2BSPQ-GP-ONE360 Degree Intelligent Audio & Video Portable All-in-One Device

Product User Manual Standard Package Contents Product Illustration 360° Intelligent Audio & Video Portable All-in-One Device Please read this manual carefully before using the product. 1. Main Unit 2. Stackable Magnetic Battery 3. Tripod X 1 X 1 X 1 X 1 X 1 X 1 4. Data Cable 5. User Manual 6. Certificate of Conformity Meeting / Privacy Button Power on/ Mute Button Display Mode Button Rotating Lens Cover Type-C Port Battery Level Indicator Magnetic Battery Connector Type-C Port TF Card Slot USB-C Cable Power Button Camera Lens Bluetooth Speaker Button WiFi / Recording Button Volume Down Button Volume Up Button TF Card Indicator Light WiFi Indicator Light Operating Instructions 1. Operating Mode: Panoramic Meeting Mode 1.1 Connection (1) When using the magnetic battery for power: Press the battery “Power” button to check if the magnetic battery is charged. Connect the main unit to the magnetic battery. When the main unit’s “Power/Mute” button shows a steady white light, it is powered on. (2) When not using the magnetic battery for power: Use the data cable to connect the main unit to the computer. After the computer is powered on, the main unit’s “Power/Mute” button will show a steady white light, indicating it is powered on. 1.2 Startup and Operation (1) Power on: Long-press the Power/Mute button. Device enters the last used mode. (2) Switch Mode: If not in Panoramic Meeting Mode (solid blue Meeting/Privacy light), long-press the Meeting/Privacy button. (3) Connect to computer: Ensure the data cable is properly connected. (4) Device Recognition: Open your conferencing app and select “GP-8A” (camera, mic, speaker). (5) Switch display modes: Long-press the Display Mode button to toggle between Panoramic Focus (A·T) and Split-Screen (H·H). (6) Microphone: Short-press the Power/Mute button to toggle mic on/off. (7) Camera: Short-press the Meeting/Privacy button to toggle camera on/off. (8) Power Off: Long-press the Power/Mute button. When not using a magnetic battery When using a magnetic battery T YPE-CU SB/TYPE-CT YPE-C U SB/TYPE-C 2. Operating Mode: Panoramic Recording Mode (1) Insert the TF card while the device is off. (2) Enter Panoramic Meeting Mode (the “Conference/Privacy” light turns solid blue). Make sure the TF card light is solid blue and the “WiFi/Record” light is solid white; if not, check the card. (3) Press the “WiFi/Record” button to start recording (flashes white), and press again to stop (returns to solid white). (4) Hold the “Display Mode” button to switch between display options (“A·T” = Panoramic Close-Up, “H·H” = Split Screen). (5) Press the “Power/Mute” button to toggle the microphone, and the “Conference/Privacy” button to toggle the camera. (6) To power off, hold “Power/Mute,” remove the TF card, and check recordings via a card reader. Files are saved as MP4 in 2-minute clips. TF Card Slot WiFi / Record Button Insert TF card before powering on. After entering Meeting Mode, short-press the WiFi/Record button. 3. Operating Mode: Bluetooth Speaker Mode (1) Hold the “Power/Mute” button to turn on. (2) To switch modes, hold the “Bluetooth Speaker” button (blue light flashes for pairing). (3) On your device, enable Bluetooth and select “GP-8A.” Once paired, the blue light stays solid. (4) Press the “Bluetooth Speaker” button to toggle sound. (5) Use “Volume Up/Down” to adjust — hold to change continuously. 4. How to Stack and Use the magnetic batterys (1) Each magnetic battery has a capacity of 10,000mAh. (2) Press the battery “Power” button to display the remaining charge (percentage). (3) When used as a standalone power bank, both TYPE-C ports support fast charging. (4) The main unit and magnetic battery connect quickly via the magnetic dock. (5) Charge the magnetic battery through its TYPE-C port. The main unit’s USB TYPE-C port cannot charge the battery. (6) When stacking multiple magnetic batterys, charging starts from the bottom battery and continues upward. After pressing and holding the “Bluetooth Speaker” button, select “GP-8A” for Bluetooth pairing. Connected via magnetic dock When the upper power bank is charging, the lower one cannot charge at the same time. Charging is prioritized for the bottom module. Product Specifications 360° Intelligent Audio & Video Portable All-in-One Device Model Main Control Chip Image Sensor Lens Focal Length Lens Depth of Field Lens Viewing Angle Video Encoding Frame Rate Video Tool Function keys Product Size Magnetic Battery Operating Environment GP-8A Dragonfly Zero 1/2.8 - inch CMOS, 2 MP 2.9mm 3-5M H: 360°, V: 60° H.264/MJPEG 1080P@25/30fps Cloud Meeting Tool Temperature: - 10°C to 50 °C Humidity: 10 % ~ 95 % 7 Functional Keys Main Unit: 80 mm, Height: 83 mm (without battery) magnetic Battery: 80 mm, Height: 41 mm 10000 mAh External Module GoPal Mic Array Omnidirectional MIC + 3A Algorithm 2-3M G711A/PCM/AAC 4W MP4 Panoramic + Close-up, Split-Screen Local TF Card Recording (requires TF card) 8W Type-C (USB 2.0), Bluetooth Main Unit: 280g Magnetic Battery: 220g Moonlight Silver Sahara GoldCosmic Black Product Alias Sound Source Localization Mic Pickup Audio Codec Built- in Speaker Pickup Radius File Storage Screen Mode Recording Mode External Connection Product Weigh Product Color Power Consumption Frequently Asked Questions 1. When the main unit is connected to a computer via USB, does it still need the magnetic battery (or external power supply)? Not always. The power output of the computer’s USB or TYPE-C port varies by brand and model. If the power supply is insufficient, you will need to connect an external magnetic battery or external power supply to ensure stable power. 2. What kind of meeting rooms is this panoramic smart audio-video all-in-one device suitable for? It is suitable for small to medium meeting rooms with a radius of 3–5 meters (about 7–15 people). The optimal radius is 2–3 meters. Please note that environmental factors such as background noise, echo, or lighting conditions may affect audio and video perfor…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Nov. 20, 2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BSPQ-GP-ONE [Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd.] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd.] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Andy Fu Rev 1/26/2023 Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Nov. 20, 2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BSPQ-GP-ONE [Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd.] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Andy Fu

