RemoteControlOperationGuide INMOXR2 说明书（美国 & 西班牙） OperatingManualofINMOXR2SportsSmartGlasses Thankyouforchoosingoursportssmartglasses!Tohelpyouquicklygetacquaintedwiththe operationofthisdevice,wehaveincludedacomprehensivemanualwithyourpurchase.Please readthismanualcarefullybeforeusingyourproducttoenablebetteruseofit. PackingList INMOXR2SportsSmartGlasses x1 Nosepadsx2 Anti-slipsleevex1 Sparelensesx2 Audioearpadsx1 Glassescleaningclothx1 ProtectiveStorageBoxx1 USBchargingcablex1 InstructionManualx1 RemoteControlInstallationGuide 1.Alignthesiliconepadandinstallitbeneath themountingbase 2.Attachthesiliconepadandpositionthe mountingbasefirmlyagainstthehandlebar orstem 3.Usetwostrapstodiagonallyfastenthefour4.Installationcomplete mountinglugsaroundthehandlebar InstalltheINMOXApp UnlockallfeaturesoftheINMOXR2SportsSmartGlasses 1.DownloadtheApp Option1(Recommended):Useyourphone’scameratoscantheofficialQRcodebelow, whichwilltakeyoutotheofficialwebsitefordownloadtheapp. Option2:OpentheAppStoreorgoogleplayAppStore,searchfor'INMOX,'anddownloadthe officialapp. 2.Completetheinstallation Oncedownloaded,tap'Install'andallowtheapptoinstallonyourdevice. ActivateappfeaturesbyscanningtheprovidedQRcode. ProductImagesandBasicSpecifications AfterinstallingtheINMOXapp,youneedtoscantheofficialQRcodetoactivateallitsfeatures. Step1:OpentheINMOXapp Step2:Gototheactivationpage Step3:ScantheQRcode Step4:Completetheactivation OncetheQRcodeisverified,theapplicationwilldisplayaconfirmationmessagethatsays 'ActivationSuccessful'. ProductFunctionIndicatorLightStatus Function FlashingPattern PowerOn First,thebluelightstaysonfor2seconds,thentheredandbluelights flashalternatelyevery0.5seconds PowerOff Theredlightstaysonfor2secondsandthenturnsoff WaitingforConnection Thehostdevice'sredandbluelightsflashalternatelyevery0.5seconds, andtheslavedevice'slightturnsoff ConnectionSuccessful Thehostdevice'slightturnsoff PlayingBoththehostandslavedevices'lightsturnoff Paused Thehostdevice'slightturnsoff IncomingCallBoththehostandslavedevices'bluelightsflashonceevery3seconds OnaCall Boththehostandslavedevices'bluelightsflashonceevery3seconds LowBatteryTheredlightflashesonceevery3seconds ChargingTheredlightremainsoncontinuously. FullyChargedThelightturnsoff ProductSpecifications Category Specification BasicInformation ProductNameINMOXR2 Model SportsGlasses1510 FrameMaterialTR90 LensMaterial PC(Polycarbonate) LensCoatingColorDarkNightBlack/PearlWhite NetWeight44g Dimensions160×60×150mm Bluetooth&Audio BluetoothVersion5.4 Frequency 2.4GHz MaximumTransmission Range 10meters SoundQuality Hi-Fistereo AudioDecoding 16-bit Signal-to-NoiseRatio(SNR) ≥60dB Battery&Charging BatteryCapacity 100mAh ContinuousTalkTime7hours MusicPlaybackTime 7hours StandbyTimeUpto10days ChargingCurrent 100mA ChargingTime 2hours LowVoltageAlert 3.3V;AutoPower-Offat3.1V Environmental OperatingTemperature -10°Cto50°C ProductOperationInstructions PowerOn/PowerOff • PowerOn:Pressandholdboththeleftandrighttemplepowerbuttonsfor4seconds.The bluelightwillstayonfor2seconds,andanaudioprompt“Poweron”willplay.Thered andbluelightswillthenflashalternatelytoindicatethedeviceispoweredon. • PowerOff(Method1):InPairingMode,pressandholdthelefttemplepowerbuttonfor6 secondstopoweroffbothtemplessimultaneously.Anaudioprompt“Powerof”willplay, andtheredlightwillstayonfor2secondsbeforeturningoff. • PowerOff(Method2):InPairingMode,presstherighttemplepowerbutton4timesinquick successiontopoweroffbothtemplessimultaneously.Anaudioprompt“Powerof”will play,andtheredlightwillstayonfor2secondsbeforeturningoff. AutomaticPairingBetweenLeftandRightTemples Whentheglassesarepoweredon,thedevicewillautomaticallydetectandpairtheleftandright temples. PairingwithaMobileDevice 1.OpentheINMOXAPP. 2.Locate“INMOXR2”inthepairinglist,thentaptoconnect. 3.Anaudioprompt“Connected”willplayoncepairingissuccessful. Answering/EndingCalls • AnsweraCall:Toansweranincomingcall,brieflypressthelefttemplepowerbutton. • EndaCall:Duringacall,brieflypressthelefttemplepowerbuttontohangup. Note:WhenmusicisplayingviaBluetooth,anincomingcallwillautomaticallypausethemusic. Pressthepowerbuttontoanswerthecall.Afterthecallends,brieflypressthelefttemplepower buttontoresumemusicplayback. RejectingCalls Whenreceivinganincomingcall,pressandholdthelefttemplepowerbuttonforapproximately 2secondstorejectthecall. MusicPlay/Pause WiththeglassesconnectedtothephoneviaBluetoothandmusicplaying,clickthelefttemple buttonto“playmusic”.Clickthelefttemplebuttonagainto“pausemusicplayback”. ActivateVoiceAssistant Whenthedeviceisinstandbymode,double-clickthepowerbuttonontherighttempleto activateSiriorGoogleVoiceAssistant. Push-to-Talk(PTT)Function TheglassesareconnectedtoyourphoneviaBluetooth,andtheappisonthegroupchatpage. • Pressandholdtherighttemplebuttonto“StartTalk.” • Releasethebuttontosendavoicemessage. LanguageModeSwitching(Chinese/English) Whentheleftandrighttempleshavebeenautomaticallypairedandarenotconnectedtoa mobiledeviceviaBluetooth,simultaneouslypressandholdthepowerbuttonontheleft/right templefor6secondstoswitchbetween“ChineseMode”or“EnglishMode”. • SwitchingtoChineseMode:Voiceprompt“中文模怯”(ChineseMode) • SwitchingtoEnglishMode:Voiceprompt“EnglishMode” UnpairingtheLeftandRightTemples Aftersuccessfullypairingtheleftandrighttemples: • Quicklypressthelefttemplebutton6timesinsuccession,orquicklypresstherighttemple button6timesinsuccession,tounpairthetwotemples. PrecautionsforUse • Donotbendthetemplesexcessivelyoutwardorapplyforcethatexceedstheproduct's mechanicalloadcapacity. • Donotforciblyremovethenosepadsorlenses. • Lensescomplywithlight-tintedsunglasses(Category1):capableoflimitedblockingof sunlightandglare. • ChargingInstructions:ConnecttheUSBchargingcabletoacomputerUSBportor compatiblepoweradapter.Itisrecommendedtopowerofftheglassesbeforecharging. • ChargingIndicator:Duringcharging,theredindicatorlightremainssteadilylit;whenthe batteryisfullycharged,thelightturnsoff. • Post-ChargingSafety:Afterthedeviceisfullycharged,promptlydisconnectthecharging c…
