2BTQ7-251226MMOO BOX

3 MOOBOX M1 INSTRUCTION MANUAL 4 Package Instructions *1x MOOBOX SPEAKER *1x Charger and adapter *1x User Manual 5 6 7 Power Button Operation: Press and hold approximately 5 seconds to turn the device on or off; a short press will turn off the screen. Operating Instructions for Apple Devices 1. Power on the device For the first connection, please ensure the device is near your router and phone. 2. Connect the Phone to the Internet 2.1 Connect your phone to the current Wi-Fi network. 2.2 Turn on the Bluetooth switch on your phone, but do not connect it (to any device). 3.Download the App Apple users can download (the app) by searching for "solohuman" in the App Store or scanning the QR code. 8 4.Usage on the App Tap the searched device, enter the password of your phone's current Wi-Fi network in the pop-up window, tap "Connect", and wait briefly for the connection to succeed—then you can start using the device. 5. Play Music Turn on your phone's Bluetooth and connect to the device “MOOBOX M1” After a successful connection, open any player to play music. For Apple devices, using the "APPLE MUSIC" app to play music provides a better experience of lyric casting to the screen. 9 Product Specifications: Product Model: CMBM1695 Product Dimensions: 116 × 121 × 236 mm Net Weight: 1.38 kg Number of Speakers: 2 Speaker Channels: 2.0 Maximum Power: 15 W Power Input: 5V 3A Battery Capacity: 8000 mAh Connection Method: Bluetooth Connection Package Contents: Main Unit × 1, User Manual × 1, Certificate of Conformity × 1 Disclaimer: Our company shall not be liable for any direct or indirect losses arising from the use of this product. 10 Warning & Precautions The accompanying app for this product supports mobile operating systems of Android 10.0 and above / iOS 16.0 and above. Warning Operating this device in a residential environment may cause radio interference. Danger Do not expose to flames or place near heat sources. Notice Avoid prolonged use in humid environments. Do not disassemble or attempt to repair this product unless you are a qualified professional. Please place the speaker appropriately. Children should use it under parental supervision. 11 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 12 ISED Warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. *RF warning for Mobile device: This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. A distance between the surrounding area and the top surface of the device is greater than 20cm. Cet appareil contient des émetteurs/récepteurs exemptés de licence qui sont conformes aux RSS exemptés de licence d’innovation, sciences et développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: 1. Cet appareil ne peut pas causer d’interférences. 2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un fonctionnement indésirable de l’appareil. la distance entre l'utilisateur et le dispositif ne doit pas être inférieure à 20 cm 13 EU Declaration Conformity Hereby, Suzhou ShaoHao Tech Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. In accordance with Article10(2) and Artical10(10), This product is allowed to use in all EU member states. A complete declaration of conformity can be obtained at: https://pitchbook.com/profiles/company/1239833-26 Warnings 1 2 3 4 5 6 7 Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Use careful with the earphone maybe possible excessive sound pressure from Audiocan cause hearing loss. Adapter shall be installed near the equipment and shall be easily accessible. To charge the device, please use the charger with the device or CE approved charger with output p…

Text truncated - open the document above for the full version.

