2BTQQ-ND05Wireless Power Bank

Type-C NName: Wireless Power Bank Model No.: ND05 Battery Type: Lithium Polymer Material: ABS+PC Battery Capacity: 10000mAh (38.5Wh ) Rated Capacity: 6000mAh Energy Conversion: ≥60% USB-C Port Input: 5VDC, 3A/9VDC, 2A/12VDC,1.5A USB-C Port Output: 5VDC, 3A/9VDC, 2.22A/12VDC,1.67A USB-C Wire Input: 5VDC, 3A/9VDC, 2A12VDC,1.5A USB-C Wire Output: 5VDC, 3A/9VDC, 2.22A 12VDC,1.67A USB-A Port Output:5VDC,3A Total output: 5VDC, 3A(15W Max) Phone Wireless Charging Output: 15W Max Product size: 110*70*18mm 4.33*2.76*0.7inch) Net weight: 193g/0.43lb Instructions Manual 16. Operating temperature should be between 10°C to 45°C / 50°F to 113°F 17. Storage Temperature range: -10 to 60 18. When disposing of secondary cells or batteries, keep cells or batteries of differnet electronchemical systems separate from each other. INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS WARNING – When using this product, basic precautions should always be followed,including the following: a) Read all the instructions before using the product. b) To reduce the risk of injury , close supervision is necessary when the product is used near children. c) Do not put fingers or hands into the product. d) Do not expose power bank to rain or snow. e) Use of a power supply or charger not recommended or sold by power pack manufacturer may result in a risk of fire or injury to persons. f) Do not use the power bank in excess of its output rating. Overload outputs above rating may result in a risk of fire or injury to persons. g) Do not use the power bank that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury. h) Do not disassemble the power bank. Take it to a qualified service person when service or repair is required . Incorrect reassembly may result in a risk of fire or injury to persons. i) Do not expose a power pack to fire or excessive temperature. Exposure to fire or temperature above 100°C may cause explosion.The temperature of 100°C can be replaced by the temperature of 212°F. j) Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. k) Switch off the power bank when not in use. SAVE THESE INSTRUCTIONS CAUTION:Risk of Fire and Burns.Do Not Open,Crush,Heat Above(45)or Incinerate.Follow Manufacturer's Instructions. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement.

Rev 1/26/2023 Shenzhen Xinshi’an Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-24-2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BTQQ-ND05 Shenzhen Xinshi’an Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Shenzhen Xinshi’an Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) Fengshan Cui Rev 1/26/2023 Shenzhen Xinshi’an Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-24-2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BTQQ-ND05 Shenzhen Xinshi’an Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name)

ShenzhenXinshi'anTechnologyCo.,Ltd. Room401,NO.49XinheRoad,ShangmuguCommunity,PinghuStreet,LonggangDistrict, Shenzhen,518000, China Date:12-29-2025 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 FCCID:2BTQQ-ND05 FRN:0037763299 USAgent–AttestationStatement/Part2.911(d)(7) ShenzhenXinshi'anTechnologyCo.,Ltd.certifies,thatasof12-29-2025,wehavedesignated FCCUSAgent,LLCtoacceptserviceofprocessonourbehalfforFCCID:2BTQQ-ND05. ShenzhenXinshi'anTechnologyCo.,Ltd.,acceptstomaintainanagentofserviceofprocessin theUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. FCCUSAgent,LLC,acceptsasofthedateofthefilingofthisapplication,theobligationofbeing thedesignatedagentforthepurposeofacceptingserviceofprocessonbehalfofShenzhen Xinshi'anTechnologyCo.,Ltd.forFCCID:2BTQQ-ND05. DesignatedAgentInformation: CompanyName:FCCUSAgent,LLC FRN:0033402884 Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA ContactPerson:TimPayne Phone:708-571-3148 Email:[email protected] Sincerely, Company:ShenzhenXinshi'anTechnologyCo., Ltd. DesignatedAgent:FCCUSAgent,LLC CompanyRepresentative:FengshanCuiDesignatedAgentRepresentative:TimPayne Signature:[Signature]Signature:

ShenzhenXinshi'anTechnologyCo.,Ltd. Date:Dec.29,2025 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID: 2BTQQ-ND05 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName Long-termconfidentiality: Schematics BlockDiagram OperationalDescription Schematics.pdf BlockDiagram.pdf OperationalDescription.pdf Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. Sincerely, ShenzhenXinshi'anTechnologyCo.,Ltd. Signature FengshanCui/manager TypednameandTitle

