2BSVY-BLT25001Bird Feeder with Camera

Dongguan Bolite Jiaju Co.,LTD
Bird Feeder with Camera - FCC ID 2BSVY-BLT25001 - Dongguan Bolite Jiaju Co.,LTD
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Nov 28, 2025
Application Purpose
Original Equipment
Equipment Note
Bird Feeder with Camera
Frequency Range
2402.00000000 - 2480.00000000
Company
Dongguan Bolite Jiaju Co.,LTD
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Manual Bird Feeder Camera Metal Catalog What’s in the Box...................................................1 About the Product..................................................2 Charging................................................................4 18 APP Function Int roduction................................... Assembly............................................................... 5 13 Connection and Configuration ............................... Out door Ins tallation .............................................. 9 Adding Birdseed...................................................10 Rainproof Design..................................................11 Multiple Mounting Options....................................12 Cleaning...............................................................20 FAQ.......................................................................20 Warning................................................................21 What's in the Box 1 Feeder + Camera AntennaSolar panel Perch Hanging bracket Thumbscrews *2Roof Hose clips*2Solar panel baseRoof screws *3 StrapManual user manual Screwdriver Screw kit *2A Screw kit *3 B About the Product 2 123 456 789 8 1 3 4 5 6 9 2 Roof Perch Solar panel Granary Hanging bracket Hinge Bird feeder camera Antenna Thumbscrews 7 3 Before installing or removing the Micro SD card, ensure the device is turned off or the power supply is disconnected. It is recommended to use cloud storage, which is safe and reliable for storing alarm records and accessing related video in real time. Status light Solid blueDevice is on and operating normally Device is being accessed by the client Low battery Low-power standby/not started Slowly flashing blue Solid red None Description Power Button: Press and hold for 3 to 4 seconds to turn the device on or off You will hear a voice prompt. Reset Button: Press and hold for 5 to 10 seconds to restore the device to factory settings. Silicone cover of power supply port (Can connect external power supply/solar panel to charge the battery of the device) Power interface Reset button Power button Power lightStatus light White light PIR human sensor Microphone Light-sensitive sensor Lens USB Reset TF Card POWER Remove the protective film 4 Tip: When the device indicator light turns red, or the APP receives a low battery alarm, please charge the camera immediately, otherwise the camera will not be able to turn on when the battery is exhausted, and charging will take longer. To charge the device, open the silicone cover and use the power supply port to connect external power/solar panel. Charging Fully charge the camera before use There are two charging options available: 1. Before using it for the first time, connect it to a 5V charger with a Type-C cable (not included in the package) and charge it for at least 5 hours. 2. Charging by solar panel (included in the package). Status light Solid orangeCharging Description * Please note that a solid blue light during charging indicates that the device is operating. Warning We're Here to Help When charging, both the ambient temperature and the camera temperature should be above 32°F(0°C). If the camera is exposed to cold temperatures for an extended period of time, it should be brought back to room temperature before charging. For any product questions, please do not hesitate to send EMAILS to get our best service. 5 Assembly Installation of Grain Bin Covers: 12 3 456 Remove the protective film Installation of Antennas: 90° 6 7 Installation of Solar Panels: 90° 360° 21 3 45 Screw kitA 8 Connecting to The Power Supply: 9 Step 1Step 2Step 3 Step 1Step 2Step 3 Outdoor Installation Mounting by straps Mounting by screws Attach the fixed bracket to the tree with straps. Note: For maximum stability, we recommend using straps and screws together on the tree. Attach the bird feeder to the bracket with the thumbscre. Attach the bird feeder to the bracket with the thumbscre. Installation complete. Installation complete. Attach bracket to tree with B screws kit. Screw kitB Step 1Step 2Step 3 10 Step 1Step 2Step 3 Installation by pole Adding Birdseed Use the hose clips to secure the hanging bracket onto the pole. Attach the bird feeder to the bracket with the thumbscrew. Installation complete. Open the lid of the granary and pour in the bird food. To prevent rainwater from flowing along the cable into the charging port and causing damage to the feeder, please secure the solar panel's power cable into the groove of the hanging bracket as shown in the illustration. 11 Rainproof Design 12 Multiple Mounting Options 180° The base of the feeder features multiple mounting holes, allowing you to secure the hanging bracket in different positions based on your desired orientation. Additionally, the bracket can be rotated 180° for further adjustment. 13 1 Connection and Configuration Step 1 Download app and Register an account Scan the QR code to download iCSee or search iCSee in mobile application market to download. 2 Run iCSee, register an account and login(Support third-party account) iCSee 14 1 2 3 Step 2 Configure and add device Connect your phone to WiFi network and turn on Bluetooth. Open the iCSee appregister an account and login (Figure 1). After successful loginClick the "+" button in the top right corner of the screen (Figure 2). Figure 1Figure 2 15 1 2 Figure 3Figure 4 Method 1: Connect The Device Via Bluetooth When the APP discovers the Bluetooth of the device, there will be a pop-up window. Click on the right "OK" to go to the next step (Figure 3). Note: Make sure your phone is connected to WiFi and has Bluetooth turned on Input the wifi password and confirm (Figure 4). 2.4GHz 5GHz x 16 3 Wait for device configuration to complete (Figure 5 and 6). Figure 5Figure 6 17 Figure 7Figure 8 4 5 Name your device and select the recording mode (Figure 7). If you have any other questions, you can get help through online customer service. After configuration is successful, jump to device l…

