2BTW7-AI201Wisdom Twin Dual-Screen Translator

產品圖示 操作說明 開/關機 長按電源鍵，可進行開機或關機操作。 80mm 120mm 產品使用手冊 Product manual 註：產品圖片若與實物不符，請以實物為准！ 下拉快捷菜單 從顯示幕頂部下滑打開快捷菜單，可以進行音量調節、螢幕亮度 調節、藍牙開關與設置、WIFI設置。 聯網 使用翻譯功能前，請先連接網路，可通過以下任一方式： ①WIFI連接：從螢幕頂部下滑打開快捷菜單，點擊WIFI設置，選擇 並連接網路。 ②有線連接：插入網線至設備網口，即可聯網。 AI大模型對話翻譯 在首頁點擊“對話翻譯”進入功能頁面，點擊介面下方語言欄，選擇 雙方所用語言，長按麥克風按鈕說話，當說完後鬆開按鈕，會自動 翻譯並朗讀結果。 包裝材料 保持原包裝盒和防護緩衝材料，以備將來搬家或者需要郵寄本設備 進行維修等時使用。 (1)該環保使用期限只適用於產品在用戶手冊上所規定的條件下使 用。 環保標識年限表 檢查更新 當新版本軟體發佈時，點擊“檢查更新”按鈕可進行線上升級。 包裝材料清單 翻譯機*1、數據線*1、說明書*1、包裝盒*1 產品參數 產品參數 語音功能 採用雙麥陣列數字麥克風，基於Beamforming定向增強技術： ①有效提升說話者方向的監聽靈敏度； ②可以有效地抑制環境中的雜訊和混響，音頻品質顯著提升； ③大大提高雜訊環境下的語音識別準確度。 產品名稱：智會雙子 台式雙屏多語種翻譯機 產品貨號：AI-201 使用方法：見說明書 執行標準：GB 4943.1-2022 質檢證明：合格 製造商：寧波貝髮合禮文化有限公司 地址：寧波北崙小港緯六路68號 售後電話：+86 755 86978812 本產品及相關文件上印製的「 」商標及相關版權皆屬寧波貝髮合禮文化有限 公司；未經合法授權而使用和複製，將依法追究其法律責任。 解析度：1024*600 IPS LCD：雙7英寸觸摸屏 揚聲器：2*4歐3W 語音對話：雙矽麥 BT： 4.0 WIFI：2.4G/5G 介面：Type-C，支持充電、數據傳輸 電池：5000mAh 操作系統：Android 9.0 產地：中國深圳 智會雙子 台式雙屏多語種翻譯機 電池保養建議 ①完全放電的電池通常可迴圈充電約1000次（視使用條件和環境 略有差異）。 ②若充滿電後的使用時間下降至初期的一半，建議更換電池，請 諮詢售後服務人員。 ③若長時間不使用設備，建議每三個月為電池充一次電，防止過 度放電導致電池損壞。 操作與安全 在使用本設備的過程中，請遵循使用安全和注意事項正確使用本 設備，避免造成人身傷害和物品損壞。 (1)為了減少火災或者電池損壞的危險，請不要讓本設備淋雨或者 受潮。 (2)為了減少火災發生的風險，請勿使用，毛毯、被褥等易燃物品 覆蓋本設備。 (3)為了防止設備損壞，嚴禁私自拆開設備，維修請諮詢設備售後 服務部。 (4)請勿在設備過熱情況下使用。 (5)請勿使用任何非指定的電源適配器，這可能會造成設備故障。 (6)溫度-20°C~+55°C範圍記憶體放產品及其配件，當環境溫度過 高或過低時，可能會引起設備故障。 保修說明注意事項 保修憑證 請將此保修卡妥善保存，若保修卡遺失恕不補發。產品故障維修時需要出示 此卡，若您無法提供保修卡或相關購買憑證，則產品保修期起算起將以產品 序列號對應的出廠日期為准。 保修條款 本產品自購買之日起一年內，在用戶按照用戶手冊正常操作使用的前提下， 如出現非人為故障，可享受免費保修服務。 申請保修時，請用戶提供有效的購買憑證，並聯系當地經銷商，由其協助與 廠家對接維修事宜。 保修範圍 (1)本保修協議適用於銷售的雙屏翻譯機主機設備。 (2)數據線等易損配件不屬於本產品保修範圍。 下列情況主機不在免費保修範圍內，但仍提供維修服務，用戶需要支付維修 費用： (1)超過保修期； (2)本產品售出後人為原因造成的損壞； (3)不按正確方法操作或保管； (4)未經授權用戶自行拆開機器進行維護修理； (5)浸泡、損壞或者燃燒電路板； (6)正常磨損導致產品外觀有損傷、劃傷、損壞等情況； (7)地震、火災等不可抗拒因素造成的損壞； (8)與產品無關的其他原因所致。 充電說明 ①建議使用5V/3A電源適配器為設備充電。 ②充電時電源指示燈為紅色，充滿電後指示燈變為藍色。 安全資訊 電池充電和保護 本設備使用內置可充電電池，充電與維護需注意以下事項： 產品RoHS聲明 溫度提示 ①由於電池特性，低溫環境（<5°C）下充電時間將延長。 ②建議在5°C至35°C環境中進行充電，以確保效率與安全。 產品名稱 環保使用期限 整機 數據線 印刷品、包裝 (2)環保使用期限的起始日期以產品的生產日期為准，部分無法從 產品本身直接查詢生產日期的配件則以整機的生產日期為准，電子 電氣產品中的有害物質在正常使用的條件下不會發生外泄或突變， 用戶使用該電子資訊產品不會對環境造成嚴重污染或對其人身、財 產造成嚴重傷害。 產品保固卡 ·姓名： ·郵件： ·電話： ·地址： 用戶資訊 ·產品名稱： ·產品條碼： ·產品型號： ·購買日期： 產品資訊 ·送修日期： ·維修記錄： ·故障描述： 維修明細 關於廢棄設備的處理 請不要將廢棄的設備與一般生活垃圾一同棄置。正確地處置廢 棄的產品有助於避免對環境和人類健康造成潛在的負面影響。 具體的處理方法請遵循當地的規章制度。 Product Icon Operating Instructions Power on/off Long press the power button to turn the device on or off. Packaging materials Keep the original packaging box and protective cushioning materials in case you need to move or mail the device for repair, etc. (1) The environmental protection use period only applies when the product is used under the conditions specified in the user manual. Environmental Labeling Years Table Drop-down shortcut menu Swipe down from the top of the screen to open the quick menu, where you can adjust the volume, screen brightness, Bluetooth switch and settings, and WIFI settings. Networking Before using the translation function, please connect to the Internet first. You can use any of the following methods: ①WIFI connection: Swipe down from