2BSP5-U152Wireless Adapter

AC1300 Wireless Adapter U152 Version 1.0 User Manual Shenzhen Plery Network Tech Co., Ltd. ADDRESS: 10th Floor, Building H, Huanan Digital Valley,No. 1 Huanan Road, Longhua District, Shenzhen, China EMAIL: [email protected] WEBSITE: www.szplery.com 03 04 1. Device Installation 2. Driver Installation 2-1 Driver Download: Enter into the plery official website: http://www.szplery.com/ Go to the Support center and select to download the Adapter Driverof model U152. Open the driver folder, double-click the driver Setup.exe installation file, select Next - Install. 1-1 Insert the network adapter directly into the USB port on the computer. 2-2 After the driver installation is completed, restarting your computer. If there is work in progress or a file being written, you can choose to restart later. If there is nothing else, it is recommended to restart immediately. English Manual 05 06 2-3 Click on the network icon " " in the bottom-right corner of the desktop, then click on the " " icon. 2-4 Select the WiFi network you want to connect, enter the password, and enjoy the network. 2-5 After restart your computer, the driver installation is completed. Now You can right click "This PC", and choose "Manage" to enter the Computer Management to view the Driver Manager status. 2-6 After entering the management page, click on "Device Manager" and "Network Adapters", and you can see the installed network adapter driver status. (Tips: This step requires that the network adapter is connected to the computer.) 07 08 2-7 Double click to view device details. If there is no abnormality, the following figure shows that the driver runs normally, and you can view the "Driver Details". Q1. What can I do if the WiFi adapter's driver cannot be recognized after plug in? A1: Try to plug into another USB port. For desktop computers, please try to use the USB interface behind the host for more stable connection. A2: Driver file conflicts. It is recommended to uninstall all the previously downloaded driver files and programs (Including drivers for other brands of WiFi adapter), restart the computer and install again. A1: Plug in the USB WiFi adapter, right-click the "MyComputer" icon on the computer desktop, click "Properties" to find the"Device Manager", and check if the WiFi adapter appears in "OtherDevices". It indicates that if the system has recognized it. 3. FAQ Q3. What can I do if no WiFi signal can be detected after installed the WiFi adapter? A1: Check if the WiFi function and signal strength of the nearby router work properly by connected to the WiFi through cell phone directly. A2: Check whether the wireless router and wireless AP have settings to hide the wireless network name. A3: System firewall blocking, please set to allow or close. A4: Try to reduce the distance between the WiFi adapter and the router, and avoid the obstacles such as thick walls, metals or large-area mirrors. A5: Try to adjusting the orientation of the antenna to improve signal reception. Q2. How to confirm that the operating system has recognized the WiFi adapter? Q4. What can I do if the WiFi signal can be detected but cannot connected? A1: Check the signal strength of the router. Try to connect to the WiFi somewhere with a stronger signal. A2: Ensure you have entered the correct password. A3: Check whether the DHCP function of the router is enabled. If not, the WiFi adapter won't be able to obtain the IP address and connect to the internet. A4: Check if you have set the binding of your Mac address and the router. If yes, you need to set the binding of the Mac address and the WiFi adapter. A5: Ensure the encryption type of the router is one of WPA-PSK, WPA2-PSK, WPA, WPA3, WPA2-PSK and 64/128 bit WEP. 09 10 Thank you for purchasing our product. To ensure your after-sales service rights, please carefully read the following warranty regulations. The following situations are not covered under the free maintenance, and our company can provide paid services. Please note: Product malfunction or damage caused by improper installation, use, maintenance, or storage as per the user manual. Repairs requested beyond the warranty or replacement period; Unauthorized alteration or destruction of the product's barcode. Unauthorized modification of inherent configuration files or disassembly of the product without permission. Damage to the product caused by accidental factors or human actions, such as applying inappropriate voltage, exposure to high temperatures or water, mechanical damage, drops, severe oxidation, or rust, etc. Failures or damages caused by reasons other than the product's design, technology, manufacturing, or quality issues. Warranty Card Dear Valued Clients, 1. Use the product safely to prevent Electric shock risk 2. Do not use in humid environment 3. Use supporting power supply to prevent product damage 4. Use the product safely to prevent inflammable and explosive risks Warning STATEMENT Shenzhen Plery Network Technology Co., LTD Copyright, all rights reserved Without the specific written permission of the Company no entity or individual may copy, transcribe or translate part or all of the contents of this book without authorization. lt may not be distributed or used for any commercial, profit-making purposes in any form or by any means (electronic, mechanical, photocopied, recorded or otherwise possible). The product specifications and information mentioned in this manual are for reference only and subject to change without prior notice. Unless otherwise agreed, this manual is for use only. All statements,information, etc.in this manual do not constitute a guarantee of any kind. PLERY is a registered trademark of Shenzhen plery Network Technology Co., LTD. All other trademarks or registered trademarks mentioned in this document are the property of their respective owners. Copyright Q/PRWL 001-2025 Certificate Quality inspector Date of manufacture Execution standards 11 12 FCC RF Exposure Information and Statement. The SAR limit …

