2BTC4-SB924163GAMEPAD RGB S2

Quick start guide • Guide de démarrage rapide Guía rápida • Schnellstartanleitung • Guida rapida SB924163 • GAMEPAD RGB S2™ Size : 105 mm x 105 mm Recharge Recharger • Recarga Auaden • Ricarica USB Type-C USB Type-C 1.2. USB Type-A Switch 2 Connecting Switch 2 Connexion • Switch 2 Conexión Switch 2 Verbinden • Switch 2 Collegamento 1. 2. USB Type-A 3. 4. 1.2. Paired USB Type-C Dongle connection Connexion par dongle • Conexión mediante dongle Dongle-Verbindung • Connessione tramite dongle OR Dongle connection Connexion par dongle • Conexión mediante dongle Dongle-Verbindung • Connessione tramite dongle Trigger stops Trigger verrou • Bloqueo del gatillo Schultertastenwegs-Verkürzung • Blocco del grilletto Back button lock Verrou du bouton arrière • Bloqueo del botón trasero Sperre der Rücktaste • Blocco del pulsante posteriore RGB lighting modes for SB923906 • GAMEPAD S2™ Modes d’éclairage RGB • Modos de iluminación RGB RGB-Beleuchtungsmodi • Modalità di illuminazione RGB Change mode (4 modes) • Changer de mode (4 modes) • Cambiar modo (4 modos) • Modus wechseln (4 Modi) • Cambia modalità (4 modalità) 2x+ 1x+ Change colour • Changer de couleur • Cambiar color • Farbe ändern • Cambia colore 1x+ Lighting brightness (100/70/50/25%) • Luminosité de l’éclairage (100/70/50/25%) • Brillo de la luz (100/70/50/25%) • Beleuchtungshelligkeit (100/70/50/25%) • Luminosità dell’illuminazione (100/70/50/25%) 2x+ Switch ON/OFF lighting • Activer/Désactiver le mode lumineux • Activar/Desactivar el modo de luz • Lichtmodus ein-/ausschalten • Attivare/Disattivare la modalità luce • RGB lighting modes for SB924163 • GAMEPAD RGB S2™ Modes d’éclairage RGB • Modos de iluminación RGB RGB-Beleuchtungsmodi • Modalità di illuminazione RGB Standard/ Turbo/ Auto-Fire modes Modes turbo (Standard/Automatique) • Modos turbo (Estándar/Automático) Turbo-Modi (Standard/Automatisch) • Modalità Turbo (Standard/Automatico) + Lighting brightness (OFF/25/50/75/100%) • Luminosité de l’éclairage (OFF/25/50/75/100%) • Brillo de la luz (OFF/25/50/75/100%) • Beleuchtungshelligkeit (OFF/25/50/75/100%) • Luminosità dell’illuminazione (100/70/50/25%) Standard > Turbo > Auto-Fire modes > Standard + L1R1 L2R2 1 x Switch ON/OFF lighting • Activer/Désactiver le mode lumineux • Activar/Desactivar el modo de luz • Lichtmodus ein-/ausschalten • Attivare/Disattivare la modalità luce • Change mode (3 modes) • Changer de mode (3 modes) • Cambiar modo (3 modos) • Modus wechseln (3 Modi) • Cambia modalità (3 modalità) + Change colour • Changer de couleur • Cambiar color • Farbe ändern • Cambia colore + ++ Adjust Turbo speed (global) Régler la vitesse du turbo (global) • Ajustar velocidad Turbo (global) Turbo-Geschwindigkeit einstellen (global) • Regolare la velocità del turbo (globale) Motor vibration adjustment Réglage de la vibration du moteur • Ajuste de la vibración del motor Motorschwingungseinstellung • Regolazione della vibrazione del motore ++ 100% 0% 30% 70% Battery Status État de la batterie • Estado de la batería Batteriestatus • Stato della batteria Charging • En charge • Cargando • Wird geladen • In carica Low battery • Batterie faible • Batería baja • Schwacher Akku • Batteria scarica Reset Réinitialisation • Restablecer Zurücksetzen • Reimpostazione Information • Informations • Información • Informationen• Informazioni If you experience functional issues using GAMEPAD S2™ / GAMEPAD RGB S2™, please download the latest rmware installer from https://snakebyte.com/pages/downloads, then run the installer program and follow the on screen instructions. • Si vous rencontrez des problèmes de fonctionnement avec la manette GAMEPAD S2™ / GAMEPAD RGB S2™, veuillez télécharger le programme d’installation du dernier rmware depuis https://snakebyte. com/pages/downloads, puis exécutez le programme d’installation et suivez les instructions à l’écran. • Si experimenta problemas de funcionamiento al usar el GAMEPAD S2™ / GAMEPAD RGB S2™, descargue el instalador del rmware más reciente desde https://snakebyte.com/pages/downloads, luego ejecute el programa de instalación y siga las instrucciones en pantalla. • Wenn bei der Verwendung des GAMEPAD S2™ / GAMEPAD RGB S2™ Funktionsprobleme aureten, laden Sie bitte das neueste Firmware-Installationsprogramm von https://snakebyte.com/pages/ downloads herunter, führen Sie anschließend das Installationsprogramm aus und folgen Sie den Anweisungen auf dem Bildschirm. • Se riscontri problemi di funzionamento con GAMEPAD S2™ / GAMEPAD RGB S2™, scarica l’ultima versione del programma di installazione del rmware da https://snakebyte.com/pages/downloads, quindi esegui il programma di installazione e segui le istruzioni visualizzate sullo schermo. Made in China • Fabriqué en Chine © 2025 snakebyte • SB923906 • SB924163 • Version 10/2025 Email: [email protected] | Website: www.snakebyte.com Manufacturer/APAC Import: snakebyte technolgies Limited • Unit 907-908 • Lu Plaza • 2 Wing Yip Street • Kwun Tong • Kowloon • Hong Kong North/Latin America Import: snakebyte usa Inc. • 8799 Balboa Ave No. 265 • San Diego • CA 92123 • USA UK Import: Snakebyte UK Limited • Suite 106 Denning House C/O Know Tax • 1a George Street • Wolverhampton • WV2 4DP • United Kingdom EU Import: snakebyte distribution GmbH • Konrad-Zuse Strasse 13 • 58239 Schwerte • Germany Australia/New Zealand Import: Directed Electronics Australia PTY LTD • 115-119 Link Road • Melbourne Airport VIC • 3045 • Australia All rights reserved. This document may not in whole or in part be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, or reduced to any electronic medium or machine-readable form without prior consent, in writing, from snakebyte distribution GmbH. snakebyte is a registered trademark of snakebyte distribution GmbH. snakebyte, the snakebyte logo are trademarks or registered trademarks of snakebyte GROUP. © 2025 snakebyte. Nintendo Switch™, Nintendo Swit…

