2BTSZ-BT-BC1Baoruler

宝尺测量仪 使用说明书 Baoruler operation instructions 装箱清单/Packing list 编号 名称 宝尺测量仪 个 1 1 根 12USB充电线 个 1 3 束口袋 份 1 4 合格证 份 1 5 保修卡 份 1 6 使用说明书 单位 数量 Number Name Baoruler piece 1 1 piece 12USB charging cable piece 1 3 Bundle pocket copy 1 4 Certificate copy 1 5 Warranty card copy 16Operation instructions UnitNumber 产品整体示意图/Product schematic diagram Please use a power adapter that meets applicable safety standards and is CCC certified for charging 重要提示 | Important 请使用符合适用安全标准且经CCC认证的电源适配器充电 1 Pilot lamp 指示灯 2 测量基准点 Datum mark 3 充电口 Charging port 使用说明/Instructions 请扫描本页底部二维码下载应用程序APP，以便连接设备。 Please scan the QR code at the bottom of this page to download the application APP for device connection. 一、下载APP | Download the App 将设备平拿在手中，连续上下晃动两次，指示灯亮即开机成功。 Hold the device flat in your hand and shake it up and down twice in a row. When the indicator light is on, it indicates that the device has been successfully turned on. 二、开启设备 | Turn on the device 启动设备，打开宝尺应用程序，按照界面引导连接设备。 Start the device, open the Baoruler application, and follow the interface to connect the device. 三、连接APP | Connect APP 参阅用户手册了解应用程序APP各项功能的使用，开启您的测量之路。 Refer to the user manual to learn how to use the various functions of the application app and start your measurement journey. 四、开始使用 |Start using Scan the code and reply with "Baoruler" to obtain the application APP and user manual. 扫码回复“宝尺”即可获取应用程序APP以及用户手册。 APP下载提示APP download prompt 产品参数 产品名称：宝尺测量仪 产品型号：BT-BC1 产品净重：约50g 产品尺寸：61.8mm*61.8mm*19.8mm 工作温度：-10°C~+50°C 存储温度：-20°C~+70°C 接口类型：TYPE-C 电池类型：锂电池 续航时间：连续测量7-8小时 [1] 工作电压：3V - 3.5V 存储容量：2MB 无线通讯：蓝牙 输出频率：100HZ 防水防尘：IP65 防震防撞：抗1.8米自然跌落 测量范围：加速度：±4G；角速度：±1000°/S 测量精度：单次闭合测量，误差率0.5% [2] [1]电池工作时间与工作环境、工作温度和电池寿命有关； [2]测量精度为熟悉操作后的理论误差率，会受人为操作的影响而变化； Product parameters Product Name: Baoruler Product model: BT-BC1 Net weight of the product: approximately 50g Product size: 61.8mm * 61.8mm * 19.8mm Working temperature: -10 °C~+50 °C Storage temperature: -20 °C~+70 °C Interface type: Type-C Battery Type: Lithium Battery Battery life: continuous measurement for 7-8 hours [1] Working voltage: 3V-3.5V Storage capacity: 2MB Wireless communication: Bluetooth Output frequency: 100Hz Waterproof and dustproof: IP65 Anti shock and anti-collision: resistant to a natural drop of 1.8 meters Measurement range: Acceleration: ± 4g; Angular velocity: ± 1000 °/s Measurement accuracy: Single closed measurement with an error rate of 0.5% [2] [1] The working time of the battery is related to the working environment, working temperature, and battery life; [2] The measurement accuracy is the theoretical error rate after familiar operation, which may vary due to the influence of human operation; 注意事项/Matters needing attention 禁止私自拆卸本产品，否则内部器件可能会受到损坏。 It is prohibited to disassemble this product without authorization, otherwise the internal components may be damaged. 请不要摔打或用力敲击产品，粗暴的使用有可能损坏产品或发生故障。 Please do not hit or forcefully tap the product, rough use may damage the product or cause malfunctions. 请不要将设备浸泡或在大雨中使用，同时尽量防止设备从高处跌落。 Please do not soak the equipment or use it in heavy rain, and try to prevent the equipment from falling from a height. 本设备采用不可拆卸的内置电池，切勿自行更换电池，以免导致设备无法正 常运行或电池损坏。 This device uses a non removable built-in battery. Do not replace the battery yourself to avoid causing the device to malfunction or battery damage. 当充电完毕或者不充电时，请断开电源适配器与设备的连接并从电源插座上 拔掉电源适配器。 When charging is complete or not, please disconnect the power adapter from the device and unplug the power adapter from the power outlet. 说明书中的产品、配件、用户界面等插图均为示意图。由于产品的更新与升 级，产品实物与示意图可能略有差异。 The illustrations of products, accessories, user interfaces, etc. in the manual are all schematic diagrams. Due to product updates and upgrades, there may be slight differences between the actual product and the schematic diagram. 仪器出现任何的质量问题，或对仪器有任何疑问时请及时联系宝图公司，我 们将第一时间为您解决。 If there are any quality problems with the instrument or any questions about the instrument, please contact Baotu Company in a timely manner, and we will solve them for you as soon as possible. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 注意事项/Matters needing attention 若有售后服务需求，请拨打宝图服务电话：023-67808899 或访问宝图官网联系我们：www.baotukeji.com 制造商：重庆宝图科技发展有限公司 地址：重庆市两江新区金开大道1239号融科金开中心写字楼2-1栋12楼 If you have any after-sales service needs, please call Baotu Service Hotline: 023-67808899 Or visit the official website of Baotu to contact us: www.b…

Text truncated - open the document above for the full version.

