VS-ST04-01 SmartTagProductManual VS-ST04-01 Ver:1.0.0 VitalsiliconTechnologiesCo.,Ltd VS-ST04-01 1ProductOverview VS-ST04-01isanintelligenttagproductthatcanbeintegratedintovarious carrierssuchasclothing.Itiscapableofmonitoringthewearer'sphysiological characteristicindicatorsincludingnecktemperature,sweatvolume,indoorpositioning, movementstatus,exerciseamount,exerciseintensity,sleepquality,fatigueindexand stressindex.Thesephysiologicalcharacteristicdatacanbepresentedinadataor graphicalformthroughtheWeChatMiniProgramortheintegratedmanagement platform. 2ProductForm TheVS-ST04-01intelligenttagadoptsaflexiblepackagingprocess.Itis packagedwithfluorine-freehydrophobicwovenfabricthroughahot-pressingprocess. Meanwhile,theinternalstructureisdividedandarrangedusingEVAfoam,resulting inexcellentoverallflexibilityandbendability.Theproducthasalengthandwidthof 74*53mm,withthemaximumthicknessofthecentralareabeing4.6mm.Thewidth ofthesurroundingedgeareaismorethan10mmandthethicknessisapproximately 0.5mm,whichisusedforsewingontoapplicationcarrierssuchasclothing. SmartTag:VS-ST04-01ApplicationCase:SmartClothing(T-shirt) VS-ST04-01 VS-ST04-01 3ProductFunctions 3.1NeckTemperatureMonitoring Aftertheuserputsonthesmartclothing(takingintegrationintoaT-shirtasan example,thesamebelow),thereal-timechangesintheuser'snecktemperaturecanbe viewedthroughtheWeChatMiniProgramortheintegratedmanagementplatform. 3.2SweatVolumeMonitoring Aftertheuserputsonthesmartclothing,thereal-timechangesintheuser'sneck sweatvolumecanbeviewedthroughtheWeChatMiniProgramortheintegrated managementplatform. 3.3MovementStatusMonitoring Aftertheuserputsonthesmartclothing,thereal-timechangesintheuser's movementstatusorposturecanbeviewedthroughtheWeChatMiniProgramorthe integratedmanagementplatform,includingsomedangerousactionssuchasfalling andhandstand,andspecialalarmscanbegivenfordangerousactions. MovementStatusDescription StaticWhentheuserstaysstillinplace,the"Static"statusisdisplayed. ActiveWhentheuseriswalkingorrunning,the"Active"statusisdisplayed. LyingDownWhentheuserislyingdown,the"LyingDown"statusisdisplayed. FallingWhentheuserfallsdown,the"Falling"statusisdisplayed. HandstandWhentheuserdoesahandstand,the"Handstand"statusisdisplayed. 3.4Real-timeHigh-precisionPositioning Aftertheuserputsonthesmartclothing,withthesupportofahigh-precision indoorpositioningbasestation,thereal-timepositioningchangesandmovement trajectoryoftheusercanbeviewedthroughtheWeChatMiniProgramorthe integratedmanagementplatform. VS-ST04-01 3.5ExerciseAmountandExerciseIntensity Aftertheuserputsonthesmartclothing,indicatorssuchastheuser'sexercise amountandexerciseintensity,suchasstepcount,canbeviewedthroughtheWeChat MiniProgramortheintegratedmanagementplatform. 3.6SleepQuality Aftertheuserputsonthesmartclothing,theuser'ssleepqualitycanbeviewed throughtheWeChatMiniProgramortheintegratedmanagementplatform,including theanalysisofstatusessuchasdeepsleep,lightsleep,rapideyemovement(REM) andwakefulness,andausersleepqualityreportispresented. 3.7FatigueIndex Aftertheuserputsonthesmartclothing,thefatigueleveloftheuser'sphysical functionscanbeviewedthroughtheWeChatMiniProgramortheintegrated managementplatform.Whenthefatigueindexexceeds60duetofactorssuchas ambienttemperatureandhumidity,andactivityamount,itisrecommendedtosuspend activitiesandrestforrecovery. 3.8StressIndex Aftertheuserputsonthesmartclothing,theuser'sbehavioralstressindexcanbe viewedthroughtheWeChatMiniProgramortheintegratedmanagementplatform. Whenthestressindexisrelativelyhigh,itisrecommendedthattheuserrelax appropriatelyandadjustpsychologicalstress. 4ProductUsageInstructions Takingsmartclothingasanexample,whenusingitforthefirsttime,itis necessarytoshaketheclothing,andthensendaspecificcommandthroughthe WeChatMiniProgramortheintegratedmanagementplatformtoactivatetheproduct. Onlyafteractivationcanitbeusednormally. VS-ST04-01 Aftertheproductisactivated,whentheuserputsonthesmartclothing,the intelligenttagwillbeawakenedfromthedormantstate,andtheWeChatMini Programortheintegratedmanagementplatformwilldisplaytheuser'sphysiological characteristicdata,asdescribedintheproductfunctionsinSection3.Whenthe systemdetectsthattheusertakesoffthesmartclothing,theintelligenttagwill re-enterthedormantstate. 5ScopeofApplication Thisproductisapplicabletoanyclothing/hometextilecarriers,suchasT-shirts, downjackets,jackets,outdoorjackets,pants,sleepingbags,pajamas,etc. 6SafetyRequirementsandPrecautions Pleaseensurethatthetagpartofthesmartclothingisindirectcontactwiththe skin;otherwise,thecollecteddatawillbeinaccurate. Pleaseensurethatthesmartclothingisusedundertherequiredoperating environmentconditions(seeTechnicalParameters).Usingitinanenvironment thatdoesnotmeettheconditionswillcausemeasurementerrors. Donotmodifyordisassemblethisproductinanyform,anddonotimpact, squeezeorputitintofire. Donotplaceitinahigh-temperatureenvironmentorunderdirectsunlight.Ifitis placedinfireorheatedtoabove100°C,thereisariskoffireandexplosion. Thisproductisnotamedicaldeviceandisnotusedformedicalpurposes. 7StorageandTransportation Thetransportationtoolsforthisproductshouldbecleanandfreeofpollution. Whentransportingtheproduct,itisnecessarytoavoidexposuretosunlightand rain,anditmustnotbemixedwithtoxic,harmful,odorousitemsoritemsthat VS-ST04-01 affectproductqualityforloadingandtransportation. Whenhandling,pleasetakeandplaceitgentlytopreventimpactandsevere vibration. Thepackagingshouldbefirm,moisture-proof,clean,beautifulandfreeofodors, andeasyforloading,unloading,storageandtransportation. Whenwashingthisproduct,donotusestrongoxidizingdetergentsor disinfectants.Thewashingwatertemperatureordryingtemperatureshouldnotbe higherthan50°C.Whendrying,avoidhigh-temperatureenvironmentsordirect sunlight. Donotstoreitinahigh-temperatureenvironmentorunderdirectsunlight. Itshouldbestoredinacool,ventilatedanddryspace,andmustnotbestored togetherwithtoxic,harmful,odorous,volatileorcorrosiveitems. 8MainTechnicalParameters NameSmartTagSize74*53*4.6mm CommunicationBluetooth4.2Weight ＜1…