Text truncated - open the document above for the full version.

Snakebyte Ltd. & Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Dezember 16, 2025 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BTC4-SB924163 Snakebyte Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Marc Kuepper Title: CPO & Partner Address: Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Tel.: +852 27628010 Email: [email protected]

Snakebyte Ltd. & Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Dec. 16, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: [2BTC4-SB924163] Product Name: [GAMEPAD RGB S2] This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature: Printed Name: Marc Kuepper Title: CPO & Partner Address: Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Tel.: +852 27628010 Email: [email protected] Snakebyte Ltd. & Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

Snakebyte Ltd. Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, China Date: 12/12/2025 Federal Communications Commission Authorization and Evaluation Division 7 435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BTC4-SB924163 FRN: 0037684156 US Agent -Attestation Statement/ Part 2.911 (d)(7) Snakebyte Ltd. certifies, that as of [12/12/2025], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BTC4-SB924163 Snakebyte Ltd., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission­ related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Snakebyte Ltd. for FCC ID: 2BTC4-SB924163 Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Snakebyte Ltd. Address: Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Company Representative: Marc Kuepper Signature:_�-� Email: [email protected] Tel: +852 27628010 Designated Agent: FCC US Agent, LLC Designated Agent Representative: Tim Payn 飞 D.�,,,,.o<dS,Tim Signat 叨 言 ＄ 芒 益 Payne ,m训"'"�沁巾讨"""'' "'又om,� D,,_'°'""""'AD 必 ' 00'

