2BUHT-D1Intelligent Robot Dog

有毒有害物质或元素 铅 （Pb） 汞 （Hg） 镉 (Cd) 六价铬 (Cr6+) 多溴 联苯 (PBB) 多溴 二苏醚 (PBDE) 部件 名称 塑料 外壳 : 表示该有毒有害物质在该部件所有均质材料中的 含量在GB/T26572-2011<<电子电气产品中限用物质 的限量要求>>规定的限量要求以下。 x: 表示该有毒有害物质至少在该部件的某一均质材 料中的含量超出GB/T26572-2011<<电子电气产品中 限用物质的限量要求>>规定的限量要求，且目前业界 没有成熟的替代方案，符合欧盟RoHS指令环保要求。 电池 线路 板 线缆 连接 器 11 电子信息产品有害物质申明 1. 产品建议使用年龄为14岁及以上，14岁以下使用者 建议在监护人陪同下使用 2. 产品使用时，请勿将手靠近机器狗的前后腿，谨防被 前后腿夹伤；拿起机器狗时，也请勿过于靠近机足 3. 使用时请注意防水，请不要将产品浸入水中，电子器 件进水会导致产品无法使用 4. 如果发现电池有任何异常，请立即停止使用 5. 本产品包含人工智能系统，其语音交互功能由人工智 能驱动，请注意甄别。输出内容仅为人工智能生成， 不代表品牌方立场，若因AI输出内容对用户造成误导， 品牌方不承担相关责任 6. 产品在使用过程中会收集和处理用户的语音数据，仅 用于用户主动唤醒并进行的AI对话功能，同时数据对 加密和非标注信息处理。该数据会在AI处理完后，进 行自动删除 7. 在室内使用产品时，请注意不要造成家具损坏和破坏 8. 切勿将机器狗乱扔，乱碰撞。若因用户操作不当导致 任何财产损失，品牌方不承担赔偿责任 9. 请勿在设备开机状态下，强行掰动机器狗的四肢及耳朵 10、O TA升级时，请确保电量充足，严禁中途断电 D1 用户手册 注意事项: v1.0 请在使用前仔细阅读此手册，并妥善保管以备日后查询。 *所有图片仅供参考，请以产品实物为准* 1 部件说明 产品介绍 2 产品清单 机器狗 / 充电线 / 说明书 遥控器（仅遥控器版本&EDU版本包含） 干电池*2（仅遥控器版本&EDU版本包含） 1. 抚摸感应区 2. 尾巴 3. 显示屏 4. 耳朵 5. 充电插口 6. 复位孔 7. 电源键 8. 前肢 9. 充电指示灯 10. 后肢 机器狗Gogobot D1 ×1 3 配件说明 3. 电量&充电提醒 1) App可以查看机器狗电量 2) 低电量时，机器狗会有表情变化 3) 使用type-c插头充电 4) 充电时，充电指示灯亮起，充满后熄灭 4. AI对话 呼叫“gogo”既可开启语音对话 5. 遥控器操控 1) 遥控器版本附带遥控器和两节7号电池 2) 遥控器使用2节7号电池，安装电池后才能使用 3) 机器狗开机后30s内，长按3秒“ ”按钮开机后，蓝色 指示灯闪烁同时扫描设备并连接，耳朵摇晃为连接完成。 继续长按3秒“ ”键则会关机，蓝色指示灯熄灭 4) 长按3秒“O”键，听到提示音则且耳朵竖起，进入校准 模式。用户可以在校准模式操作机器狗前进后退转弯来 校准机器狗步伐。其中推动摇杆到机器狗不动为校准一 次，校准分数会显示在机器狗屏幕上，建议校准分数大 于95为佳。可以反复校准，取最后一次的校准数值为准。 再次长按3秒“O”键看到耳朵竖起后则会推出校准模式 5) 推动“摇杆”操控机器狗移动 6) 按住“L ”“R”任意一按键，推动摇杆启动特殊移动模式 7) 按“A”进行握手，按“B”坐下，按“C”趴下，按“D” 站立 6. 个性化编程 EDU版本，请扫描下方二维码查看使用文档 7. 多设备联机 1) 机器狗开机后，连续单击电源键5次，此台机器选定为 主机，在无线范围内的所有刚开机5秒内的机器狗，自 动连接为从机 2) 听到提示音后，机器狗进入主机或者从机模式 3) 所有的从机只做和机器狗主机一样的动作，包括App 操控，遥控器操控 4) 关机后，退出主机或者从机模式 1. 开关机说明 长按3秒，即可开机或者关机 2. App连接以及联网 1) 应用商店搜索“ gogobot”或者扫描二维码下载App 2) 在App内搜索设备连接 3) 输入wifi名称和密码进行联网 type-c 7号干电池 ×2 仅支持遥控器&EDU版本 充电线 ×1 遥控器 ×1 仅支持遥控器&EDU版本 C A B D 说明书 ×1 说明书 Gogobot 4 10 机器狗 5 使用说明 6789 Gogo! 在的,主人 主机 从机从机 规格说明 【Gogobot Labs Limited】 【高高機器人實驗室有限公司】 www.gogobot.io 「关注我们」 小红书社交媒体入口 社媒名称：Gogobot YouTube社交媒体入口 社媒名称：Gogobot ins 社交媒体入口 社媒名称：Gogobot Facebook社交媒体入口 社媒名称：Gogo Bot 登录入口： https://www.facebook.com/profile.php?id=61584720410428 10 联系方式 type-c 3. Battery & Charging 1) You can check the battery level via the App. 2) When the battery is low, the robot's facial expressions will change to indicate low power. 3) Use a Type-C cable for charging. 4) The Charging Indicator stays on during charging and turns off when the battery is full y charged. 6. Personalized Programming Please scan the QR code below to access the programming documentation. 7. Multi-Device Synchronization 1) Power on the robot dog and press the power button 5 times to set it as the Master . Other units nearby (within Bluetooth r ange) that were turned on within the last 5 seconds will automaticall y pair as Slaves. 