2BTDL-S1ULTRAS1PROIntelligent Lawn Mower

Rev 1/26/2023 Kunshan Lantuo Intelligent Robot Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-05-2025 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2BTDL-S1ULTRAS1PRO Applicant FRN: 0037688223 [Kunshan Lantuo Intelligent Robot Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, [FCC US Agent, LLC] is our designated U.S. agent for service of process for the above referenced FCC ID. [Kunshan Lantuo Intelligent Robot Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [FCC US Agent, LLC] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: FCC US Agent, LLC U.S. Agent FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Tel.: 708-571-3148 Email: [email protected] Sincerely, Kunshan Lantuo Intelligent Robot Co., Ltd FCC US Agent, LLC Liu XiaoQiang Tim Payne [U.S. Agent signature]

Kunshan Lantuo Intelligent Robot Co., Ltd Date: 12-21-2025 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2BTDL-S1ULTRAS1PRO Dear Sir or Madam, [Kunshan Lantuo Intelligent Robot Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, [Kunshan Lantuo Intelligent Robot Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please contact us. Sincerely, Contact name: Xiaoqiang Liu Company name: Kunshan Lantuo Intelligent Robot Co., Ltd Address: 2F, Room 2, No. 179, Waihejing Road, Kunshan Development Zone Comprehensive Bonded Area, Kunshan, Jiangsu, China Telephone Number: +86 15123511045 E-mail: [email protected]

Kunshan Lantuo Intelligent Robot Co., Ltd Data: 2025-12-21 Subject: Statement of disable ANT port by software FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 To Whom It May Concern: We, Kunshan Lantuo Intelligent Robot Co., Ltd, hereby declare that Intelligent Lawn Mower uses ANT2 for 2.4GHz Wi-Fi & Bluetooth, ANT4 (4G DRX) and ANT5 (4G MAIN) for LTE, and ANT1 port and ANT3 port disabled by software. There will be no third party’s software or configuration tool to program the device out of compliance of the technical rules under which it has been certified. Best Regards Contact name: Xiaoqiang Liu Company name: Kunshan Lantuo Intelligent Robot Co., Ltd Address: 2F, Room 2, No. 179, Waihejing Road,Kunshan Development Zone Comprehensive Bond, Kunshan, Jiangsu, China E-mail: [email protected] Tel: +86 15123511045

Kunshan Lantuo Intelligent Robot Co., Ltd Declaration about Identity of Products Suzhou Lantuo Technology Co.,Ltd hereby solemnly declares： FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 The Intelligent Lawn Mower produced by our company, the power supply, electrical principle, PCBlayout and electrical structure used in Model S1 Pro and model S1 Ultra are the same, but the battery pack capacity is different. Signature & Stamp (签字及盖章):

Kunshan Lantuo Intelligent Robot Co., Ltd Date (21/12/2025) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Dear Sir or Madam, We, (Kunshan Lantuo Intelligent Robot Co., Ltd), hereby authorize Wenqiang LU from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151 Heng Tong Road Shanghai 201108 P.R. China to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on (Dec.31,2026). Sincerely, Company Officer: Xiaoqiang Liu Telephone Number: +86 15123511045 Email: [email protected]

Kunshan Lantuo Intelligent Robot Co., Ltd Date: 21/12/2025 TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2BTDL-S1ULTRAS1PRO Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, (Kunshan Lantuo Intelligent Robot Co., Ltd) hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation PCB layout (Kunshan Lantuo Intelligent Robot Co., Ltd) also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Internal Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Xiaoqiang Liu Telephone Number: +86 15123511045 Email: [email protected]

External Photos Documentation Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Page 1 of 3 Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra External Photos Documentation Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Page 2 of 3 Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra External Photos Documentation Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Page 3 of 3 Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra

