2BTCD-MINDONEMindOne

iKKO Technology Co., Limited

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Dec 11, 2025
Application Purpose: Original Equipment
Equipment Note: MindOne
Frequency Range: 2402.00000000 - 2480.00000000
Company: iKKO Technology Co., Limited
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Federal Communication Commission Interference Statement FCC ID: 2BTCD-MINDONE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Radiation Exposure Statement: This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless device employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conducted using standard operating positions (10mm) accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.

RF Exposure Info

Page: 1/11 Ref : ACR.163.3.25.BES.B Cancel and replace the report ACR.163.3.25.BES.A SHENZHEN LGT TEST SERVICE CO., LTD. ROOM 205, BUILDING 13, ZONE B, ZHENXIONG INDUSTRIAL PARK, NO.177, RENMIN WEST ROAD, JINSHA, KENGZI STREET, PINGSHAN DISTRICT, SHENZHEN, GUANGDONG, CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: 2225-EPGO-450 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 06/06/2025 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz Technical Manager 6/12/2025 Checked & approved by: Pedro Ruiz Technical Manager 6/12/2025 Authorized by: Kim Rutkowski Quality Manager Customer Name Distribution : SHENZHEN LGT TEST SERVICE CO., LTD. Issue Name Date Modifications A Pedro Ruiz 6/12/2025 Initial release B Pedro Ruiz 6/20/2025 Customer name & address Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E 6/23/2025 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 3/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment .................................................................................................... 10 Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 4/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number 2225-EPGO-450 Product Condition (new / used) New Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.226 M Dipole 2: R2=0.224 M Dipole 3: R3=0.229 M 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figure 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 5/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it …

Text truncated - open the document above for the full version.

Test Setup Photos

Page 1 of 2 Report No.: LGT25J017 Appendix - Test Setup photos Set-up for Transmitter & Receiver Spurious Emissions, 9kHz to 30MHz Set-up for Transmitter & Receiver Spurious Emissions, 30MHz to 1000MHz Page 2 of 2 Report No.: LGT25J017 Set-up for Radiated Spurious Emission, Above 1GHz Set-up for Conducted Emission

Test Setup Photos

FCC ID_SAR Setup photos Right Touch Right Tilt Left Touch Left Tilt Body Front side (separation distance is 10mm) Body Back side (separation distance10mm) Body Left side (separation distance is 10mm) Body Right side (separation distance is 10mm) Body Top side (separation distance is 10mm) Body Bottom side (separation distance is 10mm)