2) A prompt tone will sound once the dog successfully enters Master or Sla ve mode. 3) Slaves will replicate all actions performed by the Master unit, whether contr olled by the App or remote . 4) Simply turn off the device to exit Master/Slave mode. 1. Power On/Off Long press the power button for 3 seconds to turn the device on or off. 2. App Connection & Networking 1) Search for "gogobot" in the App Store/Google Play or scan the QR code to download the app. 2) Search for the device within the app to connect. 3) Enter your Wi-Fi name and password in the app to connect the robotic dog to the internet. 4. AI Conversation Sa y the wake word "gogo" to start a voice conversation. 5. Remote Control (Remote Version) 1) The remote version includes a controller and two AAA batteries. 2) Install the 2 AAA batteries before use. 3) Within 30s after the robotic dog is powered on, long-press the " " button f or 3 seconds. The blue indicator light will flash while scanning and connecting to the device , and the ears wiggling indicates the connection is complete. Continuing to long-press the " " button for 3 seconds will power off the device , and the blue indicator light will turn off. 4) Long-press the "O" button for 3 seconds. Hearing a prompt tone and seeing the ears stand up indicates entry into calibration mode. Users can operate the robotic dog to move f orward, backward, or turn to calibrate its gait. Moving the jo ystick until the dog stops constitutes one calibration; the scor e will be displayed on the screen, and a score above 95 is r ecommended. Calibration can be repeated, with the final value taken as the standard. Long-pressing the "O" button again for 3 seconds until the ears stand up will exit calibr ation mode. 5) Use the Joysticks to control the robot's movement. 6) Hold the top "L" or "R" buttons while moving the joysticks to trigger special movement modes. 7) Press A to Shake Hands, B to Sit, C to Lie Down, and D to Stand Up. Warranty Coverage C A B D Gogobot 56789 Unbind “O”Scan the device and connect “B”Sit down “D”stand “A”handshake “C”Lie down joystick “L” “R” Gogo! Hi！ Host SlaveSlave 【Gogobot Labs Limited】 【高高機器人實驗室有限公司】 www.gogobot.io CMIIT ID is located on the product nameplate. Copyright © All rights reserved. The Gogobot trademark is the property of Gogobot Labs Limited Co., Ltd. 注:无线电型号核准CMIIT ID见产品铭牌。 版权所有 ©Gogobot商标均归高高機器人實驗室有限公司所有, 保留一切权利。 RedNote Social Media Name：Gogobot YouTube Social Media Name：Gogobot Instagram Social Media Name：Gogobot Facebook Social Media Name：Gogo Bot Login Portal： https://www.facebook.com/profile.php?id=61584720410428 101112 Operating Instructions Specifications Contact Us & Follow Us FCCWarranty Policy 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to Part 15 o…