1/1 USAgentforServiceofProcessLETTEROFATTESTATION Applicant’sName: DragonflyIntelligentVisionandTechnology (Shenzhen)Co.,Ltd. USAgentforServiceofProcess’sName: HOPEKCORPORATIONINC Title:ManagerTitle:Manager Signatur TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: HOPEK CORPORATION INC Address: 16755 Coyote Bush Dr Unit 84, San Diego, CA 92127 United States FRN: 0034562900 Contact Name: Peter Davis Telephone No: 561-235-6113 E-mail: [email protected] This letter is to confirm that the US Agent for Service of Process accepts responsibility to act as a local representative on behalf of Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Applicant: Company Name: Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Product Description: 360 Degree Intelligent Audio & Video Portable All-in-One Device FRN: 0037599339 Grantee Code: 2BSPQ FCC ID: 2BSPQ-GP-ONE Contact Name: Andy Fu Address: Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Telephone No: 18123653842 E-mail: [email protected] The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. This Agreement is valid until (Permanently valid). Date: 2025/11/20 eSignature

Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 24, 2025 Subject; Request for Confidentiality FCC ID: 2BSPQ-GP-ONE To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Andy Fu Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Date: Nov. 20, 2025 Product Model Number: GP-ONE, GP-MAX, GP-8A, GP-8B, GP-8C, GP-8D, GP-PRO FCC ID: 2BSPQ-GP-ONE To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 18123653842 On behalf of: Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd.

Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Family models declaration letter Nov. 20, 2025 We Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Of Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Declare under our sole responsibility that the product FCC ID: 2BSPQ-GP-ONE Product: 360 Degree Intelligent Audio & Video Portable All-in-One Device Model Number: GP-ONE, GP-MAX, GP-8A, GP-8B, GP-8C, GP-8D, GP-PRO All the models are the same circuit and module, except the model No.. Sincerely, Andy Fu/ Manager E-mail: : [email protected] Phone: 18123653842 Fax: 18123653842 Address : Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China

Acknowledgment Letter CUSTOMER APPROVED BY Approved byChecked byPrepared by SUPPLIER APPROVED BY Approved byChecked byPrepared by FN-LINK TECHNOLOGY LIMITED No. 50, Tiezai Road, Gongle Community, Xixiang Subdistrict, Bao'an District, Shenzhen City. Floor 14, Building B, Fenghuang Zhigu. Customer Project Name Customer NO. GP8AB1006 specification FPC antenna for 2.4-5G, size 28.08X27.81MM; wire length 120MM, wire diameter 1.13mm (black color), 1st generation terminal port facing downward. Supplier NO. Specification NO. Write by Wei Yuanji REV. Ver.2.0 Date 2025-9-10 Note antenna testing FN-LINK TECHNOLOGY LIMITED Dragonfly Intelligence 1. Index FN-LINK TECHNOLOGY LIMITED No. content Page - Acknowledgment form cover 1 - Version Change Log 2 1 Acknowledgment Form List 3 2 Test equipment and conditions 4 3 Prototype structure description document 5 4 Antenna finished product drawing 6 5 S11 7 6 Gain / Efficiency / 3D Graph 8 7 packaging 9 1. Test Equipment & Conditions 1.1 Network Analyzers : KEYSIGHT P5002A 1.2 Communications Test Set: R&S CMW 500 1.3 3D Chamber Test System: 24-channel testing system 1.Test schematic diagram of the microwave anechoic chamber 2. explain。 This report summarizes the electrical performance results of the antenna in this project, including the S11 parameters, Gain and Efficiency of the antenna. FN-LINK TECHNOLOGY LIMITED FN-LINK TECHNOLOGY LIMITED Antenna finished product drawing black line Disconnect the wire Unit：mm FN-LINK TECHNOLOGY LIMITED Product picture FN-LINK TECHNOLOGY LIMITED Specification A. Electrical Properties Frequency Rang 2.4-5G-GHz Impedance50Ω Nominal VSWR 2.0 Max. (with casing) VSWR 4.0 4.5 (in free space) Gain(peak)2.4GHz(2.6) 5GHz(4.1) Out of roundness 3.0 dBi（Max.） RadiationOmni-Directional PolarizationLinear Vertical B.Physical Properties ConnectorType IPEX Generation 1 CableOD:1.13mm Antenna Body FPC electrolytic copper C.Environmental Operating Temp-40°C~+65°C Storage Temp-40°C~+65°C FN-LINK TECHNOLOGY LIMITED Black antenna S11 Freq/GHz240024502500500055005850 VSWR1.61.31.31.41.31.3 FN-LINK TECHNOLOGY LIMITED WIFI antenna for 2.4 - 5G data transmission Frequency/MhzMaxGain/dBiEfficiency / % 24003.0659.26 24103.161.4 24203.6464.16 24303.6266.13 24403.8968.19 24503.7467.97 24603.9366.67 24704.0565.81 24804.1264.87 24904.0163.25 25003.8861.11 50001.1153.44 51001.7860.55 52001.7960.48 53001.3357.5 54002.2262.66 55002.454.57 56001.7763.35 57002.6456.99 58002.1254.87 FN-LINK TECHNOLOGY LIMITED WIFI 2.4-5G Antenna Apple Polar Plot (Black antenna)3DPattern@2400-2500MHz 5150-5850MHz

Ext Photos Model: GP-ONE Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

Mode:GP-ONE

Int Photos Model: GP-ONE Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 BT ANT WIFI ANT Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19