Test Report

Report No.: LGT25J017RF11 Page 56 of 80 CFS NVNT 2-DH5 2402MHz CFS NVNT 2-DH5 2441MHz CFS NVNT 2-DH5 2480MHz Report No.: LGT25J017RF11 Page 57 of 80 CFS NVNT 3-DH5 2402MHz CFS NVNT 3-DH5 2441MHz CFS NVNT 3-DH5 2480MHz Report No.: LGT25J017RF11 Page 58 of 80 Band Edge Condition Mode Frequency (MHz) Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 No-Hopping -58.52 -20 Pass NVNT 1-DH5 2480 No-Hopping -59.11 -20 Pass NVNT 2-DH5 2402 No-Hopping -55.82 -20 Pass NVNT 2-DH5 2480 No-Hopping -58.45 -20 Pass NVNT 3-DH5 2402 No-Hopping -56.5 -20 Pass NVNT 3-DH5 2480 No-Hopping -57.22 -20 Pass Report No.: LGT25J017RF11 Page 59 of 80 Test Graphs Band Edge NVNT 1-DH5 2402MHz No-Hopping Ref Band Edge NVNT 1-DH5 2402MHz No-Hopping Emission Band Edge NVNT 1-DH5 2480MHz No-Hopping Ref Report No.: LGT25J017RF11 Page 60 of 80 Band Edge NVNT 1-DH5 2480MHz No-Hopping Emission Band Edge NVNT 2-DH5 2402MHz No-Hopping Ref Band Edge NVNT 2-DH5 2402MHz No-Hopping Emission Report No.: LGT25J017RF11 Page 61 of 80 Band Edge NVNT 2-DH5 2480MHz No-Hopping Ref Band Edge NVNT 2-DH5 2480MHz No-Hopping Emission Band Edge NVNT 3-DH5 2402MHz No-Hopping Ref Report No.: LGT25J017RF11 Page 62 of 80 Band Edge NVNT 3-DH5 2402MHz No-Hopping Emission Band Edge NVNT 3-DH5 2480MHz No-Hopping Ref Band Edge NVNT 3-DH5 2480MHz No-Hopping Emission Report No.: LGT25J017RF11 Page 63 of 80 Band Edge(Hopping) Condition Mode Frequency (MHz) Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 Hopping -57.93 -20 Pass NVNT 1-DH5 2480 Hopping -57.94 -20 Pass NVNT 2-DH5 2402 Hopping -56.32 -20 Pass NVNT 2-DH5 2480 Hopping -57.5 -20 Pass NVNT 3-DH5 2402 Hopping -56.26 -20 Pass NVNT 3-DH5 2480 Hopping -56.41 -20 Pass Report No.: LGT25J017RF11 Page 64 of 80 Test Graphs Band Edge(Hopping) NVNT 1-DH5 2402MHz Hopping Ref Band Edge(Hopping) NVNT 1-DH5 2402MHz Hopping Emission Band Edge(Hopping) NVNT 1-DH5 2480MHz Hopping Ref Report No.: LGT25J017RF11 Page 65 of 80 Band Edge(Hopping) NVNT 1-DH5 2480MHz Hopping Emission Band Edge(Hopping) NVNT 2-DH5 2402MHz Hopping Ref Band Edge(Hopping) NVNT 2-DH5 2402MHz Hopping Emission Report No.: LGT25J017RF11 Page 66 of 80 Band Edge(Hopping) NVNT 2-DH5 2480MHz Hopping Ref Band Edge(Hopping) NVNT 2-DH5 2480MHz Hopping Emission Band Edge(Hopping) NVNT 3-DH5 2402MHz Hopping Ref Report No.: LGT25J017RF11 Page 67 of 80 Band Edge(Hopping) NVNT 3-DH5 2402MHz Hopping Emission Band Edge(Hopping) NVNT 3-DH5 2480MHz Hopping Ref Band