2BU2J-ARGUSAmazon Argus

Amazon ARGUS RFID Reader Datasheet 1. Overview The Amazon ARGUS is a high-performance, 16-port UHF RFID reader designed for fixed installaCons requiring fast, reliable EPC-class tag detecCon. ARGUS integrates the Silion SIM7400 RFID module with a custom interface PCB, providing a streamlined soluCon for inventory tracking, asset monitoring, and real-Cme sensing in enterprise environments. Figure 1 - Amazon ARGUS Assembled Unit 2. System Architecture Below is a high-level overview of Amazon ARGUS: • RFID Module: Silion SIM7400 (Impinj E710-based) • Interface PCB: USB-UART bridge, power regulation, GPIO control • External Connectivity: USB-C for data, DC input for power • Antenna Connectivity: 16 coaxial UHF ports Figure 2 ARGUS Block Diagram 3. Product Descrip:on 3.1 User Interface The front interface provides essential connectivity and status indication: • Status LED: Fully user-programmable indicator for application states or diagnostics • USB-C Connector: Main communication interface to a host PC • DC Power Input: External DC supply input for powering the RFID module and internal electronics Figure 3 Front User Ports The rear panel contains: • Sixteen (16) UHF Antenna Ports: Individually addressable ports enabling multi - zone read coverage. Figure 4 Rear RFID Antenna Ports 3.2 RFID Engine Amazon ARGUS uses the Silion SIM7400 module, a high-performance 16-port UHF reader module based on the Impinj E710 chipset. Key capabilities include: • Protocols Supported: EPC Global Gen2 (ISO 18000-6C) • Transmit Power: Adjustable from 5 dBm to 30 dBm (±1 dBm) • Receiver Sensitivity: -86 dBm • Dense Reader/Anti-Collision Performance: Optimized for high-tag-count environments • Real-Time Telemetry: Temperature, RSSI, antenna detection, and other diagnostics These characteristics make the module suitable for deployments requiring: • Multi-antenna scanning • High-rate tag inventory • Reliable read performance across varying RF conditions Figure 5 Silion SIM7400 RFID Module 3.3 Interface PCB The interface PCB integrates the RFID module with standard host systems and performs all required power and signal management. Figure 6 Interface PCB USB–UART Bridge • FT2232 Dual-Channel USB-UART IC • Provides high-speed UART communication to the SIM7400 module • Exposes additional channels for GPIO and LED control Power Subsystem • Dedicated 5V / 5A regulated power rail • Designed to meet the peak consumption of the SIM7400 during maximum transmit power Silion Interface Header • Power (5V / GND) • UART TX/RX • GPIO lines for module enable, reset, and general control Status LED • Controlled through the FT2232 • User-programmable for read events, errors, or system heartbeat 4. So=ware Integra:on ARGUS communicates with the SIM7400 through a direct serial channel exposed via USB. This allows: • Access to official Silion APIs with no custom driver layer • Simple PC integration with either Java, C, or C#/.NET • Easy implementation of high-level functions including: o Tag inventory o Antenna switching o Region configuration o Power adjustments o Real-time telemetry Because the system uses standard UART-over-USB, it is compatible with most operating systems without additional software requirements beyond Silion’s SDK. 5. Technical Specifica:ons The following specificaCons are derived from the Silion SIM7400 RFID module and apply to the Amazon ARGUS. Figure 7 Technical Specifica2ons FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Amazon Add: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Covered Equipment Certification Attestation Letter Date: 2026-5-21 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BU2J-ARGUS Amazon (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Amazon (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Amazon (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA- 24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Sincerely, Name/Title： Brenton Schoenthaler/Manager Company: Amazon Address: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Phone: (512) 710-6183 Fax: N/A E-Mail: [email protected]

Amazon 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2026/05/22 U.S. Agent Designation Amazon acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BU2J-ARGUS): Name and company of U.S. agent: Amazon Physical U.S. address of agent: 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 FRN of U.S. agent: 0038102521 Phone of U.S. agent: +1-512-710-6183 Email address of U.S. agent: [email protected] Amazon acknowledges their obligation to accept service of process on behalf of Amazon with the FRN [0038102521] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. An expiration date for this letter does not exist. Sincerely, Signature Brenton Schoenthaler Manager Amazon Signature Brenton Schoenthaler Director Amazon 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Amazon Add: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Date: 2026-5-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint SHENZHEN CTA TESTING TECHNOLOGY CO., LTD.,Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community,Fuhai Street, Bao‘an District, Shenzhen, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Amazon,11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States (Applicant Name and address) Sincerely, Name/Title： Brenton Schoenthaler/Manager Company: Amazon Address: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Phone: (512) 710-6183 Fax: N/A E-Mail: [email protected]

Amazon Add: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Date: 2026-5-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Name/Title： Brenton Schoenthaler/Manager Company: Amazon Address: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Phone: (512) 710-6183 Fax: N/A E-Mail: [email protected]