Page 1 of 16 Report No.: AiTSZ-251231012FW6 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. RF Exposure evaluation Product Name : MOO BOX Brand Name : N/A Model : 251226M Series Model : N/A FCC ID : 2BTQ7-251226M Applicant : Suzhou ShaoHao Tech Co., Ltd. Address : Jinfeng Business Creative Center, Wuzhong District, Suzhou City, Jiangsu Province, China Manufacturer : Suzhou ShaoHao Tech Co., Ltd. Address : Jinfeng Business Creative Center, Wuzhong District, Suzhou City, Jiangsu Province, China Standard(s) : 47CFR §1.1310, 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt : Dec. 31, 2025 Date of Test : Dec. 31, 2026~ Jan. 08, 2026 Issued Date : Jan. 08, 2026 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Aalen.Ye Allen Wang Page 2 of 16 Report No.: AiTSZ-251231012FW6 Report Revise Record Report Version Issued Date Notes M0 Jan. 08, 2026 Initial Release Page 3 of 16 Report No.: AiTSZ-251231012FW6 Contents 1 GENERAL INFORMATION ....................................................................................................................................... 4 1.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 4 1.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 6 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 6 2 METHOD OF MEASUREMENT ................................................................................................................................ 7 2.1 APPLICABLE STANDARD .................................................................................................................................................. 7 2.2 LIMIT ......................................................................................................................................................................... 7 2.3 MPE CALCULATION METHOD ......................................................................................................................................... 8 2.4 ANTENNA INFORMATION ............................................................................................................................................... 8 2.5 MANUFACTURING TOLERANCE ........................................................................................................................................ 8 2.6 MPE RESULT ............................................................................................................................................................. 14 2.7 CONCLUSION ............................................................................................................................................................. 16 Page 4 of 16 Report No.: AiTSZ-251231012FW6 1 GENERAL INFORMATION 1.1 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 25°C Relative Humidity: 55 % Air Pressure: 101 kPa 1.2 General Description of EUT Product Name: MOO BOX Model/Type reference: 251226M Serial Model: N/A Power Supply: Input: DC 5V3A Adapter Information: N/A Hardware Version: TURNER_MB_V1.0 Software Version: MooBOX_A133122625_V03 Sample(s) Status: AiTSZ-251231012-1(Normal sample) AiTSZ-251231012-2(Engineer sample) Bluetooth: Supported type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: FPC antenna Antenna gain: 3.64dBi Bluetooth LE: Supported type: Bluetooth LE 1M/2M Modulation: GFSK Operation frequency: 2402MHz~2480MHz Channel number: 40 Channel separation: 2MHz Antenna type: FPC antenna Antenna gain: 3.64dBi 2.4G WIFI: Supported type: 802.11b/802.11g /802.11n(HT20)/802.11n(HT40)/ 802.11ax(HEW20)/802.11ax(HEW40) Modulation: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Page 5 of 16 Report No.: AiTSZ-251231012FW6 802.11ax: OFDMA (1024QAM, 256QAM, 64QAM, 16QAM, QPSK, BPSK) Operation frequency: 802.11b/802.11g/802.11n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz 802.11ax(HEW20): 2412MHz~2462MHz 802.11ax(HEW40): 2422MHz~2452MHz Channel number: 802.11b/802.11g/802.11n(HT20): 11 802.11n(HT40): 7 802.11ax(HEW20): 11 802.11ax(HEW40): 7 5G WIFI: Supported type: 20MHz system 40MHz system 80MHz system 160MHz system 802.11a 802.11n 802.11ac 802.11ax 802.11n 802.11ac 802.11ax N/A N/A Operation frequency: 5180-5240MHz 5260-5320MHz 5500-5700MHz 5745-5825MHz 5190-5230MHz 5270-5310MHz 5510-5670MHz 5755-5795MHz N/A N/A …

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2BTQ7-251226M Page 2 of 2 FCC ID: 2BTQ7-251226M