- Page 1 of 11 - Report No.: HB20250918059E-03 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com RF EXPOSURE Test Report Product: 360 Degree Intelligent Audio & Video Portable All-in-One Device Trade Mark: That Dragonfly Model Number: GP-ONE FCC ID: 2BSPQ-GP-ONE Prepared for Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 11 - Report No.: HB20250918059E-03 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 6 1.4 ANCILLARY EQUIPMENT .............................................................................................................................................. 6 2 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 7 2.1 TEST LABORATORY ..................................................................................................................................................... 7 2.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 7 2.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 7 2.4 TEST SOFTWARE ........................................................................................................................................................ 7 3 LIST OF TEST EQUIPMENT ................................................................................................................................ 8 4 RF EXPOSURE .................................................................................................................................................. 9 4.1 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS........................................................................................................ 9 4.1.1. Limit ............................................................................................................................................................ 9 4.1.2. Test Result ................................................................................................................................................... 9 - Page 3 of 11 - Report No.: HB20250918059E-03 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Address ................................. : Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Manufacturer's Name .......... : Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Address ................................. : Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Product description Product name ........................ : 360 Degree Intelligent Audio & Video Portable All-in-One Device Model Number ....................... : GP-ONE Standards ............................. : FCC CFR 47 PART 1 , 1.1310 Test procedure ....................... : KDB 447498 D01 General RF Exposure Guidance v06 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Sept. 18, 2025~Oct. 17, 2025 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : (M i n g L i u) Authorized Signatory : (L e o S u) - Page 4 of 11 - Report No.: HB20250918059E-03 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Revision History Revised No. Date of Issue Description 01 Oct. 17, 2025 Original - Page 5 of 11 - Report No.: HB20250918059E-03 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel:…

Text truncated - open the document above for the full version.

- Page 1 of 61 - Report No.: HB20250918059E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Test Report Product: 360 Degree Intelligent Audio & Video Portable All-in-One Device Trade Mark: That Dragonfly Model Number: GP-ONE FCC ID: 2BSPQ-GP-ONE Prepared for Dragonfly Intelligent Vision and Technology (Shenzhen) Co. , Ltd. Room 809B, 8F, Building 7, Shenzhen Bay Science and Technology Eco-park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 61 - Report No.: HB20250918059E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 6 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 6 1.2 TEST MODE .............................................................................................................................................................. 6 1.3 OPERATION CHANNEL LIST ........................................................................................................................................... 7 1.4 TEST SETUP .............................................................................................................................................................. 7 1.5 POWER SETTING CONFIGURATION PARAMETERS ............................................................................................................... 7 1.6 ANCILLARY EQUIPMENT .............................................................................................................................................. 8 2 SUMMARY OF TEST RESULT ............................................................................................................................. 9 3 TEST FACILITIES AND ACCREDITATIONS .......................................................................................................... 10 3.1 TEST LABORATORY ................................................................................................................................................... 10 3.2 ENVIRONMENTAL CONDITIONS ................................................................................................................................... 10 3.3 MEASUREMENT UNCERTAINTY ................................................................................................................................... 10 3.4 TEST SOFTWARE ...................................................................................................................................................... 11 4 LIST OF TEST EQUIPMENT .............................................................................................................................. 12 5 TEST ITEM AND RESULTS ............................................................................................................................... 14 5.1 ANTENNA REQUIREMENT .......................................................................................................................................... 14 5.1.1 Standard Requirement ............................................................................................................................. 14 5.1.2 Test Result ................................................................................................................................................. 14 5.2 CONDUCTED EMISSION ............................................................................................................................................. 15 5.2.1 Limits ........................................................................................................................................................ 15 5.2.2 Test Procedures ......................................................................................................................................... 15 5.2.3 Test Setup.................................................................................................................................................. 16 5.2.4 Test Result ................................................................................................................................................. 16 5.3 RADIATED EMISSION ................................................................................................................................................ 19 5.3.1 Limits ........................................................................................................................................................ 19 5.3.2 Test Procedures ......................................................................................................................................... 19 5.3.3 Test Setup.................................................................................................................................................. 19 5.3.4 Test Result ................................................................................................................................................. 20 5.3.5 Radiated Band Edge ................................................................................................................................. 25 5.3.6 Spurious Emission in …

Text truncated - open the document above for the full version.

Photographs of the Test Setup Model: GP-ONE Radiated Emission Below 1GHz Radiated Emission Above 1GHz Conducted Emission