Edge(Hopping) NVNT 3-DH5 2480MHz Hopping Emission Report No.: LGT25J017RF11 Page 68 of 80 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 -59.32 -20 Pass NVNT 1-DH5 2441 -60.38 -20 Pass NVNT 1-DH5 2480 -59.28 -20 Pass NVNT 2-DH5 2402 -57.93 -20 Pass NVNT 2-DH5 2441 -59.55 -20 Pass NVNT 2-DH5 2480 -59.05 -20 Pass NVNT 3-DH5 2402 -53.5 -20 Pass NVNT 3-DH5 2441 -59.36 -20 Pass NVNT 3-DH5 2480 -58.22 -20 Pass Report No.: LGT25J017RF11 Page 69 of 80 Test Graphs Tx. Spurious NVNT 1-DH5 2402MHz Ref Tx. Spurious NVNT 1-DH5 2402MHz Emission Tx. Spurious NVNT 1-DH5 2441MHz Ref Report No.: LGT25J017RF11 Page 70 of 80 Tx. Spurious NVNT 1-DH5 2441MHz Emission Tx. Spurious NVNT 1-DH5 2480MHz Ref Tx. Spurious NVNT 1-DH5 2480MHz Emission Report No.: LGT25J017RF11 Page 71 of 80 Tx. Spurious NVNT 2-DH5 2402MHz Ref Tx. Spurious NVNT 2-DH5 2402MHz Emission Tx. Spurious NVNT 2-DH5 2441MHz Ref Report No.: LGT25J017RF11 Page 72 of 80 Tx. Spurious NVNT 2-DH5 2441MHz Emission Tx. Spurious NVNT 2-DH5 2480MHz Ref Tx. Spurious NVNT 2-DH5 2480MHz Emission Report No.: LGT25J017RF11 Page 73 of 80 Tx. Spurious NVNT 3-DH5 2402MHz Ref Tx. Spurious NVNT 3-DH5 2402MHz Emission Tx. Spurious NVNT 3-DH5 2441MHz Ref Report No.: LGT25J017RF11 Page 74 of 80 Tx. Spurious NVNT 3-DH5 2441MHz Emission Tx. Spurious NVNT 3-DH5 2480MHz Ref Tx. Spurious NVNT 3-DH5 2480MHz Emission Report No.: LGT25J017RF11 Page 75 of 80 Number of Hopping Channel Condition Mode Hopping Number Limit Verdict NVNT 1-DH5 79 15 Pass NVNT 2-DH5 79 15 Pass NVNT 3-DH5 79 15 Pass Report No.: LGT25J017RF11 Page 76 of 80 Test Graphs Hopping No. NVNT 1-DH5 2441MHz Hopping No. NVNT 2-DH5 2441MHz Hopping No. NVNT 3-DH5 2441MHz Report No.: LGT25J017RF11 Page 77 of 80 Dwell Time Condition Mode Frequency (MHz) Pulse Time (ms) Total Dwell Time (ms) Burst Count Period Time (ms) Limit (ms) Verdict NVNT 1-DH5 2441 2.879 310.932 108 31600 400 Pass NVNT 2-DH5 2441 2.883 282.534 98 31600 400 Pass NVNT 3-DH5 2441 2.885 276.96 96 31600 400 Pass Report No.: LGT25J017RF11 Page 78 of 80 Test Graphs Dwell NVNT 1-DH5 2441MHz One Burst Dwell NVNT 1-DH5 2441MHz Accumulated Dwell NVNT 2-DH5 2441MHz One Burst Report No.: LGT25J017RF11 Page 79 of 80 Dwell NVNT 2-DH5 2441MHz Accumulated Dwell NVNT 3-DH5 2441MHz One Burst Dwell NVNT 3-DH5 2441MHz Accumulated Report No.: LGT25J017RF11 Page 80 of 80 APPENDIX II - MEASUREMENT PHOTOS Note: Please see the attached RF_Test Setup photos for FCC ID. ※※※※※END OF THE REPORT※※※※※

