2BTXT-PETTI002Pettichat

INSTRUCTION Search and download PettiChat mobile app from App Store, Google Play, or pettichat.com. 1 2 Create your PettiChat account — tap Sign Up and follow the steps. 3 Take out the device and press the Power Button for 1 second. When you hear the start voice prompt, the device is on. Getting Started Press the power button The device will automatically enter Wi-Fi setup mode, accompanied by a voice prompt. Open the PettiChat App to complete your pet profile setup and network configuration. 4 5 Getting Started After the setup is completed, the device will automatically restart and get everything ready. You can then clip the device onto your pet’s collar or clothing. 7 You can check the chat history and your pet’s location in the app. You can also change your pet’s voice and character settings. 6 Start using PettiChat! When your pet makes a sound, PettiChat will translate it into a human-like voice. You may also start a conversation by using the wake-up word. "Hello, Hello" + your pet's name ( e.g., "Hello, hello, Pipi!" ) How to clip Functions Pet sound translation When your pet vocalizes or performs certain recognizable actions, the device detects the patterns and converts them into human-like speech using PettiChat algorithms, then plays the message through the device. Pet conversation Say “Hello Hello” followed by your pet’s name (e.g., “Hello Hello Pipi”) to start chatting with your pet. Pet tracking The device can locate your pet with an accuracy of around 5 meters. Battery life in tracking-only mode lasts up to 4 days. 1 2 3 Technical Specifications Dimensions 46 mm × 34 mm × 18 mm Weight 27.2 g Protection IP56 12 3 Battery 280 mAh 4 Charging Input DC 5V, 140 mA 5 Charging Cable Magnetic charging cable 6 Power On/Off Short press for wake up/interrupt Long press for reset Wi-Fi Warnings Do not force your pet to wear the device. It is not a training or punishment tool. Do not use it for shocking, restraining, or any harmful purpose. Stop using immediately if your pet shows discomfort or strong resistance to the sound or light. The device is not bite-proof. Prevent pets from chewing or swallowing any parts. Avoid using the device in extreme temperatures or strong magnetic environments (e.g., dryers, microwaves, magnets). Do not disassemble or modify the device, as it may affect performance or cause hazards. 1 2 3 4 Warnings Use only original charging accessories, and avoid charging in humid environments. While the device is water-resistant, long-term immersion is not recommended. Translation results are based on sound-pattern recognition and algorithmic inference. They are not 100% accurate and should be interpreted reasonably. Translation results cannot replace medical diagnostics. 5 6 7 8 Warnings Location accuracy may vary due to environmental or signal factors. Do not rely on the device as the only method for preventing loss; it does not replace proper supervision. Conversation simulation is for entertainment and companionship only. It should not be interpreted as your pet’s actual intent. Keep the device and small parts out of reach of children to avoid accidental swallowing. 9 10 11 FCC STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. FCC STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This devic…

Text truncated - open the document above for the full version.

Rev1/26/2023 (HangzhouPettichatTechnologyCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:1/28/2026 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2BTXT-PETTI002 [HangzhouPettichatTechnologyCo.,Ltd.]certifiesthattheequipmentforwhichauthorizationissought isnot“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection 2.903oftheFCCrules. [HangzhouPettichatTechnologyCo.,Ltd.](“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovidedby KasperskyLab,Inc.oranyofitssuccessorsandassignees,includingequipmentwithintegratedKaspersky Lab,Inc.(oranyofitssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24- 886andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, JiachunDu/CTO Rev1/26/2023 (HangzhouPettichatTechnologyCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:1/28/2026 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2BTXT-PETTI002 [HangzhouPettichatTechnologyCo.,Ltd.](“theapplicant”)certifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityorany ofitssubsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature) (Applicantprintedname):JiachunDu/CTO

HangzhouPettichatTechnologyCo.,Ltd. Date:2026-1-28 DearSir/Madam, We,HangzhouPettichatTechnologyCo.,Ltd.Herebydeclaresthe,followingstatement Productname:Pettichat Modelno.:PETTI-002,PETTI PCBboard,circuit,structureandinternalofthesemodel(s)arethesame,Onlymodel numberandcoloraredifferentforthesemodel: Sincerely, Name/Title:JiachunDu/CTO Company:HangzhouPettichatTechnologyCo.,Ltd. Address:Room503B,BuildingA5,No.2-150YunlianRoad,YuhangDistrict,Hangzhou, China Phone:+8618868110080 E-Mail:[email protected]

HangzhouPettichatTechnologyCo.,Ltd. Date：2026-1-28 ProductModelNumber:PETTI-002,PETTI FCCID：2BTXT-PETTI002 Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C. CanadaV5J5K5toactonourbehalfonallmattersconcerningtheabove namedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformation relatedtotheapprovalprojecttotheappliedcertificationbodyandtothe notificationentitiesandtodiscussanyissuesconcerningtheapproval application.AnyandallactscarriedoutbyQAILaboratoriesLtd.onour behalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:JiachunDu/CTO Email:[email protected] Telephone:+8618868110080 Onbehalfof:HangzhouPettichatTechnologyCo.,Ltd.

HangzhouPettichatTechnologyCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:January28,2026 Subject;RequestforConfidentiality FCCID:2BTXT-PETTI002 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:JiachunDu Title:CTO

Zhejiang Hengke Industrial Co., Ltd. No. 1555 Jiashan Avenue, Dayun Town, Jiashan County, Jiaxing City, Zhejiang Province Antenna Specification Customer Name Project Name IPET Working Band 2.4G Description FPC Version V1.0 Date 2025.11.03 Project Information Tuning Instrument Network AnalyzerAgilent E5071C Frequency Range 100KHz ~ 8.5GHz TestItem Return Loss/VSWR/Smith Chart /Isolation Typical Setup for Test System Combined-Axes System Anechoic Chamber +X +Y +Z Combined-Axes System Comment: E1 plane means XZ section, E2 plane means YZ section, H plane means XY section. Test Result -Passive FrequencyEfficiencyGain . dB 240000000043%1.32 241000000043%1.40 242000000043%1.38 243000000043%1.24 244000000042%1.27 245000000042%1.22 246000000042%0.94 247000000042%0.95 248000000041%0.88 249000000040%0.87 250000000040%0.85 size Copper foil Gold plating Product shape Release liner slot Release liner 3M adhesive PI layer AD adhesive Copper foil Oil layer Total product thickness (excluding release liner) = 0.11mm ± 0.03 浙江恒科实业有限公司 assive data - directional pattern

AnnexA ExternalPhotos TestModelNo.:PETTI-002 Page 1 of4 AnnexA ExternalPhotos TestModelNo.:PETTI-002 Page 2 of4 AnnexA ExternalPhotos TestModelNo.:PETTI-002 Page 3 of4 AnnexA ExternalPhotos TestModelNo.:PETTI-002 Page 4 of4

Size:15*10mm FCCID:2BTXT-PETTI002

AnnexB ExternalPhotos TestModelNo.:PETTI-002 Page 1 of3 AnnexB ExternalPhotos TestModelNo.:PETTI-002 Page 2 of3 FPCantenna AnnexB ExternalPhotos TestModelNo.:PETTI-002 Page 3 of3

MAXLAB Testing Co.,Ltd.Report No.: MAX25100118P01-R02RF RF TEST REPORT Report Reference No. ....................... : MAX25100118P01-R02 RF FCC ID.................................................:2BTXT-PETTI002 Compiled by ( position+printed name+signature) .. : Engineer/ Cindy Zheng Supervised by ( position+printed name+signature)..: Manager/Haley Wen Approved by ( position+printed name+signature)..: RF Manager/ Vivian Jiang Date of issue.........................................:January 19, 2026 Testing Laboratory Name................:MAXLAB Testing Co.,Ltd. Address ................................................. : 1/F, Building B, Xinshidai GR Park,Shiyan Street, Bao'an District, Shenzhen,Guangdong, 518052, People’s Republic of China Applicant’s name...............................:Hangzhou Pettichat Technology Co., Ltd. Address ................................................. : Room 503B, Building A5, No.2-150 Yunlian Road, Yuhang District, Hangzhou, China Test specification .............................. : Standard ................................................ :FCC 1.1310 MAXLAB Testing Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the MAXLAB Testing Co.,Ltd.is acknowledged as copyright owner and source of the material. MAXLAB Testing Co.,Ltd.takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ........................ : Pettichat Trade Mark............................................:Pettichat Manufacturer.........................................:Compupal (Group) Corporation Model/Type reference.........................:PETTI-002 Listed Models ...................................... :PETTI Modulation Type ................................... :GFSK CCK/ DSSS/ OFDM Operation Frequency .......................... :From 2412-2462MHz From 2402-2480MHz Rating.....................................................:DC 3.7V From Battery or DC 5V by USB port Result ..................................................... :PASS MAXLAB Testing Co.,Ltd.Report No.: MAX25100118P01-R02RF RF EXPOSURE EVALUATION METHOD According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) EUT Specification Frequency band (Operating)WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.150GHz ~ 5.250GHz WLAN: 5.725GHz ~ 5.850GHz Others BT:2402-2480MHz Device categoryPortable (<20cm separation) Mobile (>20cm separation) Others Antenna diversitySingle antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power7.97 dBm (0.00627W) Antenna gain (Max)1.40 dBi Evaluation appliedMPE Evaluation SAR Evaluation MAXLAB Testing Co.,Ltd.Report No.: MAX25100118P01-R02RF RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. MAXLAB Testing Co.,Ltd.Report No.: MAX25100118P01-R02RF Maximum measured transmitter power. Operating Mode Freque ncy Measur ed Power max. power Antenna Gain min. test separation distance [√f(GHz)] ResultLimit (MHz)(dBm)(mW)(dBi)(mm) 802.11b 24127.295.361.4051.5531.66433 24377.936.211.4051.5611.93853 24627.976.271.4051.5691.96643 802.11g 24125.963.941.4051.5531.22523 24375.653.671.4051.5611.14673 24625.903.891.4051.5691.22093 802.11n (HT20) 24124.542.841.4051.5530.88353 24374.572.861.4051.5610.89423 24624.863.061.4051.5690.96093 GFSK 24023.972.491.4051.5500.77323 24403.132.061.4051.5620.64233 24803.062.021.4051.5750.63723 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion:No SAR is required.

