2BTTT-W001WellVow Wled Controller

Wellvow – WLED Controller User Manual Introduction WLED powers addressable LEDs with instant control from your phone or browser. Enjoy effects, presets, segments, multi-device sync, and MQTT/HTTP APIs. At glance ①：Micro-USB Port ②：Adapter Input ③：Reset Button ④：Button 0(GPIO0) ⑤：Button 25(GPIO25) ⑥：Indicator LED ⑦：MIC ⑧：Output2 ⑨：Output1 Parameter Input DC20~36V 5Amax Wireless Module ESP32-MINI-1-N4 Output&Button Output1---GPIO15 Output2---GPIO2 Reset Button---ESP_RST Button 0---GPIO0 Button 25---GPIO25 Mic Generic I2S PDM mic Pin I2S SD---GPIO35 Pin I2S WS---GPIO27 Operating Temperature -20~50°C Compatible Models Type A Govee permanent outdoor Lights 2 Govee permanent outdoor Lights Elite Type B Govee permanent outdoor Lights Pro Indicator LED Solid green ESP32 module power OK Green off ESP32 module not powered LED Preferences Type A(for Govee permanent outdoor Lights 2/Elite) Calculate PSU Value Use 18mA per LED as the base. Length=Number of LEDs PSU = Number of LEDs × 12mA Example: Out1 with 72 LEDs → Length=72；PSU = 72 × 12 = 864mA Out2 with 36 LEDs → Length=72；PSU = 72 × 12 = 432mA Set WLED Parameters In WLED channel settings: Set max. mA/LED to 51mA Set PSU to your calculated value (e.g., 864mA / 432mA) Type B(for Govee permanent outdoor Lights Pro) Calculate PSU Value Use 18mA per LED as the base. Length=Number of LEDs PSU = Number of LEDs × 18mA Example: Out1 with 60 LEDs → Length=60；PSU = 60 × 18 = 1080mA Out2 with 30 LEDs → Length=60；PSU = 30 × 18 = 540mA Set WLED Parameters In WLED channel settings: Set max. mA/LED to 110mA Set PSU to your calculated value (e.g., 1080mA / 540mA) Button Button Type Function Button0 Pushbutton Single press: On/Off Button25 Pushbutton • In normal mode: Single press → Cycle through the 144 standard lighting effects. Double press → Switch to Music Mode. • In Music Mode: Single press → Cycle through the 23 music-reactive effects. Double press → Exit Music Mode and return to normal effect selection. How to Connect to WLED Step 1 — Power & LED hookup Based on the variant you purchased, connect the corresponding power supply and light(s) for your model. (Ensure matching voltage, correct polarity, and common GND; data goes to LED DIN.) Step 2: Connect to Device Hotspot Open your phone Settings → Wi-Fi (WLAN). In the available networks list, find the hotspot named WLED-AP. Tap the network to connect. On your phone, connect to WLED-AP with password wled1234 If the portal doesn’t open, browse to http://4.3.2.1 or http://192.168.4.1 step 3: Open Setup Page After connection, wait a few seconds. The WLED Wi-Fi Setup Page will automatically pop up.If it does not appear, open your browser and enter:4.3.2.1 to access the setup page manually. Step 4: Configure Home Wi-Fi On the setup page, you can: Manually enter your home Wi-Fi SSID (name) and password. Or tap Scan to search for nearby Wi-Fi networks, select the one you want, and enter the password. Tap Save, and the controller will reboot and try to connect to your home Wi-Fi network. Alternative: If you don’t want to connect to a router, stay in AP Mode. Simply click To the controls on the portal page. You can control WLED directly over the WLED-AP hotspot. Step 5: Use AP Mode (No Router Needed) If you don’t want to connect to a home Wi-Fi network, you can keep using AP Mode. Open your phone Settings → Wi-Fi, connect to WLED-AP. The default password is:wled1234 With AP Mode, you can control lights directly via the WLED app or the web interface, without an internet connection. Step 6 — Open WLED on your network Reconnect your phone to your home Wi-Fi. Then open wled.local (mDNS-enabled devices) or the IP shown on your router. Step 7 — Control Your Lights Once you have successfully connected to Wi-Fi or accessed the device through AP Mode, the WLED control interface will appear. You can adjust colors, brightness, effects, and presets directly from this page. Alternatively, you can also use the WLED-Native App for control. Download: Search for “wled-native” in the Apple App Store (iOS) or the Google Play Store (Android). Step 8 — First-time LED setup In Config → LED Preferences set: LED Type, Color Order (often GRB), Data Pin, LED Count, and Max Current/Brightness Limiter. Save. No light → recheck polarity, common ground, and DIN direction. For detailed usage, see the official docs: https://kno.wled.ge Open-Source Notice: This product uses WLED (licensed under EUPL-1.2). WLED © Christian Schwinne (“Aircoookie”) and contributors. Source & license: https://github.com/Aircoookie/WLED Customer Support & Warranty We’re here to help! If you experience any issues or need assistance with this product, please don’t hesitate to contact us. Contact Channels: Email: [email protected] Website:www.wellvow.com Amazon Messenger: Search “wellvow” in your order history to message us directly This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to tr…

Text truncated - open the document above for the full version.