Snakebyte Ltd. & Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong December 16, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BTC4-SB924163 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below :  Block Diagram  Schematics  Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Sincerely, (Signature) Title: CPO & Partner Address: Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Tel.: +852 27628010 Email: [email protected]

Snakebyte Ltd. & Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong (December 18, 2025) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BTC4-SB924163 I, the undersigned, hereby authorize (Shenzhen Alpha Product Testing Co., Ltd.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Shenzhen Alpha Product Testing Co., Ltd) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with Snakebyte Ltd. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, (Signature) (Full name of contact person listed on FCC’s website): Marc Kuepper (Title): CPO & Partner Tel: +852 27628010 Fax: / Email: [email protected]

Differences Description We Snakebyte Ltd. state: Product name: GAMEPAD RGB S2 Model: SB924163, SB924286, SBU024166, SBU024289 FCC ID: 2BTC4-SB924163 Except for the model name and color, the PCB design, software, circuit, and RF characteristics of all models remain consistent Signature: Name Marc Kuepper Position CPO & Partner Company Name Snakebyte Ltd. Address Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Tel +852 27628010 Fax / Email [email protected]

FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163

1cm 0.5cm Label Location FCC ID: 2BTC4-SB924163 Snakebyte Ltd. Product name: GAMEPAD RGB S2 Model No.: SB924163 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163 2.4G ANT FCC ID: 2BTC4-SB924163 FCC ID: 2BTC4-SB924163

FCC ID: 2BTC4-SB924163 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz: -3.075dBm (0.493 mW) output power] (0.493 mW /5mm)·[√2.480(GHz)]= 0.155<3.0 for 1-g SAR Then SAR evaluation is not required

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008-3008-95 Website: http://www.a-lab.cn FCC TEST REPORT FCC ID: 2BTC4-SB924163 On Behalf of Snakebyte Ltd. GAMEPAD RGB S2 Model No.: SB924163, SB924286, SBU024166, SBU024289 Prepared for : Snakebyte Ltd. Address : Unit 907-908, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Hong Kong Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2511046-C16-R01 Date of Receipt : November 11, 2025 Date of Test : November 11, 2025 - December 02, 2025 Date of Report : December 02, 2025 Version Number : V0 Test Result : Pass Page 2 of 61 Report No.: A2511046-C16-R01 TABLE OF CONTENTS Description Page 1. Summary of Standards And Results ............................................................................................ 6 1.1. Description of Standards and Results ..................................................................................... 6 2. General Information........................................................................................................................ 7 2.1. Description of Device (EUT) .................................................................................................... 7 2.2. Accessories of Device (EUT) .................................................................................................. 9 2.3. Tested Supporting System Details .......................................................................................... 9 2.4. Block Diagram of connection between EUT and simulators ................................................... 9 2.5. Test Mode Description ............................................................................................................. 9 2.6. Test Conditions ...................................................................................................................... 10 2.7. Test Facility ............................................................................................................................ 10 2.8. Measurement Uncertainty ..................................................................................................... 10 2.9. Test Equipment List ............................................................................................................... 11 3. Maximum Peak Output power ..................................................................................................... 13 3.1. Limit ....................................................................................................................................... 13 3.2. Test Procedure ...................................................................................................................... 13 3.3. Test Setup .............................................................................................................................. 13 3.4. Test Result ............................................................................................................................. 13 4. Bandwidth ..................................................................................................................................... 14 4.1. Limit ....................................................................................................................................... 14 4.2. Test Procedure ...................................................................................................................... 14 4.3. Test Result ............................................................................................................................. 14 5. Carrier Frequency Separation ..................................................................................................... 19 5.1. Limit ....................................................................................................................................... 19 5.2. Test Procedure ...................................................................................................................... 19 5.3. Test Result ............................................................................................................................. 19 6. Number Of Hopping Channel ...................................................................................................... 20 6.1. Limit ....................................................................................................................................... 20 6.2. Test Procedure ...................................................................................................................... 20 6.3. Test Result ............................................................................................................................. 20 7. Dwell Time ..................................................................................................................................... 21 7.1. Test limit ................................................................................................................................. 21 7.2. Test Procedure ...................................................................................................................... 21 7.3. Test Result ............................................................................................................................. 21 8. Radiated emissions ...................................................................................................................... 23 8.1. Limit ....................................................................................................................................... 23 8.2. Block Diagram of Test setup ..............................................…

