2BTGD-POWERSH11Wireless Power Bank

Power appliance Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 [December 4, 2025] U.S. Agent Designation [Power appliance Co., Ltd.] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought FCC ID: 2BTGD-POWERSH11 Name and company of U.S. agent: [GLOCERTS TECHNOLOGY INC] Physical U.S. address of agent: [19784 SUNKISSED RIDGE DR, RIVERSIDE, CA 92507] FRN of U.S. agent: [0036339737] Email address of U.S. agent: [[email protected]] Telephone of U.S.agent: (626) 588-8039 [GLOCERTS TECHNOLOGY INC] acknowledges their obligation to accept service of process on behalf of [Power appliance Co., Ltd.]. [Power appliance Co., Ltd.] with the FRN [0037700713] accepts its obligation to maintain an agent for service of process in the United States for no less than 1 year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Signature [su rina] [Huiying Fan] [manager] [Director] [Manufacturer's Name] [GLOCERTS TECHNOLOGY INC]

power appliance Co., Ltd. (December 4, 2025) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BTGD-POWERSH11 [power appliance Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) su rina power appliance Co., Ltd. (December 4, 2025) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BTGD-POWERSH11 [power appliance Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) su rina

power appliance Co., Ltd. Model Difference Data：December 4, 2025 Product description: Wireless Power Bank Model name: POWER SH11, ZEN-10000 Trade Name: N/A FCC ID: 2BTGD-POWERSH11 All the model are the same circuit and RF module, only the appearance color and specification are different. Regards Sincerely Client’s signature : Client’s name / title : su rina（manager） Contact information / address：2-4-7 Izumimachi, Chuo Ward, Osaka 540-0019, Japan

power appliance Co., Ltd. (December 4, 2025) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Wireless Power Bank / POWER SH11, ZEN-10000 / FCC ID: 2BTGD-POWERSH11) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: su rina Title: manager

power appliance Co., Ltd. (December 4, 2025) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: su rina Title: manager

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: POWER SH11 External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

FCC ID LABEL: Label Location: FCC ID: 2BTGD-POWERSH11 Model No.: POWER SH11

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 11 RF EXPOSURE REPORT Compiled by: Reviewed by: Approved by: Kai Chen Martin Feng Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description: Wireless Power Bank FCC ID: 2BTGD-POWERSH11 Trademark(s): N/A Model/Type reference: POWER SH11, ZEN-10000 Applicant’s name: power appliance Co., Ltd. Address: 2-4-7 Izumimachi, Chuo Ward, Osaka 540-0019, Japan Manufacturer: power appliance Co., Ltd. Address: 2-4-7 Izumimachi, Chuo Ward, Osaka 540-0019, Japan Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Oct. 17, 2025 Sample tested Date: Oct. 17, 2025 to Oct. 25, 2025 Issue Date: Oct. 25, 2025 Report No.: CTB25101700201RF02 Test Standards FCC CFR 47 part1, 1.1307(b), 1.1310, 47 CFR§2.1091; KDB 680106 D01 Wireless Power Transfer v04 Test Results PASS Remark: This is wireless charger EMF report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page2 of 11 Table of Contents Page 1 . GENERAL INFORMATION 3 1.1 . Independent Operation Mode 3 1.2 . Test Supporting System 3 2 .LIST OF TEST AND MEASUREMENT INSTRUMENTS 4 2.1 . For conducted emission at the mains terminals test 4 3. METHOD OF MEASUREMENT 5 3. 1.Applicable Standard 5 4. TEST RESULT 6 4.1. Conducted Emission at the Mains Terminals Test 6 4.2. Equipment Approval Considerations: 7 4.3. E and H field Strength 7 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page3 of 11 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: 1.1.1. wireless charger power: 5W/7.5W/10W/15W MAX 1.2. Test Supporting System Adapter Description: Adapter Model No.: HP18A-0902000-AU Power Input: AC100-240V~ 1.0A 50/60Hz Output: 9V2.0A DC Line: Unshielded, Detachable 1.2m Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page4 of 11 2.L IST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Item Equipment Brand Model No. Frequency Range Last calibration Calibrated until 1 EMF TESTER Wavecontrol SMP600/WP40 0-3 15SN0164/21W P1200029 2024.10.28 2025.10.27 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page5 of 11 3. METHOD OF MEASUREMENT 3. 1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According to KDB 680106 D01 Wireless Power Transfer v04. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page6 of 11 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Note: Measurements should be made from all sides and the top of the primary/client pair, with the 20 cm-0cm measured from the center of the top, and 15cm-0cm measured from the center of the rest Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) 20 cm-0cm measured from the center of the top, and 15cm-0cm measured from the center of the rest sides. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points were completed. e) The EUT were measured according to the dictates of KDB 680106 D01 Wireless Power Transfer v04. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25101700201RF02 EMF Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page7 of 11 4.2. Equipment Approval Considerations: The EUT does comply with item 5(b) of KDB 680106 V04 1) Power transfer frequency is less than 1MHz Yes, the device operate in the frequency range from 110kHz to 205kHz 2) The output power from each transmitting element (e.g., coil) is less than or equal to 15 watts. Yes, the maximum output power of the primary coil is 15000mW. 3) A client device providing the maximum permitted load is placed in physical contact with the transmitter (i.e., the surfaces of the transmitter and client device enclosures need to be in physical contact). Yes, the surfaces of the transmitter and client device enclosures are in physical contact 4) Only § 2.1091-Mobile exposure conditions apply (i.e., this provision does not cover § 2.1093-Portable exposure conditions).. No, the EUT is portable condition assessment. 5) The E-field and H-field strengths, at and beyond 20 cm surrounding the device surface, are demonstrated to be less than 50% of the applicable MPE limit, per KDB 447498, Table 1. Yes, the EUT field strength levels are less 50% x MPE limit. 6) For systems with more than one radiating structure, the conditions specified in (5) must be met when the system is fully loaded (i.e., clients absorbing maximum power available), and with all the radiating structures operating at maximum power at the same time, as per design c…

