Bed Alarm System Large Bed Alarm System Chair Pad (optional) Call Button (Optional) INSTRUCTION MANUAL IMPORTANT: Read this manual before use I O T N U S L F O O S R D B E E N T G T I E S R E D H E A L T H + 1 Identifying the parts of the set The 2 main components of the Bed Alarm System are the Bed Sensor Pad (the bed pad for short) and the Monitor (some folks cal it the pager). There are two versions of the Bed Pad, one is 10 x 30 inches (standard) and the other is 20 x 30 inches large The Bed Pad 10X30 in The Bed Pad 20X30 in The Monitor The Monitor 2 Optional Lunderg Accessories Pocket to access the Transmitter The chair pad (Optional) 3 How to Turn ON the Bed Pad transmitter 1.Flip the bed pad to the instructions side and open the transmitter pocket (located in the neck of the pad) to access the DELAY / OFF / ON switch. 2.Switch the transmitter 'ON' for normal operation. If loved ones moves a lot or if experiencing false alarms, switch it to "DELAY". The transmitter is shipped in the OFF position. We do that to maximize the battery life of the transmitter as its batteries can't be replaced. ONLY turn it OFF if you are not going to use the bed pad for long periods of time. 3.To make sure the pad is activated, press and release the sensor pad. The Status / In use red LED light on the transmitter module should turn on. 4.Put the transmitter back in the transmitter pocket and snap it shut. Transmitter of the sensor pad DELAY / OFF / ON Built - in Transmitter Module LED Light Sensor Pad 10 x 30 in Bed Pad 4 Transmitter of the sensor pad DELAY / OFF / ON Built - in Transmitter Module LED Light Sensor Pad 20 x 30 in Bed Pad 5 Where to place the bed pad & how to secure the pad 1.The top side of the bed pad should be facing up, while the back side (side with quick guide instructions) should be facing down. Position the bed sensor pad across the bed beneath the hips of the patient. The neck of the bed sensor pad should exit out the side of the bed. The pad should be on top of the mattress (never below)! In a king or queen bed, the pad should be placed on one side of the mattress, never in the middle! 2.The pad MUST be placed below a fitted sheet, which greatly reduces sliding. *Do the same if you bought the Large pad Neck of the pad should hang off the side FItteD sheeT Bed pad Mattress 6 The Monitor(The Pager) Red/Green status LED light Stop Button Pair Button Volume Button Sensors FRONT 7 Screw to access battery compartment ON/OFF Switch Clip to hang in pocket SIDEBACK Main function instructions Battery Cover 8 Battery Cover & Batteries To comply with shipping and warehouse regulations we have to ship the monitor (pager) without the batteries inside of the pager. We have included a small screwdriver and shipped it with the battery cover unscrewed for your convenience! Simply insert the 2 x AA batteries (the most common ones) in the battery compartment following the + and - symbols. Cover the battery compartment with the battery cover and screw it with the screwdriver provided. The life of the battery will vary based on usage. You are ready to start using your pager! Simply insert the 2 x AA batteries (the most common ones) in the battery compartment following the + and - symbols. Cover the battery compartment with the battery cover and screw it with the screwdriver provided. The life of the battery will vary based on usage. You are ready to start using your pager! NOTE: unlike the batteries in the built-in transmitter module of the bed sensor pad and chair sensor pad, which can’t be replaced, the 2 x AA batteries of the monitor CAN be replaced. 9 1.Make sure the monitor/pager is switched ON! 2.Make sure the transmitter inside the bed pad is switched to ON or DELAY. It won’t work if the pad is OFF! 3.Press the "PAIR" button on the wireless monitor unit until the status LED light turns a steady green. Make sure to complete the pairing before the light turns off! 4.Press and release the centre zone of the bed sensor pad to pair it and add it into the monitor’s memory. The Status LED won’t be steady anymore and the Sensor 1’s red led light will blink once to indicate it has been paired. Your monitor can control up to 3 bed sensor pads or other compatible devices (such as the Chair Alarm or Call Button). If you had another bed pad or device already paired it would then be added as Sensor 2 or Sensor 3 (if you had already paired 2 extra devices). 5.Test that the bed sensor pad is working by pressing and releasing. The alarm should sound, and the sensor light will blink red to indicate the alarm is activated. If you only have one pad, Sensor 1 will be the one blinking. To stop the alarm press the “STOP” button. Note that the bed alarm remains paired after pressing STOP and it will be activated again as soon as it detects weight on it. How to pair the bed pad with the monitor 10 1.Make sure the monitor / pager is switched ON! 2.Make sure the transmitter inside the chair pad is switched to ON or DELAY. 