Chongqing Baotu Technology Development Co., Ltd. Covered Equipment Certification Attestation Letter 12/22/2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BTSZ-BT-BC1 Chongqing Baotu Technology Development Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Chongqing Baotu Technology Development Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Chongqing Baotu Technology Development Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Ming Zhang Title: Manager Company Name: Chongqing Baotu Technology Development Co., Ltd. Date: 12/22/2025

Chongqing Baotu Technology Development Co., Ltd. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: December 22, 2025 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BTSZ-BT-BC1 Chongqing Baotu Technology Development Co., Ltd.(“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Chongqing Baotu Technology Development Co., Ltd. FRN: 0037773033 Address: Room 20-22, Floor 12th, Building 1, No. 42 Jinzhou Avenue, North New Area, Chongqing, P. R. China Signature: Contact Person: S Ming Zhang Tel: 18523307036 Email: [email protected]

DATE: December 22, 2025 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BTSZ-BT-BC1 Product Name: Baoruler Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Ming Zhang Title: Manager Company: Chongqing Baotu Technology Development Co., Ltd.

Date: December 22, 2025 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Ming Zhang Title: Manager Company: Chongqing Baotu Technology Development Co., Ltd.

DATE: December 22, 2025 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen CCUT Quality Technology Co., Ltd. (1F, Building 35, Changxing Technology Indstrl Park Changzhen Community, Yutang Street,Shenzhen,China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Chongqing Baotu Technology Development Co., Ltd. (Room 20-22, Floor 12th, Building 1, No. 42 Jinzhou Avenue, North New Area, Chongqing, P. R. China). <Signature> Name: Ming Zhang Title: Manager Applicant Company: Chongqing Baotu Technology Development Co., Ltd.

Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 1 of 10 Annex A. EUT External Photos EUT View 1 Model : BT-BC1 EUT View 2 Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 2 of 10 EUT View 3 EUT View 4 Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 3 of 10 EUT View 5 EUT View 6 Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 4 of 10 EUT View 7 EUT View 8

Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 10 of 10 Annex D. Label and Inf ormation FCC Label Sample Label Size: 3cm*1.5cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 5 of 10 Annex B. EUT Internal Photos EUT Internal View 1 EUT Internal View 2 Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 6 of 10 EUT Internal View 3 EUT Internal View 4 SMD Antenna Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 7 of 10 EUT Internal View 5

FCC ID: 2BTSZ-BT-BC1 RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BLE Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit -8.35 -8(±1) -7 0.19953 2480 5 0.0628 3.0 So a SAR test is not required