Text truncated - open the document above for the full version.

A 43.5±0.5mm B38.5±1mm C20.5±0.5mm D<1.5mm E 45mm ± 3mm F3±2mm G No holes Thickness of the magnetic sheet 0.5±0.1mm Shape of magnetic sheet Circular single-slot black film on the front Adhesive backing thickness Ordinary double-sided tape Specification of high-position tape 3mm Tape

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 23 TEST REPORT Compiled by: Reviewed by: Approved by: Kai Chen Martin Feng Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description: Wireless Power Bank FCC ID: 2BTGD-POWERSH11 Trademark(s): N/A Model/Type reference: POWER SH11, ZEN-10000 Applicant’s name: power appliance Co., Ltd. Address: 2-4-7 Izumimachi, Chuo Ward, Osaka 540-0019, Japan Manufacturer: power appliance Co., Ltd. Address: 2-4-7 Izumimachi, Chuo Ward, Osaka 540-0019, Japan Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Oct. 17, 2025 Sample tested Date: Oct. 17, 2025 to Oct. 25, 2025 Issue Date: Oct. 25, 2025 Report No.: CTB25101700201RF01 Test Standards FCC Part 15 C Test Results PASS Remark: This is wireless charger radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB25101700201RF01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 23 TABLE OF CONTENTS 1. GENERAL INFORMATION ........................................................................................................................ 3 1.1. Report information ................................................................................................................................. 3 1.2. Measurement Uncertainty ..................................................................................................................... 3 1.3. Test Facility ........................................................................................................................................... 3 1.4. Test Uncertainty .................................................................................................................................... 4 2. PRODUCT DESCRIPTION ......................................................................................................................... 5 2.1. EUT Description .................................................................................................................................... 5 2.2. Block Diagram of EUT Configuration ..................................................................................................... 5 2.3. Test Conditions ..................................................................................................................................... 5 2.4. DescriptionOfSupport Units (Conducted Mode) .................................................................................... 6 3. TEST RESULTS SUMMARY ...................................................................................................................... 7 4. TEST EQUIPMENT USED .......................................................................................................................... 8 4.1. MEASUREMENT INSTRUMENTS LIST ............................................................................................... 8 5. CONDUCTED EMISSION TEST ............................................................................................................... 11 5.1. Block Diagram of Test Setup ............................................................................................................... 11 5.2. Test Standard ...................................................................................................................................... 11 5.3. Conducted Emission Limit ................................................................................................................... 11 5.4. EUT Configuration on Test .................................................................................................................. 11 5.5. Operating Condition of EUT ................................................................................................................ 11 5.6. Test Procedure .................................................................................................................................... 12 5.7. Test Result .......................................................................................................................................... 12 6. RADIATED EMISSION MEASUREMENT ................................................................................................ 15 6.1. Block Diagram of Test Setup ............................................................................................................... 15 6.2. Test Standard ...................................................................................................................................... 16 6.3. EMI Test Receiver Setup..................................................................................................................... 16 6.4. Test Procedure .................................................................................................................................... 16 6.5. Test Result .......................................................................................................................................... 16 7. OCCUPIED BANDWIDTH ........................................................................................................................ 20 7.1. Block Diagram of Test Setup .....................................................................…

Text truncated - open the document above for the full version.

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: POWER SH11 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: POWER SH11 Radiated Emission 9KHz-30MHz 30MHz-1GHz Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Conducted emissions