3.Press the "PAIR" button on the wireless monitor unit until the status LED light on the monitor turns steady green. Make sure to complete the pairing before the light turns off! 4.Press and release the center zone of the chair sensor pad to pair it and add it into the monitor’s memory. The status of the LED light on the monitor won’t be steady anymore and the Sensor’s 1 red LED light will blink once to indicate it has been paired. Your monitor can control up to 3 devices! If you had another chair sensor pad or compatible device (such as the Bed Alarm or Call Button) already paired it would then be added as Sensor 2 or Sensor 3 (if you had already paired 2 extra devices). 5.Test that the sensor pad is working by pressing and releasing. The alarm should sound, and the sensor light will blink red to indicate the alarm is activated. If you only have one pad, Sensor 1 will be the one blinking. To stop the alarm press the "STOP" button. Note that the chair alarm remains paired after pressing STOP and it wi…
Text truncated - open the document above for the full version.
Henan Thunderbolt Intelligent Technology Co., Ltd. Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2025/12/15 U.S. Agent Designation Henan Thunderbolt Intelligent Technology Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BTNG-LT9013): Name and company of U.S. agent: GLOCERTS TECHNOLOGY INC Physical U.S. address of agent: 19784 SUNKISSED RIDGE DR RIVERSIDE, CA 92507 United States FRN of U.S. agent: 0036339737 Email address of U.S. agent: [email protected] GLOCERTS TECHNOLOGY INC acknowledges their obligation to accept service of process on behalf of Henan Thunderbolt Intelligent Technology Co., Ltd. Henan Thunderbolt Intelligent Technology Co., Ltd. with the FRN [0037746617] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Liming Yao Manager Henan Thunderbolt Intelligent Technology Co., Ltd. Signature Huiying Fan Director GLOCERTS TECHNOLOGY INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5
FCC ID: 2BTNG-LT9013 External Photos of the EUT FCC ID: 2BTNG-LT9013 FCC ID: 2BTNG-LT9013 FCC ID: 2BTNG-LT9013
Label and Location Size: L: 1.0cm*W: 0.5cm Label and Location FCC ID : 2BTNG-LT9013
FCC ID: 2BTNG-LT9013 Internal Photos of the EUT ANT FCC ID: 2BTNG-LT9013 FCC ID: 2BTNG-LT9013
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. ..................... : FCC ID. ........................................... : CTA2511260200102 2BTNG-LT9013 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Ace Chai Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Dec. 05, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : Henan Thunderbolt Intelligent Technology Co., Ltd. Address ............................................ : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : LARGE BED ALARM SYSTEM Trade Mark ........................................ N/A Manufacturer ..................................... : Henan Thunderbolt Intelligent Technology Co., Ltd. Model/Type reference ....................... : LT9013 Listed Models ................................... : N/A Ratings .............................................. : DC 3.0V From battery Result ................................................ : PASS Report No.: CTA2511260200102 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : LARGE BED ALARM SYSTEM Model /Type : LT9013 Listed Models : N/A Applicant : Henan Thunderbolt Intelligent Technology Co., Ltd. Address : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Manufacturer : Henan Thunderbolt Intelligent Technology Co., Ltd. Address : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA2511260200102 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................... 4 2 S U M M A R Y .............................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Special Accessories 5 2.4 Modifications 5 3 T E S T E N V I R O N M E N T ................................................ 6 3.1 Address of the test laboratory 6 3.2 Test Facility 6 3.3 Statement of the measurement uncertainty 6 4 T E S T L I M I T ............................................................ 7 4.1 Requirement 7 4.2 Conducted Power Results 7 4.3 Manufacturing tolerance 8 4.4 Evaluation Result 8 4.5 Simultaneous Transmission for SAR Exclusion 8 5 C O N C L U S I O N .......................................................... 8 Report No.: CTA2511260200102 Page 4 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device, RF Exposure, Equipment Authorization Procedures. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Report No.: CTA2511260200102 Page 5 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Nov. 26, 2025 Testing commenced on : Nov. 26, 2025 Testing concluded on : Dec. 05, 2025 2.2 Product Description Product Description: LARGE BED ALARM SYSTEM Model/Type reference: LT9013 Power supply: DC 3.0V From battery Hardware version: V1.0 Software version: V1.0 Testing sample ID: CTA25112602001-1# (Enginee…
Text truncated - open the document above for the full version.