Text truncated - open the document above for the full version.

Page 1 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Appendix B RF Test Data for 5.2GWIFI (Conducted Measurement) Product Name: Wireless Adapter Test Model: U152 Environmental Conditions Temperature: 24.6 C Relative Humidity: 53.8% ATM Pressure: 100.0 kPa Test Engineer: Suichao Lai Supervised by: Yan Chen Page 2 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com B.1 Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 28.920 5165.640 5194.560 --- --- 5200 24.280 5188.640 5212.920 --- --- 5240 27.720 5225.640 5253.360 --- --- 11N20SISO Ant1 5180 32.600 5163.800 5196.400 --- --- 5200 26.760 5187.480 5214.240 --- --- 5240 22.760 5229.480 5252.240 --- --- 11N40SISO Ant1 5190 72.000 5155.040 5227.040 --- --- 5230 66.000 5198.480 5264.480 --- --- 11AC20SISO Ant1 5180 24.640 5166.400 5191.040 --- --- 5200 27.080 5185.600 5212.680 --- --- 5240 26.640 5226.320 5252.960 --- --- 11AC40SISO Ant1 5190 73.360 5154.640 5228.000 --- --- 5230 69.440 5194.880 5264.320 --- --- 11AC80SISO Ant1 5210 137.440 5147.920 5285.360 --- --- Page 3 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs 11A_Ant1_5180 11A_Ant1_5200 11A_Ant1_5240 Page 4 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N20SISO_Ant1_5180 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 Page 5 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_5190 11N40SISO_Ant1_5230 11AC20SISO_Ant1_5180 Page 6 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC20SISO_Ant1_5200 11AC20SISO_Ant1_5240 11AC40SISO_Ant1_5190 Page 7 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC40SISO_Ant1_5230 11AC80SISO_Ant1_5210 Page 8 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Result TestMode Antenna Freq(MHz) 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant2 5180 21.320 5169.000 5190.320 --- --- 5200 23.160 5189.160 5212.320 --- --- 5240 21.880 5228.920 5250.800 --- --- 11N20SISO Ant2 5180 22.040 5168.680 5190.720 --- --- 5200 24.440 5187.600 5212.040 --- --- 5240 24.320 5228.160 5252.480 --- --- 11N40SISO Ant2 5190 65.520 5158.720 5224.240 --- --- 5230 64.560 5198.800 5263.360 --- --- 11AC20SISO Ant2 5180 30.880 5163.680 5194.560 --- --- 5200 25.600 5188.280 5213.880 --- --- 5240 26.120 5226.480 5252.600 --- --- 11AC40SISO Ant2 5190 74.960 5151.040 5226.000 --- --- 5230 65.360 5195.520 5260.880 --- --- 11AC80SISO Ant2 5210 116.640 5154.640 5271.280 --- --- Page 9 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs 11A_Ant2_5180 11A_Ant2_5200 11A_Ant2_5240 Page 10 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N20SISO_Ant2_5180 11N20SISO_Ant2_5200 11N20SISO_Ant2_5240 Page 11 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant2_5190 11N40SISO_Ant2_5230 11AC20SISO_Ant2_5180 Page 12 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC20SISO_Ant2_5200 11AC20SISO_Ant2_5240 11AC40SISO_Ant2_5190 Page 13 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC40SISO_Ant2_5230 11AC80SISO_Ant2_5210 Page 14 of 72 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, G…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID:2BSP5-U152 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 Page 2 of 2 FCC ID:2BSP5-U152 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3

