2BUKS-C64UCommodore 64 Ultimate

COMMODORE64 ULTIMATE USER’S GUIDE Published by Commodore® International Corporation 1stEdition, October 2025 Copyright © 2025 Commodore International Corporation and © MOS Technology, Inc. All rights reserved. No part of this manual may be re- produced, stored in a retrieval system, or transmitted in any form or by any means without prior written permission of Commodore, except as expressly permitted under applicable copyright law. This device, manual, and associated documentation incorporate material subject to copyrights by various owners. Used with permission. Commodore® and the Commodore logo are registered trademarks of Commodore Corporation BV or its affiliates in certain countries. Commodore 64 Ultimate ™, Commobot™, and C6T4™ are trademarks of Commodore Corporation BV or its affiliates. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trade- marks or registered trademarks of HDMI Licensing Administrator, Inc. Other names are trademarks of their respective owners. All rights reserved. ii T ABLE OF CONTENTS Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Fun Things to Try! . . . . . . . . . . . . . . . . . . . . . . . . . .x Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi 1 SETTING UP1 Unpacking and Connecting the Commodore 64 Ultimate . . . .3 Installing and Switching On the C64U . . . . . . . . . . . . . .5 The Multi Function Switch . . . . . . . . . . . . . . . . . . . . .6 Configuring the C64U . . . . . . . . . . . . . . . . . . . . . . .6 Typing Commands . . . . . . . . . . . . . . . . . . . . . . . . . 12 2 THE C64U FILE BROWSER15 The Disk File Browser . . . . . . . . . . . . . . . . . . . . . . . . 17 Updating the C64U Firmware . . . . . . . . . . . . . . . . . . . 19 Using Disk Images . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Using Cartridge ROM Files . . . . . . . . . . . . . . . . . . . . . 24 Using Tape Images . . . . . . . . . . . . . . . . . . . . . . . . . 26 Using PRG and T64 Files . . . . . . . . . . . . . . . . . . . . . . 27 Playing SID Music Files . . . . . . . . . . . . . . . . . . . . . . . 27 File Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 3 GETTING STARTED31 The Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Back to Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Loading and Saving Programs . . . . . . . . . . . . . . . . . . . 37 PRINT and Calculations . . . . . . . . . . . . . . . . . . . . . . . 40 Precedence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Combining Things . . . . . . . . . . . . . . . . . . . . . . . . . . 46 4 BEGINNING BASIC PROGRAMMING49 The Next Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Quote Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 iii EditingTips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 IF...THEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 FOR...NEXT Loops . . . . . . . . . . . . . . . . . . . . . . . . . . 59 5 ADVANCED BASIC63 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Simple Animation . . . . . . . . . . . . . . . . . . . . . . . . . . 66 INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 GET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Random Numbers and Other Functions . . . . . . . . . . . . . . 72 Guessing Game . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 Your Roll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 Random Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . 77 6 ADVANCED COLOR AND GRAPHIC COMMANDS79 Color and Graphics . . . . . . . . . . . . . . . . . . . . . . . . . 81 PRINTing Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Color CHR$ Codes . . . . . . . . . . . . . . . . . . . . . . . . . 83 PEEKs and POKEs . . . . . . . . . . . . . . . . . . . . . . . . . . 85 Screen Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Screen Memory Map . . . . . . . . . . . . . . . . . . . . . . . . 87 Color Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . 89 More Bouncing Balls . . . . . . . . . . . . . . . . . . . . . . . . 90 7 SPRITE GRAPHICS93 Introduction to Sprites . . . . . . . . . . . . . . . . . . . . . . . 95 Sprite Creation . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Additional Notes on Sprites . . . . . . . . . . . . . . . . . . . . 104 Binary Arithmetic . . . . . . . . . . . . . . . . . . . . . . . . . . 105 8 CREATING SOUND109 Using Sound If You’re Not a Computer Programmer . . . . . . . 111 Structure of a Sound Program . . . . . . . . . . . . . . . . . . . 111 Sample Sound Program . . . . . . . . . . . . . . . . . . . . . . 111 Making Music on Your Commodore 64 . . . . . . . . . . . . . . 113 Important Sound Settings . . . . . . . . . . . . . . . . . . . . . 115 Playing a Song on the Commodore 64 . . . . . . . . . . . . . . 121 Creating Sound Effects . . . . . . . . . . . . . . . . . . . . . . 122 Sample Sound Effects to Try . . . . . . . . . . . . . . . . . . . . 123 9 ADVANCED DATA HANDLING125 iv READand DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . 127 Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129 Subscripted Variables . . . . . . . . . . . . . . . . . . . . . . . 130 Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133 Simulated Dice Roll with Arrays . . . . . . . . . . . . . . . . . . 134 Two-Dimensional Arrays . . . . . . . . . . . . . . . . . . . . . . 135 10 USING COMMODORE 64 PERIPHERALS139 Using Commodore 64 Peripherals . . . . . . . . . . . . . . . . . 141 Joysticks, gamepads, and mice . . . . . . . . . . . . . . . . . . 141 Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142 Disk drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: MOS Technology Inc. FRN: 0037900974 Contact Name: Jake Young Address: 8 The Green, Ste A, Dover, Kent, DE 19901, USA Telephone No: +61 478793574 Email: [email protected] Applicant: Company Name: MOS Technology Inc. FRN: 0037900974 Contact Name: Jake Young Address: 8 The Green, Ste A, Dover, Kent, DE 19901, USA Telephone No: +61 478793574 Email: [email protected] [MOS Technology Inc.] certifies that, as of the date of this filing of the application with the TCB, [MOS Technology Inc.] is our designated US agent for service of process for the above referenced FCC ID. [MOS Technology Inc.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [MOS Technology Inc.] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2026.01.30 Applicant’s Name: Jake Young US Agent’s Name: Jake Young Title: Director of Manufacturing Title: Director of Manufacturing Signature Signature Docusign Envelope ID: D679EE69-4529-4E83-9309-850E0A7EA3F5

