Electronic Calendar Frequently Asked Questions and Solutions I. Solutions for inability to connect to WiFi networks: 1. The WiFi password may have been entered incorrectly. Please enter the correct password. 2. Turn the WiFi switch off and then on again. 3. Restore factory settings. II. USB cable connected to computer but no response Solution: 1. First, check whether the connection cable between the device and the computer is connected. 2. Check whether the USB debugging switch is turned on. III. Solutions for freezing or crashing during operation or startup: 1. Turn off the power and restart. 2. Contact the manufacturer or dealer.。 User manual Contents Preface .............................................................................. Warning................................................................................ Features ............................................................................... Packing list ............................................................................ Product Description (RK3326/ RK3562)............................................. Menu icon function .................................................................. Basic settings ........................................................................ Frequently asked questions and solutions ...................................... Preface Warning Menu icon function Settings Custom function settings, basic settings, network settings Gallery View photos, videos, local videos, and slideshows. YT Music Offers online streaming and download features for songs, albums, playlists, and music videos. Google Play Store Download games and apps. Scheduled power on/off You can set the startup and shutdown times for this device. Introduction to Basic Settings Features YouTube Video sharing, uploading, watching, entertainment, education, music, and more, with live streaming support. Files Read files, images, and videos from USB drives Sound Set media volume, alarm volume, ringtone volume, select ringtone or mute. Application View installed apps Screenshot settings Set screenshot delay, screenshot storage location, and display on status bar (must be selected). Storage You can check the local storage status and remaining space. Memory You can view the memory usage of each application. Location information Used for network positioning. Safety Set the screen lock screen password and unknown source (need to be opened when installing the APP). Account Set up or log in to your account. Google Google, services, location information, and security settings. Language and input method Set the system language, keyboard, and input method. Backup and reset Back up data, accounts, and restore factory settings. Date and time Set the date and time, and select the country time zone. Barrier-free Subtitles, zoom gestures, font size, display size; can be selected in the status bar. Developer options USB debugging (must be selected; a connection prompt will appear in the upper left corner when the data cable is connected). About the equipment You can view the device model, system version number, and status information. Type-C Check the box for PC, connect OTG, and uncheck the box for reading USB flash drives. 2 2 3 3 4 6 7 10 1 678910 234 5 1. Main unit 2. Power adapter 3. Instruction manual System： Network： Interface： Peripheral device： Packing list Check the product packaging box for the following items. Thank you for choosing our Electronic calendar! Before turning on the machine, please read this manual carefully to understand how to use the machine and precautions. Only use the power adapter, power cord, and other accessories provided by the manufacturer. Do not block or cover the ventilation and heat dissipation holes on the machine. Do not use or store this machine in dusty, humid, or high-temperature environ- ments. If the machine malfunctions, do not attempt to disassemble or repair it yourself. Contact the manufacturer or dealer for assistance. Avoid stepping on the power cord or power adapter to prevent damage that could lead to electrical hazards. If the power adapter's wires are damaged, do not continue using it, as this may pose a safety risk. During thunderstorms or when the machine is not in use for an extended period, unplug the power cord. When in use, do not place the machine on the edge of a table or in areas accessible to children to prevent the machine from falling or causing injury to children. Avoid bumping or dropping the display screen during transportation or use. Do not apply excessive force to the display screen or strike it with sharp or hard objects to prevent damage. Use a clean, soft cloth or a soft cloth with a small amount of mild cleaner to gently wipe the Electronic calendar device. Do not use any corrosive solvents such as alcohol, ammonia, or hydrogen peroxide, as this may damage the surface protective coating. ★ ★ ★ ★ ★ ★ ★ ★ ★ Type-C and power ports RK3326 RockChip Quad-core Cortex-A35, 1.5GHz clock speed Android 8.1ystem RK3562 RockChip Quad-core 64-bit processor, up to 2.0GHz clock speed Android 13 system built-in 2x3W speakers Supports 802.11.ax WiFi Browser When connected to the Internet, simply enter the URL to search for the content you need. WIFI Click on the WiFi option, turn on WiFi, select a WiFi network, and enter the correct password to connect. More Contents include flight mode, network sharing and portable hotspot, VPN, reset network settings, Ethernet, and WiFi priority settings. Calculator For easy calculation。 Check the time, set alarms, stopwatches, and countdown timers. Clock Notice Set to turn off or turn on all app notifications. Display Set brightness, wallpaper, sleep time, screen saver, and font size. Calendar Check the date, add a memo. Product description 402.18mm 344.16mm 193.59mm 251.61mm Front view ： Left and right views ： 32.05mm Rear view: Top view ： 4 12 3 VOL+VOL-ON/OFF ②① ③ VESA Power Type-C Cable tray hole 31 X156 This device complies with part 15 of …

Text truncated - open the document above for the full version.

Shenzhen XinPai TechnologyCo.,Ltd. Covered Equipment Certification Attestation Letter 3/10/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BU6N-X156 Shenzhen XinPai TechnologyCo.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhen XinPai TechnologyCo.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Shenzhen XinPai TechnologyCo.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd. Date: 3/10/2026

Shenzhen XinPai TechnologyCo.,Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 3/2/2026 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2BU6N-X156 FRN of applicant: 0038142469 Per section 2.911(d)(7) of the FCC rules, [Shenzhen XinPai TechnologyCo.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Herland International Trading Inc FCC Registration Number (FRN): 0036324101 Physical U.S. Company Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Contact Person: Jianfeng Gao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Jack bu Title: Manager Company Name: Shenzhen XinPai TechnologyCo.,Ltd. Date: 3/2/2026 Agent Signed (if different from Applicant): Signed: Printed name: Jianfeng Gao Title: Manager Company Name: Herland International Trading Inc Date: 3/2/2026

Shenzhen XinPai TechnologyCo.,Ltd. 2026-02-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen DL Testing Technology Co., Ltd.（101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China）to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen XinPai TechnologyCo.,Ltd.（Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City） <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd.