Report No: 709502501599-00E EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 5 Rev. 23.00 MPE Calculation Applicant: Kunshan Lantuo Intelligent Robot Co., Ltd Address: 2F, Room 2, No. 179, Waihejing Road,Kunshan Development Zone Comprehensive Bond, Kunshan, Jiangsu, China Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO Model No.: S1 Pro, S1 Ultra Reference RF report # 709502501599-00B, 709502501599-00C, 709502501599-00D, EFTA25090045-IE-02-R1, Remark According to the client's declaration, all models are the power supply, electrical principle, PCB layout and electrical structure used in Model S1 Pro and model S1 Ultra are the same, but the battery pack capacity is different. So model S1 Ultra was chosen to perform all the tests, other model S1 Pro is deemed to fulfill all the requirement without further testing. According to subpart 15.247(i) and subpart §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1,500 / / f/1500 30 1,500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); Report No: 709502501599-00E EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 5 Rev. 23.00 P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); 2.4G BLE for 709502501599-00B Calculated Data: FPC antenna Maximum peak output power at antenna input terminal (dBm): 7 Maximum peak output power at antenna input terminal (mW): 5.01 tune-up conducted power(dBm): 8 tune-up conducted power(mW): 6.31 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 5.12 Maximum Antenna Gain (numeric): 3.2509 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.00408 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1.00 Note: The tune-up conducted power (8 dBm) was declared by the manufacturer. The max power density 0.00408 (mW/cm2) < 1 (mW/cm2) 2.4G EDR for 709502501599-00C Calculated Data: FPC antenna Maximum peak output power at antenna input terminal (dBm): 7.71 Maximum peak output power at antenna input terminal (mW): 5.90 tune-up conducted power(dBm): 8.5 tune-up conducted power(mW): 7.08 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 5.12 Maximum Antenna Gain (numeric): 3.2509 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.00458 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1.00 Note: The tune-up conducted power (8.5 dBm) was declared by the manufacturer. The max power density 0.00458 (mW/cm2) < 1 (mW/cm2) Report No: 709502501599-00E EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 3 of 5 Rev. 23.00 2.4G Wi-Fi for 709502501599-00D Calculated Data: FPC antenna Maximum peak output power at antenna input terminal (dBm): 23.68 Maximum peak output power at antenna input terminal (mW): 233.35 tune-up conducted power(dBm): 24.5 tune-up conducted power(mW): 281.84 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 5.12 Maximum Antenna Gain (numeric): 3.2509 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.18228 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1.00 Note: The tune-up conducted power (24.5 dBm) was declared by the manufacturer. The max power density 0.18228 (mW/cm2) < 1 (mW/cm2) LTE Band2 for EFTA25090045-IE-02-R1 Calculated Data: FPC antenna Maximum peak output power at antenna input terminal (dBm): 23.31 Maximum peak output power at antenna input terminal (mW): 214.29 tune-up conducted power(dBm): 24 tune-up conducted power(mW): 251.19 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 3.20 Maximum Antenna Gain (numeric): 2.0893 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.10441 MPE limit for general population exposure at prediction frequency (mW/cm 2 ): 1 Note: The tune-up conducted power (24 dBm) was declared by the manufacturer. The max power density 0.09305 (mW/cm2) < 1 (mW/cm2) Report No: 709502501599-00E EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 4 of 5 Rev. 23.00 LTE Band4 for EFTA25090045-IE-02-R1 Calculated Data: FPC antenna Maximum peak output power at antenna input terminal (dBm): 23.33 Maximum peak output power at antenna input terminal (mW): 215.28 tune-up conducted power(dBm): 24 tune-up conducted power(mW): 251.19 Prediction distance (cm): 20 Antenna Gain, typical (dBi): 3.44 Maximum Antenna Gain (numeric): 2.2080 The worst case is power density at predication frequency at 20 cm (mW/cm 2 ): 0.11034 MPE limit f…

Text truncated - open the document above for the full version.

