2BTAF-DEL-4301Commercial Digital Signage

23.6" Desktop Digital Signage AndroidWIFI DEL236 Display Specifications Screen Size: 23.6-inch Brand： Deerlan Model： DEL236 Resolution： 1920×1080 (FHD) Display Area： 521.28 × 293.22 mm（H×V） Aspect Ratio： 16:9 Viewing Angle： 89°/89°/89°/89°(L/R/U/D) Brightness： ≥500cd/m2 Backlight Type： ELED Color Depth： 16.7M（8-bit） Refresh Rate： 60HZ Pixel Arrangement RGB vertical stripe System Parameters OS： Android System Version： Android 7.1 CPU： Allwinner40M Quad-Core 1.2GHz RAM： 1GB Storage： 8GB(Standard) Preinstalled Software： Digital Signage Player Interfaces： DC-IN*1 RJ45*1 USB*2 Video Formats： WMV, AVI, FLV, RM, RMVB, MPEG, TS, MP4，etc. Image Formats: BMP, JPEG, PNG, GIF Connectivity: Ethernet, Wi-Fi (Optional: 3G/4G) Scheduled Power On/Off: Customizable Hot-Swap Support: Mouse & Keyboard Third-Party Apps: Supported Physical Specifications Bezel Material: ABS Chassis Material: Cold-rolled steel Dimensions: Refer to engineering drawing Package Dimensions: As per actual product Package Material: Corrugated cardboard Net Weight: 8kg Gross Weight: 10kg Stand: Metal base Mounting: Bottom screw fixation Environmental Specifications Usage: Indoor only Input Voltage: AC 110-120V Standby Power: ≤1W Operating Power: ≤50W Operating Environment: Temperature: -10°C to 55°C Humidity: 10% to 90% RH Storage Environment: Temperature: -15°C to 65°C Humidity: 10% to 95% RH Accessories Included Power cable ×1 Wi-Fi antenna ×1 Remote control ×1 Certificate of compliance & warranty card ×1 each Tools Required for Installation: Electric drill/screwdriver Shanghai DeerlanTechnology Co., Ltd. CAUTION: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF exposure compliance statement:This device has been evaluated to meet the general RF exposure requirement This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Rev1/26/2023 ShanghaiDeerlanTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:11-26-2025 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2BTAF-DEL-4301 ShanghaiDeerlanTechnologyCo.,Ltd(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. ShanghaiDeerlanTechnologyCo.,Ltd(“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovidedby KasperskyLab,Inc.oranyofitssuccessorsandassignees,includingequipmentwithintegratedKaspersky Lab,Inc.(oranyofitssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24- 886andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (signature) XiuxiuPeng/manager Rev1/26/2023 ShanghaiDeerlanTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:11-26-2025 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2BTAF-DEL-4301 ShanghaiDeerlanTechnologyCo.,Ltd(“theapplicant”)certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (signature) XiuxiuPeng/manager

ShanghaiDeerlanTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:11-26-2025 Ref:AttestationStatementsPart2.911(d)(7)Filing FCCIDorGranteeCode:FCCID:2BTAF-DEL-4301 ApplicantFRN:0037670932 ShanghaiDeerlanTechnologyCo.,Ltd(“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,REPAmericaLLCisourdesignatedU.S.agentforserviceofprocess fortheabovereferencedFCCID.ShanghaiDeerlanTechnologyCo.,Ltdacceptstomaintain anagentfornolessthanoneyearafterthegranteehasterminatedallmarketingand importationortheconclusionofanyCommission-relatedproceedinginvolvingtheequipment. REPAmericaLLCaccepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:REPAmericaLLC U.S.AgentFRN:0034192500 Address:350TerrySt.200Longmont,CO80501UnitedStates ContactPerson:BenXU Tel.:(719)201-3314 Email:[email protected] Sincerely, ShanghaiDeerlanTechnologyCo.,Ltd REPAmericaLLC XingLi/managerBenXU/manager (sign)(sign)

Shanghai Deerlan Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 11-27 -2025 SUBJECT: FCC Application for FCC ID: 2BTAF-DEL-4301 To Whom It May Concern: I, the undersigned, hereby states this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules, and will apply the Supplier's Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. I understand the following FCC requirements: 1. De vices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Pt 2.1077 contains the list of information that must be included in the Supplier's Declaration of Conformity, which must be supplied with each product sold. The SDoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(b), the responsible party is either the Manufacturer or if the product is imported the Importer. Regards, Sincerely, (signature) Name: Xing Li Title: manager

ShanghaiDeerlanTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:11-27-2025 ConfidentialityRequestregardingapplicationforcertificationofFCCID:2BTAF-DEL-4301 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitType BlockDiagram OperationalDescription Schematics Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrantfor thisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,wealsorequest temporaryconfidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitType Sincerely, (signature) Name:XingLi Title:manager

Model Confirmation Letter We, Shanghai Deerlan Technology Co., Ltd , certify the product: Commercial Digital Signage , Model No.: DEL-4301, DEL-15.6, DEL-23.8, DEL-3201, DEL-3202, DEL-3203, DEL-4302, DEL-4303, DEL-4901, DEL-4902, DEL-5001, DEL-5002, DEL-5501, DEL-5502, DEL-6501, DEL-6502 There are multiple models of the product, with differences in the size of the appearance and customer requirements for different models in the market, resulting in multiple models. However, the internal circuit boards, PCBs, BOMs, and other electrical structures of these models are the same, and these differences will not affect RF&EMC performance. (signature) Name: Xing Li Title: manager Company: Shanghai Deerlan Technology Co., Ltd Shanghai Deerlan Technology Co., Ltd FCC ID: 2BTAF-DEL-4301

ShanghaiDeerlanTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:11-26-2025 SUBJECT:FCCApplicationforFCCID:2BTAF-DEL-4301 ToWhomItMayConcern: We,theundersigned,herebyauthorizeColinHuangatShenzhenDACETestingTechnology Co.,Ltd.onourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment. AnyandallactscarriedoutbyShenzhenDACETestingTechnologyCo.,Ltd.onourbehalf shallhavethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,theapplicant, arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301oftheAnti-DrugActof 1988,21USC853a,andnopartytotheapplicationissubjecttoadenialoffederalbenefits pursuanttothatsection. Regards, Sincerely, (signature) Name:XingLi Title:manager

FCCID:2BTAF-DEL-4301 External

FCCID:2BTAF-DEL-4301 FCCIDplace SAMPLE: CommercialDigitalSignageModel:DEL-4301 INPUT:100-240V~50-60Hz FCCID:2BTAF-DEL-4301 FCCWARNING:Thisdevicecomplieswithpart15oftheFCC Rules.Operationissubjecttothefollowingtwoconditions:(1) Thisdevicemaynotcauseharmfulinterference,and(2)this devicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2BTAF-DEL-4301 Internal

FCCID:2BTAF-DEL-4301 Testsetup ConductedEmissionatACpowerline Emissionsinfrequencybands(below1GHz) Emissionsinfrequencybands(above1GHz)