Text truncated - open the document above for the full version.

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2600255 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page RF Test Report (BLE) Report No.: JYTSZ-R12-2600255 Applicant: GOGOBOT LABS LIMITED Address of Applicant: FLAT/RM 1911 LEE GARDEN ONE 33 HYSAN AVENUE CAUSEWAY BAY HK Equipment Under Test (EUT) Product Name: Gogobot Intelligent Robot Dog Model No.: Gogobot D1 Trade Mark: N/A FCC ID: 2BUHT-D1 Applicable Standards: FCC CFR Title 47 Part 15C (§15.247) Date of Sample Receipt: 25 Mar., 2026 Date of Test: 26 Mar., to 22 Apr., 2026 Date of Report Issued: 24 Apr., 2026 Test Result: PASS Project by: Date: 24 Apr., 2026 Project Engineer Reviewed by: Date: 24 Apr., 2026 Senior Engineer Approved by: Date: 24 Apr., 2026 Manager Report No.: JYTSZ-R12-2600255 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-148-C1 Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 38 Version 1 Version No. Date Description 00 24 Apr., 2026 Original Report No.: JYTSZ-R12-2600255 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-148-C1 Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 38 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Disclaimer ............................................................................................................................................... 4 3.3 Test Mode and Test Environment .......................................................................................................... 5 3.4 Description of Test Auxiliary Equipment ................................................................................................ 5 3.5 Measurement Uncertainty ...................................................................................................................... 5 3.6 Additions to, Deviations, or Exclusions from the Method ....................................................................... 5 3.7 Laboratory Facility .................................................................................................................................. 6 3.8 Laboratory Location ................................................................................................................................ 6 3.9 Test Instruments List .............................................................................................................................. 6 3.10 Measurement Setup and Procedure ........................................................................................................... 8 4 Test Channel .......................................................................................................................................... 8 4.1 Test Setup .............................................................................................................................................. 8 4.2 Test Procedure ..................................................................................................................................... 11 4.3 Test Results ................................................................................................................................................. 12 5 Summary .............................................................................................................................................. 12 5.1 Clause and Data Summary .............................................................................................................. 12 5.1.1 Test Limit .......................................................................................................................................... 13 5.1.2 Antenna requirement ............................................................................................................................ 14 5.2 AC Power Line Conducted Emission ................................................................................................... 15 5.3 Emissions in Restricted Frequency Bands ...............…

Text truncated - open the document above for the full version.

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 2 BLE, Wi-Fi Test Setup Photos Radiated Spurious Emission Below 1GHz Above 1GHz JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 2 Conducted Emission Conducted method ------End------

