2BSSX-MBR001Intelligent Care Companion Device

Intelligent Care Companion Device MBR001 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harm full interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This Device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Device has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the device kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the device. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. ISED Statement ‐ English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. ‐ French:Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux CNR exempts de licence d’Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas causer d’interférences. (2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement indésirable de l’appareil. SpecificAbsorption Rate (SAR) information: This device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.ISED RF Exposure Information and Statement the SAR limit of and Canada(ISED) is 1.6 W/kg averaged over one gram of tissue. Devicetypes: device has also been tested against this SAR limit.This device was tested for typical body-worn operations with the back of the device kept 0mm from the body. To maintain compliance with ISED RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the device. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with ISED RF exposure requirements, and should be avoided. Informations sur le débit d’absorption spécifique (DAS) : Cet appareil répond aux exigences gouvernementales en matière d’exposition auxondes radio. Les lignes directrices sont fondées sur des normes qui ont été élaborées par des organismes scientifiques indépendants dans le cadre d’une évaluation périodique et approfondie d’études scientifiques. Les normes comprennent une marge de sécurité substantielle conçue pour assurer la sécurité de toutes les personnes, quel que soit leur âge ou leur état de santé. La limite DAS du Canada (ISDE) est de 1,6 W/kg en moyenne sur un gramme de tissu. Types d’appareils : l’appareil a également été testé par rapport à cette limite DAS. Cet appareil a été testé pour des opérations typiques portées sur le corps, l’arrière de l’appareil étant à 0 mm du corps. Pour maintenir la conformité aux exigences d’exposition RF d’ISDE, utilisez des accessoires qui maintiennent une distance de séparation de 0 mm entre le corps de l’utilisateur et l’arrière de l’appareil.L’utilisation de clips de ceinture, d’étuis et d’accessoires similaires ne doit pas à ces exigences peut ne pas être conforme aux exigences d’exposition aux RF d’ISDE et doit être évitée The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.L'appareil destiné à foncti…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] S T L A B S SAR Dipole Performance Measurement Report EUT Type： SAR Validation Dipole and Waveguide Model Name： DIP2G450, WGA32 Brand Name: SATIMO Test Conclusion： Pass Test Date： 11 Dec. 2024&03 Jul. 2025 Date of Issue： 03 Jul. 2025 Testing Engineer : (Xin.Liu) Technical Manager : (Shifan. Long) Authorized Signatory : (Bovey Yang) ISSUED BY Shenzhen STS Test Services Co., Ltd. Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until PC Acer N/A N/A N/A N/A E-Field Probe MVG SSE2 SN 08/21 EPGO352 2024.09.18 2025.09.17 Dielectric Probe Kit MVG SCLMP SN 32/14 OCPG67 2024.09.18 2025.09.17 Phantom1 MVG SAM SN 32/14 SAM115 N/A N/A Phantom2 MVG SAM SN 32/14 SAM116 N/A N/A Attenuator Agilent 99899 DC-18GHz N/A N/A Directional coupler Narda 4226-20 3305 N/A N/A Network Analyzer Agilent E5071C MY46520378 2024-09-25 2025-09-26 Multi Meter Keithley Multi Meter 2000 4050073 2024-09-25 2025-09-26 Signal Generator Agilent N5182A MY50140530 2024-09-25 2025-09-26 Power Amplifier DESAY ZHL-42W 9638 2024-09-25 2025-09-26 Power Meter R&S NRP 100510 2024-09-25 2025-09-26 Power Sensor R&S NRP-Z11 101919 2024-09-25 2025-09-26 Power Sensor Keysight U2021XA MY56280002 2024-09-25 2025-09-26 Temperature hygrometer SuWei SW-108 N/A 2024.10.15 2025.10.14 Thermograph Elitech RC-4 S/N EF7176501537 2024.10.15 2025.10.14 ISSUED BY Shenzhen STS Test Services Co., Ltd. 2. <Justification of the extended calibration> Referring to KDB 865664 D01, if dipoles are verified in return loss<-20dB, (within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 2450 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2023.07.04 -26.03 - 46.3 - 2024.07.01 -26.42 1.50 47.25 2.05 2025.07.03 -26.91 3.38 47.4 2.37 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 2450 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 5000 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2023.07.04 < -8.23 - - - 2024.07.01 -13.17 - - - 2025.07.03 -13.72 - - - The return loss is <-8dB, within 20% of prior calibration; Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 5000MHz

FCC ID: 2BSSX-MBR001 Test Setup Photos of the EUT FCC ID: 2BSSX-MBR001

SAR Setup photos for FCC ID: 2BSSX-MBR001 Back Side (separation distance is 0mm) Top side(separation distance is 0mm)

1. Antenna Description: Antenna type PIFA Antenna Model MBR001 Frequency range 2400-2500MHz, 5180-5240MHz, 5745-5825MHz Manufacturer Shanghai MBrainet Intelligent Technology Co.,Ltd Address Unit 025, Room 302-1, No.468, Zhongshan South 1 st Road, Huangpu District, Shanghai, China ANT Peak Gain 0.77 dBi for 2400-2500MHz 2.12 dBi for 5180-5240MHz 2.06 dBi for 5745-5825MHz 2. Antenna Photo: Length :21.04mm Width:16.92mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz 5180MHz 5220MHz 5240MHz 5745MHz 5785MHz 5825MHz

1 FCC Appendix RF Test Data for BLE FCC ID : 2BSSX-MBR001 Company : Shanghai MBrainet Intelligent Technology Co.,Ltd EUT : Intelligent Care Companion Device Model Number : MBR001 Report No. : CTA25101000601 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.640 2401.700 2402.340 0.5 PASS 2440 0.644 2439.700 2440.344 0.5 PASS 2480 0.656 2479.692 2480.348 0.5 PASS BLE_2M Ant1 2402 1.048 2401.448 2402.496 0.5 PASS 2440 1.136 2439.448 2440.584 0.5 PASS 2480 1.088 2479.448 2480.536 0.5 PASS 3 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 4 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 5 BLE_2M_Ant1_2480 6 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0031 2401.5206 2402.5237 --- --- 2440 1.0067 2439.5193 2440.5260 --- --- 2480 1.0057 2479.5214 2480.5271 --- --- BLE_2M Ant1 2402 2.0055 2401.0338 2403.0393 --- --- 2440 1.9895 2439.0368 2441.0263 --- --- 2480 1.9970 2479.0386 2481.0356 --- --- 7 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 8 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 9 BLE_2M_Ant1_2480 10 Appendix C: Maximum conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 0.05 ≤30 PASS 2440 -0.13 ≤30 PASS 2480 -0.01 ≤30 PASS BLE_2M Ant1 2402 0.09 ≤30 PASS 2440 -0.10 ≤30 PASS 2480 0.01 ≤30 PASS 11 Appendix D: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -15.60 ≤8.00 PASS 2440 -15.55 ≤8.00 PASS 2480 -15.46 ≤8.00 PASS BLE_2M Ant1 2402 -17.62 ≤8.00 PASS 2440 -17.39 ≤8.00 PASS 2480 -17.54 ≤8.00 PASS 12 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 13 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 14 BLE_2M_Ant1_2480 15 Appendix E: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 -0.33 -50.89 ≤-20.33 PASS High 2480 -0.08 -51.88 ≤-20.08 PASS BLE_2M Ant1 Low 2402 -0.51 -36.74 ≤-20.51 PASS High 2480 -0.05 -51.78 ≤-20.05 PASS 16 Test Graphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 BLE_2M_Ant1_Low_2402 17 BLE_2M_Ant1_High_2480 18 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference -1.36 -1.36 --- PASS 30~1000 -1.36 -68.49 ≤-21.36 PASS 1000~26500 -1.36 -42 ≤-21.36 PASS 2440 Reference -1.29 -1.29 --- PASS 30~1000 -1.29 -68.77 ≤-21.29 PASS 1000~26500 -1.29 -41.89 ≤-21.29 PASS 2480 Reference -0.18 -0.18 --- PASS 30~1000 -0.18 -68.59 ≤-20.18 PASS 1000~26500 -0.18 -42.73 ≤-20.18 PASS BLE_2M Ant1 2402 Reference -0.30 -0.30 --- PASS 30~1000 -0.30 -68.4 ≤-20.3 PASS 1000~26500 -0.30 -42.7 ≤-20.3 PASS 2440 Reference -2.66 -2.66 --- PASS 30~1000 -2.66 -57.97 ≤-22.66 PASS 1000~26500 -2.66 -45.61 ≤-22.66 PASS 2480 Reference -0.26 -0.26 --- PASS 30~1000 -0.26 -67.97 ≤-20.26 PASS 1000~26500 -0.26 -43.01 ≤-20.26 PASS 19 Test Graphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 20 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 21 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 22 BLE_1M_Ant1_2480_1000~26500 BLE_2M_Ant1_2402_0~Reference 23 BLE_2M_Ant1_2402_30~1000 BLE_2M_Ant1_2402_1000~26500 BLE_2M_Ant1_2440_0~Reference 24 BLE_2M_Ant1_2440_30~1000 BLE_2M_Ant1_2440_1000~26500 25 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 BLE_2M_Ant1_2480_1000~26500 26 27 Appendix G: Duty Cycle Test Result TestMode Antenna Freq(MHz) ON Time [ms] Period [ms] X DC [%] xFactor Limit Verdict BLE_1M Ant1 2402 0.41 0.62 0.6613 66.13 1.80 --- --- 2440 0.41 0.62 0.6613 66.13 1.80 --- --- 2480 0.41 0.62 0.6613 66.13 1.80 --- --- BLE_2M Ant1 2402 0.23 0.63 0.3651 36.51 4.38 --- --- 2440 0.23 0.63 0.3651 36.51 4.38 --- --- 2480 0.23 0.63 0.3651 36.51 4.38 --- --- 28 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 29 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 30 BLE_2M_Ant1_2480

1 FCC Appendix RF Test Data for 2.4GWIFI FCC ID : 2BSSX-MBR001 Company : Shanghai MBrainet Intelligent Technology Co.,Ltd EUT : Intelligent Care Companion Device Model Number : MBR001 Report No. : CTA25101000603 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 9.160 2407.480 2416.640 0.5 PASS 2437 8.880 2432.520 2441.400 0.5 PASS 2462 8.160 2458.040 2466.200 0.5 PASS 11G Ant1 2412 16.280 2403.960 2420.240 0.5 PASS 2437 16.360 2428.880 2445.240 0.5 PASS 2462 16.280 2453.920 2470.200 0.5 PASS 11N20SISO Ant1 2412 17.240 2403.440 2420.680 0.5 PASS 2437 17.360 2428.400 2445.760 0.5 PASS 2462 17.320 2453.400 2470.720 0.5 PASS 11N40SISO Ant1 2422 34.160 2405.200 2439.360 0.5 PASS 2437 34.160 2420.120 2454.280 0.5 PASS 2452 34.240 2434.960 2469.200 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 7 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 8 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.991 2405.5566 2418.5476 --- --- 2437 12.949 2430.5566 2443.5056 --- --- 2462 12.982 2455.5252 2468.5072 --- --- 11G Ant1 2412 16.604 2403.7523 2420.3563 --- --- 2437 16.585 2428.7515 2445.3365 --- --- 2462 16.582 2453.7538 2470.3358 --- --- 11N20SISO Ant1 2412 17.453 2403.3306 2420.7836 --- --- 2437 17.451 2428.3168 2445.7678 --- --- 2462 17.480 2453.3004 2470.7804 --- --- 11N40SISO Ant1 2422 34.858 2404.7297 2439.5877 --- --- 2437 34.868 2419.6908 2454.5588 --- --- 2452 34.888 2434.6627 2469.5507 --- --- 9 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 10 11G_Ant1_2412 11G_Ant1_2437 11 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 12 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 13 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 14 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 14.97 ≤30.00 PASS 2437 15.15 ≤30.00 PASS 2462 15.35 ≤30.00 PASS 11G Ant1 2412 13.44 ≤30.00 