2BSVX-NX5Sound card

1234 8765 9 10 12 11 18 17 15 16 14 13 1 2 3 4 Hardware Introduction I、Functional Area Introduction: 1.: Press this button lightly to enter the power on state. 2. :Lightly press this button to turn on or off the ear return function. 3. :Lightly press this button to mute the microphone sound, and long press again to unmute the microphone. 4. :By default, the "internal storage" is turned off when turned on. If you want to turn on the "internal storage", lightly press this button and the light will flash. This feature is used on the computer. (Turning off the internal speaker means turning off all sounds on the computer. In the live broadcast room, the other party cannot hear all the sounds on your computer, only the sound of the microphone.) 5.Avoid: Lightly press this button to turn on the dodge function l i ght fla sh i n g. W h e n t h e m i c roph o n e s ou n d i s i npu t, t h e a c c o m p a n i m e n t s o u n d f a d e s o u t o r d e c r e a s e s, a n d t h e accompaniment returns to normal after the microphone sound ends; Lightly press this button again to turn off the dodge function. 6.Follow Singing: Lightly press this button to turn on and off the singing function; (Long press this button to turn on and off the original sound). 7.Autotune: Suitable for singing electronic music songs. Pressing this key lightly in electronic music mode can adjust the electronic music tone and provide voice prompts. 8.Mode:Lightly press this key to switch in sequence:Popular、Professional、Voice、RAP、Girltomale、Male to Girl、To child、Monster. 9. In BT mode, you can control the previous song, play pause, and next song; (Note: In the tone changing mode, it is for f ine-tuning the tone, while in other modes it is for controlling the up and down tracks). 10.S p e c i a l e f f e c t s: S h o r t p r e s s o n e o f t h e b u t t o n s t o o u t p u t a n a t m o s p h e r e s o u n d e f f e c t d u r i n g l i v e s t r e a m i n g . 11.Customization: Long press one of the buttons, and when you hear a prompt sound, you can enter the custom recording mode. Release it to automatically save the recording. (When long pressing this button again and hearing a prompt sound, it will automatically delete the previous recording content and re record). To delete a custom recording: Long press the noise reduction button to enter the deletion process. At this time, all custom indicator lights will flash, and once the deletion is successful, they will become constantly on. 12.Noise suppression: The default noise reduction on light flashes, which can reduce microphone environmental noise and improve recording quality. Press this button lightly to turn off the noise reduction light and keep it on; (Long press this key to delete custom recorded content, and the corresponding indicator lights for all custom keys will flash. If the deletion is successful, the light will remain on.). 13.Indicator light: Singing mode indicator light; Lightly press the mode button to select the mode, and the corresponding indicator light will flash. 14.Indicator light: This indicator flashes when OTG is not connected. 15.indicator light: If the OTG connection is successful, this indicator light will flash. 16.Monitor Vol:Rotate in the "+" direction to increase headphone volume output, and rotate in the "-" direction to increase headphone volume output. The indicator light will change accordingly. 17.Mic Echo:Rotate in the "+" direction to increase microphone reverberation intensity, and rotate in the "-" direction to decrease microphone reverberation intensity. 18.Mic Vol:Rotate in the "+" direction to increase microphone volume input, and rotate in the "-" direction to decrease microphone volume input. The indicator light will change accordingly. 19.Indicator light Charging indicator light: When charging, the indicator light turns red and the fully charged light turns off. II、Interface name 1. Live streaming: Connect your phone and sound card through a 3.5mm audio cable for live streaming and recording. 2. M o b i l e p h o n e/c o m p u t e r: S u p p o r t s Ty p e-C d a t a c a b l e connection to 5V/1A power supply for charging and Connect to a computer or phone via Type-C and live stream while charging. 3.Earphones: Earphones connected to a 3.5mm interface. 4.M i c ro p h o n e: C a n b e c o n n e c t e d t o a 3.5 m m i n t e r f a c e microphone. Signal to noise ratio：106dB Output Power: 600mW Whole machine power consumption：5W Rated input：5V/1A Recording: 16bit/48KHz,90dB signal to noise ratio Replay: 16bit/48KHz,100dB signal to noise ratio Distortion: 0.1%(recording), 0.005%(replay) Battery capacity: 600MA Interface type Mic interface：3.5mm Live streaming interface: 3.5mm OTG charging interface: Type-C Ear microphone interface: 3.5mm [1]The device does not work when it is turned on. 1)Please check if all cables are connected correctly. 2)Please check if the device has enough power, please charge it and try again [with battery version]. [2]There is noise or no sound when using the headset. 1)Please try to re-plug the headset, and plug the headset before turning on the sound card. 2)Please check if the monitor switch is on. 3)Please use the original headset of the phone. [3]Noise is heard during live broadcast. 1)Turn down the microphone volume appropriately. 2)Check if the microphone and headset are fully inserted in the opposite position. [4]No accompaniment can be heard during live broadcast. 1)Turn up the accompaniment volume. 2)Check if the accompaniment cable is fully inserted into the device and the accompaniment phone. [5]They cannot hear the reverb and accompaniment during the live broadcast. 1)Turn up the accompaniment volume. 2)Check if the accompaniment cable is fully inserted into the device and the accompaniment phone. [6]The sound of the microphone cannot be monitored. 1)Check if the microphone or headphones are connected properly. 2)Please check if the monitor switch is on. [7]The computer cannot recognize the soun…