Text truncated - open the document above for the full version.

Attestation Statements

DongguanBoliteJiajuCo.,LTD CoveredEquipmentCertificationAttestationLetter 11/20/2025 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID:2BSVY-BLT25001 DongguanBoliteJiajuCo.,LTD(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. DongguanBoliteJiajuCo.,LTD(“theapplicant”)certifiesthat,asofthedateofthefiling oftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. DongguanBoliteJiajuCo.,LTD(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedor providedbyKasperskyLab,Inc.oranyofitssuccessorsandassignees,including equipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsandassignees) cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446D01 CoveredEquipmentGuidancesectionB(2a). Signature Printedname:QuanlinLiu Title:Generalmanager CompanyName:DongguanBoliteJiajuCo.,LTD Date:11/20/2025

Cover Letter(s)

DongguanBoliteJiajuCo.,LTD 11/20/2025 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2BSVY-BLT25001 PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BlockDiagrams TheoryofOperation Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signature Printedname:QuanlinLiu Title:Generalmanager

External Photos

FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001

ID Label/Location Info

LabelandLabelLocation

Internal Photos

FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001 FCCID:2BSVY-BLT25001

RF Exposure Info

Page1of7 FCCTESTREPORT FCCID:2BSMZ-BLT25001 Product: BirdFeederwithCamera ModelName: BLT25001 Brand : BOLITE ReportNo.: PTC25090912101E-FC03 Preparedfor DongguanBoliteJiajuCo,,LTD Room101,No478,LiaobuJinxingRoad,LiaobuTown,Dongguan,Guangdong Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China. ReportNo.:PTC25090912101E-FC03 Page2of7 TESTRESULTCERTIFICATION Applicant’sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Manufacture'sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Productname:BirdFeederwithCamera Modelname:BLT25001 Testprocedure:FCCCFR47Part1.1307(b)(1) TestDate: October09,2025toOctober20,2025 DateofIssue: October20,2025 TestResult:PASS ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedinthe revisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC25090912101E-FC03 Page3of7 Contents Page 2TESTSUMMARY...............................................................................................................................................4 3GENERALINFORMATION..............................................................................................................................5 3.1GENERALDESCRIPTIONOFE.U.T..........................................................................................................5 4RFEXPOSURE..................................................................................................................................................6 4.1REQUIREMENTS........................................................................................................................................6 4.2THEPROCEDURES/LIMIT........................................................................................................................6 4.3MPECALCULATIONMETHOD..................................................................................................................7 4.4TESTRESULT...........................................................................................................................................7 ReportNo.:PTC25090912101E-FC03 Page4of7 2TestSummary TestItemsTestRequirementResult MaximumPermissibleExposure (ExposureofHumanstoRFFields) 15.247(i)PASS Remark: N/A:NotApplicable ReportNo.:PTC25090912101E-FC03 Page5of7 3GeneralInformation 3.1GeneralDescriptionofE.U.T. ProductName : BirdFeederwithCamera ModelName : BLT25001 Specification : BluetoothBLE 802.11b/g/nHT20 OperationFrequency : 2402-2480MHzforBLE 2412-2462MHzfor802.11b/g/n(HT20) 2422-2452MHzfor802.11n(HT40) NumberofChannel : 40channelsForDTS 11channelsfor802.11b/g/n(HT20) 9channelsfor802.11n(HT40) TypeofModulation : GFSK,ForDTS DSSSwithDBPSK/DQPSK/CCKfor802.11b; OFDMwithBPSK/QPSK/16QAM/64QAMfor802.11g/n; Antennainstallation : Externalantenna AntennaGain : 4.74dBi Powersupply : Input:DC5V Battery Model:ZM18650-2600-2P Voltage:3.7V Capacity:5200mAh HardwareVersion : V1.0 SoftwareVersion :V1.0 ReportNo.:PTC25090912101E-FC03 Page6of7 4RFExposure TestRequirement :FCCPart1.1307(b)(1) EvaluationMethod :KDB447498D01GeneralRFExposureGuidancev06 4.1Requirements Systemsoperatingundertheprovisionsofthissectionshallbeoperatedinamannerthatensuresthat thepublicisnotexposedtoradiofrequencyenergylevelsinexcesslimitformaximumpermissible exposure.Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeen definedasamobiledevicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuser andthedevice. 4.2Theprocedures/limit (A)LimitsforOccupational/ControlledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-3.06141.63(100)*6 3.0-301842/f4.89/f(900/f)*6 30-30061.40.1631.06 300-1500F/3006 1500-100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-1.346141.63(100)*30 1.34-30824/f2.19/f(180/f)*30 30-30027.50.0730.230 300-1500F/150030 1500-100,0001.030 Note:f=frequencyinMHz;*Plane-waveequivalentpowerdensity ReportNo.:PTC25090912101E-FC03 Page7of7 4.3MPECalculationMethod E(V/m)= d GP30 PowerDensity:Pd(W/m²)= 377 2 E E = Electricfield(V/m) P=PeakRFoutputpower(W) G=EUTAntennanumericgain(numeric) d = Separationdistancebetweenradiatorandhumanbody(m) Theformulacanbechangedto Pd = 2 377 30 d GP   θφ FromthepeakEUTRFoutputpower,theminimummobileseparationdistance,d=0.2m,aswellas thegainoftheusedantenna,theRFpowerdensitycanbeobtained 4.4TestResult Mode Antenna Gain (numeric) Max.Peak OutputPower (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(mW) PowerDensity (mW/cm2) LimitofPower Density (mW/cm2) Result 2480(BLE_1M)2.981.861.86±11.9319683170.0011447741Pass 2412(11N20)2.9815.7815.78±147.6430986810.0282305871Pass Remark:2.4GWi-FiandBLEdonotsupportsimultaneoustransmission. Conclusion: 1.Calculateintheworst-casemode. 2.Max.TuneUpPowerisdeclaredbymanufacturer,andusedtocalculate. ******THEENDREPORT******