Amazon Add: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Date: 2026-5-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BU2J-ARGUS Product Name: Amazon Argus Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Sincerely, Name/Title： Brenton Schoenthaler/Manager Company: Amazon Address: 11501 Alterra Pkwy, Suite 200,Austin Texas 78758 United States Phone: (512) 710-6183 Fax: N/A E-Mail: [email protected]

FCC ID: 2BU2J-ARGUS External Photos of the EUT ANT FCC ID: 2BU2J-ARGUS FCC ID: 2BU2J-ARGUS FCC ID: 2BU2J-ARGUS

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location

FCC ID: 2BU2J-ARGUS Internal Photos of the EUT FCC ID: 2BU2J-ARGUS FCC ID: 2BU2J-ARGUS FCC ID: 2BU2J-ARGUS FCC ID: 2BU2J-ARGUS

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID............................................. : CTA26011201302 2BU2J-ARGUS Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Apr. 07, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Amazon Address............................................ : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Amazon Argus Trade Mark ........................................ N/A Manufacturer .................................... : Amazon Model/Type reference ...................... : Argus Listed Models ................................... : N/A Rating ............................................... : Input: 12V 4A Result ............................................... : PASS Report No.: CTA26011201302 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Amazon Argus Model /Type : Argus Listed Models : N/A Applicant : Amazon Address : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Manufacturer : Amazon Address : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26011201302 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 MPE Calculation Method ......................................................................................... 7 4.3 Conducted Power Results ....................................................................................... 7 4.4 Manufacturing tolerance .......................................................................................... 8 4.5 Standalone MPE Result ........................................................................................... 8 4.6 Simultaneous Transmission for MPE Result ........................................................... 8 5 Conclusion ........................................................................................................................... 8 Report No.: CTA26011201302 Page 4 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB 447498 D01 Gene…

Text truncated - open the document above for the full version.