FCC ID: 2BSP5-U152 Test Positions Horizontal-Up (Separation distance of 5mm) Horizontal-Down (Separation distance of 5mm) Vertical-Front (Separation distance of 5mm) Vertical-Back (Separation distance of 5mm)

Page 1 of 40 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Shenzhen Plery Network Tech Co., Ltd. Wireless Adapter Test Model: U152 Prepared for : Shenzhen Plery Network Tech Co., Ltd. Address : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : January 14, 2026 Number of tested samples : 2 Sample No. : C260114002-1, C260114002-2 Serial number : Prototype Date of Test : January 14, 2026 ~ February 02, 2026 Date of Report : February 02, 2026 Page 2 of 40 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15 E (15.407) Report Reference No. ................. : LCSC01136013EC Date of Issue ................................... : February 02, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address ........................................... : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Shenzhen Plery Network Tech Co., Ltd. Address ........................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Test Specification Standard ......................................... : FCC CFR 47 PART 15 E (15.407) Test Report Form No. ................... : TRF-4-E-118 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : Wireless Adapter Trade Mark ...................................... : PLERY Test Model ...................................... : U152 Ratings ............................................ : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Supervised by: Approved by: Lifeng Le / File administrators Justin Zhu / Technique Director Gavin Liang/ Manager Page 3 of 40 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC01136013EC February 02, 2026 Date of issue EUT......................................... : Wireless Adapter Test Model............................... : U152 Applicant............................... : Shenzhen Plery Network Tech Co., Ltd. Address.................................. : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Shenzhen Plery Network Tech Co., Ltd. Address................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Factory................................... : Shenzhen Plery Network Tech Co., Ltd. Address................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Page 4 of 40 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 February 02, 2026 Initial Issue -- Page 5 of 40 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ........................................................................................................................ 6 1.2. SUPPORT EQUIPMENT LIST .............…

Text truncated - open the document above for the full version.

Page 1 of 41 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Shenzhen Plery Network Tech Co., Ltd. Wireless Adapter Test Model: U152 Prepared for : Shenzhen Plery Network Tech Co., Ltd. Address : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : January 14, 2026 Number of tested samples : 2 Sample No. : C260114002-1, C260114002-2 Serial number : Prototype Date of Test : January 14, 2026 ~ February 02, 2026 Date of Report : February 02, 2026 Page 2 of 41 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15E (15.407) Report Reference No. ................. : LCSC01136013EB Date of Issue .................................. : February 02, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address .......................................... : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Shenzhen Plery Network Tech Co., Ltd. Address .......................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Test Specification Standard ......................................... : FCC CFR 47 PART 15E (15.407) Test Report Form No.................... : TRF-4-E-146 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Wireless Adapter Trade Mark ..................................... : PLERY Test Model ...................................... : U152 Ratings ........................................... : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Supervised by: Approved by: Lifeng Le / File administrators Justin Zhu / Technique Director Gavin Liang/ Manager Page 3 of 41 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC01136013EB February 02, 2026 Date of issue EUT......................................... : Wireless Adapter Test Model............................... : U152 Applicant............................... : Shenzhen Plery Network Tech Co., Ltd. Address.................................. : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Shenzhen Plery Network Tech Co., Ltd. Address................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Factory................................... : Shenzhen Plery Network Tech Co., Ltd. Address................................... : 10th Floor, Building H, Huanan Digital Valley, No.1 Huanan Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Page 4 of 41 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 February 02, 2026 Initial Issue --- Page 5 of 41 FCC ID:2BSP5-U152 Report No.: LCSC01136013EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ........................................................................................................................ 6 1.2. SUPPORT EQUIPMENT LIST ........................…

Text truncated - open the document above for the full version.

