2BTP2-TTBS01E-tikett Base Station

CEDAR AP Quick Start Guide 1、 status light LED1: Not used temporarily LED2: ESL transceiver status light white flash Monitor price tag broadcast green flash Send power management flashing blue idle purple flash Read and write price tags LED3: Network status light red The network cable is not plugged in and the base station WIFI is not connected to the hotspot. blue The network cable is plugged in or the base station WIFI is connected, but cannot connect to the Internet (external network) green Can connect to the Internet normally (external network) LED4, LED5: motherboard power indicator light 2、 Base station network settings 1. Wired Internet access 1.1 DHCP dynamic IP Internet access 1.1.1 Power on, connect the Internet cable, wait for LED2 white light to flash, other lights do not flash. 1.1.2 Search WIFI on mobile phone or computer: woap-xxxx (default) 1.1.3 Connect your mobile phone or computer to the base station WIFI. The default password for the base station WIFI is: 12345678. 1.1.4 Browser opens: 192.168.66.1 (default) 1.1.5 Log in to the base station background, username: root, password: 123456 (default) 1.1.6 Select menu: network ➤ Interface ➤ WAN 1.1.7 Protocol selection: DHCP client (if you are already a DHCP client, no operation is required in the following steps) 1.1.8 Click the button: Switch protocol 1.1.9 Click the button: Save & Apply View network lights If the upper-level network segment is also 192.168.66.*, please connect to the base station hotspot to set the gateway IP of other network segments. 1.2 Static IP Internet access 1.2.1 Power on, plug in the Internet cable, wait until the white LED2 light flashes, other lights do not flash. 1.2.2 Search WIFI on mobile phone or computer: woap-xxxx (default) 1.2.3 Connect your mobile phone or computer to the base station WIFI. The default password for the base station WIFI is: 12345678. 1.2.4 Browser opens: 192.168.66.1 (default) 1.2.5 Log in to the base station background, username: root, password: 123456 (default) 1.2.6 Select menu: network ➤ Interface ➤ WAN 1.2.7 Protocol selection: static address 1.2.8 Click the button: Switch protocol 1.2.9 Enter the IPv4 address: The network segment is allowed by the superior and is not in use. 1.2.10 Enter IPv4 subnet mask ：255.255.255.0， You don’t need to fill in the others. 1.2.11 Click the button: Save & Apply View network lights 2. WIFI Internet access 2.1 Turn on the power, wait for LED2 white light to flash, other lights do not flash 2.2 Search WIFI on mobile phone or computer: woap-**** (default) （ *Note: If the hotspot is intermittent, please reset the network settings and try again ） 2.3 Connect your mobile phone or computer to the base station WIFI. The default password for the base station WIFI is: 12345678. 2.4 Log in to the base station background, username: root, password: 123456 (default) 2.5 Select menu: network ➤ Wireless 2.6 Select mode: Select bridge/trunk 2.7 Click the button: Scan and wait for the scan to complete 2.8 Opt in: Choose the WIFI you want to connect to If the WIFI you want is not found, repeat step 2.7 2.9 Enter STA password: Enter the password for the base station to connect to WIFI 2.10 Click the button: Save & Apply View network lights 3、 Base station configuration 1. Turn on the power, wait for LED2 white light to flash, other lights do not flash 2. Search WIFI on mobile phone or computer: woap-xxxx (default) 3. Connect your mobile phone or computer to the base station WIFI. The default password for the base station WIFI is: 12345678. 4. Log in to the base station background, username: root, password: 123456 (default) 5. Select menu: Electronic price tag ➤ Base station configuration Start configuring the base station (host address, store number, user, password, please consult after-sales) 4、 language settings 1. Turn on the power, wait for LED2 white light to flash, other lights do not flash 2. Search WIFI on mobile phone or computer: woap-xxxx (default) 3. Connect your mobile phone or computer to the base station WIFI. The default password for the base station WIFI is: 12345678. 4. Log in to the base station background, username: root, password: 123456 (default) 5. Select menu: System ➤ System ➤ Language and interface ( Language and Style) ➤ Language ( Language) 6. Choose a language 7. click button :Save & Apply 5、 troubleshooting 1. Question: Are the three yellow-green lights flashing at the same time? Answer: Generally, the base station has just been powered on, the system is restarted or reset, and the three lights will flash together for about 30 seconds before returning to normal. 2. Question: Does the WIFI of the base station come and go? Answer: How to set up bridge mode wirelessly? This is usually caused by the base station not being able to connect to the hotspot. Please unplug the network cable and reset the network settings. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this devic…

Text truncated - open the document above for the full version.