Test Report

Page1of61 FCCTESTREPORT FCCID:2BSVY-BLT25001 Product:BirdFeederwithCamera ModelName:BLT25001 Brand:BOLITE ReportNo.:PTC25090912101E-FC01 Preparedfor DongguanBoliteJiajuCo.,LTD Room101,No478,LiaobuJinxingRoad,LiaobuTown,Dongguan,Guangdong Preparedby PreciseTesting&CertificationCo.,Ltd Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC25090912101E-FC01 Page2of61 1TESTRESULTCERTIFICATION Applicant’sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Manufacture'sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Productname:BirdFeederwithCamera Modelname:BLT25001 Standards:FCCCFR47Part15Section15.247 Testprocedure:ANSIC63.10-2020 TestDate: October09,2025toOctober20,2025 DateofIssue: October20,2025 TestResult:Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlyto thetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,thisdocument maybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC25090912101E-FC01 Page3of61 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 2.1TESTSITE............................................................................................................................................................6 3GENERALINFORMATION.......................................................................................................................................7 3.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................7 3.2CHANNELLIST.....................................................................................................................................................8 4EQUIPMENTDURINGTEST....................................................................................................................................9 4.1EQUIPMENTSLIST.............................................................................................................................................9 4.2MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5CONDUCTEDEMISSION..........................................................................................................................................13 5.1E.U.T.OPERATION............................................................................................................................................13 5.2EUTSETUP.......................................................................................................................................................13 5.3TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 5.4MEASUREMENTPROCEDURE............................................................................................................................14 5.5CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6RADIATEDSPURIOUSEMISSIONS......................................................................................................................17 6.1EUTOPERATION...............................................................................................................................................17 6.2TESTSETUP......................................................................................................................................................18 6.3SPECTRUMANALYZERSETUP..........................................................................................................................19 6.4TESTPROCEDURE.............................................................................................................................................20 6.5SUMMARYOFTESTRESULTS...........................................................................................................................22 7CONDUCTBANDEDGEANDSPURIOUSEMISSIONSMEASUREMENT....................................................30 7.1TESTPROCEDURE.............................................................................................................................................30 7.2TESTSETUP......................................................................................................................................................30 7.3TESTRESULT....................................................................................................................................................31 86DBBANDWIDTHMEASUREMENT......................................................................................................................38 ReportNo.:PTC25090912101E-FC01 Page4of61 TESTPROCEDURE...................................................................................................................................................38 TESTSETUP..........