2BUJ8-490400-MORPHMORPHEUS SMART FIXTURE

Ground Mount Directional Uplights, Wall Washers and Mini Flood Fixture Installation Sheet FOR OUTDOOR USE ONLY WITH LOW VOLTAGE LANDSCAPE POWER UNITS 12 Volt, Class 2 only. WARNING: Luminaires must be installed in accordance with the National Electrical Code (NEC), Canadian Electrical Code (CEC) and local codes. Failure to do so will void the warranty and may result in serious injury and/or damage to the luminaire. WARNING: Risk Of Fire/Injury To Persons. Keep away from combustibles. Turn off/unplug to change lamp. Do not touch lamp. Replace after Servicing. WARNING: Risk of Electric Shock. Install all luminaires 10 feet (3.05 m) or more from a pool, spa, or fountain. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS The fixture cable shall a)be protected by routing in close proximity to the luminaire or fitting, or next to a building structure such as a house or deck; b) not be buried except for a maximum 6 inches (15.2 cm) in order to connect to the main low voltage cable; and c) have the length cut off so that it is connected to a connector within 6 inches (15.2 cm) from a building structure, a luminaire, or fitting. Lighted lamp is HOT! WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS: • Turn off/unplug and allow to cool before replacing lamp. • Lamp gets HOT quickly! Contact only switch/plug when turning on. • Do not touch hot lens, guard, or enclosure. • Keep lamp away from materials that may burn. • Do not touch the lamp at any time. Use a soft cloth. Oil from skin may damage lamp. •Do not operate the luminaire fitted with a missing or damaged shield. • Mount the luminaire in or on non-combustible mounting surfaces only. SAVE THESE INSTRUCTIONS Luminaire can become very hot depending on lamp wattage used. Lens and metal around lamp can become hot enough to blister hands. Particular care should be taken to locate luminaires where small children cannot reach them if high wattage lamps are used. DO NOT USE EXTENSION CORDS ON POWER UNITS. NOTE: Always use UL, cUL, and CSA recognized wire connectors for connections. LUMINAIRE IS UL LISTED FOR ABOVE GROUND INSTALLATION ONLY . 10505 NW 112th Avenue, Suite 18, Miami, FL 33178 | 1.888.DAUER.LED | [email protected] LUMINAIRE MOUNTING (with ground stake): 1. To prevent electric shock, disconnect transformer from electrical supply before installation or service. 2. Run wire pigtail from luminaire through the mounting hole in top of ground stake. 3. Thread luminaire into threaded hole in ground stake. 4.Place stake in desired position and insert into ground until flange of stake is flush to grade. 5.Strip the (2) leads from the luminaire pigtail wire. Using the two (2) silicone filled safety connectors (by others), connect the leads from the luminaire to the main supply cable leads. NOTE: Luminaires are supplied with 18-2 cable pigtail for secure connection to the main supply cable. The fi xture supply cable is to be protected by routing in close proximity to the luminaire. The fixture supply should be buried to a maximum depth of 6 inches (15.2 cm) in order to connect to the main secondary supply cable. To purchase additional lengths of main low voltage cable for the connection of the equipment, please contact your local electrical supply distribution company. Only use Main Secondary Cable of the type specified in the National Electric Code or Canadian Electric Code for landscape lighting applications. If in doubt, check with your local electrical authority. 6. Aim luminaire to desired angle. Lock into place by tightening screw in adjustable knuckle. 6” Maximum Silicone Filled Safety Connectors Pigtail Ground Mounted Fixture Ground Stake Main Supply Cable 10505 NW 112th Avenue, Suite 18, Miami, FL 33178 | 1.888.DAUER.LED | [email protected] Lumières directionnelles montées au sol, rondelles murales et fiche d’installation de mini projecteur d’inondation POUR UNE UTILISATION EXTÉRIEURE UNIQUEMENT AVEC UN PAYSAGE BASSE TENSION UNITÉS D’ALIMENTATION 12 volts, classe 2 uniquement. AVERTISSEMENT: Les luminaires doivent être installés en conformité avec le National Electrical Code (NEC), Code can- adien de l’électricité (CCE) et les codes locaux. Ne pas le faire annuler la garantie et peut entraîner des blessures graves et / ou des dommages à l’appareil. ATTENTION: risque d’incendie / blessures. Tenir à l’écart des matières combustibles. Éteignez / débranchez de changer la lampe. Ne pas toucher la lampe. Remplacer après entretien. Avertissement: le risque de choc électrique.Installer tous les luminaires de 10 mètres (3,05 m) ou plus à partir d’une pi- scine, Spa, ou de fontaine. INSTRUCTIONS RELATIVES AU RISQUE D’INCENDIE OU DE BLESSURES CONSIGNES DE SÉCURITÉ IMPORTANTES Le câble du luminaire doit a) être protégé par un acheminement à proximité immédiate du luminaire ou du luminaire, ou à côté d’une structure de bâtiment telle qu’une maison ou une terrasse; b)ne pas être enterré sauf sur un maximum de 6 pouces (15,2 cm) afin de se connecter au câble principal basse tension; et c) faire couper la longueur de manière à ce qu’il soit connecté à un connecteur à moins de 6 pouces (15,2 cm) d’une structure de bâtiment, d’un luminaire ou d’un luminaire. La lampe allumée est CHAUD! AVERTISSEMENT - Pour réduire le risque d’incendie ou de blessure: • Couper / débranchez et laissez refroidir avant de remplacer la lampe. •La lampe devient CHAUDE rapidement! Contactez commutateur / la fiche lorsque vous allumez. • Ne touchez pas chaud lentille, garde, ou de l’enceinte. • Gardez la lampe loin de matériaux qui pourraient brûler. • Ne touchez pas la lampe à aucun moment. Utilisez un chiffon doux. Huile de la peau peut endommager la lampe. • Ne pas faire fonctionner le luminaire équipé d’un écran manquant ou endommagé. •La surface de montage de l’installation d’un luminaire ou • non inflammable. CONSERVER CES INSTRUCTIONS Luminaire peut devenir très chaud fonction de la puissance de la lampe u…