Local Representative Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BTP2-TTBS01 TTBS01 We hereby acknowledge as follows: i. both signees confirm that the point of contact accepts responsibility to act as a US- American Representative on behalf of the applicant ii. the point of contact provides the physical U.S. address and email as listed below iii. both parties maintain the requirements of this agreement for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. iv. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. US-American Point of Contact Applicant/Approval Holder Signature Date: 2025-12-22 Signature Date: 2025-12-22 Company Name: HOORAY INDUSTRY LLC INNOVATIVE TEKNOLOJI A.S FRN: 0033926106 0037759024 Contact Name: Cindy Wu Alaattin Tamer Cengiz Address: 1408 Pinon Place Fullerton, CA 92835 United States Muallimkoy Mah. Deniz Cad.No:143-5,33 Gebze Kocaeli Turkey 41400 Phone: (626) 910-5808 +905414986341 Email: [email protected] [email protected]

FCC ID: 2BTP2-TTBS01 External Photos of the EUT FCC ID: 2BTP2-TTBS01 FCC ID: 2BTP2-TTBS01

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BTP2-TTBS01

FCC ID: 2BTP2-TTBS01 Internal Photos of the EUT WIFI Antenna 2.4G Antenna PCB Antenna no use FCC ID: 2BTP2-TTBS01 FCC ID: 2BTP2-TTBS01 FCC ID: 2BTP2-TTBS01

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID............................................. : CTA25112000803 2BTP2-TTBS01 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Dec. 04, 2025 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : INNOVATIVE TEKNOLOJI A.S Address............................................ : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : E-tikett Base Station Trade Mark ....................................... : N/A Manufacturer .................................... : INNOVATIVE TEKNOLOJI A.S Model/Type reference ...................... : TTBS01 Listed Models ................................... : N/A Ratings ............................................. : Input: 12V1A or POE 48V0.2A Result ............................................... : PASS Report No.: CTA25112000803 Page 2 of 9 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : E-tikett Base Station Model /Type : TTBS01 Listed Models : N/A Applicant : INNOVATIVE TEKNOLOJI A.S Address : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Manufacturer : INNOVATIVE TEKNOLOJI A.S Address : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25112000803 Page 3 of 9 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 MPE Calculation Method ......................................................................................... 7 4.3 Conducted Power Results ....................................................................................... 7 4.4 Manufacturing tolerance .......................................................................................... 8 4.5 Standalone MPE Result ........................................................................................... 8 4.6 Simultaneous Transmission for MPE Result ........................................................... 9 5 Conclusion ........................................................................................................................... 9 Report No.: CTA25112000803 Page 4 of 9 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standard…

Text truncated - open the document above for the full version.