ShenzhenXinshi'anTechnologyCo.,Ltd. FCCID:2BTQQ-ND05 POWEROFATTORNEY Date:Dec.29,2025 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern: We,theundersigned,herebyauthorizeWaltekTestingGroupCo.,Ltd.(DevalQin) onourbehalf,toapplytotheFederalCommunicationsCommissiononour equipment.AnyandallactscarriedoutbyWaltekTestingGroupCo.,Ltd.(Deval Qin)onourbehalfshallhavethesameeffectasactsofourown.This authorizationexpiresonDec.28,2026. Sincerely, ShenzhenXinshi'anTechnologyCo.,Ltd. Signature FengshanCui/manager TypednameandTitle

ShenzhenXinshi'anTechnologyCo.,Ltd. FCCID:2BTQQ-ND05 Date:12/30/25 Subject:authorizationforaddingfamilymodels TowhomitMayconcern, Statement WewouldliketoconfirmtheproductWirelessPowerBankwithmodelsND05,ND06,ND07, ND08,ND09,ND10aresameinallrespects.Onlythemodelnamesaredifferent. Yourssincerely, [signature] FengshanCui manager ShenzhenXinshi'anTechnologyCo.,Ltd.

Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 4 of 10 2. Photographs –Constructional Details 2.1. EUT – External View Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 5 of 10 Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 6 of 10 Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 7 of 10

Model No.: ND05 Name:Wireless Power Bank 1INP7/60/74-2 Battery Type:Lithium Polymer USB-C port input: 5VDC, 2A/9VDC, 2A/12VDC, 1.5A USB-C wire input: 5VDC, 2A/9VDC, 2A/12VDC, 1.5A USB-C wire output: 5VDC, 2A/9VDC, 2.22A/12VDC, 1.67A Lightning wire output: 5VDC, 2A USB-A output: 5VDC, 2A USB-C port output: 5VDC, 2A/9VDC, 2.22A/12VDC, 1.67A Wireless charging output: 15W Max Total output: 5VDC, 2A(10W) Battery Capacity: 10000mAh (3.85V 38.5Wh) FCC ID: 2BTQQ-ND05 Rated Capacity: 6000mAh (5VDC,2A) Energy Conversion≥60% Manufacturer:Shenzhen Xinshi'an Technology Co., Ltd. Address:Room 401, NO.49 Xinhe Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen,China. SN: SNXXXXXXXX CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above(45) or Incinerate. Follow Manufacturer’s Instructions. ATTENTION : Risque d'incendie et de brûlures. Ne pas ouvrir, écraser, chauffer au-dessus de (45) ou incinérer. Suivre les instructions du fabricant. Cet appareil, ses piles et cordons se recyclent À DÉPOSER EN MAGASIN À DÉPOSER EN DÉCHÈTERIE Points de collecte sur www.quefairedemesdechets.fr Privilégiez la réparation ou le don de votre appareil ! Made in China

Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 8 of 10 2.2. EUT – Internal View Ant. Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 9 of 10 Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 10 of 10 ======End======

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 11 TEST REPORT Referen ce No. .................... : WTD25D12327788W003 FCC ID ................................ : 2BTQQ-ND05 Applicant ............................ : Shenzhen Xinshi'an Technology Co., Ltd. Address .............................. : Room 401, NO.49 Xinhe Road, Shangmugu Community, Pinghu Street, Lon ggang District, Shenzhen, China Manufacturer .................... : Shenzhen Xinshi'an Technology Co., Ltd. Address .............................. : Room 401, NO.49 Xinhe Road, Shangmugu Community, Pinghu Street, Lon ggang District, Shenzhen, China Product ............................... : Wireless Power Bank Model(s). ............................ : ND05, ND06, ND07, ND08, ND09, ND10 Standards........................... : FCC 47CFR Part 1.1307 Date of Receipt Sample .... : 2025-11-15 Date of Test ....................... : 2025-12-19 to 2025-12-29 Date of Issue ...................... : 2026-04-24 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Estel Qian / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD25D12327788W003 Page 2 of 11 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2. Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2. CONTENTS ............................................................................................................................................................ 2 3. REVISION HISTORY ............................................................................................................................................ 3 4. GENERAL INFORMATION .................................................................................................................................. 4 4.1. GENERAL DESCRIPTION OF E.U.T. ............................................................................................................ 4 4.2. DETAILS OF ACCESSORIES ......................................................................................................................... 4 4.3. SUBCONTRACTED ....................................................................................................................................... 4 4.4. ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 4 4.5. TEST FACILITY ............................................................................................................................................ 5 4.6. TEST MODE ................................................................................................................................................. 5 5. TEST SUMMARY .................................................................................................................................................. 6 6. EQUIPMENT USED DURING TEST .................................................................................................................. 7 6.1. EQUIPMENTS LIST ...................................................................................................................................... 7 6.2. DESCRIPTION OF AUXILIARY EQUIPMENT .................................................................................................. 7 6.3. TEST EQUIPMENT CALIBRATION ................................................................................................................ 7 7. RF EXPOSURE ...................................................................................................................................................... 8 7.1. EUT OPERATION ........................................................................................................................................ 8 7.2. TEST SETUP ............................................................................................................................................... 8 7.3. FIELD STRENGTH MEASUREMENTS ........................................................................................................... 9 7.4. MATHEMATICAL MODEL .............................................................................................................................. 9 7.5. FCC RULES .............................................................................................................................................. 10 7.6. TEST RESULT ........................................................................................................................................... 11 Reference No.: WTD25D12327788W003 Page 3 of 11 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 3. Revision History Test Report No. Date of Receipt Sample Date of Test Date of Issue Purpose Comment Approved WTD25D12327788W003 2025-11-15 2025-12-19 to 2025-12-29 2026-04-24Original - Valid Reference No.: WTD25D12327788W003 Page 4 of 11 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4. General Information 4.1. General Description of E.U.T. Product: Wireless Power Bank Model(s): ND05, ND06, ND07, ND08, ND09, ND10 Model Description: Model ND05 was tested in the report. Only the model names are different. Test Sample No.: 1-1/1 Frequency Range: 110-205kHz Antenna installation: Inductive loop coil Antenna Hardware Version: V006-ZL-V3.0 Software Version: V006-V3.0 4.2. Details of accessories Ratings: USB-C port input: 5VDC, 2A/9VDC, 2A/1…