Text truncated - open the document above for the full version.

Page 1 of 3 ReportNo.:STS2512058 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 3 ReportNo.:STS2512058 Photo3 Photo4 Page 3 of 3 ReportNo.:STS2512058 Photo5 Photo6

Page 1 of 2 FCC ID: 2BUJ8-490400-MORPH Setup photo AC Conduction RF Conduction Page 2 of 2 FCC ID: 2BUJ8-490400-MORPH RE (Below 1GHz) RE (Above 1GHz)

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512058W02 Issued for Dauer Manufacturing Corp 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Product Name: MORPHEUS SMART FIXTURE Brand Name: N/A Model Name: 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s): 490400-2700K MORPHEUS SMART FIXTURE 2700K FCC ID: 2BUJ8-490400-MORPH Test Standards: FCC Part15.247 Page 2 of 78 Report No.: STS2512058W02 TEST REPORT Applicant’s Name ................. : Dauer Manufacturing Corp Address ................................. : 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Manufacturer's Name ........... : GRE ALPHA ELECTRONICS (VIETNAM) COMPANY LIMITED Address ................................. : No 03 VSIP II-A street No.17, Vietnam - Singapore II-A Industrial Park, Vinh Tan ward, Ho Chi Minh City, Viet Nam Product Description Product Name ........................ : MORPHEUS SMART FIXTURE Brand Name ........................... : N/A Model Name .......................... : 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s) .................... : 490400-2700K MORPHEUS SMART FIXTURE 2700K Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 09 Dec. 2025 Date (s) of performance of tests ............. : 09 Dec. 2025 ~ 30 Dec. 2025 Date of Issue .......................................... : 30 Dec. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 78 Report No.: STS2512058W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. DUTY CYCLE 30 4.1 TEST STANDARD 30 4.2 TEST PROCEDURE 30 4.3 DEVIATION FROM STANDARD 30 4.4 TEST SETUP 30 4.6 TEST RESULTS 30 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 5.1 LIMIT 31 5.2 TEST PROCEDURE 31 5.3 DEVIATION FROM STANDARD 31 5.4 TEST SETUP 31 5.5 EUT OPERATION CONDITIONS 31 5.6 TEST RESULTS 31 6. POWER SPECTRAL DENSITY TEST 32 6.1 LIMIT 32 6.2 TEST PROCEDURE 32 6.3 DEVIATION FROM STANDARD 32 6.4 TEST SETUP 32 6.5 EUT OPERATION CONDITIONS 32 6.6 TEST RESULTS 32 Page 4 of 78 Report No.: STS2512058W02 Table of Contents Page 7. BANDWIDTH TEST 33 7.1 LIMIT 33 7.2 TEST PROCEDURE 33 7.3 DEVIATION FROM STANDARD 33 7.4 TEST SETUP 33 7.5 EUT OPERATION CONDITIONS 33 7.6 TEST RESULTS 33 8. PEAK OUTPUT POWER TEST 34 7.1 LIMIT 34 8.2 TEST PROCEDURE 34 8.3 DEVIATION FROM STANDARD 34 8.4 TEST SETUP 34 8.5 EUT OPERATION CONDITIONS 34 8.6 TEST RESULTS 34 9. ANTENNA REQUIREMENT 35 9.1 STANDARD REQUIREMENT 35 9.2 EUT ANTENNA 35 APPENDIX 1-TEST DATA 36 DUTY CYCLE 36 MAXIMUM PEAK CONDUCTED OUTPUT POWER 42 -6DB BANDWIDTH 43 OCCUPIED CHANNEL BANDWIDTH 49 MAXIMUM POWER SPECTRAL DENSITY LEVEL 55 BAND EDGE 61 CONDUCTED RF SPURIOUS EMISSION 68 APPENDIX 2-PHOTOS OF TEST SETUP 78 Page 5 of 78 Report No.: STS2512058W02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Dec. 2025 STS2512058W02 ALL Initial Issue Page 6 of 78 Report No.: STS2512058W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 78 Report No.: STS2512058W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 78 Report No.: STS2512058W02 