Test Report

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 80 RF TEST REPORT Product Name: MindOne Model Number: MindOne-D01, D01, D01-GB, Mindone, AB05, D02 FCC ID: 2BTCD-MINDONE Issued For : iKKO Technology Co., Limited 804, 8th Floor, Heungkong Financial Center, Intersection of Linhai Avenue and Xinghai Avenue,Nanshan, Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT25J017RF11 Sample Received Date: Oct. 10, 2025 Date of Test: Oct. 10, 2025 ~ Nov. 19, 2025 Date of Issue: Nov. 19, 2025 Report No.: LGT25J017RF11 Page 2 of 80 TEST REPORT CERTIFICATION Applicant: iKKO Technology Co., Limited Address: 804, 8th Floor, Heungkong Financial Center, Intersection of Linhai Avenue and Xinghai Avenue,Nanshan, Shenzhen, China Manufacturer: iKKO Technology Co., Limited Address: 804, 8th Floor, Heungkong Financial Center, Intersection of Linhai Avenue and Xinghai Avenue,Nanshan, Shenzhen, China Product Name: MindOne Trademark: ikko Model Number: MindOne-D01, D01, D01-GB, Mindone, AB05, D02 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT25J017RF11 Page 3 of 80 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 30 4.1 LIMIT 30 4.2 TEST PROCEDURE 30 4.3 TEST SETUP 30 4.4 EUT OPERATION CONDITIONS 31 4.5 TEST RESULTS 31 5. NUMBER OF HOPPING CHANNEL 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 32 6. AVERAGE TIME OF OCCUPANCY 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 TEST SETUP 33 6.4 EUT OPERATION CONDITIONS 33 6.5 TEST RESULTS 33 7. HOPPING CHANNEL SEPARATION MEASUREMEN 34 7.1 LIMIT 34 7.2 TEST PROCEDURE 34 Report No.: LGT25J017RF11 Page 4 of 80 7.3 TEST SETUP 34 7.4 EUT OPERATION CONDITIONS 34 7.5 TEST RESULTS 34 8. BANDWIDTH TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 TEST SETUP 35 8.4 EUT OPERATION CONDITIONS 35 8.5 TEST RESULTS 35 9. OUTPUT POWER TEST 36 9.1 LIMIT 36 9.2 TEST PROCEDURE 36 9.3 TEST SETUP 36 9.4 EUT OPERATION CONDITIONS 36 9.5 TEST RESULTS 36 10. ANTENNA REQUIREMENT 37 10.1 STANDARD REQUIREMENT 37 10.2 EUT ANTENNA 37 APPENDIX I - TEST RESULTS 38 DUTY CYCLE 38 MAXIMUM PEAK CONDUCTED OUTPUT POWER 42 -20DB BANDWIDTH 46 OCCUPIED CHANNEL BANDWIDTH 50 CARRIER FREQUENCIES SEPARATION 54 BAND EDGE 58 BAND EDGE(HOPPING) 63 CONDUCTED RF SPURIOUS EMISSION 68 NUMBER OF HOPPING CHANNEL 75 DWELL TIME 77 APPENDIX II - MEASUREMENT PHOTOS 80 Report No.: LGT25J017RF11 Page 5 of 80 Revision History Rev. Issue Date Revisions 00 Nov. 19, 2025 Initial Issue Report No.: LGT25J017RF11 Page 6 of 80 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT25J017RF11 Page 7 of 80 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 Temperature ±0.5°C 10 Humidity ±2% 11 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT25J017RF11 Page 8 of 80 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: MindOne Test Model Number: MindOne-D01 Series Number: D01, D01-GB, Mindone, AB05, D02 Model Difference: Only the models are different. Channel List: Please refer to the Note 3. Bluetooth: Frequency:2402 – 2480 MHz Modulation: GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) Antenna Type: PIFA Antenna Antenna Ga…

Text truncated - open the document above for the full version.

