G_Ant1_2437 10 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11 11N20SISO_Ant1_2462 12 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Maximum Peak conducted output power [dBm] Limit [dBm] Verdict 11B Ant1 2412 14.78 ≤30.00 PASS 2437 15.19 ≤30.00 PASS 2462 14.88 ≤30.00 PASS 11G Ant1 2412 12.95 ≤30.00 PASS 2437 13.15 ≤30.00 PASS 2462 13.50 ≤30.00 PASS 11N20SISO Ant1 2412 13.15 ≤30.00 PASS 2437 13.52 ≤30.00 PASS 2462 13.73 ≤30.00 PASS 13 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -14.51 ≤8.00 PASS 2437 -14.27 ≤8.00 PASS 2462 -14.35 ≤8.00 PASS 11G Ant1 2412 -21.57 ≤8.00 PASS 2437 -21.13 ≤8.00 PASS 2462 -20.84 ≤8.00 PASS 11N20SISO Ant1 2412 -21.10 ≤8.00 PASS 2437 -20.97 ≤8.00 PASS 2462 -20.87 ≤8.00 PASS 14 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 15 11G_Ant1_2412 11G_Ant1_2437 16 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 17 11N20SISO_Ant1_2462 18 Appendix E: Band edge measurements Test Result TestMode Antenn a ChNam e Frequency[MH z] RefLevel[dB m] Result[dB m] Limit[dBm ] Verdic t 11B Ant1 Low 2412 1.13 -53.62 ≤-18.87 PASS High 2462 1.01 -56.12 ≤-18.99 PASS 11G Ant1 Low 2412 -7.24 -46.73 ≤-27.24 PASS High 2462 -7.24 -54.05 ≤-27.24 PASS 11N20SIS O Ant1 Low 2412 -7.51 -49.69 ≤-27.51 PASS High 2462 -6.60 -54.18 ≤-26.6 PASS 19 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 20 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 21 11N20SISO_Ant1_High_2462 22 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference -1.19 -1.19 --- PASS 30~1000 -1.19 -55.52 ≤-21.19 PASS 1000~26500 -1.19 -43.71 ≤-21.19 PASS 2437 Reference -0.17 -0.17 --- PASS 30~1000 -0.17 -55.8 ≤-20.17 PASS 1000~26500 -0.17 -44.36 ≤-20.17 PASS 2462 Reference 0.70 0.70 --- PASS 30~1000 0.70 -55.81 ≤-19.3 PASS 1000~26500 0.70 -45.27 ≤-19.3 PASS 11G Ant1 2412 Reference -7.91 -7.91 --- PASS 30~1000 -7.91 -59.26 ≤-27.91 PASS 1000~26500 -7.91 -43.49 ≤-27.91 PASS 2437 Reference -7.83 -7.83 --- PASS 30~1000 -7.83 -59.54 ≤-27.83 PASS 1000~26500 -7.83 -44.16 ≤-27.83 PASS 2462 Reference -7.59 -7.59 --- PASS 30~1000 -7.59 -59.09 ≤-27.59 PASS 1000~26500 -7.59 -44.74 ≤-27.59 PASS 11N20SISO Ant1 2412 Reference -8.55 -8.55 --- PASS 30~1000 -8.55 -60.03 ≤-28.55 PASS 1000~26500 -8.55 -43.5 ≤-28.55 PASS 2437 Reference -7.17 -7.17 --- PASS 30~1000 -7.17 -60.35 ≤-27.17 PASS 1000~26500 -7.17 -44.14 ≤-27.17 PASS 2462 Reference -8.01 -8.01 --- PASS 30~1000 -8.01 -60.6 ≤-28.01 PASS 1000~26500 -8.01 -44.88 ≤-28.01 PASS 23 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 24 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 25 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 26 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 27 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 28 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 29 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 30 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 31 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 32 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 33 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 34 Appendix G: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11G Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11N20SISO Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 35 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 36 11G_Ant1_2412 11G_Ant1_2437

37 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 38 11N20SISO_Ant1_2462