the top of the screen to open the quick menu, tap WIFI settings, select and connect to the network. ②Wired connection: Plug the network cable into the device's network port to connect to the Internet. AI large model dialogue translation On the homepage, click "Dialogue Translation" to enter the function page, click the language bar at the bottom of the interface, select the language used by both parties, press and hold the microphone button to speak, and release the button when you are finished speaking, and the result will be automatically translated and read aloud. Check for updates When a new version of the software is released, click the "Check for Updates" button to upgrade online. Packaging material list Translator*1, data cable*1, instruction manual*1, packaging box*1 Battery care advice ① A fully discharged battery can usually be cycled for about 1,000 times (depending on the usage conditions and environment). ② If the usage time after full charge drops to half of the initial time, it is recommended to replace the battery. Please consult after-sales service personnel. ③ If the device is not used for a long time, it is recommended to charge the battery once every three months to prevent over-discharge from causing battery damage. Warranty Instructions Notes Warranty certificate Please keep this warranty card properly. If the warranty card is lost, no replacement will be issued. This card is required for product repair. If you cannot provide the warranty card or relevant purchase receipt, the product warranty period will be calculated based on the factory date corresponding to the product serial number. Warranty Terms Within one year from the date of purchase, if the user operates the product normally according to the user manual, free warranty service is available if there is no non-human-caused failure. When applying for warranty, please provide a valid purchase receipt and contact the local dealer, who will assist in the repair with the manufacturer. Warranty coverage (1) This warranty agreement applies to the dual-screen translator host device sold. (2) Data cables and other fragile accessories are not covered by this product warranty. The following situations do not include free warranty coverage, but we still provide repair services and users need to pay for the repairs: (1) Expiration of the warranty period; (2) Damage caused by human factors after the product is sold; (3) Improper operation or storage; (4) Unauthorized users disassemble the machine for maintenance and repair; (5) Circuit boards are soaked, damaged or burned; (6) Normal wear and tear causes damage, scratches, or other damage to the product appearance; (7) Damage caused by force majeure such as earthquakes and fires; (8) Other reasons unrelated to the product. Product RoHS Declaration Safety Information Operation and safety When using this device, please follow the safety instructions and precautions to use the device correctly to avoid personal injury and…

Text truncated - open the document above for the full version.