Test Report

天线测试报告 test report 客户：财富项目名：MSD01 射频：江工日期：2025.10.13 实验室测试环境及设备测试项目测试设备 S11、S12 、VSWR 、LOSS网络分析仪E5071B、E5062A Efficiency、Gain 3D Radiation Pattern Satimo SG16暗室、GP7*4*3暗室、E5071B TRP、TIS Satimo SG16暗室、GP7*4*3暗室、8960 、 CMW500、MT8820C、E4438C、项目调试简介整机类型 4G金属框频段信息天线形式天线种类及频段信息主天线 2G: 850/900/1800/1900 3G: W1/2/5/8 4G:B1/3/5/7/8/12/13/17/20/28/66/38/39/40/41PIFA 副天线双频WIFI+BT+GPSPIFA 分集天线 700M-2710MHZPIFA 天线材质FPC 变更记录说明时间版本说明 2025.7.10 手板机器调试对地模拟状态调试 2025.7.16 优化调试 2025.9.5 手改天线逻辑验证 2025.9.9 增加环境处理及天线匹配 2025.10.13 试产机器测试 FSChannelTRP TIS灭TIS亮 ChannelTRP TIS灭TIS亮 LTE-1 L 15.8 LTE-7 L 17.5 M 15.4 M 17.7 H 15.2 -90.8 H 17.3 -89.8 LTE-2 L 15.6 LTE-8 L 15.8 M 16.2 M 15.7 H 16.1 -90.6 H 14.6 -91.8 LTE-3 L 15.9 LTE-12 L 13.2 M 16.2 M 13.1 H 16.7 -91.4 H 13.5 -86.5 LTE-4 L 16.2 LTE-13 L M 16.6 M H 16.8-90.3 H LTE-5 L 15.3 LTE-17 L 14.4 M 15.5 M 14.5 H 15.6 -89.3 H 14.8 -87.6 天线测试数据天线测试数据 FSChannelTRP TIS灭TIS亮 FSChannelTRP TIS灭TIS亮 LTE-20 L 15 LTE-40 L 15.5 M 15.2 M 16.3 H 15.2 -90.7 H 17.7 -88 LTE-28 L 14.2 LTE-41 L 18.6 M 15.3 M 18.0 H 15.5 -89.9 H 18.3-91.3 LTE-66 L 16.2 M 16.6 H 16.5 -90.4 LTE-38 L 17.8 M 18.7 H 18.3 -90 LTE-39 L 16.2 M 15.7 H 16.6 -88.5 天线测试数据 FSChannelTRP TIS灭TIS亮 FSChannelTRP TIS灭TIS亮 WCDMA-1 L 15.4 GSM850 L 24.6 M 15.6 M 24.6 H 15.2 -104.5 H 24.4 -101.9 WCDMA-2 L 15.5 GSM900 L 27.3 M 15.2 M 27 H 15.8 -100.5 H 27-103.4 WCDMA-5 L 15.2 DCS1800 L 23.8 M 15.5 M 23.4 H 15.3 -103.2 H 22.7-98.2 WCDMA-8 L 16.7 PCS1900 L 22.4 M 17.2 M 22.4 H 16.9 -105.6 H 22.3-98.4 7.天线增益 GAIN GAIN(dBi）GAIN(dBi） B1-2.89B38-2.32 B2-2.56B39-2.51 B3-3.04B40-2.48 B4-2.63B41-2.25 B5-3.7W1-2.89 B7-2.19W2-2.56 B8-4.13W5-3.63 B12-4.49W8-4.13 B13-4.63GSM850-3.7 B17-4.59EGSM900-4.13 B20-3.59DCS1800-3.04 B28-4.33PCS1900-2.56 B66-2.63GPS-3.25 2.4G WIFI-2.99 BT-2.99 5.8G WIFI-2.43 增益 GSM天线3D方向图低频中频高频三合一测试 FSChannelTRP TIS灭 2.4G WIFI L 9.4 M 9.7 H 10.1-78.3 5.8G WIFI L 5.8 M 5.2 H 5.3-70.2 小板匹配小板匹配分集天线匹配三合一天线匹配 NFC天线匹配主板原匹配 NFC实测 TYPE 1卡：3cm TYPE 2卡：2cm TYPE 3卡：2.5cm TYPE 4卡：1cm TYPE 5卡：3.5cm 公交卡：1cm 环境处理环境处理环境处理联系方式：射频：江工电话：15014104367 邮箱：[email protected] 地址：龙华区龙观大道440号龙城工业区御龙办公楼二楼联系方式 THE END