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: MOS Technology Inc. Grantee code: 2BUKS FCC ID: 2BUKS-C64U FRN: 0037900974 Contact Name: Jake Young Address: 8 The Green, Ste A, Dover, Kent, DE 19901, USA Fax No: +61 478793574 Email: [email protected] i. [MOS Technology Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [MOS Technology Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [MOS Technology Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2025/10/17 Applicant’s Name: Jake Young Title: Director of Manufacturing Signature The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist Docusign Envelope ID: D679EE69-4529-4E83-9309-850E0A7EA3F5

Docusign Envelope ID: D679EE69-4529-4E83卢9309-850EOA7EA3F5 MOS Technology Inc. Device Commodore 64 Ultimate Company name MOS Technology Inc. Grantee c。de ZBUKS FCCID ZBU邸－C64U FRN 0037900974 Contact name Jake Young Address 8 The Green, Ste A, D。·Ver, Kent, DE 19901, USA Telephone number +61 478793574 E-mailjakey@comm。d。re-international.com Chipset/module information ESP32-S3 Operating System (if applicable) N/A Storage Capacity (hard drive or N/A 。，ther permanent mem。ryst。rage. if applicable) Item 1. The device is able to install software/program installation? 口Yes,go to Item 2. 因No.In this臼饵，the rest of the items do not apply. The device cannot support installati。n of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity s。仕ware: ＃ General Requirements (F。r all Devices) Yes/ N。。r c。mments N/A Internet connection for activation and updates (For all NIA Ooeratino Systems) Code 00018768 Ed. 1

TCB CALL página 1 File FCC ID: 2BUKS-C64U Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. On the official register: https://icis.corp.delaware.gov/Ecorp/EntitySearch/NameSearch.aspx TCB CALL página 2 In google: This is a company that physically located at that valid US address. TCB CALL página 3 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter" >

C5266091_X10_Ed.2 1/2 <MOS Technology Inc.> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2026.01.30 Subject: Request for Confidentiality FCC ID: 2BUKS-C64U To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Docusign Envelope ID: D679EE69-4529-4E83-9309-850E0A7EA3F5 C5266091_X10_Ed.2 2/2 Sincerely, Signature: Name: Jake Young Title: Director of Manufacturing Docusign Envelope ID: D679EE69-4529-4E83-9309-850E0A7EA3F5