Vanch(Ningbo) Brand Management Co.,Ltd. Covered Equipment Certification Attestation Letter 3/10/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BTW7-AI201 Vanch(Ningbo) Brand Management Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Vanch(Ningbo) Brand Management Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Vanch(Ningbo) Brand Management Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd. Date: 3/10/2026

Vanch(Ningbo) Brand Management Co.,Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 3/2/2026 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2BTW7-AI201 FRN of applicant: 0037797073 Per section 2.911(d)(7) of the FCC rules, [Vanch(Ningbo) Brand Management Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Herland International Trading Inc FCC Registration Number (FRN): 0036324101 Physical U.S. Company Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Contact Person: Jianfeng Gao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Jack bu Title: Manager Company Name: Vanch(Ningbo) Brand Management Co.,Ltd. Date: 3/2/2026 Agent Signed (if different from Applicant): Signed: Printed name: Jianfeng Gao Title: Manager Company Name: Herland International Trading Inc Date: 3/2/2026

Vanch(Ningbo) Brand Management Co.,Ltd. 2026-02-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen DL Testing Technology Co., Ltd.（101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China）to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Vanch(Ningbo) Brand Management Co.,Ltd.（No. 68, Weiliu Road, Beilun District, Ningbo, 315020, Zhejiang, China） <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd.

Vanch(Ningbo) Brand Management Co.,Ltd. 2026-02-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd.

Vanch(Ningbo) Brand Management Co.,Ltd. 2026-02-25 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BTW7-AI201 Product Name: Wisdom Twin Dual-Screen Translator Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  SOFTWARE SECURITY DESCRIPTION These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd.

Vanch(Ningbo) Brand Management Co.,Ltd. FCC ID: 2BTW7-AI201 Product Similarity Declaration Applicant: Vanch(Ningbo) Brand Management Co.,Ltd. Address: No. 68, Weiliu Road, Beilun District, Ningbo, 315020, Zhejiang, China Manufacturer: Vanch(Ningbo) Brand Management Co.,Ltd. Address: No. 68, Weiliu Road, Beilun District, Ningbo, 315020, Zhejiang, China Product Name: Wisdom Twin Dual-Screen Translator Trade Mark: AITOP Model Number: AI-201, AI-202 We (Vanch(Ningbo) Brand Management Co.,Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except for the model name, appearance color. <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd.

1/1 Vanch(Ningbo) Brand Management Co.,Ltd FCC Software Configuration Control Declaration Date: 2026-02-25 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Company Name: Vanch(Ningbo) Brand Management Co.,Ltd. FCC ID: 2BTW7-AI201 Product Name: Wisdom Twin Dual-Screen Translator Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. <Signature>: Name: Jack Bu Title: Manager Company: Vanch(Ningbo) Brand Management Co.,Ltd.

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 26*23mm Model.: AI-201 FCC ID: 2BTW7-AI201 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ANT Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BTW7-AI201 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) and 2.1091 Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Test Result of RF Exposure Evaluation For BT Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 1.87 1.5382 0.0006 1.0 PASS Remark: antenna gain=3.25dBi For WiFi 2.4G Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 13.33 21.5278 0.0091 1.0 PASS Remark: antenna gain=3.25dBi For WiFi 5.8G Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 1.52 1.4191 0.0009 1.0 PASS Remark: antenna gain=5.05dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.0006/1 + 0.0091/1 + 0.0009/1 = 0.0106< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

深圳华讯视通科技有限公司 Shenzhen Huaxunshitong Technology Co.,Ltd. 2026-3-6 测 试项目Test items 设 备Equipment 1. S参数 （S-1.回波损耗 （Return Loss）网络分析仪: Agilent E5071B parameter）2.电压驻波比（VSWR） H P 8753D 2. 有源测试1.发射功率 （TRP）1.暗室：ETS 7x4x3 m (3D) Chamber （Active ）2.接收灵敏度（TIS） E TS 5x3x3 m (3D) Chamber 2.综合测试仪: Agilent 8960 E5515B ×2 S tarPoint SP6011 3.无源测试1.天线增益 （Gain）1.暗室：ETS 7x4x3 m (3D) Chamber （Passive）2.天线效率 （Efficiency） E TS 5x3x3 m (3D) Chamber 2.网络分析仪：Agilent E5071B H P 8753D 深圳华讯视通科技有限公司 Shenzhen Huaxunshitong Technology Co.,Ltd. 效率与增益 Efficiency and Gain WiFi-2.4G 效率与增益Efficiency and Gain WiFi-2.4G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 效率与增益Efficiency and Gain WiFi-5G 结构图纸Structural Drawings 深圳华讯视通科技有限公司 Shenzhen Huaxunshitong Technology Co.,Ltd. Thanks！