PASS 2437 13.95 ≤30.00 PASS 2462 13.97 ≤30.00 PASS 11N20SISO Ant1 2412 13.91 ≤30.00 PASS 2437 14.40 ≤30.00 PASS 2462 14.33 ≤30.00 PASS 11N40SISO Ant1 2422 13.27 ≤30.00 PASS 2437 13.29 ≤30.00 PASS 2452 13.41 ≤30.00 PASS 15 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -14.34 ≤8.00 PASS 2437 -13.91 ≤8.00 PASS 2462 -13.31 ≤8.00 PASS 11G Ant1 2412 -21.01 ≤8.00 PASS 2437 -20.49 ≤8.00 PASS 2462 -20.44 ≤8.00 PASS 11N20SISO Ant1 2412 -20.22 ≤8.00 PASS 2437 -20.49 ≤8.00 PASS 2462 -20.16 ≤8.00 PASS 11N40SISO Ant1 2422 -21.21 ≤8.00 PASS 2437 -21.27 ≤8.00 PASS 2452 -22.30 ≤8.00 PASS 16 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 17 11G_Ant1_2412 11G_Ant1_2437 18 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 19 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 20 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 21 Appendix E: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 1.23 -51.99 ≤-18.77 PASS High 2462 1.26 -55.45 ≤-18.75 PASS 11G Ant1 Low 2412 -7.05 -43.04 ≤-27.05 PASS High 2462 -6.27 -52.5 ≤-26.27 PASS 11N20SISO Ant1 Low 2412 -6.92 -46.47 ≤-26.92 PASS High 2462 -6.71 -52.55 ≤-26.71 PASS 11N40SISO Ant1 Low 2422 -9.82 -51.57 ≤-29.82 PASS High 2452 -10.16 -54.05 ≤-30.16 PASS 22 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 23 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 24 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 25 26 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 0.75 0.75 --- PASS 30~1000 0.75 -54.11 ≤-19.25 PASS 1000~26500 0.75 -44.66 ≤-19.25 PASS 2437 Reference -0.30 -0.30 --- PASS 30~1000 -0.30 -55.9 ≤-20.3 PASS 1000~26500 -0.30 -45.07 ≤-20.3 PASS 2462 Reference -0.17 -0.17 --- PASS 30~1000 -0.17 -55.4 ≤-20.17 PASS 1000~26500 -0.17 -45.46 ≤-20.17 PASS 11G Ant1 2412 Reference -6.68 -6.68 --- PASS 30~1000 -6.68 -59.49 ≤-26.68 PASS 1000~26500 -6.68 -44.17 ≤-26.68 PASS 2437 Reference -6.80 -6.80 --- PASS 30~1000 -6.80 -59.48 ≤-26.8 PASS 1000~26500 -6.80 -44.43 ≤-26.8 PASS 2462 Reference -6.84 -6.84 --- PASS 30~1000 -6.84 -59.18 ≤-26.84 PASS 1000~26500 -6.84 -44.88 ≤-26.84 PASS 11N20SISO Ant1 2412 Reference -7.57 -7.57 --- PASS 30~1000 -7.57 -58.86 ≤-27.57 PASS 1000~26500 -7.57 -43.94 ≤-27.57 PASS 2437 Reference -6.07 -6.07 --- PASS 30~1000 -6.07 -58.84 ≤-26.07 PASS 1000~26500 -6.07 -44.57 ≤-26.07 PASS 2462 Reference -7.12 -7.12 --- PASS 30~1000 -7.12 -59.02 ≤-27.12 PASS 1000~26500 -7.12 -44.78 ≤-27.12 PASS 11N40SISO Ant1 2422 Reference -10.20 -10.20 --- PASS 30~1000 -10.20 -61.49 ≤-30.2 PASS 1000~26500 -10.20 -44.18 ≤-30.2 PASS 2437 Reference -10.28 -10.28 --- PASS 30~1000 -10.28 -61.84 ≤-30.28 PASS 1000~26500 -10.28 -44.59 ≤-30.28 PASS 2452 Reference -10.12 -10.12 --- PASS 30~1000 -10.12 -61.62 ≤-30.12 PASS 1000~26500 -10.12 -44.69 ≤-30.12 PASS 27 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 28 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 29 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 30 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 31 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 32 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 33 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 34 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 35 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 36 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 37 11N20SISO_Ant1_2462_30…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA25101000603 2BSSX-MBR001 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Oct. 21, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : Shanghai MBrainet Intelligent Technology Co.,Ltd Address ............................................ : Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Intelligent Care Companion Device Trade Mark ....................................... : AlmaCAREVUE Manufacturer .................................... : Shanghai MBrainet Intelligent Technology Co.,Ltd Model/Type reference ...................... : MBR001 Listed Models ................................... : MBR002, MBR003, MBR004, MBR011, MBR012, MBR013, MBR014 Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Ratings ............................................. : Input: 5.0V 2A Battery: 3.8V 5100mAh 19.38Wh Result ............................................... : PASS Report No.: CTA25101000603 Page 2 of 28 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Intelligent Care Companion Device Model /Type : MBR001 Listed Models : MBR002, MBR003, MBR004, MBR011, MBR012, MBR013, MBR014 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Shanghai MBrainet Intelligent Technology Co.,Ltd Address : Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Manufacturer : Shanghai MBrainet Intelligent Technology Co.,Ltd Address : Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25101000603 Page 3 of 28 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 6 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory.................................................................…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................. : FCC ID. ......................................... : CTA25101000601 2BSSX-MBR001 Compiled by ( position+printed name+signature) : File administrators Zoey Cao Supervised by ( position+printed name+signature) : Project Engineer Ace Chai Approved by ( position+printed name+signature) : RF Manager Eric Wang Date of issue ...................................: Oct. 21, 2025 Testing Laboratory Name .............: Shenzhen CTA Testing Technology Co., Ltd. Address ..........................................: Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name...........................: Shanghai MBrainet Intelligent Technology Co.,Ltd Address ...........................................: Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Test specification ......................... : Standard ..........................................: FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................ : Intelligent Care Companion Device Trade Mark ......................................: AlmaCAREVUE Manufacturer ...................................: Shanghai MBrainet Intelligent Technology Co.,Ltd Model/Type reference .....................: MBR001 Listed Models ..................................: MBR002, MBR003, MBR004, MBR011, MBR012, MBR013, MBR014 Modulation ......................................: GFSK Frequency ........................................ From 2402MHz to 2480MHz Ratings ............................................: Input: 5.0V 2A Battery: 3.8V 5100mAh 19.38Wh Result ..............................................: PASS Report No.: CTA25101000601 Page 2 of 34 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Intelligent Care Companion Device Model /Type : MBR001 Listed Models : MBR002, MBR003, MBR004, MBR011, MBR012, MBR013, MBR014 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Shanghai MBrainet Intelligent Technology Co.,Ltd Address : Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Manufacturer : Shanghai MBrainet Intelligent Technology Co.,Ltd Address : Unit 025, Room 302-1, No.468, Zhongshan South 1st Road, Huangpu District, Shanghai, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25101000601 Page 3 of 34 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS .................…