1. Antenna Description: Antenna type External antenna Model LT9013 Frequency range 433.96MHz Manufacturer Henan Thunderbolt Intelligent Technology Co., Ltd. Address Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China ANT Peak Gain 2.0 dBi 2. Antenna Photo: We statement that All measurements were performed radiated and therefore additional antenna gain documentation is not required. Length :166.13mm Width:1.53mm
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.231 Report Reference No. .................... : FCC ID. ........................................... : CTA25112602001 2BTNG-LT9013 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Dec. 06, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ........................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Henan Thunderbolt Intelligent Technology Co., Ltd. Address ............................................ : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Test specification ........................... : Standard ........................................... : FCC Part 15.231 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : LARGE BED ALARM SYSTEM Trade Mark ....................................... : N/A Manufacturer .................................... : Henan Thunderbolt Intelligent Technology Co., Ltd. Model/Type reference ...................... : LT9013 Listed Models .................................. : N/A Modulation ....................................... : ASK Frequency ......................................... 433.96MHz Ratings ............................................. : DC 3.0V From battery Result ............................................... : PASS Report No.: CTA25112602001 Page 2 of 27 T E S T R E P O R T Equipment under Test : LARGE BED ALARM SYSTEM Model /Type : LT9013 Listed Models : N/A Applicant : Henan Thunderbolt Intelligent Technology Co., Ltd. Address : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Manufacturer : Henan Thunderbolt Intelligent Technology Co., Ltd. Address : Room 1904, Unit 1, Building 5, Courtyard 20, Taihong Jianye International City, West Siji Road, Shuangtie South Road, Erqi District, Zhengzhou City, Henan, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25112602001 Page 3 of 27 Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT configuration 5 2.6 Block Diagram of Test Setup 6 2.7 Special Accessories 6 2.8 Related Submittal(s) / Grant (s) 6 2.9 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 8 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 20dB Bandwidth 18 4.4 Deactivation Time 19 4.5 Antenna Requirement 20 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 21 6 P H O T O S O F T H E E U T ............................................................. 22 Report No.: CTA25112602001 Page 4 of 27 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.231:Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. ANSI C63.10-2020+Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 : American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA25112602001 Page 5 of 27 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Nov. 26, 2025 Testing commenced on : Nov. 26, 2025 Testing concluded on : Dec. 05, 2025 2.2 Product Description Product Name: LARGE BED ALARM SYSTEM Model/Type reference: LT9013 Power supply: DC 3.0V From battery Testing sample ID: CTA251126020-1# (Engineer sample), CTA251126020-2#(Normal sample) Modulation: ASK Operation frequency: 433.96MHz Channel number: 1 Antenna type: External antenna Antenna gain: 2.0 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.0V From battery 2.4 Short description of the Equipment under Test (EUT) This is a LARGE BED ALARM SYSTEM. For more details, refer to the user’s manual of the EUT. 2.5 EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab Report No.: CTA25112602001 Page 6 of 27 2.6 Block Diagram of Test Setup 2.7 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or la…
Text truncated - open the document above for the full version.
FCC ID: 2BTNG-LT9013 Test Setup Photos of the EUT
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 433.96 MHz - 433.96 MHz | - |