1. Antenna Description: Antenna type Internal antenna Model TTBS01-WiFi Frequency range 2400-2500MHz Manufacturer INNOVATIVE TEKNOLOJI A.S Address Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY ANT Peak Gain 5 dBi 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ................... : FCC ID. .......................................... : CTA25112000801 2BTP2-TTBS01 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Dec. 04, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : INNOVATIVE TEKNOLOJI A.S Address ............................................ : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : E-tikett Base Station Trade Mark ....................................... : N/A Manufacturer .................................... : INNOVATIVE TEKNOLOJI A.S Model/Type reference ...................... : TTBS01 Listed Models ................................... : N/A Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : Input: 12V1A or POE 48V0.2A Result ............................................... : PASS Report No.: CTA25112000801 Page 2 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : E-tikett Base Station Model /Type : TTBS01 Listed Models : N/A Applicant : INNOVATIVE TEKNOLOJI A.S Address : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Manufacturer : INNOVATIVE TEKNOLOJI A.S Address : Muallimkoy Mah. Deniz Cad. No:143-5, 33 Gebze Kocaeli, 41400 TURKEY Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25112000801 Page 3 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 6 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility........................................................................................................................................ 7 3.3 Environmental conditions .................................................................................................................. 7 3.4 Test Description ...................................................................................................…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for 2.4GWIFI FCC ID : 2BTP2-TTBS01 Company : INNOVATIVE TEKNOLOJI A.S EUT : E-tikett Base Station Model Number : TTBS01 Report No. : CTA25112000801 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.240 2406.920 2417.160 0.5 PASS 2437 10.240 2431.920 2442.160 0.5 PASS 2462 10.240 2456.920 2467.160 0.5 PASS 11G Ant1 2412 15.720 2404.040 2419.760 0.5 PASS 2437 15.960 2428.960 2444.920 0.5 PASS 2462 15.920 2453.880 2469.800 0.5 PASS 11N20SISO Ant1 2412 17.320 2403.440 2420.760 0.5 PASS 2437 17.200 2428.400 2445.600 0.5 PASS 2462 16.880 2453.360 2470.240 0.5 PASS 11N40SISO Ant1 2422 35.840 2404.080 2439.920 0.5 PASS 2437 35.680 2419.320 2455.000 0.5 PASS 2452 35.680 2434.160 2469.840 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 7 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 8 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.506 2405.2882 2418.7942 --- --- 2437 13.351 2430.3569 2443.7079 --- --- 2462 13.374 2455.3300 2468.7040 --- --- 11G Ant1 2412 16.751 2403.6771 2420.4281 --- --- 2437 16.744 2428.7110 2445.4550 --- --- 2462 16.687 2453.6660 2470.3530 --- --- 11N20SISO Ant1 2412 17.799 2403.1456 2420.9446 --- --- 2437 17.813 2428.1158 2445.9288 --- --- 2462 17.816 2453.1183 2470.9343 --- --- 11N40SISO Ant1 2422 35.975 2404.0889 2440.0639 --- --- 2437 35.974 2419.1170 2455.0910 --- --- 2452 36.028 2434.0845 2470.1125 --- --- 9 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 10 11G_Ant1_2412 11G_Ant1_2437 11 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 12 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 13 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 14 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 13.87 ≤30.00 PASS 2437 14.04 ≤30.00 PASS 2462 14.19 ≤30.00 PASS 11G Ant1 2412 13.12 ≤30.00 PASS 2437 13.36 ≤30.00 PASS 2462 13.63 ≤30.00 PASS 11N20SISO Ant1 2412 12.98 ≤30.00 PASS 2437 13.25 ≤30.00 PASS 2462 13.39 ≤30.00 PASS 11N40SISO Ant1 2422 13.31 ≤30.00 PASS 2437 13.64 ≤30.00 PASS 2452 13.68 ≤30.00 PASS 15 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -11.95 ≤8.00 PASS 2437 -12.00 ≤8.00 PASS 2462 -11.71 ≤8.00 PASS 11G Ant1 2412 -17.51 ≤8.00 PASS 2437 -17.48 ≤8.00 PASS 2462 -16.94 ≤8.00 PASS 11N20SISO Ant1 2412 -17.62 ≤8.00 PASS 2437 -17.04 ≤8.00 PASS 2462 -16.41 ≤8.00 PASS 11N40SISO Ant1 2422 -20.15 ≤8.00 PASS 2437 -20.08 ≤8.00 PASS 2452 -19.77 ≤8.00 PASS 16 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 17 11G_Ant1_2412 11G_Ant1_2437 18 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 19 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 20 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 21 Appendix E: Band edge measurements Test Result TestMode Antenn a ChNam e Frequency[MH z] RefLevel[dB m] Result[dB m] Limit[dBm ] Verdic t 11B Ant1 Low 2412 1.75 -45.4 ≤-18.25 PASS High 2462 1.80 -55.89 ≤-18.2 PASS 11G Ant1 Low 2412 -2.58 -34.9 ≤-22.58 PASS High 2462 -2.13 -57.32 ≤-22.13 PASS 11N20SIS O Ant1 Low 2412 -2.54 -33.53 ≤-22.54 PASS High 2462 -2.07 -57.86 ≤-22.07 PASS 11N40SIS O Ant1 Low 2422 -5.69 -33.88 ≤-25.69 PASS High 2452 -5.48 -57.09 ≤-25.48 PASS 22 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 23 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 24 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 25 26 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 1.53 1.53 --- PASS 30~1000 1.53 -67.4 ≤-18.47 PASS 1000~26500 1.53 -55.16 ≤-18.47 PASS 2437 Reference 1.17 1.17 --- PASS 30~1000 1.17 -43.72 ≤-18.83 PASS 1000~26500 1.17 -55.23 ≤-18.83 PASS 2462 Reference 0.33 0.33 --- PASS 30~1000 0.33 -45.89 ≤-19.67 PASS 1000~26500 0.33 -54.59 ≤-19.67 PASS 11G Ant1 2412 Reference -2.89 -2.89 --- PASS 30~1000 -2.89 -67.5 ≤-22.89 PASS 1000~26500 -2.89 -54.7 ≤-22.89 PASS 2437 Reference -2.30 -2.30 --- PASS 30~1000 -2.30 -67.35 ≤-22.3 PASS 1000~26500 -2.30 -55.16 ≤-22.3 PASS 2462 Reference -2.50 -2.50 --- PASS 30~1000 -2.50 -67.77 ≤-22.5 PASS 1000~26500 -2.50 -55.02 ≤-22.5 PASS 11N20SISO Ant1 2412 Reference -3.25 -3.25 --- PASS 30~1000 -3.25 -67.81 ≤-23.25 PASS 1000~26500 -3.25 -54.93 ≤-23.25 PASS 2437 Reference -3.08 -3.08 --- PASS 30~1000 -3.08 -67.42 ≤-23.08 PASS 1000~26500 -3.08 -55.63 ≤-23.08 PASS 2462 Reference -2.68 -2.68 --- PASS 30~1000 -2.68 -67.86 ≤-22.68 PASS 1000~26500 -2.68 -55.03 ≤-22.68 PASS 11N40SISO Ant1 2422 Reference -5.84 -5.84 --- PASS 30~1000 -5.84 -67.51 ≤-25.84 PASS 1000~26500 -5.84 -55.39 ≤-25.84 PASS 2437 Reference -5.39 -5.39 --- PASS 30~1000 -5.39 -68.38 ≤-25.39 PASS 1000~26500 -5.39 -55.28 ≤-25.39 PASS 2452 Reference -5.57 -5.57 --- PASS 30~1000 -5.57 -67.37 ≤-25.57 PASS 1000~26500 -5.57 -54.82 ≤-25.57 PASS 27 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 28 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 29 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 30 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 31 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 32 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500

33 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 34 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 35 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 36 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 37 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 38 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 39 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 40 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 41 11N40SISO_Ant1_2452_1000~26500 42 Appendix G: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B Ant1 2412 8.36 8.40 99.52 2437 8.35 8.40 99.40 2462 8.34 8.39 99.40 11G Ant1 2412 0.14 0.19 73.68 2437 0.15 0.20 75.00 2462 0.15 0.20 75.00 11N20SISO Ant1 2412 0.18 0.23 78.26 2437 0.17 0.22 77.27 2462 0.17 0.22 77.27 11N40SISO Ant1 2422 0.18 0.23 78.26 2437 0.18 0.23 78.26 2452 0.18 0.23 78.26 43 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 44 11G_Ant1_2412 11G_Ant1_2437 45 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 46 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 47 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452

FCC ID: 2BTP2-TTBS01 Test Setup Photos of the EUT FCC ID: 2BTP2-TTBS01