Text truncated - open the document above for the full version.

Page 50 of 61 Report No.: A2511046-C16-R01 Page 51 of 61 Report No.: A2511046-C16-R01 Page 52 of 61 Report No.: A2511046-C16-R01 Page 53 of 61 Report No.: A2511046-C16-R01 Page 54 of 61 Report No.: A2511046-C16-R01 Page 55 of 61 Report No.: A2511046-C16-R01 Page 56 of 61 Report No.: A2511046-C16-R01 Page 57 of 61 Report No.: A2511046-C16-R01 Page 58 of 61 Report No.: A2511046-C16-R01 Page 59 of 61 Report No.: A2511046-C16-R01 2.4G ANT Page 60 of 61 Report No.: A2511046-C16-R01 Page 61 of 61 Report No.: A2511046-C16-R01 -------END OF REPORT-------

2.4G-2.48G Band Onboard PIF A antenna test report Ante1ma manufacturer: Guohua Development Holding Co. , Ltd l're妇ncy (lHz) Pe吐Gain(北i) Average Gain (dBi) VSI/IR l叩“如ce (0 ) 儿tennaT兀心 Polarization 2400-2480 2. <199 >-4 <3.2 son PlaM釭Inv釭ted i'知tenru,on bo江d Linear — ＿ ＿ Test enviroruuent: Zhongk c International darkroom test system ， ｀ Physical object and physical size of the antenna (unit:mm) ＇ ， 一圈111111 匕一 Antenna passive S parameter: Standing wave ratio (VSWR), echo loss (Return Loss) and Smith circle diagram 111I� 可伯 M..,, 如E 圈小刚:,,.. ,,,� 於1 Ante1ma 2402MHz 2D-Theta Pattern 2400.000MHz H 2400.000MHz E1 "」 U " ) - ｀＇ • u 衄 I “ ，＂ r 碱、 川 r 卜 1 叶 享 (＼ - 口 ,)o ＼ 1;>J1 1'11- 心它 210 ｀心 " 噜 II Antenna 2450MHz 2D-Phi Pattern 2450. 00氓HzH 2450.000MHz E1 ［］ .. -� 下． 严 叩 令 扣 ＇，心 --+ — _- 九0 ,,. Antenna 2480MHz 2D-Phi Pattern 2480.000MHz H 2480.000MHz El ,_ .... 心. '10 · - 面 如o .,.. 几，． 2400.000MHz E2 �•a 00 / r""' 沁九 ＼ “｀ ,'" \ f '1 1戊' ＇ ' 今"' 1'0 " " I. , w 2450.000MHz E2 110 , 111 1 '!fl ..、 - _,. 仅'·'- " • 加 ｀即 2480.000MHz E2 ;l(U 冲 1 11 力40 Manufacturer: Shenzhen Zuanma Intelligent Control Technology Co.,Ltd. Address: 715, Building 3, Zhonggang Plaza (Zone B), Exhibition Bay, No. 83 Zhanjing Road, Zhancheng Community, Fuhai street, Bao' an District, Shenzhen，Guangdong Province

FCC ID: 2BTC4-SB924163 1.1. Photo of Radiated Emission test FCC ID: 2BTC4-SB924163 1.2. Photo of Conducted Emission test