1 深圳市飞敏科技有限公司 ShenZhen City FeiMin Technology CO.,LTD. 产品承认书 SPECIFICATION FOR APPROVED 客户 CUSTOMER: 北京唱吧科技股份有限公司 产品名称 PRODUCTS: FPC天线 客户料号 PART NO: 产品型号 Spec.: FM-S2473-机器狗（120mm） 日期 Data: 2026.1.26 备注：承认盖章后请回复一份承认书（或复印件）给我司，其余由贵公司存档 REMARK:Please send us one(or copy)of this approval with stamp after accepting,other copies filed by the customer. 地址：深圳市宝安区西乡街道固兴社区盛辉路 4 号科运达电商基地 8 楼 801室 ADD: Room 801, 8th Floor, Keyunda E-commerce Base, No. 4 Shenghui Road, Guxing Community, Xixiang Subdistrict, Baoan District, Shenzhen. 电话Tel: 0755-23035723 传真Fax: 0755-23036702 邮箱E-mail: [email protected] 网址HTTP:www.fmant.cn 客户 CUSTOMER 承认 ACCEPTED BY 审核 CHECKED BY 批准 APPROVED BY 供应商 SUPPLIER 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 2 目录 产品承认书 ..................................................................................................................... 1 1. 项目信息Project Information .................................................................................. 4 1.1. 外观尺寸Appearance and Dimensions .......................................................... 4 2. 电气性能 Electrical Characteristics ......................................................................... 5 2.1. 测试环境条件Test Environment Conditions ................................................. 5 2.2. 测示方法Measurement method ..................................................................... 5 2.2.1. 天线电压驻波比Antenna VSWR ............................................................... 5 2.2.2. 天线回波损耗Antenna Return loss ................................................... 6 2.3. 天线无源测试数据 Antenna passive test data ................................. 6 2.3.1. 测试系统Test system ............................................................................... 6 2.3.2天线效率及增益Antenna efficiency and gain .............................. 7 2.3.3.天线辐射方向图Antenna Radiation Pattern ....................................... 7 3.备注Notes .................................................................................................................... 8 4.产品包装规范Product packaging specification ......................................................... 8 ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 3 Revision history 版本 日期 状态 A1 2026-1-16 首版 A2 2026-1-26 更改线长 变更内容： 第一次变更： 变更前：（如有必要，请添加相应的图片，此处变更明细要描述清楚） 变更后：（如有必要，请添加相应的图片，此处变更明细要描述清楚） ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 4 1. 项目信息Project Information 1.1. 外观尺寸Appearance and Dimensions ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 5 2. 电气性能 Electrical Characteristics 2.1. 测试环境条件Test Environment Conditions 温度Temperature Ordinary Temperature (5 to 35°C) 湿度Humidity Ordinary Humidity (25 to 85% RH) 2.2. 测示方法Measurement method 2.2.1. 天线电压驻波比Antenna VSWR ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 6 2.2.2. 天线回波损耗Antenna Return loss 2.3. 天线无源测试数据 Antenna passive test data 2.3.1. 测试系统Test system 深圳市飞敏科技有限公司（24探头OTA 微波暗室） ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 7 2.3.2天线效率及增益Antenna efficiency and gain Freq(MHz) Efficiency (％) Gain(dBi) 2400 38.34 1.52 2410 38.19 1.56 2420 39.59 1.71 2430 40.24 1.93 2440 43.11 2.24 2450 43.19 2.20 2460 43.28 2.05 2470 42.24 2.14 2480 41.22 2.03 2490 40.24 1.53 2500 38.27 1.49 2.3.3.天线辐射方向图Antenna Radiation Pattern ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 8 3.备注Notes 1、安装时注意不能离金属部分太近，以避免影响天线性能。 2、此款天线只适用此机型，天线的位置不可以随意改动，若用于其它机器上导致效果变差，与我司无 关。 3、本承认书所使用数据（如：天线效率、增益等）均为本承认项目/天线在深圳市飞敏科技有限公司 实验室测试所得出数据 4.产品包装规范Product packaging specification 产品名称:FPC天线 一、标签要求 内标签长7CM，宽4CM左右 外标签长7CM，5CM左右 二、装箱流程 作业说明： 1.产品__PCS用PE开口袋装好，每小袋贴好内标签； 将__小袋装入大PE封口胶带袋中，尾数及备品除外。 2.每箱装__大袋产品，将箱子用胶纸以“工”字形封箱。 3.在箱子的右上角贴上外标签，不可有漏填、填错现象。 三、注意事项 装箱时要注意将天线平整放好，封胶后不可出现严重晃 动情况，未填满整箱的情况需塞入泡棉填充，避免运输 过程中造成产品不良的情况。 客户名称 供 应 商 深圳市飞敏科技有限公司 订单编号 ************* 物料编码 ************* 规格型号 ****** 产品名称 ******* 数 量 *****PCS 检验 备品 ***PCS 备注 供 应 商 深圳市飞敏科技有限公司 产品名称 ****** 物料编码 ************ 规格型号 ********** 数 量 ***PCS 产品

Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 42 Test Data Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT b 2412 Ant1 100 0 NVNT b 2437 Ant1 100 0 NVNT b 2462 Ant1 100 0 NVNT g 2412 Ant1 100 0 NVNT g 2437 Ant1 100 0 NVNT g 2462 Ant1 100 0 NVNT n20 2412 Ant1 100 0 NVNT n20 2437 Ant1 100 0 NVNT n20 2462 Ant1 100 0 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 42 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Duty Cycle NVNT b 2462MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 42 Duty Cycle NVNT g 2412MHz Ant1 Duty Cycle NVNT g 2437MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 42 Duty Cycle NVNT g 2462MHz Ant1 Duty Cycle NVNT n20 2412MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 42 Duty Cycle NVNT n20 2437MHz Ant1 Duty Cycle NVNT n20 2462MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 42 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 42 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 6.73 0 6.73 30 Pass NVNT b 2437 Ant1 6.62 0 6.62 30 Pass NVNT b 2462 Ant1 7.6 0 7.6 30 Pass NVNT g 2412 Ant1 10.36 0 10.36 30 Pass NVNT g 2437 Ant1 10.24 0 10.24 30 Pass NVNT g 2462 Ant1 11.2 0 11.2 30 Pass NVNT n20 2412 Ant1 10.37 0 10.37 30 Pass NVNT n20 2437 Ant1 10.24 0 10.24 30 Pass NVNT n20 2462 Ant1 11.21 0 11.21 30 Pass Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 8 of 42 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) limit(MHz) Verdic NVNT b 2412 Ant1 10.132 0.5 Pass NVNT b 2437 Ant1 10.133 0.5 Pass NVNT b 2462 Ant1 10.142 0.5 Pass NVNT g 2412 Ant1 16.421 0.5 Pass NVNT g 2437 Ant1 16.482 0.5 Pass NVNT g 2462 Ant1 16.495 0.5 Pass NVNT n20 2412 Ant1 16.451 0.5 Pass NVNT n20 2437 Ant1 16.522 0.5 Pass NVNT n20 2462 Ant1 16.499 0.5 Pass Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 9 of 42 Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 -6dB Bandwidth NVNT b 2462MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 10 of 42 -6dB Bandwidth NVNT g 2412MHz Ant1 -6dB Bandwidth NVNT g 2437MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 11 of 42 -6dB Bandwidth NVNT g 2462MHz Ant1 -6dB Bandwidth NVNT n20 2412MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 12 of 42 -6dB Bandwidth NVNT n20 2437MHz Ant1 -6dB Bandwidth NVNT n20 2462MHz Ant1 Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, F…

Text truncated - open the document above for the full version.

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2600130 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page RF Test Report (2.4G Wi-Fi) Report No.: JYTSZ-R12-2600130 Applicant: GOGOBOT LABS LIMITED Address of Applicant: FLAT/RM 1911 LEE GARDEN ONE 33 HYSAN AVENUE CAUSEWAY BAY HK Equipment Under Test (EUT) Product Name: Gogobot Intelligent Robot Dog Model No.: Gogobot D1 Trade Mark: N/A FCC ID: 2BUHT-D1 Applicable Standards: FCC CFR Title 47 Part 15C (§15.247) Date of Sample Receipt: 25 Mar., 2026 Date of Test: 26 Mar., to 22 Apr., 2026 Date of Report Issued: 24 Apr., 2026 Test Result: PASS Project by: Date: 24 Apr., 2026 Project Engineer Reviewed by: Date: 24 Apr., 2026 Senior Engineer Approved by: Date: 24 Apr., 2026 Manager Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-145-C1 Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 33 Version 1 Version No. Date Description 00 24 Apr., 2026 Original Report No.: JYTSZ-R12-2600130 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-145-C1 Project No.: JYTSZR2603041 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 33 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Disclaimer ............................................................................................................................................... 4 3.3 Test Mode and Environment .................................................................................................................. 5 3.4 Description of Test Auxiliary Equipment ................................................................................................ 5 3.5 Measurement Uncertainty ...................................................................................................................... 6 3.6 Additions to, Deviations, or Exclusions from the Method ....................................................................... 6 3.7 Laboratory Facility .................................................................................................................................. 6 3.8 Laboratory Location ................................................................................................................................ 6 3.9 Test Instruments List .............................................................................................................................. 7 3.10 Measurement Setup and Procedure ........................................................................................................... 9 4 Test Channel .......................................................................................................................................... 9 4.1 Test Setup .............................................................................................................................................. 9 4.2 Test Procedure ..................................................................................................................................... 11 4.3 Test Results ................................................................................................................................................. 12 5 Summary .............................................................................................................................................. 12 5.1 Clause and Data Summary .............................................................................................................. 12 5.1.1 Test Limit .......................................................................................................................................... 13 5.1.2 Antenna Requirement .......................................................................................................................... 14 5.2 AC Power Line Conducted Emission ................................................................................................... 15 5.3 Emissions in Restricted Frequency Bands .......…

Text truncated - open the document above for the full version.

Report No.: JYTSZ-R12-2600255 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR250xxxx No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 22 Test Data Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT BLE 2402 Ant1 83.26 0.8 NVNT BLE 2442 Ant1 83.26 0.8 NVNT BLE 2480 Ant1 82.99 0.81 Report No.: JYTSZ-R12-2600255 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR250xxxx No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 22 Test Graphs Duty Cycle NVNT BLE 2402MHz Ant1 Duty Cycle NVNT BLE 2442MHz Ant1 Duty Cycle NVNT BLE 2480MHz Ant1 Report No.: JYTSZ-R12-2600255 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR250xxxx No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an D…
