Read and Save These Important Instructions Customer Suppor Guangdong Tongyuan Electric Co., Ltd. Address: 8 Dadi Road, Shapuwei, Songgang Town, Bao'a n District, Shenzhen City, Guangdong Province, China Official website: www.shlipu.com t If you have any questions or concerns about your new product, please contact our helpful Customer Support Team For FAQs and more information, Please visit: www.SHLIPU.com TY-10 Plasma Air Purifier 0 User Manual Contents SAFETY INFORMATION 01-02 GETTING TO KNOW YOUR AIR PURIFIER 03 CONTROLS 04 GETTING STARTED 05-06 HOW TO USE TIPS 07 CONNECT TO THE SMART LIFE APP 08 CLEANING AND MAINTENANCE 09 -11 TROUBLESHOOTING 12 SPECIFICATIONS 13-14 WARRANTY INFORMATION 15 To reduce the risk of fire, electric shock, or other injury, only use your air purifier as described in this manual. Please place and use this product properly, by ensuring it is placed on a dry, flat, and stable surface. Avoid hitting or dropping the air purifier to prevent damage or accidents. Avoid placing in direct sunlight or high-humidity environments (e.g., bathrooms). Do not use a humidifier in proximity to the air purifier to prevent water ingress. Never immerse the product in water or other liquids. Do not use it in environments where flammable or explosive materials are stored, near open flames (such as fireplaces, stoves), or in proximity to high-temperature heating devices like heaters, warm air blowers, or electric irons. Do not place water containers, medications, or flammable items on top of the product. Do not sit or stand on the product. Do not use it in places with combustible gases, vapors, metallic dust, aerosol (spray) products, or industrial oil fumes. To prevent interference, please keep the product as far away as possible from electrical appliances such as televisions, radios, microwaves, etc. To avoid the risk of fire or electric shock, ensure that this product is connected to a power supply matching the standard voltage in your area. Never touch the power plug with wet hands to prevent electric shock. When unplugging, pull the plug, not the cord. Avoid routing the power cord in areas where it may obstruct movement, and do not place it under carpets or near heat sources such as heaters, stoves, or furnaces to prevent potential safety hazards. SAFETY INFORMATION Read and Save these Safety Instructions Before Using This Air Purifier Do not cover the power cord with carpets, rugs, or other coverings, Do not place it under furniture or appliances, or in areas where people frequently walk. Place it in a location where it will not be a tripping hazard. Do not obstruct the product's intake and exhaust vents with any external objects or allow foreign objects to enter the interior of the machine, as this may cause damage. Before assembling, moving, opening the side panel, cleaning, or performing other maintenance, or during extended non-use, always disconnect the power supply. Individuals with reduced physical, sensory, or mental abilities, or those lacking experience and knowledge (including children), must not use this air purifier unless they have received supervision or guidance from a responsible person regarding its use. If this product is used in proximity to children or disabled individuals, supervise them carefully. Do not allow children to play with this product as if it were a toy. This product is not a substitute for ventilation fans, vacuum cleaners, or kitchen range hoods. Use this product only for the household purposes described in this manual. Any other uses not recommended by the manufacturer may cause fire, electric shock, or personal injury. use this product indoors only as instructed in this manual. To reduce the risk of fire or electric shock, do not use this air purifier in conjunction with any solid-state speed control devices. Do not use accessories or parts that are not provided by the original manufacturer. If the product is damaged due to the use of non-original accessories or parts, it will void the warranty and after-sales coverage. Do not attempt to repair or adjust any electrical or mechanical functions of this device. Doing so will void your warranty. All repairs should be performed by qualified professionals. Patients with cardiac pacemakers and those who have undergone coronary artery bypass grafting (CABG) should maintain a safe distance from the device while it is operating. SAFETY INFORMATION(CONT.) * * * * * * * * * * * * * * * * * * * * 0102 * GETTING TO KNOW YOUR AIR PURIFIER Control Panel Air Outlet Movable Buckle Ion Electrode Dust Collection Sheet Magnetic Side Panel Sensor Air Inlet Power Socket PM Value TVOC Value Power Button Ambient Light Button Wi-Fi Pairing Button Child Lock Button Air Quality Indicator light CONTROLS Air quality status The air purifier has a sensor to measure the fine particles and TVOC levels. The LED indicator displays air quality status in 3 colors. Very Polluted Polluted Good At startup, the sensors (including PM and TVOC sensors) will display '---' during the preheating process. Normal readings will appear automatically once preheating is completed. Please wait patiently. The illustrations of the product, accessories, and user interface in this manual are for reference only and may vary slightly due to updates. Please refer to the actual product for accuracy. * Power Cord Ambient Light 0304 GETTING STARTED 2 0 c m 2 0 c m STEP 01 Place the air purifier on a flat,stable surface with the display facing up. Allow at least 8 inches/20 cm of clearance on all sides of the air purifier. Keep away from anything that would block airflow, such as sofa, wall, and curtains. STEP 02 Remove the dust collection sheet from its plastic packaging and place it back into the air purifier. STEP 03 Plug in and tap to turn on the air purifier, now your purifier is ready to use. 0506 HOW TO USE TIPS Ambient Light Button This button controls ambient light brightness. Upon startup, the device defaults to breathing mode (softly alternate…