RF Exposure Info

Reprot No.: LGT25J017HA03 Page 84 of 154 12.5 Simultaneous Multi-band Transmission Evaluation Application Simultaneous Transmission information: Position Simultaneous State Head 1. GSM + 2.4GHz WLAN/5G WLAN + NFC 2. GSM + Bluetooth + NFC 3. WCDMA + 2.4GHz WLAN/5G WLAN + NFC 4. WCDMA + Bluetooth + NFC 5. LTE + 2.4GHz WLAN/5G WLAN + NFC 6. LTE + Bluetooth + NFC Body 1. GSM + 2.4GHz WLAN/5G WLAN + NFC 2. GSM + Bluetooth + NFC 3. WCDMA + 2.4GHz WLAN/5G WLAN + NFC 4. WCDMA + Bluetooth + NFC 5. LTE + 2.4GHz WLAN/5G WLAN + NFC 6. LTE + Bluetooth + NFC NOTE: 1. Bluetooth and WLAN can’t simultaneous transmission at the same time. 2. For simultaneous transmission at head and body exposure position, 2 transmitters simultaneous transmission was the worst state. 3. If the test separation distance is <5mm, 5mm is used for excluded SAR calculation. 4. KDB 447498 / 4.3.2 (2) when standalone SAR test exclusion applies to an antenna that transmits simultaneously with other antennas, the standalone SAR must be estimated according to following to determine simultaneous transmission SAR test exclusion: a) (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f (GHz) /x] W/kg for test separation distances≤ 50 mm; Where x = 7.5 for 1-g SAR, and x = 18.75 for 10-g SAR. b) 0.4W/Kg for 1-g SAR and 1.0W/Kg for 10-g SAR, when the separation distance is >50mm. Estimated SAR Maximum Turn-up Power Antenna to user(mm) Frequency (GHz) Stand Alone SAR(1g) [W/kg] dBm mW BT Head 4.3 2.692 5 2.44 0.112 Body 5 2.44 0.112 NFC Head -37.5 0.000178 5 0.01356 0.0000006 Body 5 0.01356 0.0000006 Reprot No.: LGT25J017HA03 Page 85 of 154 Simultaneous Mode Position Mode Max. 1-g SAR 1-g Sum SAR (W/kg) (W/kg) GSM + 2.4G WLAN + NFC Head GSM 0.343 0.577 NFC 0.0000006 2.4G WLAN 0.234 Body GSM 0.520 0.668 NFC 0.0000006 2.4G WLAN 0.148 GSM + Bluetooth+ NFC Head GSM 0.343 0.455 NFC 0.0000006 BT 0.112 Body GSM 0.520 0.632 NFC 0.0000006 BT 0.112 GSM + 5G WLAN+ NFC Head GSM 0.343 0.796 NFC 0.0000006 5G WLAN 0.453 Body GSM 0.520 0.839 NFC 0.0000006 5G WLAN 0.319 WCDMA + 2.4G WLAN + NFC Head WCDMA 0.493 0.727 NFC 0.0000006 2.4G WLAN 0.234 Body WCDMA 0.469 0.617 NFC 0.0000006 2.4G WLAN 0.148 WCDMA + Bluetooth+ NFC Head WCDMA 0.493 0.605 NFC 0.0000006 BT 0.112 Body WCDMA 0.469 0.581 NFC 0.0000006 BT 0.112 WCDMA + 5G WLAN+ NFC Head WCDMA 0.493 0.946 NFC 0.0000006 5G WLAN 0.453 Body WCDMA 0.469 0.788 NFC 0.0000006 5G WLAN 0.319 LTE + 2.4G WLAN + NFC Head LTE 1.120 1.354 NFC 0.0000006 2.4G WLAN 0.234 Body LTE 1.024 1.172 NFC 0.0000006 2.4G WLAN 0.148 LTE + Bluetooth+ NFC Head LTE 1.120 1.232 NFC 0.0000006 BT 0.112 Body LTE 1.024 1.136 NFC 0.0000006 Reprot No.: LGT25J017HA03 Page 86 of 154 BT 0.112 LTE + 5G WLAN+ NFC Head LTE 1.120 1.573 NFC 0.0000006 5G WLAN 0.453 Body LTE 1.024 1.343 NFC 0.0000006 5G WLAN 0.319 Simultaneous transmission SAR test exclusion is determined for each operating configuration and exposure condition according to the reported standalone SAR of each applicable simultaneous transmitting antenna. When the sum of SAR 