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: MOS Technology Inc. Address: 8 The Green, Ste A, Dover, Kent, DE 19901, USA Product Name: Commodore 64 Ultimate Model Number: C64U FCC Identifier: 2BUKS-C64U We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jake Young Date: 2026.01.30 Title: Director of Manufacturing Signature of applicant: Docusign Envelope ID: D679EE69-4529-4E83-9309-850E0A7EA3F5

Page 1 of 4 FCC ID:2BUKS-C64U External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label size: 39mm*48.5mm Label location

Page 1 of 6 FCC ID:2BUKS-C64U Internal Photos Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 2.4G WIFI Attenna Page 6 of 6

FCC ID: 2BUKS-C64U RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1091，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation FCC RF Exposure Evaluation Modulation Frequency (MHz) Output power to antenna (dBm) Max E.I.R.P tune-up power (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 2412 12.34 16.21 0.016096 1.0 PASS 2437 10.95 14.82 0.011688 1.0 PASS 2462 10.81 14.68 0.011317 1.0 PASS 802.11g 2412 11.54 15.41 0.013388 1.0 PASS 2437 10.8 14.67 0.011291 1.0 PASS 2462 10.53 14.40 0.010610 1.0 PASS 802.11n20 2412 10.85 14.72 0.011422 1.0 PASS 2437 9.99 13.86 0.009370 1.0 PASS 2462 9.79 13.66 0.008948 1.0 PASS 802.11n40 2422 10.41 14.28 0.010321 1.0 PASS 2437 9.74 13.61 0.008846 1.0 PASS 2452 9.88 13.75 0.009135 1.0 PASS Remark: 2.4G antenna gain=2.87dBi

ShenzhenBKCTestingCo.,Ltd.ReportNo.:BKC26020582BE-1 TestReportTel:4000-875-3820755-84829082Web:Http://www.bkc-lab.comPage1of25 TESTREPORT Applicant:MOSTechnologyInc. Address:8TheGreen,SteA,Dover,Kent,DE19901,USA Manufacturer:MOSTechnologyInc. Address:8TheGreen,SteA,Dover,Kent,DE19901,USA Factory:MOSTechnologyInc. Address:8TheGreen,SteA,Dover,Kent,DE19901,USA ProductName:Commodore64Ultimate ModelNumber:C64U Trademark: FCCID:2BUKS-C64U TestDate:December21,2025-December30,2025 DateofReport: February04,2026 TestResult: ThisdevicedescribedabovehasbeentestedbyBKC,andthetest resultsshowthattheequipmentundertest(EUT)isincompliance withtheStandardrequirements.Anditisapplicableonlytothetested sampleidentifiedinthereport. TestProcedureUsed: Standards:FCCCFRTitle47Part15SubpartCSection15.247 ANSIC63.10-2020+Cor1-2023 Preparedby(TestEngineer): CareyZheng Reviewer(Supervisor): CaseyWang Approved(Manager): JerryLiao ShenzhenBKCTestingCo.,Ltd.ReportNo.:BKC26020582BE-1 TestReportTel:4000-875-3820755-84829082Web:Http://www.bkc-lab.comPage2of25 TABLEOFCONTENT 1.GeneralInformation......................................................................................4 1.1.DescriptionofDevice(EUT).......................................................................................................................4 1.2.ChannelList..................................................................................................................................................4 1.3.Summaryoftestresult................................................................................................................................4 1.4.SpecialAccessoriesandAuxiliaryEquipment........................................................................................5 1.5.Testmode......................................................................................................................................................5 1.6.BlockDiagram...............................................................................................................................................5 1.7.TestConditions.............................................................................................................................................6 1.8.MeasurementUncertainty(95%confidencelevels,k=2)......................................................................6 1.9.TestFacility....................................................................................................................................................6 1.10.TestEquipment...........................................................................................................................................7 2.Conductedemissionatthemainsterminalstest......................................9 2.1.Limit................................................................................................................................................................9 2.2.TestSetup......................................................................................................................................................9 2.3.TestProcedure..............................................................................................................................................9 2.4.TestResult...................................................................................................................................................10 3.RadiatedSpuriousEmissions...................................................................12 3.1.Limit..............................................................................................................................................................12 3.2.TestSetup....................................................................................................................................................13 3.3.TestProcedure............................................................................................................................................15 3.4.TestResult...................................................................................................................................................16 4.ConductedSpuriousEmissions................................................................19 4.1.Limit..............................................................................................................................................................19 4.2.TestSetup....................................................................................................................................................19 4.3.TestProcedure............................................................................................................................................19 4.4.TestResult...................................................................................................................................................19 5.BandEdgeMeasurement...........................................................................20 5.1.Limit..............................................................................................................................................................20 5.2.Testsetup....................................................................................................................................................20 5.3.TestProcedure............................................................................................................................................20 5.4.TestResult...................................................................................................................................................20 6.-6dBBandwidthand99%BandwidthMeasurement..............................21 6.1.Limit..............................................................................................................................................................21 6.2.TestSetup......................................…