Ultra-Miniature 2.4GHz Chip antenna 0.37mm max Thickness P/N 2450AT07A0100 Detail Specification:Page 1 of 5 Evaluation Board No. L±± 1 W±± 2 T 3 a 4 b c Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2020 Johanson Technology, Inc. All Rights Reserved P/N Suffix Packing Style "High Frequency Ceramic Solutions" 2W max. (CW) 50 Ω 10/12/2020 Average Gain (dBi typ.) Peak Gain (dBi typ.) Part Number2450AT07A0100 2400 - 2500 1.0 (XZ-Total) Frequency (MHz) 6.5 dB min. 0.014 max -1.5 (XZ-Total) Function Feed Return Loss -40 to +125°C Terminal Configuration Recommended Storage Conditions of unused product on T&R +5 ~ +35 °C Humidity 45~75%RH 18 months max. 0.004 0.004 mmIn 0.50 Mechanical Dimensions Input Power GND GND +0.1/-0.05 Feed+0.1/-0.05 +0.1/-0.05 0.10 0.37 max 0.25 0.08 0.15 Ver 3.1 Operating Temperature General Specifications 1.000.100.039 Impedance 0.003 0.010 +.004/-.006 +.004/-.006 +.004/-.0060.006 0.020 Part Number Explanation 2450AT07A0100-EB1SMA Bulk (loose) Suffix = Se.g. 2450AT07A0100S TraySuffix = Te.g. 2450AT07A0100T 1 2 34 L W a b c T Ultra-Miniature 2.4GHz Chip antenna 0.37mm max Thickness P/N 2450AT07A0100 Detail Specification:Page 2 of 5 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2020 Johanson Technology, Inc. All Rights Reserved Ver 3.1 "High Frequency Ceramic Solutions" 10/12/2020 Mounting Considerations Test Board-Top View (Units in mm) Land Solder 0.9 4.0 0.4 0.3 0.3 0.7 1.2 0.25 1.5 5.0 3 .0 Feed line Matching circuit No Ground (Yellow area) GND Plane * 0.1 1 23 4 It is recommended that the designer leave available slots for a "pi" (shunt-series-shunt) network. The antenna matching network values above are used when antenna is mounted on Johanson's evaluation board. Matching components will vary depending on PCB design. Let us help you tune our antenna on your new layout, contact our RF Applications Eng. Team at: https://www.johansontechnology.com/ask-a-question *Line width should be designed to maintain 50Ω impedance matching characteristics. Units: mm Ultra-Miniature 2.4GHz Chip antenna 0.37mm max Thickness P/N 2450AT07A0100 Detail Specification:Page 3 of 5 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2020 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 10/12/2020 Ver 3.1 Layout Guidelines and EVB Specifications No ground (Yellow area) Ground Pi matching network recommended Feed 3 5 20 40 Test Board-Top View (Units in mm) 40 20 Ground clearance (Yellow area) 3 5 Test Board-Bottom View (Units in mm) To order a pre-tuned evaluation board with SMA connector click here: https://www.johansontechnology.com/request-a-sample Reference p/n: 2450AT07A0100-EB1SMA To request the layout files go to: https://www.johansontechnology.com/ask-a-question Ground Ultra-Miniature 2.4GHz Chip antenna 0.37mm max Thickness P/N 2450AT07A0100 Detail Specification:Page 4 of 5 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2020 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 10/12/2020 Ver 3.1 Typical Radiation Patterns @25C YZ‐plane XZ‐plane XY‐plane θ +Z (θ= 0°) +Y (θ= 90°) -Y -Z θ +Z (θ= 0°) +X (θ= 90°) -X -Z φ +X (φ= 0°) -X +Y (φ= 90°) -Y +Z +Z +Y +Y +X +X -Y -X -X -Z -Z -Y Ultra-Miniature 2.4GHz Chip antenna 0.37mm max Thickness P/N 2450AT07A0100 Detail Specification:Page 5 of 5 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2020 Johanson Technology, Inc. All Rights Reserved https://www.johansontechnology.com/tape-reel-packaging https://www.johansontechnology.com/ipcsoldering-profile https://www.johansontechnology.com/rohs-compliance Ver 3.1 "High Frequency Ceramic Solutions" 10/12/2020 Typical Electrical Performance (T=25°C) Packaging information Soldering Information Antenna layout and tuning techniques (How to obtain the new antenna matching values) https://www.johansontechnology.com/tuning Antenna layout review, tuning, and characterization services https://www.johansontechnology.com/ipc-antenna-services RoHS Compliance https://www.johansontechnology.com/msl-rating MSL Info Return Loss / Without Matching Circuits 2.12.22.32.42.52.62.72.82.92.03.0 -20 -15 -10 -5 -25 0 freq, GHz dB(S(1,1)) m1 m2 m3 m1 freq= dB(S(1,1))=-5.100 2.370GHz m2 freq= dB(S(1,1))=-20.709 2.450GHz m3 freq= dB(S(1,1))=-5.437 2.530GHz To download antenna s-parameters, please go to: https://www.johansontechnology.com/antennas

Report No: SSP25120118-1E FCC Test Report Page 1 of 33 FCC TEST REPORT FCC ID: 2BTSZ-BT-BC1 Report No. : SSP25120118-1E Applicant : Chongqing Baotu Technology Development Co., Ltd. Product Name : Baoruler Model Name : BT-BC1 Test Standard : FCC Part 15.247 Date of Issue : 2025-12-19 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP25120118-1E FCC Test Report Page 2 of 33 Test Report Basic Information Applicant..................................: Chongqing Baotu Technology Development Co., Ltd. Address of Applicant...............: Room 20-22, Floor 12th, Building 1, No. 42 Jinzhou Avenue, North New Area, Chongqing, P. R. China Manufacturer..........................: Chongqing Baotu Technology Development Co., Ltd. Address of Manufacturer........: Room 20-22, Floor 12th, Building 1, No. 42 Jinzhou Avenue, North New Area, Chongqing, P. R. China Product Name.........................: Baoruler Brand Name.............................: - Main Model..............................: BT-BC1 Series Models..........................: - Test Standard..........................: FCC Part 15 Subpart C KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.4-2014 ANSI C63.10-2020 Date of Test .............................: 2025-12-05 to 2025-12-19 Test Result...............................: PASS Tested By ................................: (Tate Chen) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP25120118-1E FCC Test Report Page 3 of 33 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.................................................................................................................................................... 22 6.3 Test Data and Results .........................................................................................................................…

Text truncated - open the document above for the full version.

Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 8 of 10 Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View 1 Report No: SSP25120118-1E FCC ID: 2BTSZ-BT-BC1 Annex of Test Report Page 9 of 10 Radiated Emission Test View 2