Shenzhen Hantang Technology Co., Ltd. 2025/12/27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BTTT-W001 [Shenzhen Hantang Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Name: fazhi chen / Business Manager Shenzhen Hantang Technology Co., Ltd. 2025/12/27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BTTT-W001 [Shenzhen Hantang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Name: fazhi chen / Business Manager

Declaration on model difference We The following models of equipment that we manufacture are identical in terms of electrical, mechanical, and physical structure; the only differences are the model name, color, Ultimately, we selected the W001 as the test model. FCCID: 2BTTT-W001 Production name Trade name Model no. WellVow Wled Controller N/A W001,W002,W003,W004, W005,W006 Signature: Date: 2026/01/05 Name: fazhi chen Title: Business Manager Company: Shenzhen Hantang Technology Co., Ltd.

Shenzhen Hantang Technology Co., Ltd. 2025/12/27 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR Product Name: WellVow Wled Controller FCCID: 2BTTT-W001 Model(s): W001,W002,W003,W004,W005,W006 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : fazhi chen / Business Manager Contact information / address: Shenzhen Hantang Technology Co., Ltd./ Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen, Guangdong,China,518108

Shenzhen Hantang Technology Co., Ltd. 2025/12/27 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION Product Name: WellVow Wled Controller FCCID: 2BTTT-W001 Model(s): W001,W002,W003,W004,W005,W006 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : fazhi chen / Business Manager Contact information / address: Shenzhen Hantang Technology Co., Ltd./ Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen, Guangdong,China,518108

External Photos W001 W002 W003

W004 W005

W006

Material: Laser Engraving Size:20mm*20mm FCC ID: 2BTTT-W001 Model: W001 Label location

Internal Photos W001 ANT W002 ANT W003 ANT W004 ANT W005 ANT W006 ANT

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512480H01 Issued for Shenzhen Hantang Technology Co., Ltd. Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Name: WellVow Wled Controller Brand Name: WellVow Model Name: W001 Series Model(s): W002,W003,W004,W005,W006 FCC ID: 2BTTT-W001 Test Standard: FCC 47CFR §2.1091 Page 2 of 7 Report No.: STS2512480H01 TEST REPORT Applicant’s Name ................. : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Manufacturer's Name ........... : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Description Product Name ........................ : WellVow Wled Controller Brand Name ........................... : WellVow Model Name .......................... : W001 Series Model(s) ...................... : W002,W003,W004,W005,W006 Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 2025-12-19 Date (s) of performance of tests ........................................................ : 2025-12-19 to 2025-12-24 Date of Issue .......................................... : 2025-12-24 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 7 Report No.: STS2512480H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 7 Page 4 of 7 Report No.: STS2512480H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-24 STS2512480H01 ALL Initial Issue Page 5 of 7 Report No.: STS2512480H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name WellVow Wled Controller Brand Name WellVow Model Name W001 Series Model(s) W002,W003,W004,W005,W006 Model Difference The following models of equipment that we manufacture are identical in terms of electrical, mechanical, and physical structure; the only differences are the model name, color, and output ports. Ultimately, we selected the W001 as the test model. Product Description The EUT is WellVow Wled Controller Operation Frequency: 2402~2480 MHz Radio Technology: BR+EDR Bluetooth Configuration: GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) 2.87 Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802.11n40:2422~2452MHz Modulation Type: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Bit Rate of Transmitter: 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz): 65/58.5/52/39/26/19.5/13/6.5Mbps 802.11n(40MHz): 135/121.5/108/81/54/40.5/37/13.5Mbps Number of Channel: 802.11b/g/n20: 11CH 802.11n 40: 7CH Antenna Type: Internal antenna Antenna Gain (dBi): 287 Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE(Support 1M) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) 2.87 Power Rating DC 12-36V Page 6 of 7 Report No.: STS2512480H01 Adapter N/A Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1.34-30 824/f 2.19/f *(180f²) 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, t…

Text truncated - open the document above for the full version.