Advantenna-p11 ™ RFID UHF wide beam antenna Barcelona London Los Angeles Tel: +34 931 814 477 [email protected] Keonn Technologies S.L. Advantenna-p11 ™ RFID UHF wide beam antenna 2 keonn.com @Keonn Product overview Advantenna-p11 is a compact RFID UHF patch antenna, with a very thin form factor, circular polarization and a radiation pattern characterized by a wide beam in all directions in one hemisphere. This radiation pattern and its thin form factor make this antenna ideal for many RFID applications such as smart shelves, smart displays, smart panels and smart tables or other surfaces. Advantenna-p11 is available in three options: • Without enclosure • With surface mount enclosure • With IP67 enclosure (rugged enclosure) A holder is available for the version without enclosure: AdvanHolder-p11 Additionally, the antenna p11 without enclosure is available in three connector options: Benefits: • Very thin form factor (8 mm with edge mount connector and 15 mm with flange connector) • Good performance • Cost effective • Rugged enclosure available • Surface mount enclosure available Applications: • Smart shelves • Smart panels • Smart tables • Smart surfaces in general Flange right angle connector with rotation Flange straight Default 180 degrees 90 degrees 270 degrees Flange right angle Edge mount Advantenna-p11 ™ RFID UHF wide beam antenna 3 keonn.com @Keonn Technical specifications Operating Frequency EU Version 865 - 868 MHz (ETSI EN 302 208) Operating Frequency US Version902 - 928 MHz (FCC part 15) Antenna TechnologyPatch Radiation patternWide beam in both directions in one hemisphere Gain EU version 3.2 dBiC (Typical), 3.4 dBiC (Max) 0.8 dBiL* US version 3.4 dBiC (Typical), 3.6 dBiC (Max) 1.1 dBiL* VSWR < 1.5:1 (Typical) Beam width (AZ / EL) 100° / 100° Front-to-Back Ratio < -15 dB Polarization Circular - LHCP (Left Hand Circular Polarization) Axial Ratio EU version* At Boresight 0.9 dB At 3dB Beamwidth 1.2 dB (Typical), 3.8 dB (Max) US version* At Boresight 1.5 dB At 3dB Beamwidth 2.1 dB (Typical), 4.5 dB (Max) Input Impedance50 Ω Connector SMA or MCX Flange straight, flange right angle or edge mount Regulation ROHS - EU Directive 2015/863 WEEE - EU Directive 2012/19/EU REACH - EC No 1907/2006 ETSI EN 302 208** IP rating Without enclosure: IP62*** With surface mount enclosure: IP62 With rugged enclosure: IP67 Temperature range-20°C to + 80°C *Measured at the center of the band ** In this case, P11 model, the beam width of the antenna is 100° and therefore the 1000 mW e.r.p limitation applies for the ETSI lower band (865 MHz to 868 MHz) According to the formula PC = Perp – GIC + 5.15 + CL (dBm) Where PC = Interrogator conducted transmit power (dBm) GIC = Antenna gain of a circular antenna (dBiC) CL = Total cable loss (dB) The maximum conducted power PC will be = 31.35 dBm + CL *** IP rating in this case indicates the conditions that the antenna can withstand at specific times and, afterwards, continue working normally, they are not conditions under which it can work permanently. Antenna radiation pattern y x Radiating side Advantenna-p11 ™ RFID UHF wide beam antenna 4 keonn.com @Keonn Mechanical specifications (without enclosure) With flange straight connector (EU/US) With right angle connector (EU/US) Size excluding connector137 mm x 137 mm x 3.3 mm (5.4 in x 5.4 in x 0.13 in) Size with flange connector137 mm x 137 mm x 15 mm (5.4 in x 5.4 in x 0.6 in) Size with edge mount connector137 mm x 137 mm x 8 mm (5.4 in x 5.4 in x 0.3 in) Antenna weight115 g 137 5.394 137 5.394 117 4.606 117 4.606 10.01 0.394 3.30 0.130 R10 0.394 Non radiating side 3.30 0.130 9.51 0.374 A (1 : 1) 2 1 Non radiating side 137 5.394 137 5.394 117 4.606 117 4.606 10.01 0.394 56.95 2.242 3.30 0.130 R10 0.394 Non radiating side 3.30 0.130 14.80 0.583 13.01 0.512 9.76 0.384 2 1 Non radiating side Flange straightFlange right angleEdge mount Units in millimeters and [inches] Advantenna-p11 ™ RFID UHF wide beam antenna 5 keonn.com @Keonn With edge mount connector (EU/US) Mechanical specifications 1 2 Radiating side 137 5.394 117 4.606 9 0.354 117 4.606 137 5.394 3.30 0.130 R10 0.394 Radiating side 3.30 0.130 8.70 0.343 0.76 0.030 4.95 0.195 Flange straightFlange right angleEdge mount Units in millimeters and [inches] Advantenna-p11 ™ RFID UHF wide beam antenna 6 keonn.com @Keonn Product operation (surface mount enclosure) Mechanical specifications (surface mount enclosure) It is intended for indoor operation. It can be installed onto the most common surfaces: wood, concrete, metal, ... All mounting components are included. Check the Installation Guide for a detailed overview of the installation steps. Connect the antenna to any RFID 50 ohm system. Please use only the screws provided with the equipment The equipment shall be fixed using 4 screws M3 x 15 mm for wood and M3 x 25 mm for other surfaces The equipment shall be use in indoor location only Size excluding connector230 mm x 230 mm x 25 mm (9.1 in x 9.1 in x 1.0 in) Antenna weight545 g Units in millimeters and [inches] Advantenna-p11 ™ RFID UHF wide beam antenna 7 keonn.com @Keonn 68 2.677 0. 7 05 R17. 9 1 84.77 6.493 164.91 6.512 165.41 3.337 4.70 0.185 53.50 2.106 53.50 2.106 Mechanical specifications (rugged enclosure) Units in millimeters and [inches] Advantenna-p11 ™ RFID UHF wide beam antenna 8 keonn.com @Keonn Product codes for ordering Examples: ADAN-p11EU-EMSMA-200: • Advantenna-p11 • Frequency band : 865,6 MHz - 867,6 MHz • Without enclosure • Edge mount connector • SMA connector • Model 200 ADAN-p11US-FRSMA-210: • Advantenna-p11 • Frequency band : 902,0 MHz - 928,0 Mhz • Without enclosure • Flange right angle connector • Default connector orientation • SMA connector • Model 210 ADAN-p11EU-FR270SMA-210: • Advantenna-p11 • Frequency band : 865,6 MHz - 867,6 MHz • Without enclosure • Flange right angle connector • Connector rotated 270º counterclockwise • SMA connector • Model 210 ADAN-P11EU-E67-SMA-200: • Advantenna-p11 • Frequency band : 865,6 MHz - 867,6 M…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA26011201301 2BU2J-ARGUS Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Ace Chai Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Apr. 07, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Amazon Address ............................................ : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Amazon Argus Trade Mark ....................................... : N/A Manufacturer .................................... : Amazon Model/Type reference....................... : Argus Listed Models .................................. : N/A Frequency .......................................... From 902.75MHz to 927.25MHz Rating ............................................... : Input: 12V 4A Result................................................ : PASS Report No.: CTA26011201301 Page 2 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Amazon Argus Model /Type : Argus Listed Models : N/A Applicant : Amazon Address : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Manufacturer : Amazon Address : 11501 Alterra Pkwy, Suite 200, Austin, TX 78758 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26011201301 Page 3 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT configuration 6 2.6 EUT operation mode 6 2.7 Block Diagram of Test Setup 6 2.8 Related Submittal(s) / Grant (s) 6 2.9 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 14 4.3 Maximum Peak Output Power 20 4.4 20dB Bandwidth 21 4.5 Frequency Separation 23 4.6 Number of hopping frequency 24 4.7 Time of Occupancy (Dwell Time) 25 4.8 Out-of-band Emissions 27 4.9 Antenna Requirement 31 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 32 6 P H O T O S O F T H E E U T ........................................................... 34 Report No.: CTA26011201301 Page 4 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2020+Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024: American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA26011201301 Page 5 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jan. 12, 2026 Testing commenced on : Jan. 12, 2026 Testing concluded on : Apr. 07, 2026 2.2 Product Description Product Description: Amazon Argus Model/Type reference: Argus Power su…

Text truncated - open the document above for the full version.