MAXLABTestingCo.,Ltd. ReportNo.:MAX25100118P01-R01 Page 1 of30 FCCPART15SUBPARTCTESTREPORT FCCPART15.247 ReportReferenceNo........................:MAX25100118P01-R01 FCCID.................................................:2BTXT-PETTI002 Compiledby (position+printedname+signature)..: Engineer/CindyZheng Supervisedby (position+printedname+signature) .. : Manager/HaleyWen Approvedby (position+printedname+signature)..: RFManager/VivianJiang Dateofissue ......................................... :January22,2026 TestingLaboratoryName ................ : MAXLABTestingCo.,Ltd. Address ................................................. : 1/F,BuildingB,XinshidaiGRPark,ShiyanStreet,Bao'anDistrict, Shenzhen,Guangdong,518052,People’sRepublicofChina Applicant’sname...............................: HangzhouPettichatTechnologyCo.,Ltd. Address.................................................: Room503B,BuildingA5,No.2-150YunlianRoad,YuhangDistrict, Hangzhou,China Testspecification..............................: Standard................................................: FCCPart15.247 MAXLABTestingCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe MAXLABTestingCo.,Ltd.isacknowledgedascopyrightownerandsourceofthematerial.MAXLAB TestingCo.,Ltd.takesnoresponsibilityforandwillnotassumeliabilityfordamagesresultingfromthe reader'sinterpretationofthereproducedmaterialduetoitsplacementandcontext. Equipmentdescription.....................: Pettichat TradeMark ............................................ : Pettichat Manufacturer ......................................... :Compupal(Group)Corporation Model/Typereference.........................:PETTI-002 ListedModels......................................: PETTI Modulation ........................................... :GFSK Frequency..............................................From2402MHzto2480MHz Ratings ................................................... :DC3.7VFromBatteryorDC5VbyUSBport Result.....................................................:PASS MAXTestingCo.,Ltd. ReportNo.:MAX25100118P01-R01 Page2of30 TESTREPORT EquipmentunderTest:Pettichat Model/Type:PETTI-002 ListedModels:PETTI ModelDeclaration:Allthemodelsareelectricalidenticalincludingthesamesoftware parameterandhardwaredesign,samemechanicalstructureand design,theonlydifferenceisthemodelnameddifferent. Applicant : HangzhouPettichatTechnologyCo.,Ltd. Address: Room503B,BuildingA5,No.2-150YunlianRoad,YuhangDistrict, Hangzhou,China Manufacturer : Compupal(Group)Corporation Address: No.1555JiashanAvenue,Jiashan,314113,Zhejiang,China. TestResult:PASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. MAXTestingCo.,Ltd. ReportNo.:MAX25100118P01-R01 Page3of30 Contents 1TESTSTANDARDS..............................................................................................................................4 2SUMMARY.................................................................................................................................................5 2.1GeneralRemarks..........................................................................................................................................5 2.2ProductDescription.....................................................................................................................................5 2.3EquipmentUnderTest.................................................................................................................................5 2.4ShortdescriptionoftheEquipmentunderTest(EUT).............................................................................5 2.5EUToperationmode.....................................................................................................................................6 2.6BlockDiagramofTestSetup.......................................................................................................................6 2.7RelatedSubmittal(s)/Grant(s)...................................................................................................................6 2.8Modifications...............................................................................................................................................6 3TESTENVIRONMENT........................................................................................................................7 3.1Addressofthetestlaboratory....................................................................................................................7 3.2TestFacility...................................................................................................................................................7 3.3Environmentalconditions............................................................................................................................7 3.4Summaryofmeasurementresults..............................................................................................................8 3.5Statementofthemeasurementuncertainty..............................................................................................8 3.6EquipmentsUsedduringtheTest..............................................................................................................9 4TESTCONDITIONSANDRESULTS.......................................................................................11 4.1ACPowerConductedEmission................................................................................................................11 4.2RadiatedEmissionsandBandEdge........................................................................................................14 4.3MaximumPeakOutputPower...................................................................................................................21 4.4PowerSpectralDensity..........................................................................................…

Text truncated - open the document above for the full version.