2. GENERA…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512058W01 Issued for Dauer Manufacturing Corp 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Product Name: MORPHEUS SMART FIXTURE Brand Name: N/A Model Name: 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s): 490400-2700K MORPHEUS SMART FIXTURE 2700K FCC ID: 2BUJ8-490400-MORPH Test Standards: FCC Part15.247 Page 2 of 59 Report No.: STS2512058W01 TEST REPORT Applicant’s Name ................. : Dauer Manufacturing Corp Address ................................. : 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Manufacturer's Name .......... : GRE ALPHA ELECTRONICS (VIETNAM) COMPANY LIMITED Address ................................. : No 03 VSIP II-A street No.17, Vietnam - Singapore II-A Industrial Park, Vinh Tan ward, Ho Chi Minh City, Viet Nam Product Description Product Name ....................... : MORPHEUS SMART FIXTURE Brand Name .......................... : N/A Model Name .......................... : 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s) .................... : 490400-2700K MORPHEUS SMART FIXTURE 2700K Standards ............................. : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 09 Dec. 2025 Date (s) of performance of tests ............. : 09 Dec. 2025 ~ 30 Dec. 2025 Date of Issue .......................................... : 30 Dec. 2025 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 59 Report No.: STS2512058W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 7 1.1 TEST FACTORY 8 1.2 MEASUREMENT UNCERTAINTY 8 2. GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF THE EUT 9 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 TEST PROCEDURE 15 3.3 TEST SETUP 15 3.4 EUT OPERATING CONDITIONS 15 3.5 TEST RESULTS 16 4. RADIATED EMISSION MEASUREMENT 18 4.1 RADIATED EMISSION LIMITS 18 4.2 TEST PROCEDURE 20 4.3 TEST SETUP 21 4.4 EUT OPERATING CONDITIONS 21 4.5 FIELD STRENGTH CALCULATION 22 4.6 TEST RESULTS 23 5. DUTY CYCLE 30 5.1 TEST STANDARD 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM STANDARD 30 5.4 TEST SETUP 30 5.6 TEST RESULTS 30 6. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 TEST SETUP 31 Page 4 of 59 Report No.: STS2512058W01 Table of Contents Page 6.4 EUT OPERATION CONDITIONS 31 6.5 TEST RESULTS 31 7. POWER SPECTRAL DENSITY TEST 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 TEST SETUP 32 7.4 EUT OPERATION CONDITIONS 32 7.5 TEST RESULTS 32 8. BANDWIDTH TEST 33 8.1 LIMIT 33 8.2 TEST PROCEDURE 33 8.3 TEST SETUP 33 8.4 EUT OPERATION CONDITIONS 33 8.5 TEST RESULTS 33 9. PEAK OUTPUT POWER TEST 34 9.1 LIMIT 34 9.2 TEST PROCEDURE 34 9.3 TEST SETUP 35 9.4 EUT OPERATION CONDITIONS 35 9.5 TEST RESULTS 35 10. ANTENNA REQUIREMENT 36 10.1 STANDARD REQUIREMENT 36 10.2 EUT ANTENNA 36 APPENDIX 1-TEST DATA 37 DUTY CYCLE 37 MAXIMUM PEAK CONDUCTED OUTPUT POWER 40 -6DB BANDWIDTH 43 OCCUPIED CHANNEL BANDWIDTH 46 MAXIMUM POWER SPECTRAL DENSITY LEVEL 49 BAND EDGE 52 CONDUCTED RF SPURIOUS EMISSION 55 Page 5 of 59 Report No.: STS2512058W01 Table of Contents Page APPENDIX 2- EUT TEST PHOTO 59 Page 6 of 59 Report No.: STS2512058W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Dec. 2025 STS2512058W01 ALL Initial Issue Page 7 of 59 Report No.: STS2512058W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 8 of 59 Report No.: STS2512058W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30M…