Shenzhen XinPai TechnologyCo.,Ltd. 2026-02-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd.

Shenzhen XinPai TechnologyCo.,Ltd. 2026-02-25 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BU6N-X156 Product Name: electronic calendar Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd.

Shenzhen XinPai TechnologyCo.,Ltd. FCC ID: 2BU6N-X156 Product Similarity Declaration Applicant: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Manufacturer: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Product Name: electronic calendar Trade Mark: N/A Model Number: X156, X801, X102, X103, X1401, X1402, X157, X158, X181, X215, X216, X238, ea15, eb15, ec15 We (Shenzhen XinPai TechnologyCo.,Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except for the model name, appearance color. <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd.

Shenzhen XinPai TechnologyCo.,Ltd. FCC ID: 2BU6N-X156 Product function Declaration Applicant: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Manufacturer: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Product Name: electronic calendar Trade Mark: N/A Model Number: X156, X801, X102, X103, X1401, X1402, X157, X158, X181, X215, X216, X238, ea15, eb15, ec15 We (Shenzhen XinPai TechnologyCo.,Ltd.) here by state that The product has (BT) function at the beginning of design. However, due to the iteration of the product, this function is no longer required at present, so through the (Software mask) method, the function is forced off, and the product (FCC ID: 2BU6N-X156) no longer has the (BT) function. <Signature>: Name: Jack Bu Title: Manager Company: Shenzhen XinPai TechnologyCo.,Ltd.

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Laser label Size: 26*23mm Model.: X156 FCC ID: 2BU6N-X156 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BU6N-X156 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) and 2.1091 Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Test Result of RF Exposure Evaluation For WiFi 2.4G Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 16.20 41.6869 0.0166 1.0 PASS Remark: antenna gain=3.02dBi For WiFi 5.8G Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 13.16 20.7014 0.0066 1.0 PASS Remark: antenna gain=2.06dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.0166/1 + 0.0066/1 = 0.0232< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260130031R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 59 FCC Part 15C Test Report FCC ID: 2BU6N-X156 Applicant: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Manufacturer: Shenzhen XinPai TechnologyCo.,Ltd. Address: Building 401,402,403,404,405,43 C, Lan Er Road, longxin community, Baolong Street, Longgang District, Shenzhen City Product Name: electronic calendar Trade Mark: N/A Model Number: X156, X801, X102, X103, X1401, X1402, X157, X158, X181, X215, X216, X238, ea15, eb15, ec15 Date of Receipt: Jan. 30, 2025 Test Date: Jan. 30, 2025 - Feb. 06, 2026 Date of Report: Feb. 06, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-260130031R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260130031R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 59 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 10 3.1.3 DEVIATION FROM TEST STANDARD 10 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 15 3.2.5 EUT OPERATING CONDITIONS 16 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 17 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 18 3.2.8 TEST RESULTS (1GHZ~25GHZ) 20 3.3 RADIATED BAND EMISSION MEASUREMENT 26 3.3.1 TEST REQUIREMENT: 26 3.3.2 TEST PROCEDURE 26 3.3.3 DEVIATION FROM TEST STANDARD 26 3.3.4 TEST SETUP 27 3.3.5 EUT OPERATING CONDITIONS 27 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 34 3.4.1 APPLICABLE STANDARD 34 3.4.2 TEST PROCEDURE 34 3.4.3 DEVIATION FROM STANDARD 34 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260130031R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 59 Table of Contents Page 3.4.4 TEST SETUP 34 3.4.5 EUT OPERATION CONDITIONS 34 3.4.6 TEST RESULTS 34 4 . AVERAGE OUTPUT POWER 41 4.1 APPLIED PROCEDURES / LIMIT 41 4.1.1 TEST PROCEDURE 41 4.1.2 DEVIATION FROM STANDARD 41 4.1.3 TEST SETUP 41 4.1.4 EUT OPERATION CONDITIONS 41 4.1.5 TEST RESULTS 42 5 . POWER SPECTRAL DENSITY TEST 46 5.1 APPLIED PROCEDURES / LIMIT 46 5.1.1 TEST PROCEDURE 46 5.1.2 DEVIATION FROM STANDARD 46 5.1.3 TEST SETUP 46 5.1.4 EUT OPERATION CONDITIONS 46 5.1.5 TEST RESULTS 47 6 . 6DB BANDWIDTH TEST 51 6.1 APPLIED PROCEDURES / LIMIT 51 6.1.1 TEST PROCEDURE 51 6.1.2 DEVIATION FROM STANDARD 51 6.1.3 TEST SETUP 51 6.1.4 EUT OPERATION CONDITIONS 51 6.1.5 TEST RESULTS 52 7 . ANTENNA REQUIREMENT 59 7.1 STANDARD REQUIREMENT 59 7.2 EUT ANTENNA 59 8 . TEST SEUUP PHOTO 59 9 . EUT PHOTO 59 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260130031R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 59 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.209, 15.205 Band Edge Emission PASS 15.247(d) Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1. MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2% 9 Power Spectral Density ±2.45dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260130031R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 59 2.. GENERAL INFORMATION 2.1. GENERAL DESCRIPTION OF EUT Product Name: electronic calendar Trade Mark: N/A Model Number: X156, X801, X102, X103, X1401, X1402, X157, X158, X181, X215, X216, X238, ea15, eb15, ec15 Test Model: X156 Model Difference All models are same as the samples except model name and appearance color, they have the same structure and circuit. Operation Frequency: 802.11b/g/n/ax(20MHz): 2412~2462 MHz 8…
