2BTQH-J03J03 Smart Lock

Mailin Lock Co., Ltd.
J03 Smart Lock - FCC ID 2BTQH-J03 - Mailin Lock Co., Ltd.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 31, 2025
Application Purpose
Original Equipment
Equipment Note
J03 Smart Lock
Frequency Range
2412.00000000 - 2462.00000000
Company
Mailin Lock Co., Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Tips: Specications are subject to change without prior notice 1.TO CONVERT BACKSET FROM 2-3/8 (60mm) TO 2-3/4 (70mm) 2.TO CONVERT BACKSET FROM 2-3/4 (70mm) TO 2-3/8 (60mm) convert Pull convert Push PREPARE THE DOOR AND CHECK DIMENSIONS (with the TEMPLATE card) 1 A Measure to confirm the size of hole in the door frame. The wide is 1"(25mm), the length is 1-3/8" (35mm), the depth is 1"(25mm). B Measure to confirm the thickness of door is 1-3/8" to 2" (35mm-50mm), the hole in the side of door is 1" (25mm). 1-3/8 (35mm) 1 (25mm) 1 (25mm) 1-3/8 to 2 (35mm-50mm) 1 (25mm) 1 3 4 FOLD H E REON DO OREDG E FOR2 50mm DOOR MARK HOLE C ENT ER MAR K H OLE C ENTER F O R 1-1/ 4 30m m D O OR THENDRILLAHOLE IN CENTEROFDOOR WIDE1 25mm DEPTH2 50mm IMPORTAN T PLACETEMPLATEONHIGH EDGEOFDOORBEVEL FOR I NST ALLING ENTRYLOCK A N DDE ADBOL T S TEM PLA TE 2 PLACETOP 36915mm ABOVEFLOOR 5 6 M A R KCE NT ER DR I LL 21854mm HOLE OFHO LE O N DOORFACE doorframe door C Measure to confirm the backset is 2- 3/8or 2-3/4 (60mm or 70mm). And adjust the length of the latch accordingly. D Measure to the size of hole in the door is 2-1/8 (54mm). confirm backset 2-3/8 or 2-3/4 (60mm or 70mm) 1 3 4 FOLDHEREON DOOREDGE FOR2 50mm DOOR MARK HOLE CENTER MARK HOLE CENTER FOR11 4 30mm DOOR THENDRILLAHOLE IN CENTEROFDOOR WIDE1 25mm DEPTH2 50mm IMPORTAN T PLACETEMPLATEONHIGH EDGEOFDOORBEVEL FORINSTALLINGEN TRYLOCK ANDDEADBOL TS TEM PLA TE 2 PLACETOP 369 15mm ABOVEFLOOR 5 6 MARKCE N T ER DRILL 21854mm HOLE OFHOLEON DOORF A CE 2-1/8 (54mm) door door 2-3/4 70(mm) 2-3/8 (60mm) Pull CHANGE HANDLE ORIENTATION 3 Left opening door Right opening door 1.Please confirm the door opening direction before installing. 2.Turn the handle to the desired direction, then tighten the reversing screw. 180 180 LeftLeft RightRight 4 5 ° 9 0 ° Exterior Assembly Interior Assembly Reversing screw 3.Make sure the arrow on the Exterior Assembly is pointing up D Screws for Latch/Striking Plate Latch Key AB C Exterior Assembly G H Screws for Mounting Plate and Exterior Assembly Interior Assembly I Battery Cover EF Striking PlateMounting Plate Hole-Aligning Device ( can use or not ) Square pole Installation & Operation Guide Please keep this guide This guide contains important information about your lock. C Snap the interior assembly to the mounting plate and tighten the screws D Insert 4 AA batteries and close the cover Interior Assembly Connect the cable Interior AssemblyKeypad Assembly Overall Parts List Ajustable Deadbolt Latch Set Installation GuideInstallation GuideInstallation GuideInstallation Guide Install striking plate and hole-aligning device in the door frame with two screws (D) provided. Insert latch into hole in side of door with the word UP up, and screw latch into door with two screws (D) provided. INSTALL THE LATCH AND STRIKING PLATE 2 B A Route the cable through the upper side of the latch. Pass the square rod through the square hole of the latch. and push the keypad onto the door. IMPORTANT: Please make sure the arrow on the Exterior Assembly is pointing up. Insert the screw sleeve into the stud and tighten it. INSTALL THE SCREW SLEEVE AND EXTERIOR ASSEMBLY 4 Install the Exterior Assembly BA 5 INSTALL THE INTERIOR ASSEMBLY AND BATTERY COVER Route cable through the mounting plate, and Tighten screws evenly. Connect cables to the interior. B A D E L doorframe C D door KL Screws for Interior Assembly J M Pin B G K 1 2 11 8 7 5 3 6 10 12 9 4 Key Exterior Assembly Thread sleeve Latch Screw Striking Plate Square pole Screw Interior Assembly Battery Cover Mounting Plate Pin 2 1 7 6 5 4 9 11 8 10 12 3 70(mm) 2-3/4 60(mm) 2-3/8 70(mm) 2-3/4 60(mm) 2-3/8 Exterior Assembly Interior Assembly Factory Default Settings Settings Factory Default Master Code 123456 Auto LockEnabled Silent Mode Disabled Wrong Code Entry Limit 5 times Shutdown Time 10 seconds Passage Mode Disabled Restore To Factory Default Settings The default Master Code is 123456.It is required that you change it to a code of your own before programming. 1.Open and unlock the door. 2.Find a paper clip, put it into the hole at the bottom, long press for 5 seconds until the lock voice prompts "initialized successfully" Back/Clear Confirm/Program/Door bell Fingerprint Intelligent card Type-C emergency power port Definitions 1.MASTER INFO The administrator's fingerprint, password, or IC card. Required for programming and feature settings. It can also be used to unlock. 2.USERS INFO Fingerprints, passwords, and IC cards of non administrators. Can only be used for unlocking. 3.WRONG ENTRY LIMIT If you enter incorrect unlock information for more than five consecutive times, the system displays the lock status. After the system is locked, operating the keyboard or swiping the card or entering the fingerprint again, even if the registered record is entered, the system will be prompted to lock and the lock time will be updated. The system is automatically unlocked 90 seconds after being locked. 29147673 password Randomdigits Randomdigits 4.THE *KEY To clear the key/back key, when entering the password, click to clear the previous input and press 3 consecutive times to clear the input Enter. 5.THE "#"KEY Confirm key or enter menu function key, press it as the door bell when there is no input when waking up before configuration networking, and press it after configuration networking to voice prompt "Requesting remote unlocking". 6.ANTI-PEEPING FUNCTION User can prevent pin code exposure to strangers by entering random digits before and after the pin code. 1.MASTER CODE (4 to 8digits) The default Master Code is 123456. It is required that you change it to a code of your own before programming. 2.USER CODE (4 to 8 digits) If the password is unlocked unsuccessfully, please reset the password according to [Quick Set Up-5.Add User info] carefully. Reset Button Paper clip The lock supports TUYA Wi-Fi protocol,you can manage your lock by connecting TUYA APP. Search TUYA in the app market or scan the code to get the APP:…