Page 1 of34 MAXLABTestingCo.,Ltd. ReportNo.:MAX25100118P01-R02 FCCPART15SUBPARTCTESTREPORT FCCPART15.247 ReportReferenceNo. ....................... :MAX25100118P01-R02 FCCID. ................................................ :2BTXT-PETTI002 Compiledby (position+printedname+signature) .. : Engineer/CindyZheng Supervisedby (position+printedname+signature)..: Manager/HaleyWen Approvedby (position+printedname+signature) .. : RFManager/VivianJiang Dateofissue.........................................:January22,2026 TestingLaboratoryName................:MAXLABTestingCo.,Ltd. Address ................................................. : 1/F,BuildingB,XinshidaiGRPark,ShiyanStreet,Bao'anDistrict, Shenzhen,Guangdong,518052,People’sRepublicofChina Applicant’sname...............................:HangzhouPettichatTechnologyCo.,Ltd. Address.................................................: Room503B,BuildingA5,No.2-150YunlianRoad,YuhangDistrict, Hangzhou,China Testspecification..............................: Standard ................................................ : FCCPart15.247 KDB558074D0115.247MeasGuidancev05r02 ANSIC63.10:2020 MAXLABTestingCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongastheMAXLAB TestingCo.,Ltd.isacknowledgedascopyrightownerandsourceofthematerial.MAXLABTesting Co.,Ltd.takesnoresponsibilityforandwillnotassumeliabilityfordamagesresultingfromthereader's interpretationofthereproducedmaterialduetoitsplacementandcontext. Testitemdescription........................: Pettichat TradeMark............................................:Pettichat Manufacturer.........................................:Compupal(Group)Corporation Model/Typereference.........................:PETTI-002 ListedModels ...................................... :PETTI ModulationType .................................. :GFSK OperationFrequency..........................:From2412MHzto2462MHz Rating.....................................................: DC3.7VFromBatteryorDC5VbyUSBport Result.....................................................:PASS MAXLABTestingCo.,Ltd. ReportNo.:MAX25100118P01-R02 Page 2 of34 TESTREPORT EquipmentunderTest:Pettichat Model/Type:PETTI-002 SeriesModelNo.PETTI ModelDeclaration:Allthemodelsareelectricalidenticalincludingthesamesoftware parameterandhardwaredesign,samemechanicalstructureand design,theonlydifferenceisthemodelnameddifferent. Applicant : HangzhouPettichatTechnologyCo.,Ltd. Address: Room503B,BuildingA5,No.2-150YunlianRoad,YuhangDistrict, Hangzhou,China Manufacturer : Compupal(Group)Corporation Address: No.1555JiashanAvenue,Jiashan,314113,Zhejiang,China. TestResult:PASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. MAXLABTestingCo.,Ltd. ReportNo.:MAX25100118P01-R02 Page 3 of34 Contents 1TESTSTANDARDS..............................................................................................................................4 2SUMMARY.................................................................................................................................................5 2.1GeneralRemarks..........................................................................................................................................5 2.2ProductDescription.....................................................................................................................................5 2.3EquipmentUnderTest.................................................................................................................................5 2.4ShortdescriptionoftheEquipmentunderTest(EUT).............................................................................5 2.5EUToperationmode.....................................................................................................................................6 2.6BlockDiagramofTestSetup.......................................................................................................................6 2.7RelatedSubmittal(s)/Grant(s)...................................................................................................................6 2.8Modifications.................................................................................................................................................6 3TESTENVIRONMENT........................................................................................................................7 3.1Addressofthetestlaboratory....................................................................................................................7 3.2TestFacility...................................................................................................................................................7 3.3Environmentalconditions............................................................................................................................7 3.4TestDescription............................................................................................................................................8 3.5Statementofthemeasurementuncertainty..............................................................................................8 3.6EquipmentsUsedduringtheTest..............................................................................................................9 4TESTCONDITIONSANDRESULTS.......................................................................................11 4.1ACPowerConductedEmission................................................................................................................11 4.2RadiatedEmission......................................................................................................................................14 4.3MaximumPeakConductedOutputPower...............................................................................................20 4.4PowerSpectralDensity..............…

Text truncated - open the document above for the full version.

FCC ID:2BTXT-PETTI002 FCC ID:2BTXT-PETTI002
