2BTKT-GL403GL403_LA tracker

GL403 Product Specification description Product Display physical specifications Overall dimensions210*41.5*15mm Total weight communication 4G moduleEG915U 4G antennaBuilt-in bracket antenna LA band LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66 GSM:850/900/1800/1900 MHz transmit power ⚫ GSM850/EGSM900: Class 4 (33 dBm ±2 dB) ⚫ DCS1800/PCS1900: Class 1 (30 dBm ±2 dB) ⚫ LTE-FDD: Class 3 (23 dBm ±2 dB) LTE features ⚫ Supports up to Cat 1 FDD ⚫ Supports 1.4/3/5/10/15/20 MHz RF bandwidth ⚫ Supports upstream QPSK and 16QAM ⚫ Supports downstream QPSK, 16QAM, and 64QAM ⚫ LTE-FDD: Maximum downlink rate of 10 Mbps, maximum uplink rate of 5 Mbps GNSS chipZhongkeweiAT6558R antennaBuilt-in ceramic antenna signal receptionSupport parallel reception and joint positioning of BDS/GPS/GLONASS Cold start TTFF ≤32s Hot start TTFF≤1s Reacquire TTFF≤1s sensitivity "Cold start acquisition sensitivity -148dBm" Hot start capture sensitivity -156dBm Re-acquisition sensitivity -160dBm Tracking sensitivity -162dBm" positioning accuracy<2m(1σ) Speed measurement accuracy<0.1m/s(1σ) Positioning update rateMaximum 5Hz POWER External voltage 9 - 90V Type-C charging voltage 5V battery 300mAH(3.7V) Power-on method "1 Power on directly with external power supply 2 Type-C power supply for direct startup 3 Battery powered, turn on the switch chargeExternal voltage or Type-C interface charging, charging current 100mA SENSOR 6-axis sensorSupport, embedded temperature sensor Hardware watchdogSupport chipGR5525RGNI RAM256 KB SiP Flash1 MB Bluetooth@ Technology External flashSupport agreement BLE 5.3 Data transmission rate 1 Mbps 、 2 Mbps 、 Long Range(500 kbps 、 125 kbps) Transmission (TX) power–20 dBm ~ +7 dBm Reception (RX) sensitivity –97 dBm（1 Mbps模式下） - –93 dBm（2 Mbps模式下） - –101 dBm（Long Range 500 kbps模式下） - –103 dBm（Long Range 125 kbps模式下） Interface switch 1. Turn on to use the battery to power the system 2. Turn on to charge the battery SIMNAND ADC Support UART Support indicator light Red light: power indicator light, green light: network signal light, blue light: GPS signal light USB Support Type-C interface ACC compatible RELAYcompatible 1_WIRE compatible SOS compatible GATE compatible RS485 compatible RS232 compatible MIC compatible BEEPcompatible FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the users authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: The equipment complies with FCC Radiation exposure limits set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

FCC ID:2BTKT-GL403 TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2BTKT-GL403 TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2BTKT-GL403 TB-RF-073-3.1 Photo 5 Appearance of EUT

FCC ID:2BTKT-GL403 TB-RF-073-3.1 Appendix I Label Appendix II Label Location i FCC ID:2BTKT-GL403 Model:GL403