Text truncated - open the document above for the full version.

ShenzhenHuakechengTechnologyCo.,Ltd. ShenZhenHKCTechnologyCo.Ltd Acknowledgedmaterialnum- ber: ApprovalP/N 19.10.003.06591346 Specificationdescription: ItemDescription Sensitivityspecification:6.5uH±10% Magneticdiskspecifications:43.5*5.3*0.5mm;double-slot reverseblackfilm.Wirespecifications:0.08*60*10Ts(inner diameter20.5mm). Wirelength:50mmsinglegroovewire frontsideordinarydoublesideadhesive/3mm hightemperatureadhesivetape Version A0 ShenzhenHuakechengTechnologyCo.,Ltd. ShenZhenHKCTechnologyCo.Ltd No.28,SouthShahuAvenue,TangxiaTown,DongguanCity,GuangdongProvince,China Formnumber:HKC-QR-QEOP-30-18A0 ApprovalCheckPrepare Approval Examine andverify RDaffirm Supplier： Supplier ShenzhenChenxingElectronicTechnologyCo.,Ltd. S60-4305-PS-50mm manufacturer： ShenzhenChenxingElectronicTechnologyCo., LTD.Manufacturer SupplierP/N: Manufacturer P/N: ManufacturerP/N S60-4305-PS-50mm Companyname:ShenzhenChenxingElectronicTechnologyCo.,LTD FactoryAddress:5thFloor,Building1,XinkechengScienceandTechnologyIndustrialPark,51DabaoRoad,XinanStreet,BaoanDistrict,Shenzhen Page1 ProductSPECIFICATIONS PRODUCTSPECIFICATIONFORAPPROVAL CustomerNa- me:CUSTOMER Huakecheng A11coil ProductName: PRODUCTNAME MaterialCode: PARTNo. 19.10.003.06591346 ProductSpecifications: PRODUCTSPEC Sensitivityspecification:6.5uH±10% Magneticdiskspecifications:43.5*5.3*0.5mm;double-slot reverseblackfilm.Wirespecifications:0.08*60*10Ts(inner diameter20.5mm). Cablelength:50mmsingle-slotcable Front:StandardDouble-SidedAdhesive/3mmHigh-TemperatureTape Sundesignatedtime： DATE 19December2025 Versiontype: VERSION REV1.0 Edition Revision Changecontent ModifiedContent Responsibility Principle Date Date Rema- rksNote REV1.0 Firstrelease ZhouXiaojue 2025-12-19 Preparedby Reviewed/Checkedby Approvedby Customer-approvedsign- atureandseal Attachedistheproductspecification.Ifyouhaveanyquestions,pleaseletusknow.Thankyou! Companyname:ShenzhenChenxingElectronicTechnologyCo.,LTD FactoryAddress:5thFloor,Building1,XinkechengScienceandTechnologyIndustrialPark,51DabaoRoad,XinanStreet,BaoanDistrict,Shenzhen Page2 SizeofProduct SPECIFICATION 1.ProductDimensions II.SchematicDiagram DiscdiameterA 43.5±0.3mm Outerdiameterof thecoilB 38±1.5mm Innerdiameterof thecoilC 20.5±0.5mm Productthickness D Thesurroundingarea is1.6mmfoldedlineat 2.0mm OutlinelengthE 50mm±2mm Fusionlength 3 ± 1mm Diameterofmagneticdiscopening G 5±0.3mm Magnettapethic- kness 0.5±0.05mm Magnetshape Circulardoublegr- oove Backadhesiveth- ickness Normaldouble-sidedadhes- iveonthefront Crack-resistantbl- ackfilm Reverse side Normaldouble-sidedadhesiveon thefront Companyname:ShenzhenChenxingElectronicTechnologyCo.,LTD FactoryAddress:5thFloor,Building1,XinkechengScienceandTechnologyIndustrialPark,51DabaoRoad,XinanStreet,BaoanDistrict,Shenzhen Page3 III.WindingParameters Terminal TERMINAL Wire diameter Numberof turns Turns Directionofwinding WindingDirection SF Silk-wrappedwire0.08*60 10TsCCW IV.ElectricalCharacteristics: TemperatureTEMPERATURE:25±10°C,RelativehumidityRELATIVEHUMIDITY:65±20% Project ITEM Terminal TERMINAL Standard SPECIFICATION Testcondition TESTFREQUENCY Measuringandtestinstrum- ents TESTEQUIPMENTS IND.S-F L ： 6.5uH±10% Q:Greaterthan50 100KHz/1.0VLCZMETER1062B 5.ProductImages