OTA TEST REPORT TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in ANSI/IEEE Std 149-2008. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 Applicant Espressif Systems (Shanghai) Co.,Ltd. Product ESP32-PICO-mini-02 Model ESP-ANT D Report No. Y2008A0669-T1 Issue Date August 12, 2020 OTA Test Report Report No: Y2008A0669-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 2 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENTS 1. Test Laboratory .............................................................................................................................. 3 1.1. Notes of the Test Report ................................................................................................... 3 1.2. Testing Location ................................................................................................................ 3 1.3. Laboratory Environment .................................................................................................... 3 2. General Description of Equipment under Test ............................................................................... 4 2.1. Applicant and Manufacturer Information ............................................................................ 4 2.2. General information ........................................................................................................... 4 2.3. Test Date ........................................................................................................................... 4 2.4. Applied Standards ............................................................................................................. 5 3. Test Conditions .............................................................................................................................. 6 3.1. Test Configuration ............................................................................................................. 6 3.2. Test Measurement ............................................................................................................. 6 4. Test Results ................................................................................................................................... 7 4.1. Gain and Efficiency ............................................................................................................ 7 5. Equipment List ............................................................................................................................... 8 ANNEX A Pattern Plots ............................................................................................................................ 9 ANNEX B：The EUT Appearance and Test Configuration ................................................................. 11 B.1 EUT Appearance ................................................................................................................. 11 Picture 1: Constituents of EUT ................................................................................................. 11 B.2 Test Setup ............................................................................................................................ 12 OTA Test Report Report No: Y2008A0669-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 3 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Testing Location Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] 1.3. Laboratory Environment Temperature Min. =19°C，Max. = 25°C Relative humidity Min. =40%，Max. =72% Shield effect 0.7-6GHz > 100dB Ground resistance <0.5 OTA Test Report Report No: Y2008A0669-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 4 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2. General Description of Equipment under Test 2.1. Applicant and Manufacturer Information Applicant Name Espressif Systems (Shanghai) Co.,Ltd. Applicant address Suite 204, Block 2, 690 Bibo Road, Zhang Jiang Hi-Tech Park, Shanghai, China Manufacturer Name Espressif Systems (Shanghai) Co.,Ltd. Manufacturer address Suite 204, Block 2, 690 Bibo Road, Zhang Jiang Hi-Tech Park, Shanghai, China 2.2. General information EUT Description Product Name: ESP32-PICO-mini-02 Model ESP-ANT D Antenna Type: PCB Antenna Test Frequency: 2400MHz ~ 2483.5MHz Test lab. of the antenna gain and radiation pattern measurement: TA Technology (Shanghai) Co., Ltd. 2.3. Test Date The test is performed on August 10, 2020. . OTA Test Report Report No: Y2008A0669-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 5 of 12 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2.4. Applie…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512480W01 Issued for Shenzhen Hantang Technology Co., Ltd. Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Name: WellVow Wled Controller Brand Name: WellVow Model Name: W001 Series Model(s): W002,W003,W004,W005,W006 FCC ID: 2BTTT-W001 Test Standards: FCC Part15.247 Page 2 of 44 Report No.: STS2512480W01 TEST REPORT Applicant’s Name ................. : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Manufacturer's Name ........... : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Description Product Name ........................ : WellVow Wled Controller Brand Name ........................... : WellVow Model Name .......................... : .. : W001 Series Model(s) .................... : W002,W003,W004,W005,W006 Test Standards ..................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ......................................................... : 2025-12-19 Date (s) of performance of tests ............................... : 2025-12-19 to 2025-12-24 Date of Issue .......................................... : 2025-12-24 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 44 Report No.: STS2512480W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.6 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS 21 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 Page 4 of 44 Report No.: STS2512480W01 Table of Contents Page 6.4 EUT OPERATION CONDITIONS 28 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX 1-TEST DATA 32 DUTY CYCLE 32 MAXIMUM CONDUCTED OUTPUT POWER 32 -6DB BANDWIDTH 34 MAXIMUM POWER SPECTRAL DENSITY LEVEL 38 BAND EDGE 40 CONDUCTED RF SPURIOUS EMISSION 42 APPENDIX 2- EUT TEST PHOTO 44 Page 5 of 44 Report No.: STS2512480W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-24 STS2512480W01 ALL Initial Issue Page 6 of 44 Report No.: STS2512480W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 44 Report No.: STS2512480W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 44 Report No.: STS2512480W01 2. GENERAL …

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512480W03 Issued for Shenzhen Hantang Technology Co., Ltd. Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Name: WellVow Wled Controller Brand Name: WellVow Model Name: W001 Series Model(s): W002,W003,W004,W005,W006 FCC ID: 2BTTT-W001 Test Standards: FCC Part15.247 Page 2 of 81 Report No.: STS2512480W03 TEST REPORT Applicant’s Name ................. : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Manufacturer's Name ........... : Shenzhen Hantang Technology Co., Ltd. Address ................................. : Room 212,No.135 Shihuan Road Longteng Community ShiyanSubdistict Baoan District,ShenZhen,Guangdong,China,518108 Product Description Product Name ........................ : WellVow Wled Controller Brand Name ........................... : WellVow Model Name .......................... : W001 Series Model(s) .................... : W002,W003,W004,W005,W006 Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test S…

Text truncated - open the document above for the full version.
