Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 1 | 15E | 5.96 GHz - 7.12 GHz | 12.00 mW |
| 2 | 15E | 5.96 GHz - 7.08 GHz | 25.00 mW |
| 3 | 15E | 5.99 GHz - 7.03 GHz | 49.00 mW |
| 4 | 15E | 6.03 GHz - 6.99 GHz | 93.00 mW |
| 5 | 15E | 6.11 GHz - 6.91 GHz | 163.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Power Output listed is EIRP. Device is a 2 x 2 MIMO configuration, enabled for 6 GHz operations as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures.
U-NII bands 5 ~ 8 are under the control of a standard power access point function is turned off by software for this module. Module just support U-NII bands 5~8 are under the control of a low-power indoor access point (P1) function.
