2BUGM-AIRIMAGE2Air Quality Sensor

Camfil AB
Air Quality Sensor - FCC ID 2BUGM-AIRIMAGE2 - Camfil AB
Click to zoom

Application Details

Equipment Class
PCB - PCS Licensed Transmitter
Date of Grant
Jul 03, 2026
Application Purpose
Original Equipment
Equipment Note
Air Quality Sensor
Frequency Range
699.00000000 - 716.00000000
Company
Camfil AB
Country
Sweden

Documents & Files

Select a file to view

Users Manual

β†—

Attestation Statements

β†—
β†—

Cover Letter(s)

β†—

External Photos

β†—
β†—

ID Label/Location Info

β†—

Internal Photos

β†—
β†—

RF Exposure Info

β†—
β†—
β†—

Test Report

β†—
β†—
β†—
β†—
β†—
β†—
β†—
β†—

Test Setup Photos

β†—
β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

AirImage 2.0 User Manual Unlock IAQ control – intelligently – standard mode Β© All rights reserved. Camfil reserves the right to modify this manual at any time without notice. Without prior written consent from Camfil, any part of the manual should not be duplicated, reproduced or translated into any other languages. Version history: Version Revision date Revision description 1.0 06/10/2025 First release Table of content About this manual ....................................................................................................................4 Glossary of symbols ................................................................................................................5 Important safety information ..................................................................................................5 Mounting ..................................................................................................................................6 Technical information ..............................................................................................................7 Set-up ......................................................................................................................................8 Link the first CamCleaner ........................................................................................................8 Screen views ............................................................................................................................9 Settings..................................................................................................................................10 MyCamfilConnect portal ........................................................................................................11 Maintenance ..........................................................................................................................12 Troubleshooting ....................................................................................................................12 Guarantees and undertakings ...............................................................................................13 Disclaimer of liability ..............................................................................................................13 Manufacturer’s declaration of conformity ............................................................................14 Camfil AirImage 2.0 Manual – Standard Mode 32 Camfil AirImage 2.0 Manual – Standard Mode Important safety information: β€’ Do not open the AirImage 2.0 casing β€’ Only use the original power supply provided by Camfil β€’ Do not cover the inlets or outlets β€’ Use of equipment, components, and accessories other than those specified by Camfil may impair the safe operation of the equipment. β€’ The safe operation of the equipment as part of a larger system is the responsibility of the installer of the system. β€’ The AirImage 2.0 is not waterproof. Exposing it to water or setting it in a pool of water can severely damage your AirImage 2.0. β€’ DO NOT mount the AirImage 2.0 upside down. This will affect the functionality of the measurements β€’ Mount the AirImage on an inside wall approximately 1.4 m (4-Β½ ft) from the floor (or in the specified location), to allow exposure to the average zone temperature. Avoid locations that are exposed to discharge air from registers or radiation from appliances, lights, or the sun β€’ Clean the AirImage 2.0 carefully with a dry cloth, do not use liquid cleaners, aerosol cleaners or pressurized air to clean it. β€’ The AirImage 2.0 is not intended for outdoor use. β€’ Before plugging the power adapter into a socket, check if power source, voltage and frequency corresponds to 100– 240V and 50–60Hz. Current rating of power adapter is 0.6A. β€’ Do not use the equipment at altitudes exceeding 2,000 meters (6,560 feet). β€’ The maximum power consumption of the AirImage 2.0 is 8W β€’ The supplied power adapter is rated to operate between 0 Β°C and +40 Β°C (32 Β°F to 104 Β°F), with humidity ranging from 20% to 85% WEEE directive requires that old or defective electri- cal and electronic products must be disposed of in an environmentally sound way. The symbol means that your product should be collected separately from household waste. Please contact a retailer or your community for the nearest collection center. The power adapter is intended for use at supply voltages with fluctuations not exceeding +/-10% and classified as overvoltage category II. Glossary of symbols Control modes: Schedule: Assign CamCleaners to a personalized schedule. Pre-set up to 3 different schedules in the settings. Fan Speed: Choose a Fan Speed between 1 and 6. IAQ Control: Set a maximum PM 2.5 value that your Air Quality can reach. The CamCleaner will automati- cally turn on when the level rises above. Warning Messages: Filter message: appears when the filter capacity is at 10% (yellow) or at zero (red). Fan error: receive an error message in case the fan of one of the connected CamCleaners is not running properly. Find both on the Home screen, check CamCleaner unit infor- mation under device status for fan error details, and on the CamCleaner Control screen for exact remaining filter capacity. Menu screens: Get status updates on all connected devices, real-time environmental measurements, and a graph of historical PM 2.5 data. A 4G logo indicates a mobile connection with double arrows confirming connection to the cloud. Connect CamCleaners, adjust their control mode, and click on them to view detailed unit and filter information. Gain insights into historical PM 2.5 values, the harmful particles removed by your devices, and the clean air they delivered. Pre-set the schedule and IAQ control settings, access AirImage unit information, and adjust general settings like language, time zone, lock, or screen saver. About this manual This operator instruction manual is for Camfil’s customers. It describes the functioning of the product…