…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 85 FCCTESTREPORT FCCID:2BSMZ-BLT25001 Product:BirdFeederwithCamera ModelName:BLT25001 Brand:BOLITE ReportNo.:PTC25090912101E-FC02 Preparedfor DongguanBoliteJiajuCo,,LTD Room101,No478,LiaobuJinxingRoad,LiaobuTown,Dongguan,Guangdong Preparedby PreciseTesting&CertificationCo.,Ltd Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC25090912101E-FC02 Page 2 of 85 1TESTRESULTCERTIFICATION Applicant’sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Manufacture'sname:DongguanBoliteJiajuCo,,LTD Address:Room101,No478,LiaobuJinxing Road,LiaobuTown,Dongguan,Guangdong Productname:BirdFeederwithCamera Modelname:BLT25001 Standards:FCCCFR47Part15Section15.247 Testprocedure:ANSIC63.10-2020 TestDate: October09,2025toOctober20,2025 DateofIssue: October20,2025 TestResult:Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,thisdocumentmaybe alteredorrevisedbyPTC,personalonly,andshallbenotedintherevisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC25090912101E-FC02 Page 3 of 85 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 3GENERALINFORMATION..........................................................................................................................................6 3.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................6 3.2CHANNELLIST.....................................................................................................................................................7 3.3TESTSITE............................................................................................................................................................8 4EQUIPMENTDURINGTEST......................................................................................................................................9 4.1EQUIPMENTSLIST...............................................................................................................................................9 4.2MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5CONDUCTEDEMISSION..........................................................................................................................................13 5.1E.U.T.OPERATION............................................................................................................................................13 5.2EUTSETUP.......................................................................................................................................................13 5.3TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 5.4MEASUREMENTPROCEDURE............................................................................................................................14 5.5CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6RADIATEDSPURIOUSEMISSIONS......................................................................................................................17 6.1EUTOPERATION...............................................................................................................................................17 6.2TESTSETUP......................................................................................................................................................18 6.3SPECTRUMANALYZERSETUP..........................................................................................................................19 6.4TESTPROCEDURE.............................................................................................................................................20 6.5SUMMARYOFTESTRESULTS...........................................................................................................................21 7CONDUCTEDSPURIOUSEMISSION....................................................................................................................29 7.1TESTPROCEDURE.............................................................................................................................................29 7.2TESTSETUP......................................................................................................................................................29 7.3TESTRESULT....................................................................................................................................................29 ReportNo.:PTC25090912101E-FC02 Page 4 of 85 8BANDEDGEMEASUREMENT................................................................................................................................49 8.1TESTPROCEDURE..................