Text truncated - open the document above for the full version.

Antennamanufacturer:HongjiWirelessCommunication(Shenzhen)Co.,LTD http://www.honant.com.cn Address:12/F,WestBlockB,Building8,HuaqiangCreativeIndustryPark,Sightseeing Road,GuangmingDistrict,Shenzhen AntennaSampleDatasheet customer： entryname：2.4G天线 Materialcategory：2.4Gantenna AntennaType Monopole AntennaMaterial FPC+cable edition：A0 Date：2025.11.20 Antennamanufacturer:HongjiWirelessCommunication(Shenzhen)Co.,LTD http://www.honant.com.cn Address:12/F,WestBlockB,Building8,HuaqiangCreativeIndustryPark,Sightseeing Road,GuangmingDistrict,Shenzhen Contents 1：Antennatestequipment.................................................1 2：Passivetestreport...........................................................3 3：Structuraldrawing...........................................................5 4：Antennadiagram.............................................................5 1 1 ： Antennatestequipment Listofmeters：Agilent5071B； 1.1TheprinciplediagramoftheETSanochoicchamber 样机 网络分析仪 同轴电缆 支撑架 Picture1.Antennastatictestconnectionmethod 2 1.2PicturesoftheETSanochoicchamber InsidetheETSanochoicchamber TestMachine 3 2 ： Passivetestreport 2.1：2.4GantennaS11parameters 2.2：Passiveefficiencyofantenna Freq(MHz)Gain(dBi)Efficiency(%) 2400 -1.0627.58 2410 -1.0028.83 2420 -0.9930.85 2430 -0.7432.26 2440 -0.4733.40 2450 -0.1235.07 2460 -0.0235.65 2470 0.1539.62 2480 0.2441.49 4 2.3：Passivepatternof2.4Gantenna 2400MHz 5 3 ： tructuraldrawing