Page 1 of 29 Report No.: AiTSZ-251231012FW2 Appendix Test Data for BLE Page 2 of 29 Report No.: AiTSZ-251231012FW2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 2.123 2.500 84.92 0.71 0.03 2440 2.124 2.501 84.93 0.71 0.03 2480 2.124 2.501 84.93 0.71 0.03 2M SISO 2402 1.065 1.874 56.83 2.45 0.03 2440 1.065 1.875 56.80 2.46 0.03 2480 1.065 1.875 56.80 2.46 0.03 Page 3 of 29 Report No.: AiTSZ-251231012FW2 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 4 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 5 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 6 of 29 Report No.: AiTSZ-251231012FW2 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 1.027 / Pass 2440 1 1.028 / Pass 2480 1 1.028 / Pass 2M SISO 2402 1 2.065 / Pass 2440 1 2.071 / Pass 2480 1 2.072 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.667 >=0.5 Pass 2440 1 0.667 >=0.5 Pass 2480 1 0.666 >=0.5 Pass 2M SISO 2402 1 1.204 >=0.5 Pass 2440 1 1.251 >=0.5 Pass 2480 1 1.251 >=0.5 Pass Page 7 of 29 Report No.: AiTSZ-251231012FW2 2.2 Test Graph 2.2.1 OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 8 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 9 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 10 of 29 Report No.: AiTSZ-251231012FW2 2.2.2 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 11 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 12 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 13 of 29 Report No.: AiTSZ-251231012FW2 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 0.21 <=30 Pass 2440 1.22 <=30 Pass 2480 1.81 <=30 Pass 2M SISO 2402 0.26 <=30 Pass 2440 1.27 <=30 Pass 2480 1.86 <=30 Pass Note1: Antenna Gain: Ant1: 3.64dBi; Page 14 of 29 Report No.: AiTSZ-251231012FW2 3.2 Test Graph 3.2.1 Power 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 15 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 16 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 17 of 29 Report No.: AiTSZ-251231012FW2 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit 1M SISO 2402 0.05 <=8 Pass 2440 1.07 <=8 Pass 2480 1.62 <=8 Pass 2M SISO 2402 -1.07 <=8 Pass 2440 0.01 <=8 Pass 2480 0.56 <=8 Pass Note1: Antenna Gain: Ant1: 3.64dBi; Page 18 of 29 Report No.: AiTSZ-251231012FW2 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 19 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 20 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 21 of 29 Report No.: AiTSZ-251231012FW2 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 0.03 2440 1 1.05 2480 1 1.62 2M SISO 2402 1 -1.04 2440 1 -0.05 2480 1 0.55 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 0.03 -19.97 Pass 2440 1 1.05 -18.95 Pass 2480 1 1.62 -18.38 Pass 2M SISO 2402 1 -1.04 -21.04 Pass 2440 1 -0.05 -20.05 Pass 2480 1 0.55 -19.45 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 22 of 29 Report No.: AiTSZ-251231012FW2 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 23 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 24 of 29 Report No.: AiTSZ-251231012FW2 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV Page 25 of 29 Report No.: AiTSZ-251231012FW2 5.2.2 CSE 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV Page 26 of 29 Report No.: AiTSZ-251231012FW2 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV Page 27 of 29 Report No.: AiTSZ-251231012FW2 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV Page 28 of 29 Report No.: AiTSZ-251231012FW2 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV Page 29 of 29 Report No.: AiTSZ-251231012FW2 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV ********************** End of Report **********************