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:PTC25090912101E-FC02 Page 51 of 85 TestGraphs: 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS ReportNo.:PTC25090912101E-FC02 Page 52 of 85 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS ReportNo.:PTC25090912101E-FC02 Page 53 of 85 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS ReportNo.:PTC25090912101E-FC02 Page 54 of 85 11N40SISO-Ant1-2452-PASS ReportNo.:PTC25090912101E-FC02 Page 55 of 85 96dBBandwidthMeasurement TestRequirement:FCCCFR47Part15Section15.247 TestMethod:ANSIC63.10-2020 TestLimit Systemsusingdigitalmodulationtechniquesmayoperateinthe902-928 MHz,2400-2483.5MHz,and5725-5850MHzbands.Theminimum6dB bandwidthshallbeatleast500kHz. 9.1TestProcedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothe spectrum; 2.Setthespectrumanalyzer:RBW=100kHz,VBW=300kHz 9.2TestSetup 9.3TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1241210.0802406.9602417.0400.5PASS 11BAnt1243710.0802431.9602442.0400.5PASS 11BAnt1246210.0402456.9602467.0000.5PASS 11GAnt1241215.4402404.1202419.5600.5PASS 11GAnt1243714.6002429.8802444.4800.5PASS 11GAnt1246215.0802454.7202469.8000.5PASS 11N20SISOAnt1241215.6402403.8802419.5200.5PASS 11N20SISOAnt1243716.9202428.4802445.4000.5PASS 11N20SISOAnt1246217.0002453.4802470.4800.5PASS 11N40SISOAnt1242235.3602404.1602439.5200.5PASS 11N40SISOAnt1243735.2002419.4002454.6000.5PASS 11N40SISOAnt1245235.4402434.0802469.5200.5PASS ReportNo.:PTC25090912101E-FC02 Page 56 of 85 TestGraphs: 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS ReportNo.:PTC25090912101E-FC02 Page 57 of 85 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS ReportNo.:PTC25090912101E-FC02 Page 58 of 85 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS ReportNo.:PTC25090912101E-FC02 Page 59 of 85 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS ReportNo.:PTC25090912101E-FC02 Page 60 of 85 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS ReportNo.:PTC25090912101E-FC02 Page 61 of 85 11N40SISO-Ant1-2452-PASS ReportNo.:PTC25090912101E-FC02 Page 62 of 85 10Maximumconductedoutputpower TestRequirement:FCCCFR47Part15Section15.247 TestMethod:ANSIC63.10-2020 TestLimit: Regulation15.247(b)(3),Forsystemsusingdigitalmodulationinthe902- 928MHz,2400-2483.5MHz,and5725-5850MHzbands:1Watt.Asan alternativetoapeakpowermeasurement,compliancewiththeoneWatt limitcanbebasedonameasurementofthemaximumconductedoutput power. 10.1TestProcedure 1.AccordingtoANSIC63.10-2013clause11.9.1.3PKPM1Peakpowermetermethod.Themaximum peakconductedoutputpowermaybemeasuredusingabroadbandpeakRFpowermeter.The powermetershallhaveavideobandwidththatisgreaterthanorequaltotheDTSbandwidthand shalluseafast-respondingdiodedetector. 10.2TestSetup 10.3TestResult TestModeAntennaFrequency[MHz]PeakPower[dBm] Conducted Limit[dBm] Verdict 11BAnt1241215.18≤30.00PASS 11BAnt1243714.04≤30.00PASS 11BAnt1246214.32≤30.00PASS 11GAnt1241216.02≤30.00PASS 11GAnt1243714.96≤30.00PASS 11GAnt1246214.92≤30.00PASS 11N20SISOAnt1241215.78≤30.00PASS 11N20SISOAnt1243714.90≤30.00PASS 11N20SISOAnt1246214.87≤30.00PASS 11N40SISOAnt1242215.70≤30.00PASS 11N40SISOAnt1243714.89≤30.00PASS 11N40SISOAnt1245215.24≤30.00PASS EUT Powermeter Attenuator ReportNo.:PTC25090912101E-FC02 Page 63 of 85 11PowerSpectraldensity TestRequirement:FCCCFR47Part15Section15.247 TestMethod:ANSIC63.10-2020 TestLimit:Regulation15.247(e)Thepowerspectraldensityconductedfromthe intentionalradiatortotheantennaduetothedigitalmodulation operationofthehybridsystem,withthefrequencyhoppingoperation turnedoff,shallnotbegreaterthan8dBminany3kHzbandduring anytimeintervalofcontinuoustransmission. 11.1TestProcedure 1.Connecttheantennaport(s)tothespectrumanalyzerinput. 2.Configurethespectrumanalyzerasshownbelow: Centerfrequency=DTSchannelcenterfrequency Span=1.5timestheDTSbandwidth RBW=3KHz,VBW=10KHz Sweeptime=autocouple Detector=peak Tracemode=maxhold 3.Placetheradioincontinuoustransmitmode,allowthetracetostabilize,viewthetransmitterwaveformon thespectrumanalyzer. 4.UsethepeakmarkerfunctiontodeterminethemaximumamplitudelevelwithintheRBW. 5.Ifmeasuredvalueexceedslimit,reduceRBW(nolessthan3KHz)andrepeat. 11.2TestSetup 11.3TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict 11BAnt12412-10.46≤8.00PASS 11BAnt12437-11.28≤8.00PASS 11BAnt12462-11.51≤8.00PASS 1…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Quanlin Liu(General manager)
[email protected]Fax: +86-13924376518

Test Firm

Precise Testing & Certification Co., LTD.Yang Juan
[email protected]

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz1.53 mW
215C2.41 GHz - 2.46 GHz39.99 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. This device supports 20 and 40 MHz bandwidth modes. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