FCC ID:2BTKT-GL403 TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 6 Internal of EUT Photo 7 Internal of EUT FCC ID:2BTKT-GL403 TB-RF-073-3.1 Photo 8 Appearance of PCB Photo 9 Appearance of PCB GSM&LTE Ant BLE Ant GPS Ant FCC ID:2BTKT-GL403 TB-RF-073-3.1 Photo 10 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0028-3 Page: 1 of 11 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.toby-lab.com Maximum Permissible Exposure Evaluation FCC ID: 2BTKT-GL403 Report No. : TBR-C-202512-0028-3 Applicant : Shanghai iMobileThing Technology Ltd Equipment Under Test (EUT) EUT Name : GL403_LA tracker Model No. : GL403 Series Model No. : GL401,GL402,GL404,GL405,GL406,GL407,GL408,GL409,GL410,GL 411,GL412,GL413,GL414,GL415,GL416,GL417,GL418,GL419,GL420 ,GL421,GL422,GL423,GL424,GL425,GL426,GL427,GL428,GL429,GL 430,GL431,GL432,GL433,GL434,GL435,GL436,GL437,GL438,GL439 ,GL440,GL441,GL442,GL442_C,GL442_X,GL443,GL444,GL445,GL4 46,GL447,GL448,GL449,GL449_C,GL449_Q,GL449_X,GL450,GL451 ,GL452,GL453,GL454,GL455,GL456,GL457,GL458,GL459,GL460,GL 461,GL462,GL463,GL464,GL465,GL466,GL467,GL468,GL469,GL480 ,GL481,GL482,GL483,GL484,GL485,GL486,GL487,GL488,GL489,GL 490,GL491,GL492,GL493,GL494,GL494_Q,GL494_X,GL495,GL496, GL497,GL498,GL499,GP401,GP402,GP403,GP404,GP405,GP406,G P407,GP408,GP409,GP410,GP410_Q,GP411,GP412,GP413,GP413 _Q,GP414,GP415,GP416,GP416_Q,GP417,GP418,GP419,GP420,G P421,GP422,GP423,GP424,GP425,GP426,GP427,GP428,GP429,GP 430,GP430_B,GP431,GP431_Q,GP432,GP433,GP434,GP435,GP43 6,GP437,GP438,GP439,GP440,GP441,GP442,GP443,GP444,GP445 ,GP446,GP447,GP448,GP449,GP460,GP461,GP462,GP463,GP464, GP465,GP466,GP467,GP467_J,GP468,GP469,GP480,GP481,GP48 2,GP483,GP484,GP485,GP486,GP487,GP488,GP489,GP490,GP490 _Q,GP491,GP492,GP493,GP493_Q,GP494,GP495,GP496,GP496_Q ,GP497,GP498,GP498_Q,GP499 Brand Name : iMobileThing Sample ID : HC-C-202512-0028-01-01&HC-C-202512-0028-02-01 Receipt Date : 2025-12-09 Test Date : 2025-12-09 to 2026-01-21 Issue Date : 2026-01-21 Standards : FCC Part 2.1091 Report No.: TBR-C-202512-0028-3 Page: 2 of 11 www.toby-lab.com TB-RF-073-3.1 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gald zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0028-3 Page: 3 of 11 www.toby-lab.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 3 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 2. MEASUREMENT UNCERTAINTY .......................................................................................... 7 3. TEST FACILITY.......................................................................................................................... 8 4. METHOD OF MEASUREMENT FOR FCC............................................................................ 9 5. TEST RESULT.......................................................................................................................... 10 Report No.: TBR-C-202512-0028-3 Page: 4 of 11 www.toby-lab.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202512-0028-3 Rev.01 Initial issue of report 2026-01-21 Report No.: TBR-C-202512-0028-3 Page: 5 of 11 www.toby-lab.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Shanghai iMobileThing Technology Ltd Address : Floor 2, No. 158 Shuanglian Road, Qingpu District, Shanghai, China Manufacturer : Shanghai iMobileThing Technology Ltd Address : Floor 2, No. 158 Shuanglian Road, Qingpu District, Shanghai, China 1.2 General Description of EUT (Equipment Under Test) EUT Name : GL403_LA tracker Models No. : GL403,GL401,GL402,GL404,GL405,GL406,GL407,GL408,GL409,G L410,GL411,GL412,GL413,GL414,GL415,GL416,GL417,GL418,GL 419,GL420,GL421,GL422,GL423,GL424,GL425,GL426,GL427,GL4 28,GL429,GL430,GL431,GL432,GL433,GL434,GL435,GL436,GL43 7,GL438,GL439,GL440,GL441,GL442,GL442_C,GL442_X,GL443, GL444,GL445,GL446,GL447,GL448,GL449,GL449_C,GL449_Q,GL 449_X,GL450,GL451,GL452,GL453,GL454,GL455,GL456,GL457,G L458,GL459,GL460,GL461,GL462,GL463,GL464,GL465,GL466,GL 467,GL468,GL469,GL480,GL481,GL482,GL483,GL484,GL485,GL4 86,GL487,GL488,GL489,GL490,GL491,GL492,GL493,GL494,GL49 4_Q,GL494_X,GL495,GL496,GL497,GL498,GL499,GP401,GP402, GP403,GP404,GP405,GP406,GP407,GP408,GP409,GP410,GP410 _Q,GP411,GP412,GP413,GP413_Q,GP414,GP415,GP416,GP416 _Q,GP417,GP418,GP419,GP420,GP421,GP422,GP423,GP424,GP 425,GP426,GP427,GP428,GP429,GP430,GP430_B,GP431,GP431 _Q,GP432,GP433,GP434,GP435,GP436,GP437,GP438,GP439,GP 440,GP441,GP442,GP443,GP444,GP445,GP446,GP447,GP448,G P449,GP460,GP461,GP462,GP463,GP464,GP465,GP466,GP467, GP467_J,GP468,GP469,GP480,GP481,GP482,GP483,GP484,GP4 85,GP486,GP487,GP488,GP489,GP490,GP490_Q,GP491,GP492, GP493,GP493_Q,GP494,GP495,GP496,GP496_Q,GP497,GP498, GP498_Q,GP499 Model Different : All these models are exactly the same in terms of the same printed circuit board, layout and electrical circuits. The only difference lies in the different names. Product Description : Operation Frequency: Bluetooth LE: 2402MHz~2480MHz GSM 850: 824.20MHz-848.80MHz PCS1900: 1850.20MHz-1909.80MHz LTE Band 2: TX: 1850MHz~1910MHz LTE Band 4: 1710~1755 MHz LTE Band 5: TX: 824MHz~849MHz LTE Band 7: TX: 2500MHz~2570MHz LTE Band 66: 2110 ~ 2200 MHz Modulation Type: Bluetooth LE: GFSK GPRS: GMSK LTE:QPSK, 16QAM Antenna Gain: 0.32dBi PCB Antenna 1.59dBi PCB A…