Mower antenna debugging report Topfriction Internet of Things Radio: Engineer Li Time: 2025.10.10 03 01 02 CONTENTS catalogue basic information Test equipment complete data antenna matching test data Unpowered/powered test data Antenna assembly diagram Environmental treatment diagram Planning Summary Project overview basic information Basic information test macro ØSATIMO，Agilent E5071C，Anristu MT8820C， CMW500,StarPointSP9500 basic information Basic information antenna loading coil Antenna circuit matching description (1) Smart lawn mower 4G-MAIN antenna compatibility: No changes (2) Smart lawn mower 4G-DIV antenna compatibility: No changes (3) BT & Wi-Fi antenna compatibility for smart lawn mowers:No changes 4G-MAIN: Assembly Diagram 4G-MAIN: Single-antenna passive measurements (echo loss, Smith circle diagram, voltage standing wave ratio) 4G-MAIN: Passive data with single antenna (efficiency, gain, pattern) FrequencyEfficiencyGain . dBi 800MHz47%1.90 820MHz46%2.22 840MHz42%2.07 860MHz40%1.39 880MHz44%1.41 900MHz42%1.70 920MHz42%1.28 940MHz36%1.52 960MHz35%1.73 980MHz34%2.25 1000MHz40%3.49 4G-MAIN: single antenna passive data (efficiency, gain, directionality) FrequencyEfficiencyGain . dBi 1700MHz51%3.44 1750MHz45%3.13 1800MHz41%2.68 1850MHz41%2.90 1900MHz42%3.20 1950MHz43%1.40 2000MHz41%2.45 2050MHz38%2.42 2100MHz36%1.83 2150MHz34%1.60 2200MHz31%2.19 2250MHz35%3.68 2300MHz41%5.14 2350MHz44%4.92 2400MHz46%4.61 2450MHz45%4.32 2500MHz49%5.11 2550MHz51%5.13 2600MHz49%5.15 2650MHz51%5.20 2700MHz50%4.64 4G-DIV: Assembly diagram 4G-DIV: single antenna passive data (return loss, Smith circle diagram, voltage standing wave ratio) 4G-DIV: single antenna passive data (efficiency, gain, directionality) FrequencyEfficiencyGain . dBi 800MHz33%0.99 820MHz36%0.72 840MHz37%0.85 860MHz35%0.86 880MHz31%0.51 900MHz26%0.34 920MHz27%0.10 940MHz29%0.75 960MHz27%0.47 980MHz22%0.06 1000MHz17%-0.43 4G-DIV: single antenna passive data (efficiency, gain, directionality) FrequencyEfficiencyGain . dBi 1700MHz57%6.51 1750MHz56%6.74 1800MHz51%5.87 1850MHz57%6.36 1900MHz53%6.72 1950MHz51%6.62 2000MHz50%6.01 2050MHz51%5.32 2100MHz55%4.44 2150MHz57%5.17 2200MHz52%5.41 2250MHz45%5.21 2300MHz41%5.52 2350MHz35%4.42 2400MHz36%3.82 2450MHz34%3.50 2500MHz34%3.35 2550MHz32%2.08 2600MHz30%1.34 2650MHz34%2.90 2700MHz36%3.65 BT： assembly drawing BT & Wi-Fi : single antenna passive data (return loss, Smith circle, voltage stand- ing ratio) BT & Wi-Fi: Single antenna passive data (efficiency, gain, direc- tionality) FrequencyEfficiencyGain . dBi 2400MHz52%5.12 2410MHz51%4.94 2420MHz51%4.67 2430MHz49%4.28 2440MHz48%3.86 2450MHz47%3.66 2460MHz47%3.61 2470MHz45%3.27 2480MHz44%3.04 2490MHz46%3.26 2500MHz45%3.19 00 Planning Summary Planning to summarize The above report is for the lawn mower project, using a mass production antenna, and the retest data of a single antenna. 1.No antenna matching changes. 2.The antenna is not grounded, and the motherboard is not treated for environmental conditions. 3.If there are many machine connection lines, it is recommended that all accessory connection lines be twisted into a twisted shape and fixed away from the antenna position. THANK YOU May you have a calm mind in a noisy world —Expand IoT

Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 87 Rev. 23.00 FCC/ISED - TEST REPORT Report Number : 709502501599-00C Date of Issue: February 6, 2026 Model : S1 Pro, S1 Ultra Product Type : Intelligent Lawn Mower Applicant : Kunshan Lantuo Intelligent Robot Co., Ltd Address : 2F, Room 2, No. 179, Waihejing Road,Kunshan Development Zone Comprehensive Bond, Kunshan, Jiangsu, China Production Facility : Kunshan Lantuo Intelligent Robot Co., Ltd Address : 2F, Room 2, No. 179, Waihejing Road,Kunshan Development Zone Comprehensive Bond, Kunshan, Jiangsu, China Test Result : ◼ Positive  Negative Total pages including Appendices : 87 TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 87 Rev. 23.00 1 Table of Contents 1 Table of Contents .................................................................................................................. 2 2 Report Modification Record .................................................................................................. 3 3 Details about the Test Laboratory ......................................................................................... 3 4 Description of the Equipment Under Test ............................................................................. 4 5 Summary of Test Standards ................................................................................................. 7 6 Summary of Test Results ...................................................................................................... 8 7 General Remarks ............................................................................................................... 10 8 Test Setups .......................................................................................................................... 11 9 Systems test configuration .................................................................................................. 14 10 Technical Requirement ....................................................................................................... 15 10.1 Conducted Emission .................................................................................................... 15 10.2 Conducted Peak Output Power & EIRP ...................................................................... 18 10.3 20 dB bandwidth and 99% Occupied Bandwidth ......................................................... 23 10.4 Carrier Frequency Separation ..................................................................................... 31 10.5 Number of hopping frequencies .................................................................................. 34 10.6 Dwell Time ................................................................................................................... 36 10.7 Spurious RF conducted emissions .............................................................................. 41 10.8 Band edge testing........................................................................................................ 45 10.9 Spurious radiated emissions for transmitter ................................................................ 58 11 Test Equipment List ............................................................................................................ 83 12 System Measurement Uncertainty ...................................................................................... 85 13 Photographs of Test Set-ups .............................................................................................. 86 14 Photographs of EUT ........................................................................................................... 87 Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 3 of 87 Rev. 23.00 2 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 709502501599-00C First Issue 02/06/2026 3 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch No.16 Lane, 1951 Du Hui Road, Shanghai 201108, P.R. China Telephone: +86 21 6141 0123 Fax: +86 21 6140 8600 FCC Registration No…

Text truncated - open the document above for the full version.

Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 36 of 87 Rev. 23.00 10.6 Dwell Time Test Method 1. The RF output of EUT was connected to the spectrum analyzer by RF cable. The path loss was compensated to the results for each measurement. 2. Set to the maximum power setting and enable the EUT transmit to hopping mode. 3. Span: Zero span, centered on a hopping channel. 4. RBW shall be ≤ channel spacing and where possible RBW should be set >> 1 / T, where T is the expected dwell time per channel. 5. Sweep: As necessary to capture the entire dwell time per hopping channel; where possible use a video trigger and trigger delay so that the transmitted signal starts a little to the right of the start of the plot. The trigger level might need slight adjustment to prevent triggering when the system hops on an adjacent channel; a second plot might be needed with a longer sweep time to show two successive hops on a channel. 6. Detector function: Peak. 7. Trace: Max hold. Use the marker-delta function to determine the transmit time per hop. If this value varies with different modes of operation (data rate, modulation format, number of hopping channels, etc.), then repeat this test for each variation in transmit time. Limit The average time of occupancy on any frequency shall not be greater than 0.4 seconds within a period of 0.4 seconds multiplied by the number of hopping channels employed. Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 37 of 87 Rev. 23.00 Dwell Time Dwell time The maximum dwell time shall be 0,4 s. According to the Bluetooth Core Specification, the worse result (DH5 mode) was reported to show compliance. The Dwell Time = Burst Width * Total Hops. The detailed calculations are showed as follows: The duration for dwell time calculation: 0.4 [s] * hopping number = 0.4 [s] * 79 [ch] = 31.6 [s*ch]; The burst width, which is directly measured, refers to the duration on one channel hop. Test Result Modulation Mode Reading (ms) Total Hops Test Result (ms) Limit (ms) Result GFSK DH5 2.888 101 291.688 < 400 Pass π/4-DQPSK 2DH5 2.889 112 323.568 < 400 Pass 8-DPSK 3DH5 2.891 100 289.1 < 400 Pass Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 38 of 87 Rev. 23.00 GFSK Modulation Test Graphs Dwell NVNT 1-DH5 2402MHz Ant1 One Burst Dwell NVNT 1-DH5 2402MHz Ant1 Accumulated Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 39 of 87 Rev. 23.00 π/4-DQPSK Modulation Dwell NVNT 2-DH5 2402MHz Ant1 One Burst Dwell NVNT 2-DH5 2402MHz Ant1 Accumulated Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 40 of 87 Rev. 23.00 8-DPSK Modulation Dwell NVNT 3-DH5 2402MHz Ant1 One Burst Dwell NVNT 3-DH5 2402MHz Ant1 Accumulated Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 41 of 87 Rev. 23.00 10.7 Spurious RF conducted emissions Test Method 1. The RF output of EUT was connected to the spectrum analyzer by RF cable. The path loss was compensated to the results for each measurement. 2. Set to the maximum power setting and enable the EUT transmit continuously. 3. Set RBW = 100 kHz, VBW=300 kHz, Peak Detector, Sweep = auto, Span = wide enough to capture the peak level of the in-band emission and all spurious emissions, Trace = max hold. Allow the trace to stabilize. Set the marker on the peak of any spurious emission recorded. The level displayed must comply with the limit specified in this Section. 4. Measure and record the results in the test report. 5. The RF fundamental frequency should be excluded against the limit line in the operating frequency Limit Frequency Range Limit (dBc) MHz 30-25000 -20 Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 42 of 87 Rev. 23.00 Spurious RF conducted emissions Only the worse case (which is subject to the maximum EIRP, π/4-DQPSK mode) test result is listed in the report. Out-of-Band Emissions 2-DH5 Channel 0 (2402MHz) Reference point Spurious Emission (30MHz – 1GHz) Spurious Emission (1GHz –5GHz) Spurious Emission (5GHz –26.5GHz) Note: The emission which exceed the limit is the fundamental. Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 43 of 87 Rev. 23.00 Out-of-Band Emissions 2-DH5 Channel 0 (2441MHz) Reference point Spurious Emission (30MHz – 1GHz) Spurious Emission (1GHz –5GHz) Spurious Emission (5GHz –26.5GHz) Note: The emission which exceed the limit is the fundamental. Report Number: 709502501599-00C EMC_SHA_F_R_02.03E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 44 of 87 Rev. 23.00 Out-of-Band Emissions 2-DH5 Channel 0 (2480MHz) Reference p…

Text truncated - open the document above for the full version.

Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra ©2026 Not to be reproduced, except in its entirety, Page 1 of 2 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch PHOTOGRAPHS OF TEST SET UP Field Strength and Harmonics Test Setup Radiated Emission Setup 9kHz ~ 30MHz 30MHz ~ 1GHz Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra ©2026 Not to be reproduced, except in its entirety, Page 2 of 2 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch 1GHz ~ 18GHz 18GHz ~ 25GHz Manufacturer: Kunshan Lantuo Intelligent Robot Co., Ltd Product: Intelligent Lawn Mower FCC ID: 2BTDL-S1ULTRAS1PRO IC: 34692-S1 Mode: S1 Ultra HVIN: S1Ultra ©2026 Not to be reproduced, except in its entirety, Page 3 of 2 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch Conducted emission Test Setup