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260210020R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 53 FCC Part 15E Test Report FCC ID: 2BTW7-AI201 Applicant: Vanch(Ningbo) Brand Management Co.,Ltd. Address: No. 68, Weiliu Road, Beilun District, Ningbo, 315020, Zhejiang, China Manufacturer: Vanch(Ningbo) Brand Management Co.,Ltd. Address: No. 68, Weiliu Road, Beilun District, Ningbo, 315020, Zhejiang, China Product Name: Wisdom Twin Dual-Screen Translator Trade Mark: AITOP Model Number: AI-201, AI-202 Date of Receipt: Feb. 10, 2026 Test Date: Feb. 10, 2026 - Mar. 16, 2026 Date of Report: Mar. 16, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 E 15.407 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-260210020R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260210020R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 53 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~40GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 26 3.3.1 TEST REQUIREMENT: 26 3.3.2 TEST PROCEDURE 26 3.3.3 DEVIATION FROM TEST STANDARD 26 3.3.4 TEST SETUP 27 3.3.5 EUT OPERATING CONDITIONS 27 4 . AVERAGE OUTPUT POWER 30 4.1 APPLIED PROCEDURES / LIMIT 30 4.1.1 TEST PROCEDURE 30 4.1.2 DEVIATION FROM STANDARD 30 4.1.3 TEST SETUP 30 4.1.4 EUT OPERATION CONDITIONS 30 4.1.5 TEST RESULTS 31 5 . POWER SPECTRAL DENSITY TEST 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . 6DB BANDWIDTH TEST 40 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260210020R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 53 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 40 6.1.1 TEST PROCEDURE 40 6.1.2 DEVIATION FROM STANDARD 40 6.1.3 TEST SETUP 40 6.1.4 EUT OPERATION CONDITIONS 40 6.1.5 TEST RESULTS 41 7 . DUTY CYCLE TEST SIGNAL 45 7.1 APPLIED PROCEDURES / LIMIT 45 7.1.1 TEST PROCEDURE 45 7.1.2 DEVIATION FROM STANDARD 45 7.1.3 TEST SETUP 45 7.1.4 EUT OPERATION CONDITIONS 45 7.1.5 TEST RESULTS 46 8 . FREQUENCY STABILITY 50 8.1 APPLIED PROCEDURES / LIMIT 50 8.1.1 TEST PROCEDURE 50 8.1.2 DEVIATION FROM STANDARD 50 8.1.3 TEST SETUP 50 8.1.4 EUT OPERATION CONDITIONS 50 8.1.5 TEST RESULTS 51 9 . TRANSMISSION IN THE ABSENCE OF DATA 53 9.1 STANDARD REQUIREMENT 53 9.2 TEST RESULT 53 10 . ANTENNA REQUIREMENT 53 10.1 STANDARD REQUIREMENT 53 10.2 EUT ANTENNA 53 11 . TEST SEUUP PHOTO 53 12 . EUT PHOTO 53 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260210020R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 53 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.407(b), 15.209 Radiated Spurious Emission PASS 15.407 (b) Band Edge Emission PASS 15.407 (a) Average Output Power PASS 15.407 (a) Power Spectral Density PASS 15.407(e) 6dB bandwidth PASS 15.407(g) Frequency Stability PASS 15.407(c) Transmission in case of Absence of Information PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1. MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 Bandwidth ±0.2% 9 Power Spectral Density ±2.45dBm 10 Frequency Stability ±0.3MHz 11 DUTY CYCLE ±0.53dB Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260210020R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 53 2.. GENERAL INFORMATION 2.1. GENERAL DESCRIPTION OF EUT Product Name: Wisdom Twin Dual-Screen Translator Trade Mark: AITOP Model Number: AI-201, AI-202 Test Model: AI-201 Model Difference All models are same as the samples except model name and appearance color,…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