Text truncated - open the document above for the full version.

ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 第1页共4页 上海杰盛康通信工程有限公司 客户承认书 SPECIFICATIONFORAPPROVAL CUSTOMER/PROJECT客户/机型：GL403 CUSTOMERP.N./客户物料号： PRODUCTNAME./物料名称：BTAntenna MODELNO./物料型号： VERSION 版本 DATE 日期 REVISIONDESCRIPTION 修订说明 T:A2024/5/24 新增 SUPPLIERAUTHORIZEDSIGNATURE/供应商承认签核 制作/PREPARED审核/CHECKED批准/APPROVED 肖文珍 CUSTOMERAUTHORIZEDSIGNATURE/客户承认签核 项目质量 Pleasereturntousonecopyof“SPECIFICATIONFORAPPROVAL”withyour approvedsignature.//客户确认签字，盖章后请回传一份承认书给我司. ADD:No.358LiuyuanRD.,BaoshanUrbanIndustrial District.,Shanghai,PR.China. 地址：上海市宝山城市工业园区柳园路358号5号楼5楼 TEL:+86-21-66276925(26/29/35)－615 杰盛康机密，未经允许，请勿转载 第2页共4页 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 一、天线参数/antennaparameters： 1 驻波比/VSWR 2 史密斯阻抗圆图/Smithimpedancecirclediagram 杰盛康机密，未经允许，请勿转载 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 第3页共4页 上海杰盛康通信工程有限公司 二、 增益和效率 /Gain&Efficiency 杰盛康机密，未经允许，请勿转载 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 第4页共4页 上海杰盛康通信工程有限公司 二、天线尺寸图/Antennasizediagram TheBluetoothantennaisanonboardantenna. 杰盛康机密，未经允许，请勿转载

Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 1 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: GL403_LA tracker Test Model: GL403 Sample ID: HC-C-202512-0028-01-01 Environmental Conditions Temperature: 25.6°C Relative Humidity: 48.6% Test Voltage: DC 3.7V Test Engineer: Gold zhang Note: For a more detailed features description, please refer to the report TBR-C-202512-0028-2 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 2 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ............................................................................................................................................ 7 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 15 5. Maximum Power Spectral Density Level ................................................................................................................................... 19 6. Band Edge ................................................................................................................................................................................... 23 7. Conducted RF Spurious Emission ............................................................................................................................................. 28 8. Restrict Band ............................................................................................................................................................................... 35 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 3 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 74.72 1.27 1.07 NVNT BLE 1Mbps 2440 Ant1 74.56 1.27 1.07 NVNT BLE 1Mbps 2480 Ant1 74.56 1.27 1.07 NVNT BLE 2Mbps 2402 Ant1 39.68 4.01 2.02 NVNT BLE 2Mbps 2440 Ant1 39.68 4.01 2.02 NVNT BLE 2Mbps 2480 Ant1 39.68 4.01 2.02 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 4 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 5 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 6 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Duty Cycle NVNT BLE 2Mbps 2440MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 7 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 0.791 30 Pass NVNT BLE 1Mbps 2440 Ant1 0.805 30 Pass NVNT BLE 1Mbps 2480 Ant1 0.692 30 Pass NVNT BLE 2Mbps 2402 Ant1 -7.105 30 Pass NVNT BLE 2Mbps 2440 Ant1 -7.083 30 Pass NVNT BLE 2Mbps 2480 Ant1 -7.283 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 8 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 9 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Power NVNT BLE 1Mbps 2480MHz Ant1 Power NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 10 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 Power NVNT BLE 2Mbps 2440MHz Ant1 Power NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0028-2 Page: 11 of 39 FCC ID:2BTKT-GL403 TB-RF-073-3.1 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1Mbps 2402 Ant1 0.66…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0028-2 Page: 1 of 36 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.toby-lab.com Radio Test Report FCC ID: 2BTKT-GL403 Report No. : TBR-C-202512-0028-2 Applicant : Shanghai iMobileThing Technology Ltd Equipment Under Test (EUT) EUT Name : GL403_LA tracker Model No. : GL403 Series Model No. : GL401,GL402,GL404,GL405,GL406,GL407,GL408,GL409,GL410,GL 411,GL412,GL413,GL414,GL415,GL416,GL417,GL418,GL419,GL420 ,GL421,GL422,GL423,GL424,GL425,GL426,GL427,GL428,GL429,GL 430,GL431,GL432,GL433,GL434,GL435,GL436,GL437,GL438,GL439 ,GL440,GL441,GL442,GL442_C,GL442_X,GL443,GL444,GL445,GL4 46,GL447,GL448,GL449,GL449_C,GL449_Q,GL449_X,GL450,GL451 ,GL452,GL453,GL454,GL455,GL456,GL457,GL458,GL459,GL460,GL 461,GL462,GL463,GL464,GL465,GL466,GL467,GL468,GL469,GL480 ,GL481,GL482,GL483,GL484,GL485,GL486,GL487,GL488,GL489,GL 490,GL491,GL492,GL493,GL494,GL494_Q,GL494_X,GL495,GL496, GL497,GL498,GL499,GP401,GP402,GP403,GP404,GP405,GP406,G P407,GP408,GP409,GP410,GP410_Q,GP411,GP412,GP413,GP413 _Q,GP414,GP415,GP416,GP416_Q,GP417,GP418,GP419,GP420,G P421,GP422,GP423,GP424,GP425,GP426,GP427,GP428,GP429,GP 430,GP430_B,GP431,GP431_Q,GP432,GP433,GP434,GP435,GP43 6,GP437,GP438,GP439,GP440,GP441,GP442,GP443,GP444,GP445 ,GP446,GP447,GP448,GP449,GP460,GP461,GP462,GP463,GP464, GP465,GP466,GP467,GP467_J,GP468,GP469,GP480,GP481,GP48 2,GP483,GP484,GP485,GP486,GP487,GP488,GP489,GP490,GP490 _Q,GP491,GP492,GP493,GP493_Q,GP494,GP495,GP496,GP496_Q ,GP497,GP498,GP498_Q,GP499 Brand Name : iMobileThing Sample ID : HC-C-202512-0028-01-01&HC-C-202512-0028-02-01 Receipt Date : 2025-12-09 Test Date : 2025-12-09 to 2026-01-21 Issue Date : 2026-01-21 Standards : FCC Part 15 Subpart C 15.247 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0028-2 Page: 2 of 36 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.toby-lab.com Test Method : ANSI C63.10: 2020 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gald zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0028-2 Page: 3 of 36 www.toby-lab.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 3 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 6 1.1 Client Information ................................................................................................................ 6 1.2 General Description of EUT (Equipment Under Test) ................................................... 6 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 8 1.4 Description of Support Units .............................................................................................. 9 1.5 Description of Test Mode ................................................................................................... 9 1.6 Description of Test Software Setting .............................................................................. 10 1.7 Measurement Uncertainty ................................................................................................ 10 1.8 Test Facility......................................................................................................................... 11 2. TEST SUMMARY..................................................................................................................... 12 3. TEST SOFTWARE .................................................................................................................. 12 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 13 5. CONDUCTED EMISSION ...................................................................................................... 14 5.1 Test Standard and Limit ................................................................................................... 14 5.2 Test Setup........................................................................................................................... 14 5.3 Test Procedure .................................................................................................................. 14 5.4 Deviation From Test Standard......................................................................................... 15 5.5 EUT Operating Mode ........................................................................................................ 15 5.6 Test Data............................................................................................................................. 15 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 16 6.1 Test Standard and Limit ................................................................................................... 16 6.2 Test Setup........................................................................................................................... 17 6.3 Test Procedure .................................................................................................................. 18 6.4 Deviation From Test Standard......................................................................................... 19 6.5 EUT Operating Mode ............…

Text truncated - open the document above for the full version.

FCC ID:2BTKT-GL403 TB-RF-073-3.1 Appendix V EUT Test Photographs Conducted Emission Test Setup Radiated Emission Test Setup-Below 1G FCC ID:2BTKT-GL403 TB-RF-073-3.1 Radiated Emission Test Setup-Below 1G GSM&LTE Photo of Setup for Radiated Emission (Above 1 GHz) GSM&LTE FCC ID:2BTKT-GL403 TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) -----END OF REPORT-----