Text truncated - open the document above for the full version.

Antenna Specifications Manufacturer: Espressif Systems (Shanghai) Co.,Ltd. Address.: Suite 204, Block 2, 690 Bibo Road, Zhang Jiang Hi-Tech Park, Shanghai, China Antenna Type: PCB Antenna Antenna Length: 14.7mm*5mm Gain and Efficiency 2.4G 3D Pattern Plots 2.4G 2D Pattern Plots

TABLE OF CONTENTS 1. Maximum Conducted Output Power ............................................................................................................................................ 2 2. -6dB Bandwidth ............................................................................................................................................................................. 9 3. Occupied Channel Bandwidth .................................................................................................................................................... 16 4. Maximum Power Spectral Density Level ................................................................................................................................... 23 5. Band Edge ................................................................................................................................................................................... 30 6. Conducted RF Spurious Emission ............................................................................................................................................. 39 1. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 12.34 0 12.34 30 Pass NVNT b 2437 Ant1 10.95 0 10.95 30 Pass NVNT b 2462 Ant1 10.81 0 10.81 30 Pass NVNT g 2412 Ant1 11.54 0 11.54 30 Pass NVNT g 2437 Ant1 10.8 0 10.8 30 Pass NVNT g 2462 Ant1 10.53 0 10.53 30 Pass NVNT n20 2412 Ant1 10.85 0 10.85 30 Pass NVNT n20 2437 Ant1 9.99 0 9.99 30 Pass NVNT n20 2462 Ant1 9.79 0 9.79 30 Pass NVNT n40 2422 Ant1 10.41 0 10.41 30 Pass NVNT n40 2437 Ant1 9.74 0 9.74 30 Pass NVNT n40 2452 Ant1 9.88 0 9.88 30 Pass Test Graphs Power NVNT b 2412MHz Ant1 Power NVNT b 2437MHz Ant1 Power NVNT b 2462MHz Ant1 Power NVNT g 2412MHz Ant1 Power NVNT g 2437MHz Ant1 Power NVNT g 2462MHz Ant1 Power NVNT n20 2412MHz Ant1 Power NVNT n20 2437MHz Ant1 Power NVNT n20 2462MHz Ant1 Power NVNT n40 2422MHz Ant1 Power NVNT n40 2437MHz Ant1 Power NVNT n40 2452MHz Ant1 2. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 11.04 0.5 Pass NVNT b 2437 Ant1 10.36 0.5 Pass NVNT b 2462 Ant1 9.895 0.5 Pass NVNT g 2412 Ant1 16.44 0.5 Pass NVNT g 2437 Ant1 16.46 0.5 Pass NVNT g 2462 Ant1 16.48 0.5 Pass NVNT n20 2412 Ant1 17.65 0.5 Pass NVNT n20 2437 Ant1 17.62 0.5 Pass NVNT n20 2462 Ant1 17.72 0.5 Pass NVNT n40 2422 Ant1 36.41 0.5 Pass NVNT n40 2437 Ant1 36.07 0.5 Pass NVNT n40 2452 Ant1 36.10 0.5 Pass Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 -6dB Bandwidth NVNT b 2462MHz Ant1 -6dB Bandwidth NVNT g 2412MHz Ant1 -6dB Bandwidth NVNT g 2437MHz Ant1 -6dB Bandwidth NVNT g 2462MHz Ant1 -6dB Bandwidth NVNT n20 2412MHz Ant1 -6dB Bandwidth NVNT n20 2437MHz Ant1 -6dB Bandwidth NVNT n20 2462MHz Ant1 -6dB Bandwidth NVNT n40 2422MHz Ant1 -6dB Bandwidth NVNT n40 2437MHz Ant1 -6dB Bandwidth NVNT n40 2452MHz Ant1 3. Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT b 2412 Ant1 12.887 NVNT b 2437 Ant1 12.846 NVNT b 2462 Ant1 12.846 NVNT g 2412 Ant1 16.481 NVNT g 2437 Ant1 16.474 NVNT g 2462 Ant1 16.471 NVNT n20 2412 Ant1 17.429 NVNT n20 2437 Ant1 17.417 NVNT n20 2462 Ant1 17.421 NVNT n40 2422 Ant1 35.672 NVNT n40 2437 Ant1 35.575 NVNT n40 2452 Ant1 35.666 Test Graphs OBW NVNT b 2412MHz Ant1 OBW NVNT b 2437MHz Ant1 OBW NVNT b 2462MHz Ant1 OBW NVNT g 2412MHz Ant1 OBW NVNT g 2437MHz Ant1 OBW NVNT g 2462MHz Ant1 OBW NVNT n20 2412MHz Ant1 OBW NVNT n20 2437MHz Ant1 OBW NVNT n20 2462MHz Ant1 OBW NVNT n40 2422MHz Ant1 OBW NVNT n40 2437MHz Ant1 OBW NVNT n40 2452MHz Ant1 4. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Duty Factor (dB) Total PSD (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 -1.61 0 -1.61 8 Pass NVNT b 2437 Ant1 -2.13 0 -2.13 8 Pass NVNT b 2462 Ant1 -1.37 0 -1.37 8 Pass NVNT g 2412 Ant1 -4.29 0 -4.29 8 Pass NVNT g 2437 Ant1 -5.07 0 -5.07 8 Pass NVNT g 2462 Ant1 -4.93 0 -4.93 8 Pass NVNT n20 2412 Ant1 -5.08 0 -5.08 8 Pass NVNT n20 2437 Ant1 -5.3 0 -5.3 8 Pass NVNT n20 2462 Ant1 -5.49 0 -5.49 8 Pass NVNT n40 2422 Ant1 -8.23 0 -8.23 8 Pass NVNT n40 2437 Ant1 -8.61 0 -8.61 8 Pass NVNT n40 2452 Ant1 -8.91 0 -8.91 8 Pass Test Graphs PSD NVNT b 2412MHz Ant1 PSD NVNT b 2437MHz Ant1 PSD NVNT b 2462MHz Ant1 PSD NVNT g 2412MHz Ant1 PSD NVNT g 2437MHz Ant1 PSD NVNT g 2462MHz Ant1 PSD NVNT n20 2412MHz Ant1 PSD NVNT n20 2437MHz Ant1 PSD NVNT n20 2462MHz Ant1 PSD NVNT n40 2422MHz Ant1 PSD NVNT n40 2437MHz Ant1 PSD NVNT n40 2452MHz Ant1 5. Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 Ant1 -51.83 -20 Pass NVNT b 2462 Ant1 -51.44 -20 Pass NVNT g 2412 Ant1 -42.01 -20 Pass NVNT g 2462 Ant1 -39.93 -20 Pass NVNT n20 2412 Ant1 -41.49 -20 Pass NVNT n20 2462 Ant1 -40.04 -20 Pass NVNT n40 2422 Ant1 -35.29 -20 Pass NVNT n40 2452 Ant1 -37.46 -20 Pass Test Graphs Band Edge NVNT b 2412MHz Ant1 Ref Band Edge NVNT b 2412MHz Ant1 Emission Band Edge NVNT b 2462MHz Ant1 Ref Band Edge NVNT b 2462MHz Ant1 Emission Band Edge NVNT g 2412MHz Ant1 Ref Band Edge NVNT g 2412MHz Ant1 Emission Band Edge NVNT g 2462MHz Ant1 Ref Band Edge NVNT g 2462MHz Ant1 Emission Band Edge NVNT n20 2412MHz Ant1 Ref Band Edge NVNT n20 2412MHz Ant1 Emission Band Edge NVNT n20 2462MHz Ant1 Ref Band Edge NVNT n20 2462MHz Ant1 Emission Band Edge NVNT n40 2422MHz Ant1 …