1g of all simultaneously transmitting antennas in an operating mode and exposure condition combination is within the SAR limit (SAR-1g 1.6 W/kg), the simultaneous transmission SAR is not required. When the sum of SAR 1g is greater than the SAR limit (SAR-1g 1.6 W/kg), SAR test exclusion is determined by the SPLSR. Reprot No.: LGT25J017HA03 Page 87 of 154 13. Equipment List Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until 750MHz Dipole MVG DIP0G750 SN 06/22 DIP0G750-638 2025.05.20 2028.05.19 835MHz Dipole MVG DIP0G835 SN 06/22 DIP0G835-639 2025.05.20 2028.05.19 1800MHz Dipole MVG DIP1G800 SN 06/22 DIP1G800-640 2025.05.20 2028.05.19 1900MHz Dipole MVG DIP1G900 SN 06/22 DIP1G900-641 2025.05.20 2028.05.19 2300MHz Dipole MVG DIP2G300 SN 06/22 DIP2G100-644 2025.05.20 2028.05.19 2450MHz Dipole MVG DIP2G450 SN 06/22 DIP2G450-645 2025.05.20 2028.05.19 2600MHz Dipole MVG DIP2G600 SN 06/22 DIP2G600-646 2025.05.20 2028.05.19 5000MHz Dipole MVG DIP5G000 SN 06/22 DIP5G000-653 2025.05.22 2028.05.21 E-Field Probe MVG SSE2 2225-EPGO-450 2025.06.06 2026.06.05 Liquid Calibration Kit MVG OCPG 87 SN 06/22 OCPG87 2025.06.02 2026.06.01 Antenna MVG ANTA 73 SN 06/22 ANTA 73 N/A N/A Ellipsoid Phantom MVG ELLI 51 SN 06/22 ELLI 51 N/A N/A Phantom MVG SAM 148 SN 06/22 SAM148 N/A N/A Phone holder MVG MSH 117 SN 06/22 MSH 117 N/A N/A Laptop positioner MVG LSH 36 SN 06/22 LSH 38 N/A N/A Directional coupler SHW SHWDCP 202203280013 N/A N/A Network Analyzer ZVL R&S 116184 2025.03.05 2026.03.04 Multi Meter DMM6500 Keithley 4527252 2025.03.06 2026.03.05 Signal Generator Keysight N5182B MY59100717 2025.03.05 2026.03.04 Wireless Communication Test Set R&S CMW500 137737 2025.03.05 2026.03.04 Power Sensor R&S Z11 116184 2025.03.05 2026.03.04 Electronic Temperature hygrometer N/A ST-W2318 N/A 2025.03.05 2026.03.04 Temperature hygrometer N/A TP101 N/A 2025.03.05 2026.03.04 Reprot No.: LGT25J017HA03 Page 88 of 154 Appendix A. System Validation Plots System Performance Check Data (750MHz) Type: Phone measurement (Complete) Area scan resolution: dx=8mm,dy=8mm Zoom scan resolution: dx=8mm, dy=8mm, dz=5mm Date of measurement: 2025-10-23 Experimental conditions. Phantom Validation plane Device Position Dipole Band CW750 Channels Middle Signal CW Frequency (MHz) 750.000 Relative permittivity 42.61 Conductivity (S/m) 0.86 Probe 2225-EPGO-450 ConvF 1.08 Crest factor: 1:1 SURFACE SAR VOLUME SAR Maximum location: X=1.00, Y=-6.00 ; SAR Peak: 1.20 W/kg SAR 10g (W/Kg) 0.563 SAR 1g (W/Kg) 0.864 Reprot No.: LGT25J017HA03 Page 89 of 154 Z Axis Scan Reprot No.: LGT25J017HA03 Page 90 of 154 System Performance Check Data (750MHz) Type: Phone measurement (Complete) Area scan resolution: dx=8mm,dy=8mm Zoom scan resolution: dx=8mm, dy=8mm, dz=5mm Date of measurement: 2025-10-26 Experimental conditions. Phantom Validation plane Device Position Dipole Band CW750 Channels Middle Signal CW Frequency (MHz) 750.…

Text truncated - open the document above for the full version.

RF Exposure Info

Text truncated - open the document above for the full version.