Page 38 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 39 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 40 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 41 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 42 of 66 Report No.: AiTSZ-251231012FW3 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) RU RU Pos ANT Level of Reference (dBm) 802.11b SISO 2412 / / 1 4.53 2437 / / 1 3.32 2462 / / 1 2.23 802.11g SISO 2412 / / 1 -7.32 2437 / / 1 -5.62 2462 / / 1 -6.17 802.11n (HT20) SISO 2412 / / 1 -6.75 2437 / / 1 -5.40 2462 / / 1 -3.95 802.11n (HT40) SISO 2422 / / 1 -10.30 2437 / / 1 -9.17 2452 / / 1 -9.41 802.11ax (HEW20) SISO 2412 SU / 1 -7.20 2437 SU / 1 -5.99 2462 SU / 1 -6.16 802.11ax (HEW40) SISO 2422 SU / 1 -11.36 2437 SU / 1 -10.18 2452 SU / 1 -10.15 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE Mode TX Type Frequency (MHz) RU RU Pos ANT Level of Reference (dBm) Limit (dBm) Verdict 802.11b SISO 2412 / / 1 4.53 -15.47 Pass 2437 / / 1 3.32 -16.68 Pass 2462 / / 1 2.23 -17.77 Pass 802.11g SISO 2412 / / 1 -7.32 -27.32 Pass 2437 / / 1 -5.62 -25.62 Pass 2462 / / 1 -6.17 -26.17 Pass 802.11n (HT20) SISO 2412 / / 1 -6.75 -26.75 Pass 2437 / / 1 -5.40 -25.40 Pass 2462 / / 1 -3.95 -23.95 Pass 802.11n (HT40) SISO 2422 / / 1 -10.30 -30.30 Pass 2437 / / 1 -9.17 -29.17 Pass 2452 / / 1 -9.41 -29.41 Pass 802.11ax (HEW20) SISO 2412 SU / 1 -7.20 -27.20 Pass 2437 SU / 1 -5.99 -25.99 Pass 2462 SU / 1 -6.16 -26.16 Pass 802.11ax (HEW40) SISO 2422 SU / 1 -11.36 -31.36 Pass 2437 SU / 1 -10.18 -30.18 Pass 2452 SU / 1 -10.15 -30.15 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 43 of 66 Report No.: AiTSZ-251231012FW3 5.2 Test Graph 5.2.1 Ref 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 44 of 66 Report No.: AiTSZ-251231012FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 45 of 66 Report No.: AiTSZ-251231012FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 46 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 47 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 48 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 49 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 50 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 51 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 52 of 66 Report No.: AiTSZ-251231012FW3 5.2.2 CSE 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV Page 53 of 66 Report No.: AiTSZ-251231012FW3 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV Page 54 of 66 Report No.: AiTSZ-251231012FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 55 of 66 Report No.: AiTSZ-251231012FW3 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV Page 56 of 66 Report No.: AiTSZ-251231012FW3 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 57 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV Page 58 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV Page 59 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 60 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 61 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 62 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV Page 63 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV Page 64 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 65 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 66 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV ********************** End of Report **********************