Page 32 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC20SISO_Ant1_Low_5745_Peak 11AC20SISO_Ant1_High_5825_Peak 11AC40SISO_Ant1_Low_5755_Peak Page 33 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11AC40SISO_Ant1_High_5795_Peak 11AC80SISO_Ant1_Low_5775_Peak 11AC80SISO_Ant1_High_5775_Peak Page 34 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Page 35 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Result Test Mod e Ante nna ChN ame Freq (MH z) Detector Freq [MHz] Result [dBm] Limit [dBm] Gain [dBi] DC Factor [dB] Result [dBuV/ m] Limit [dBuV/ m] Verdict 11A Ant2 Low 5745 Peak 5650.000 -51.53 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -39.74 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -21.93 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -16.19 ≤25.00 2.00 0.00 - -- - -- PASS High 5825 Peak 5850.000 -28.844 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -33.26 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -45.26 ≤8.00 2.00 0.00 --- --- PASS Peak 5925.000 -53.72 ≤-29.00 2.00 0.00 - -- - -- PASS 11N 20SI SO Ant2 Low 5745 Peak 5650.000 -51.047 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -39.43 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -23.07 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -15.78 ≤25.00 2.00 0.00 - -- - -- PASS High 5825 Peak 5850.000 -21.727 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -29.36 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -43.34 ≤8.00 2.00 0.00 --- --- PASS Peak 5925.000 -55.02 ≤-29.00 2.00 0.00 - -- - -- PASS 11N 40SI SO Ant2 Low 5755 Peak 5650.000 -44.323 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -29.69 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -12.75 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -12.33 ≤25.00 2.00 0.00 - -- - -- PASS High 5795 Peak 5850.000 -30.355 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -31.06 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -40.54 ≤8.00 2.00 0.00 --- --- PASS Peak 5925.000 -50.65 ≤-29.00 2.00 0.00 - -- - -- PASS 11A C20 SIS O Ant2 Low 5745 Peak 5650.000 -50.683 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -41.65 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -25.68 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -11.26 ≤25.00 2.00 0.00 - -- - -- PASS High 5825 Peak 5850.000 -23.179 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -29.73 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -44.59 ≤8.00 2.00 0.00 --- --- PASS Peak 5925.000 -52.41 ≤-29.00 2.00 0.00 - -- - -- PASS 11A C40 SIS O Ant2 Low 5755 Peak 5650.000 -42.403 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -29.09 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -11.7 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -12.12 ≤25.00 2.00 0.00 - -- - -- PASS High 5795 Peak 5850.000 -29.108 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -30.5 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -39.84 ≤8.00 2.00 0.00 --- --- PASS Page 36 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Peak 5925.000 -50.74 ≤-29.00 2.00 0.00 - -- - -- PASS 11A C80 SIS O Ant2 Low 5775 Peak 5650.000 -33.437 ≤-29.00 2.00 0.00 --- --- PASS Peak 5700.000 -18.38 ≤8.00 2.00 0.00 --- --- PASS Peak 5720.000 -12.22 ≤13.60 2.00 0.00 --- --- PASS Peak 5725.000 -15.35 ≤25.00 2.00 0.00 - -- - -- PASS High 5775 Peak 5850.000 -19.191 ≤25.00 2.00 0.00 --- --- PASS Peak 5855.000 -21.79 ≤13.60 2.00 0.00 --- --- PASS Peak 5875.000 -24.79 ≤8.00 2.00 0.00 --- --- PASS Peak 5925.000 -38.71 ≤-29.00 2.00 0.00 - -- - -- PASS Note： 3. The Antenna Gain is compensated in the graph. 4. For transmitters operating in 5150-5350 GHz band and 5470-5725 GHz band: The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. Page 37 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136013EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs 11A_Ant2_Low_5745_Peak 11A_Ant2_High_5825_Peak 11N20SISO_Ant2_Low_5745_Peak Page 38 of 63 FCC ID:2BSP5-U152 Report No.: LCSC01136…

Text truncated - open the document above for the full version.