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512058H01 Issued for Dauer Manufacturing Corp 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Product Name: MORPHEUS SMART FIXTURE Brand Name: N/A Model Name: 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s): 490400-2700K MORPHEUS SMART FIXTURE 2700K FCC ID: 2BUJ8-490400-MORPH Test Standards: FCC 47CFR §2.1091 Page 2 of 9 Report No.: STS2512058H01 TEST REPORT Applicant’s Name ................. : Dauer Manufacturing Corp Address ................................. : 10505 NW 112th AVE Suite 18 Miami, FL 33178 United States Manufacturer's Name ........... : GRE ALPHA ELECTRONICS (VIETNAM) COMPANY LIMITED Address ................................. : No 03 VSIP II-A street No.17, Vietnam - Singapore II-A Industrial Park, Vinh Tan ward, Ho Chi Minh City, Viet Nam Product Description Product Name ........................ : MORPHEUS SMART FIXTURE Brand ................................... : N/A Model Number ....................... : .. : 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s) ...................... : 490400-2700K MORPHEUS SMART FIXTURE 2700K Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 09 Dec. 2025 Date (s) of performance of tests ............. : 09 Dec. 2025 ~ 30 Dec. 2025 Date of Issue .......................................... : 30 Dec. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2512058H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2512058H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Dec. 2025 STS2512058H01 ALL Initial Issue Page 5 of 9 Report No.: STS2512058H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name MORPHEUS SMART FIXTURE Brand N/A Model Name 490400-3000K MORPHEUS SMART FIXTURE 3000K Series Model(s) 490400-2700K MORPHEUS SMART FIXTURE 2700K Model Difference Only different in model name and LED color temperatures Product Description The EUT is MORPHEUS SMART FIXTURE Operation Frequency: BLE: 2402~2480 MHz 2.4G WLAN: 802.11b/g/n 20: 2412~2462 MHz Modulation Type: BLE: GFSK 2.4G WLAN: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM, 64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM, 64-QAM Antenna gain: 0.24dBi Antenna Designation: FPC Power Rating Input: 12Vac/60Hz Output: 36V/0.58A Adapter N/A Battery N/A Hardware Version A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2512058H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2512058H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2512058H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a ra…

Text truncated - open the document above for the full version.

Page 1 of 7 ReportNo.:STS2512058 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 BT/WIFIAntenna Page 2 of 7 ReportNo.:STS2512058 Photo3 Photo4 Page 3 of 7 ReportNo.:STS2512058 Photo5 Photo6 Page 4 of 7 ReportNo.:STS2512058 Photo7 Photo8 Page 5 of 7 ReportNo.:STS2512058 Photo9 Photo10 433MRXANT Page 6 of 7 ReportNo.:STS2512058 Photo11 Photo12 Page 7 of 7 ReportNo.:STS2512058 Photo13

FCC Label FCC ID: 2BUJ8-490400-MORPH

Dauer Manufacturing Corp (2026.03.30) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2BUJ8-490400- MORPH) [Dauer Manufacturing Corp] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Craig Klomparens Dauer Manufacturing Corp (2026.03.28) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2BUJ8-490400- MORPH) [Dauer Manufacturing Corp] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Craig Klomparens

Dauer Manufacturing Corp Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026.03.30 Subject; Request for Confidentiality FCC ID: 2BUJ8-490400-MORPH To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: PM

Differences Description We Dauer Manufacturing Corp state: Product： MORPHEUS SMART FIXTURE Model Name： 490400-3000K MORPHEUS SMART FIXTURE 3000K, 490400-2700K MORPHEUS SMART FIXTURE 2700K Trade Name: N/A FCC ID: 2BUJ8-490400-MORPH The electrical circuit design, layout, components used and internal wiring for above models are identical, Only different in model name and LED color temperatures Signatory Signature: Date: 2026.03.30 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO., LTD.