Page 1 of 66 Report No.: AiTSZ-251231012FW3 Appendix Test Data for 2.4G WIFI Page 2 of 66 Report No.: AiTSZ-251231012FW3 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) RU RU Pos T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11b SISO 2412 / / 8.417 8.647 97.34 0.12 1.45 2437 / / 8.417 8.590 97.99 0.09 1.27 2462 / / 8.416 8.646 97.34 0.12 1.45 802.11g SISO 2412 / / 1.397 1.634 85.50 0.68 7.14 2437 / / 1.399 1.634 85.62 0.67 6.63 2462 / / 1.397 1.626 85.92 0.66 6.66 802.11n (HT20) SISO 2412 / / 1.304 1.548 84.24 0.74 7.34 2437 / / 1.304 1.515 86.07 0.65 6.02 2462 / / 1.305 1.533 85.13 0.70 7.03 802.11n (HT40) SISO 2422 / / 0.648 0.800 81.00 0.92 9.14 2437 / / 0.648 0.885 73.22 1.35 12.17 2452 / / 0.648 0.791 81.92 0.87 8.24 802.11ax (HEW20) SISO 2412 SU / 1.022 1.241 82.35 0.84 6.44 2437 SU / 1.022 1.259 81.18 0.91 4.89 2462 SU / 1.021 1.232 82.87 0.82 7.26 802.11ax (HEW40) SISO 2422 SU / 0.541 0.693 78.07 1.08 10.33 2437 SU / 0.541 0.760 71.18 1.48 10.65 2452 SU / 0.541 0.693 78.07 1.08 10.33 Page 3 of 66 Report No.: AiTSZ-251231012FW3 1.2 Test Graph 1.2.1 Ant1 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 4 of 66 Report No.: AiTSZ-251231012FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 5 of 66 Report No.: AiTSZ-251231012FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 6 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 7 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 8 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 9 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 10 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 11 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 12 of 66 Report No.: AiTSZ-251231012FW3 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) RU RU Pos ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 / / 1 13.496 / Pass 2437 / / 1 13.248 / Pass 2462 / / 1 13.167 / Pass 802.11g SISO 2412 / / 1 18.513 / Pass 2437 / / 1 18.500 / Pass 2462 / / 1 18.530 / Pass 802.11n (HT20) SISO 2412 / / 1 19.545 / Pass 2437 / / 1 19.394 / Pass 2462 / / 1 19.382 / Pass 802.11n (HT40) SISO 2422 / / 1 37.443 / Pass 2437 / / 1 37.350 / Pass 2452 / / 1 37.383 / Pass 802.11ax (HEW20) SISO 2412 SU / 1 19.750 / Pass 2437 SU / 1 19.739 / Pass 2462 SU / 1 19.791 / Pass 802.11ax (HEW40) SISO 2422 SU / 1 38.410 / Pass 2437 SU / 1 38.433 / Pass 2452 SU / 1 38.510 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) RU RU Pos ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 / / 1 9.268 >=0.5 Pass 2437 / / 1 9.256 >=0.5 Pass 2462 / / 1 9.253 >=0.5 Pass 802.11g SISO 2412 / / 1 16.529 >=0.5 Pass 2437 / / 1 16.486 >=0.5 Pass 2462 / / 1 16.625 >=0.5 Pass 802.11n (HT20) SISO 2412 / / 1 17.721 >=0.5 Pass 2437 / / 1 17.719 >=0.5 Pass 2462 / / 1 17.799 >=0.5 Pass 802.11n (HT40) SISO 2422 / / 1 36.189 >=0.5 Pass 2437 / / 1 36.044 >=0.5 Pass 2452 / / 1 36.177 >=0.5 Pass 802.11ax (HEW20) SISO 2412 SU / 1 18.954 >=0.5 Pass 2437 SU / 1 18.724 >=0.5 Pass 2462 SU / 1 18.843 >=0.5 Pass 802.11ax (HEW40) SISO 2422 SU / 1 37.227 >=0.5 Pass 2437 SU / 1 37.101 >=0.5 Pass 2452 SU / 1 37.424 >=0.5 Pass Page 13 of 66 Report No.: AiTSZ-251231012FW3 2.2 Test Graph 2.2.1 OBW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 14 of 66 Report No.: AiTSZ-251231012FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 15 of 66 Report No.: AiTSZ-251231012FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 16 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 17 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 18 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 19 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 20 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_ / _Ant1 (SISO)_NTNV Page 21 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW40)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_ / _Ant1 (SISO)_NTNV Page 22 of 66 Report No.: AiTSZ-251231012FW3 2.2.2 6dB BW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV Page 23 of 66 Report No.: AiTSZ-251231012FW3 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV Page 24 of 66 Report No.: AiTSZ-251231012FW3 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Page 25 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV Page 26 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV Page 27 of 66 Report No.: AiTSZ-251231012FW3 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Page 28 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_LCH_2412MHz_SU_ / _Ant1 (SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_ / _Ant1 (SISO)_NTNV Page 29 of 66 Report No.: AiTSZ-251231012FW3 802.11ax(HEW20)_HCH_2462MHz_SU_ / _Ant1 (SISO…

Text truncated - open the document above for the full version.

Page 1 of 27 Report No.: AiTSZ-251231012FW3 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : MOO BOX Brand Name : N/A Model : 251226M Series Model : N/A FCC ID : 2BTQ7-251226M Applicant : Suzhou ShaoHao Tech Co., Ltd. Address : Jinfeng Business Creative Center, Wuzhong District, Suzhou City, Jiangsu Province, China Manufacturer : Suzhou ShaoHao Tech Co., Ltd. Address : Jinfeng Business Creative Center, Wuzhong District, Suzhou City, Jiangsu Province, China Standard(s) : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Receipt : Dec. 31, 2025 Date of Test : Dec. 31, 2026~ Mar. 05, 2026 Issued Date : Mar. 05, 2026 Issued By: Guangdong Asia Hongk…

Text truncated - open the document above for the full version.