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 31 TEST REPORT Reference No. .................... : WTD25D12327788W002 FCC ID ................................ : 2BTQQ-ND05 Applicant ............................ : Shenzhen Xinshi'an Technology Co., Ltd. Address .............................. : Room 401, NO.49 Xinhe Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, China Manufacturer .................... : Shenzhen Xinshi'an Technology Co., Ltd. Address ............................. : Room 401, NO.49 Xinhe Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, China Product ............................... : Wireless Power Bank Model(s). ............................ : ND05, ND06, ND07, ND08, ND09, ND10 Standards........................... : FCC 47CFR 15.209 Date of Receipt Sample .... : 2025-11-15 Date of Test ....................... : 2025-12-19 to 2025-12-29 Date of Issue ...................... : 2026-04-24 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Estel Qian / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD25D12327788W002 Page 2 of 31 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 3 4 GENERAL INFORMATION ....................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 4.2 DETAILS OF ACCESSORIES ............................................................................................................... 4 4.3 TEST FACILITY ................................................................................................................................ 5 4.4 SUBCONTRACTED ........................................................................................................................... 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 4.6 TEST MODE .................................................................................................................................... 6 5 TEST SUMMARY ...................................................................................................................................... 7 6 EQUIPMENT USED DURING TEST ......................................................................................................... 8 6.1 EQUIPMENTS LIST ........................................................................................................................... 8 6.2 DESCRIPTION OF SUPPORT UNITS ................................................................................................... 8 6.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6.4 TEST EQUIPMENT CALIBRATION ....................................................................................................... 8 7 RADIATED SPURIOUS EMISSIONS ....................................................................................................... 9 7.1 EUT OPERATION ............................................................................................................................ 9 7.2 TEST SETUP ................................................................................................................................. 10 7.3 SPECTRUM ANALYZER SETUP ........................................................................................................ 11 7.4 TEST PROCEDURE ........................................................................................................................ 11 7.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ......................................................................... 11 7.6 SUMMARY OF TEST RESULTS ........................................................................................................ 12 8 BANDWIDTH MEASUREMENT ............................................................................................................. 28 8.1 TEST PROCEDURE ........................................................................................................................ 28 8.2 TEST RESULT ............................................................................................................................... 28 9 ANTENNA REQUIREMENT ................................................................................................................... 31 10 RF EXPOSURE ....................................................................................................................................... 31 11 PHOTOGRAPHS OF TEST SETUP AND EUT ...................................................................................... 31 Reference No.: WTD25D12327788W002 Page 3 of 31 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 3 Revision History Test Report No. Date of Receipt Sample Date of Test Date of…

Text truncated - open the document above for the full version.

Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 1 of 10 1. Test Setup photos 1.1 Photograph – Radiated Emissions For 9kHz-30MHz Test Site 2# For 30MHz-1000MHz Test Site 2# Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 2 of 10 1.2 Photograph – RF Exposure 6cm 8cm Appendix-ND05-Photos FCC ID: 2BTQQ-ND05 Reference No.: WTD25D12327788W Page 3 of 10 10cm
